Sistemalux SKILL S.6350 Assembly instructions

SKILL
BOLLARD
MODELS: S.6350, S.6360
INS-547
INSTALLATION SHEET PAGE: 1 OF 2
EV - V0LAST UPDATE: January 25, 2018
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
A- INSTALL FLANGE ACCESSORY IN CONCRETE FLUSH WITH THE MOUNTING SURFACE.
IMPORTANT - READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES, BY A PERSON FAMILIAR WITH THE
CONSTRUCTION AND OPERATION OF THE PRODUCT, AND THE HAZARDS INVOLVED. PROPER GROUNDING IS REQUIRED FOR SAFETY.
CB
B- UNFASTEN THE SET (4) SCREWS WITH THE ALLEN KEY (INCLUDED) AND PULL MOUNTING BASE OFF THE MAIN BODY. DO NOT
COMPLETELY REMOVE SCREWS
C- MAKE ALL WIRE CONNECTIONS (FOLLOWING POLARITY MARKING).
FLANGE
MAIN BODY
MOUNTING BASE
SET SCREWS
OK
NO!
NO!
LIVE BLACK
WHITE
GREEN
NEUTRAL
CONCRETE
ROCK
A
INSTALLATION IN CONCRETE WITH FLANGE - WITH INTEGRAL DRIVER (120-277V)

SKILL
BOLLARD
MODELS: S.6350, S.6360
INSTALLATION SHEET
EV - V0
PAGE: 2 OF 2
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
LAST UPDATE: January 25, 2018
INS-547
A- UNSCREW THE (4) SET SCREWS WITH ALLEN KEY (INCLUDED) AND PULL MOUNTING BASE OFF THE MAIN BODY.
B- FASTEN MOUNTING BASE TO SURFACE USING APPROPRIATE (2) ANCHORS (NOT INCLUDED)
AND (2) SCREWS (NOT INCLUDED).
C- MAKE WIRE CONNECTIONS, PLACE MAIN BODY INTO MOUNTING BASE AND FASTEN SET SCREWS.
B C
A
INSTALLATION WITHOUT FLANGE
MOUNTING BASE
SCREWS
(NOT INCLUDED)
MOUNTING BASE
D- FASTEN MOUNTING BASE TO FLANGE ACCESSORY USING (2) FLANGE ACCESSORY NUTS (INCLUDED).
E- PLACE MAIN BODY INTO MOUNTING BASE AND FASTEN SET SCREWS.
D E
MOUNTING
BASE
FLANGE
ACCESSORY NUTS
FLANGE
ACCESSORY
MAIN BODY
SET SCREWS
MAIN BODY
MOUNTING BASE
SET SCREWS
MAIN BODY
SET SCREWS
LIVE BLACK
WHITE
GREEN
NEUTRAL
1¾" (45mm)
4"(103mm)
⅞"
(24mm)
