Sistemalux Continuous Line S.7006 Assembly instructions

B
A C + D
A- INSTALL DRAINING EQUIPMENT.
B- FASTEN MOUNTING BASE USING SCREWS (NOT INCLUDED). *FOR A CONTINUOUS ROW INSTALLATION MAKE SURE
THE MOUNTING BASE IS ALIGNED WITH THE FIXTURES JONCTION.
C- INSTALL RECESSED BOX IN THE MOUNTING BASE. *FOR A CONTINUOUS ROW INSTALLATION TAKE OFF ONE
END CAP AT EACH FIXTURES JONCTIONS, AS SHOWN.
D- CONNECT THE WIRING EQUIPMENT IN THE PRE-PERFORATED HOLE OF EACH RECESSED BOX (FOLLOWING POLARITY MARKING).
WHEN INSTALLING SURFACE, MAKE SURE THE FIXTURE IS
PERFECTLY LEVELED WITH THE SURFACE.
ALWAYS USE 12" (300mm) OF GRAVEL FOR DRAINAGE
AND VERIFY THAT IT DRAINS WELL OR USE A CONCRET DRAIN
AT THE BOTTOM.
NEVER INSTALL PRODUCTS IN CASE OF FOG RAIN, OR HIGH
HUMIDITY.
CLEAN REGULARLY TO PREVENT SOIL HEAP
ON COVER AND SCREWS.
ALWAYS KEEP SURFACES CLEAN AND UNOBSTRUCTED.
12"
(300mm)
KEEP SURFACES PROTECTED FROM SOIL
AND CHEMICAL ELEMENTS.
FIXTURE CAN BE INSTALLED IN GROUND OR WALL.
NEVER INSTALL THE FIXTURE IN THE CEILING.
USE ONLY FLEXIBLE CABLES (MAX. 14 AWG)
ALWAYS USE MOUNTING COMPONENTS.
NO THROUGH WIRING, USE A CABLE CONNECTION
FOR EACH FIXTURE AS SEEN IN THE WIRING DIAGRAM BELOW.
WIRING DIAGRAM
DRIVER
DRIVER
OPTION 1:
OPTION 2:
RECESSED BOX
D
WIRING
EQUIPEMENT
WIRING
EQUIPEMENT
RECESSED
BOX
END CAP
MOUNTING BASE
CONTINUOUS LINE
MODELS: S.7006, S.7001, S.7016, S.7011, S.7012
INS-272
INSTALLATION SHEET PAGE: 1 OF 2
EV - R4
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
LAST UPDATE: MARCH 29, 2018
WARNING
GROUND INSTALLATION IN CONCRETE WITH RECESSED BOX
TO REMOTE DRIVER (24V)
IMPORTANT - READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES, BY A PERSON FAMILIAR WITH THE
CONSTRUCTION AND OPERATION OF THE PRODUCT, AND THE HAZARDS INVOLVED. PROPER GROUNDING IS REQUIRED FOR SAFETY.
MOUNTING BASE
SINGLE FIXTURE
CONTINUOUS ROW*
SINGLE FIXTURE
CONTINUOUS ROW*
GRAVEL
12"
(300mm)
NO!
C
CD
D
D
- BLACK
RED+

J
MOUNTING
BASE SCREWS
OK
NO!
NO!
SURFACE
RECESSED BOX
PROTECTOR
RECESSED
BOX CABLE
E F
G
I
H
3 Nm
SW 1"
(24mm)
RECESSED BOX
CONNECTORS
FIXTURE
CONNECTORS
FIXTURE
RECESSED
BOX
CONNECTORS
CLICK
1⅝
(40mm)
MIN: 18Ga
MAX: 14Ga
Ø ¼" - ½"
(Ø 6-12mm)
+
-
RECESSED BOX
CONNECTOR
RECESSED
BOX CABLE
CONTINUOUS LINE
MODELS: S.7006, S.7001, S.7016, S.7011, S.7012
INS-272
INSTALLATION SHEET PAGE: 2 OF 2
EV - R4
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
LAST UPDATE: MARCH 29, 2018
E- ADJUST THE MOUNTING BASE SCREWS TO LEVEL THE RECESSED BOX.
F- POUR CONCRETE AND BE SURE SURFACE IS FLUSH WITH THE RECESSED BOX.
G- REMOVE THE RECESSED BOX PROTECTOR OF AND TAKE OUT THE RECESSED BOX CABLE.
H- INSERT THE RECESSED BOX CABLE IN THE RECESSED BOX CONNECTOR (FOLLOWING POLARITY MARKING).
I- CONNECT THE RECESSED BOX CONNECTOR WITH THE FIXTURE CONNECTOR, AS SHOWN.
J- INSERT THE FIXTURE INTO THE RECESSED BOX AND MAKE SURE IT CLIPS.
OK
NO!
NO!
FINISHED
FLOOR
RECESSED BOX
