SKATEY 3200 lithium User manual

Instructions manual
Skatey 2800 Lithium
Skatey 3200 Lithium
Important
Make sure you read and understand this maual before before you use the Skatey.
Belangrijk
Gebruik de Skatey pas nadat u deze handleiding gelezen en begrepen hebt. De NL versie vind u op www.skatey.com.
Wichtig
Verwenden Sie die Skatey erst, nachdem Sie die Gebrauchsanleitung gelesen und verstanden haben.
Deutsche Anleitung nden Sie auf www.skatey.com

INSTRUCTIONS MANUAL Skatey 2800L/3200L
2
Skatey, catch the power wave
Congratulaons! You are the new owner of a Skatey electric skateboard. A praccal and fun means of transport that will
bring you a great deal of pleasure. Now that you own a Skatey product you can always contact us if you have quesons
about your board. We will help you if you need spare parts and when there is a problem with your board.
Warning
We assume that you will handle your Skatey in a safe and responsible manner. The use of an electric skateboard is not
enrely without risk. Certainly if you do not use your Skatey in a responsible manner. You need to learn how to ride a
Skatey electric skateboard, just like you learned how to ride a bicycle.
The use of a Skatey electric skateboard is enrely at your own risk.
Read these instrucons carefully and take noce of the warnings and instrucons. Don’t use your Skatey before these
instrucons have been read and the user is familiar with them.
Skatey Electric B.V. cannot be held responsible for any physical injury and wounds to you or others. You should there-
fore protect yourself well by wearing protecve clothing, a helmet, knee, elbow and wrist pads. The protecon will
absorb a large part of the impact should you fall.
Stay up to date; follow us on:

Skatey 2800L/3200LINSTRUCTIONS MANUAL
3
Content
1. Content packing 4
2. Skatey electric skateboard product descripon 4
2.1 The electric skateboard 5
2.2 The remote control 5
3. Start with your Skatey 6
3.1 Safety measures 6
3.2 Acvate the Skatey board 6
3.3 Acvang the remote control 6
3.4 Stepping on and o 7
3.5 Relax 7
3.6 Driving 7
3.7 Turning your Skatey 8
3.8 Uphill and Downhill Riding 8
3.9 Deacvang skateboard 8
3.10 Charging the skateboard 8
4. Warnings and advice 9
5 Maintenance 10
5.1 Cleaning 10
5.2 Baery 10
5.3 Check your board before driving 11
5.4 Wear and tear 11
6. Performance 12
7. Skatey board and charger specicaons 12
7.1 Skatey charger specicaons 13
8. Baery details 13
8.1 Specicaons 13
8.2 Low baery capacity 13
8.3 Special situaons 14
9. Troubleshoong 15
10. Storage 16
11. Warranty 16
12. Terms and condions 17
13. Baery disposal 18
14. EC declaraon of conformity 18
15. Contact and customer service 18

INSTRUCTIONS MANUAL Skatey 2800L/3200L
4
1. Content packing
A Skatey electric skateboard comes complete with the following items in the packing:
• Skatey electric skateboard with unique serial number.
• Remote control
• Baery for the remote control
• Charger for the skateboard
• Toolkit
• Quick start manual with unique serial number
2. Skatey electric skateboard product description
The Skatey electric skateboard is equipped with an electric motor, a baery and a remote control so you can drive au-
tomacally. All Skatey components are manufactured and assembled by hand with great care. Take careful note of the
instrucons and safety measures in this document and your Skatey board will provide you with many hours of fun.
Details:
• Innitely variable speed control with the remote control for easy driving.
• Electronic brake for powerful and safe braking, even at high speeds.
• Remote control that operates your Skatey.
• Driving at 2 preset speeds.
• Baery-saving mode for the Skatey and the remote control. When not in use the Skatey and the remote control
both power o automacally aer 5 minutes.
• High quality an slip deck.

Skatey 2800L/3200LINSTRUCTIONS MANUAL
5
2.1 The electric skateboard
The skateboard comes complete with the charger and the remote control. The deck designs may vary. The unique serial
number is located on a scker on the baery box of your skateboard.
The on/o buon and the charge socket is located on the side of the black box, that is aached to the boom of the
skateboard. The electric motor(s) of the Skatey 3200L is located on the rear axle. The Skatey 2800L has in-hub motors on
the rear wheels.
2.2 The remote control
Use the remote control for acceleraon and braking. By pulling the trigger towards you, the Skatey will accelerate.
You can regulate your speed by pulling the trigger hard or gently towards you. Push the trigger forward to brake.
Connecon:
The remote control must be within 1,5 meter of the skateboard in order to operate it. If this distance is greater there is
no connecon between the remote control and the skateboard.
Switch on/o and changing the preset speed:
• Switch on the remote by pressing the on/o buon.
• Set the preferred speed
Slow: for beginners. Press the “speed” buon; the light under the buon blinks slowly.
Fast: for professional and advanced riders. Press the “speed” buon; the light under the buon blinks fast.
• Switch o the remote pressing the on/o buon.
Pairing the skateboard with the remote control
In order to be able to control the skateboard, the board and the remote must communicate with each other. To make

INSTRUCTIONS MANUAL Skatey 2800L/3200L
6
the connecon rst switch on the skateboard, then switch on the remote control. If the red
“code” light on the remote control blinks press the “code” buon. When the light stops blink-
ing and remains red, the remote and the board are connected. Now you can drive. You only
have to do this once.
Baery
The remote control will power o aer approximately 5 minutes if not in use, this extends
the baery life. To reacvate the remote control power it o and back on again. Charge the
remote with the USB cable. If you don’t charge the baery the remote control will automa-
cally power o aer a few minutes.
3. Start with your Skatey
3.1 Safety measures
When you ride your Skatey electric skateboard you need to use protecve equipment. You should at least wear a hel-
met, wrist, elbow and knee pads. If you fall, this protecve equipment will absorb a great deal of the impact and helps
prevenng serious physical injury.
3.2 Activate the Skatey electric skateboard
To acvate the skateboard press the red colored buon on the side of the board located on the black “control box”. The
blue indicator light will light up.
3.3 activating the remote control
Acvate the remote control with the switch.
Make sure that you don’t touch the trigger during startup (if you do your board will drive away without you).

Skatey 2800L/3200LINSTRUCTIONS MANUAL
7
3.4 Stepping on and off
Make sure that you have enough space to pracce. If you are not experienced ask if someone can help you.
Place one foot on the board in the riding direcon above the front truck. Put some weight on this foot and slightly bend
your knee. Now place your other foot diagonally on the board above the rear truck. Remember to keep pung weight
on your front foot, thereby moving your bodyweight forward.
Only step o the board when you are standing sll. If you are stepping o while driving, you may fall.
3.5 Relax
It usually takes no more than a few minutes before you can stand properly and relaxed on your board with the remote
control in your hand.
3.6 Driving
If you have to learn how to drive an electric skateboard, make sure the remote is set in “slow mode”. In “slow mode”
you are less likely to fall. To put the Skatey in moon, gently pull the trigger of the remote control. Once the Skatey
starts moving, rst pracce braking. You do this by pushing the trigger forward with your index nger. Once you are used
to driving in “slow mode” you can switch to medium or fast mode.
Warning: Do not drive outside your driving abilies, adapt your driving speed to your skills!!
3.7 Turning your Skatey
The Electric Skateboard turns like any other skateboard. First assume the basic posion. Bend your knees a lile more
and apply pressure to the deck with your heels or toes and the board will turn in that direcon. More pressure will
result in ghter turns. First pracce a le turn and then a right turn.

INSTRUCTIONS MANUAL Skatey 2800L/3200L
8
3.8 Uphill and Downhill Riding
On an uphill run, you will nd that you need to keep your weight over the rear wheels to keep them from slipping. If
the hill is too steep the motor may overheat. Stop, step o and walk the steep hills. The board will take lighter riders up
hills faster and will slow down as the rider’s weight increases. On downhill runs, the motor remains engaged at all mes.
Frequent minor speed correcons with the brakes are preferable to leng your speed build and then breaking suddenly.
Never ride down hills that require constant breaking. This may damage the board’s electronics.
3.9 Deactivating skateboard and remote (switch off)
The skateboard and the remote control will switch o automacally if they have not been used for 5 minutes. The board
can be switched o manually by pushing the power switch. On the skateboard the buon is located on the side of the
Skatey on the black box (the light will dim). On the remote control the switch is located on top of the controller.
3.10 Charging skateboard
Only use the adapter supplied. Insert the adapter plug into the wall socket (the adapter light will turn green). Plug the
connector on the other side of the adapter into the socket on the board located on the side of the Skatey on the black
box. The adapter light is now red; charging has started, when the light on the adapter turns green your board is fully
charged.
Tip: do not charge the Skatey longer than necessary. The quality of the baery will deteriorate and the baery will
drain faster if you do so. Never charge the baery longer than 10 consecuve hours. Longer charge may
irreparably damage the baery.

Skatey 2800L/3200LINSTRUCTIONS MANUAL
9
4. Warnings and advice
This secon contains some warnings and advice. It is important that you read and understand these warnings and advice
in order to ensure that your experiences with the Skatey electric skateboard are always posive and enjoyable. Failing to
observe these measures may result in injuries and serious, possibly fatal wounds. Skatey Electric B.V. is under no circum-
stances responsible for any damage caused by any person to himself/herself or others.
The warnings and advice
• Always check if the Skatey is in perfect working order every me you use it. Make sure that all screws are ghtened
and that all axle units and other mechanical- and electronic components are funconing properly.
• Riding a Skatey is not allowed on public roads.
• The remote control can operate dierent Skatey’s, therefore keep enough distance from each other.
• The Skatey 2800L and the Skatey 3200L are not suitable for children under the age of 12 years.
• Young riders should not use an electric skateboard without adult supervision.
• If you are riding a Skatey for the rst me always start on the lowest speed to get familiar with the board.
• Always start o slowly, never pull trigger too hard from sll posion, its dangerous!
• Pregnant women and disabled persons may not use a Skatey.
• The Skatey should only be used if you are physically t.
• A Skatey must be operated by only one rider at a me.
• Never use the Skatey if you are under the inuence of alcohol or medicaon that infects your driving skills.
• Always wear suitable clothing and protecve gear if you are riding the Skatey. This includes elbow- wrist- and
kneepads and proper footwear However, don’t forget that wearing protecve gear when riding the Skatey will not
provide 100% protecon against injuries.
• If you’re riding a Skatey for the rst me always make sure that there’s someone nearby that can help if necessary.

INSTRUCTIONS MANUAL Skatey 2800L/3200L
10
• Before using a Skatey, make sure that you have enough riding space.
• When you are riding your Skatey don’t endanger persons, animals or objects.
• Be considerate towards other people and animals and make sure that nobody else is exposed to danger or injury, or
is obstructed or inconvenienced.
• A Skatey is electric powered and is not waterproof. Don’t ride in rain, on wet streets and trough puddles of water.
• Avoid slippery ground such as ice, snow and wet ground. The Skatey may slip.
• Avoid potholes, surface cracks and roads with obstacles such as branches, loose stones and other objects.
• Be cauous when riding on an irregular surface.
• On your board you are about 10 cm taller than you usually are. Keep this in mind when you drive.
• User’s weight should be within skateboard’s max load capacity.
• Should not be used for tricks, jumps, ramps, grinds, rough handling and prolonged steep hills.
• Never hitch a ride from a car, bicycle, etc.
5. Maintenance
5.1 Cleaning
To clean your Skatey only use a damp cloth and do not use corrosive cleaning soluons. Always prevent water, moisture
or dirt from entering the electronic components, the On buon, the charging port, under the rubber mats. This can lead
to irreparable damage. Check before and aer using the Skatey for dirt between the moving parts, if present remove
immediately.
5.2 Battery
When the Skatey is not being used for a long me it’s very important that the baery is charged at least ones a month.
Otherwise the baery loses its capacity. Never charge your Skatey longer than 10 hours.

Skatey 2800L/3200LINSTRUCTIONS MANUAL
11
5.3 Check your board before driving
The Skatey has been manufactured in such a way that it requires virtually no maintenance. However, you must sll make
sure that all screws on the wheels and axles are well-secured. If screws are loose, they must be ghtened.
5.4 Wear and tear
Because the wheels and belt are subject to wear and tear, they need to be replaced aer some me. You can nd these
and other spare parts on www.skatey.com.
6. Performance
Each type of Skatey electric skateboard has a specied driving range . The maximum achievable distance can never be
predicted exactly since it is aected by the following factors.
Weight
The rider’s weight will aect the distance. If you are a light rider, your board uses less energy to transport you thus
increasing the range and the baery will drain slower.
Surface
Riding on a at smooth surface will ensure that you can cover longer distances. Traveling uphill or on a rough or uneven
surface means that your Skatey needs to work harder in order to transport you. The baery will drain faster.
Speed and riding style
You will get further when you drive calmly and evenly. Frequent braking and accelerang takes much strength from your
baery and shortens the distance you can drive.

INSTRUCTIONS MANUAL Skatey 2800L/3200L
12
Temperature
The Skatey performs best between 15 and 35 degrees Celsius.
Charging the baery
Make sure that you do not leave the Skatey on charge for too long; never longer than 10 hours. This may reduce the bat-
tery’s capacity. The consequence of this will, among other things be, that you are no longer able to cover long distances
and that you will only be able to enjoy your Skatey over shorter distances.
7. Skatey board and charger specifications
Skateboard Skatey 2800L Skatey 3200L
Weight incl. baery 9 kilogram 10 kilogram
Maximum load 100 kilogram 100 kilogram
Maximum speed 30 kilometer per hour 35 kilometer per hour
Maximum distance up to 20 kilometer up to 20 kilometer
Charge me 2-4 hour 2-4 hour
Baery 5Ah, 2,24 Volt Lithium 5Ah, 36 Volt Lithium
Power supply 90 – 250 V 90 – 250 V
Dimensions in cm lxwxh 91 x 23 x 14 91 x 23 x 14
Wheels PU - black - 90mm PU - black - 90mm
Motor 2 x 1400W (in-hub) 2 x 1600W (aeromodeling)

Skatey 2800L/3200LINSTRUCTIONS MANUAL
13
7.1 Skatey charger Specifications
Skateboard Skatey 2800L Skatey 3200L
Input 100-240V,50/60HZ,2.5A 100-240V,50/60HZ,2.5A
Output 42V 2A 42V 2A
8. Battery information
8.1 Specifications
The high quality Skatey electric skateboard lithium baery’s have the following specicaons.
Skateboard Skatey 2800L Skatey 3200L
Type of baery Lithium Lithium
Voltage 24V 36V
Capacity 5Ah 5Ah
Operaonal temperature -15 - 50 C° -15 - 50 C°
Charging temperature 0 - 40 C° 0 - 40 C°
8.2 Low battery capacity
When you noce that your board slows down, it means that the baery is running down. Recharge the baery to ensure
that you don’t come to a stand sll.

INSTRUCTIONS MANUAL Skatey 2800L/3200L
14
8.3 Special situations
If you try to solve a problem with the baery yourself, your Skatey can be damaged. Call Customer Services if you noce:
• A strange smell coming from the baery;
• That the baery is very hot while you are on the Skatey;
• That something appears to be leaking from the baery and/or your Skatey.
9. Troubleshooting
Problem Errors and cause Soluon
Skatey does not move Skatey is not powered on Power on Skatey
Remote control is not powered on Power on remote control
Trigger is forward, resulng in braking Place the trigger in the neutral posion
Pilot lamp on the micro control unit not
lighng up
Check rechargeable baery plug connecon
Trigger pulled back when power is turned on Power o remote control, place the trigger
in the neutral posion and power remote
control back on
No tone when remote control is powered on Check whether the baery is ed properly
or baery is empty (= replacing)

Skatey 2800L/3200LINSTRUCTIONS MANUAL
15
Skatey drives slow Pre-set speed is low Adjust pre-set speed on the remote control
(underneath the baery)
Baery is almost empty Charge the baery
Severe vibraons and
noises during riding
Drive belt or drive wheel is damaged or pollu-
ted
Replace drive belt or drive wheel or clean it
Defecve wheel bearing Replace wheel
Screws on motor cover are loose Tighten screws
Skatey stops automa-
cally
Overheated motor Allow motor to cool
Micro control module automacally cuts out
(to prevent deep discharge of the baery)
Charge or replace rechargeable baery
Remote control beeps a number of mes and
then powers o
Baery is low and must be replaced
Aluminium strips on remote control are da-
maged or not hold properly
Hold remote control in the proper way or
replace remote control
Remote control and/or receiver exposed to
moisture
Drain moisture and allow to dry
Distance between Skatey and remote control
is to far
Close distance to ± 1,5m
Drive belt broken Replace drive belt

INSTRUCTIONS MANUAL Skatey 2800L/3200L
16
Skatey rides erracally Pilot lamp next to on/o switch burns but
Skatey doesn’t drive = connecon- or cable
link is loose or broken
Check all connecons
Remote control and/or receiver exposed to
moisture
Drain moisture and allow to dry
Skatey does not
charge
Pilot lamp on charger does not light up Check electrical plug and power supply. Re-
place charger
Charger pilot lamp stays red = charger and/or
baery broken
Replace charger or baery
10. Storage
Sck to the following rules to keep your board in top condion.
• Ensure that your board is fully charged. When storing it for a longer me, charge the baery every month in order
to keep the baery in good condion.
• Store your Skatey indoors in a dry room at a moderate temperature.
• Ensure that no dust gets into your board by keeping it in the original box or bag.
11. Warranty
Skatey will give a one-year warranty on manufacturing errors. Your invoice is your warranty. The invoice date is the
date on which the warranty commences. The warranty does not cover parts subject to wear such as the baery or the
wheels.

Skatey 2800L/3200LINSTRUCTIONS MANUAL
17
The warranty will expire if:
• Unexpected damage occurs due to the user himself, in the event of heavy vibraons (no at surface), wear and tear,
a collision with a person or an object or water damage.
• You have failed to adhere to the advice in these instrucons; think for example of the method of storage, weight
limits and how you should maintain and use your Skatey.
• You have aempted to repair your Skatey yourself.
• The defect has occurred due to typical wear and tear, excessive use, water damage and damage resulng from ex-
treme weather condions.
• Other damage has occurred that is not related to the product design, the technology, manufacturing errors or quality
control.
Please contact our Customer Services to nd out whether your defect is covered by the warranty.
12. Terms and conditions
Please visit our website for the terms and condions: www.skatey.com
13. Battery disposal
Used baeries may not be disposed of as domesc waste. These are classied as chemical waste and must be disposed of
in an environmentally friendly manner. You may place them in the intended collecon bins in shops or dispose of them at
KCA (minor chemical waste) depots.

INSTRUCTIONS MANUAL Skatey 2800L/3200L
18
14. EC declaration of conformity
Skatey Electric B.V.
Crommelinbaan 49c
2142 EX Cruquius
The Netherlands
Hereby declares that the following products:
Skatey electric skateboard
Conform to the spulaons contained in the following EC direcve(s), including all relevant amendments:
• EMC-direcve 2004/108/EC
• RoHS-direcve 2002/95/EC
• LVD-direcve 2006/95/EC
• R&TTE-direcve 1999/5/EC
The Electric skateboards conform to all further spulaons contained in the electromagnec compability direcve
‘2004/108/EC).
15. Contact and customer service
Do you have a queson about your Skatey? Please contact our Customer Services.

Skatey 2800L/3200LINSTRUCTIONS MANUAL
19
Skatey Electric B.V.
Crommelinbaan 49c
2142 EX Cruquius
The Netherlands
Tel: [phone]
www.skatey.com
We will answer your quesons on working days from 9:00 to 17:00.

INSTRUCTIONS MANUAL Skatey 2800L/3200L
20
