SKC Leland Legacy User manual

Operating Instructions
Leland Legacy
SKC Inc.
863 Valley View Road
Eighty Four, PA 15330
Form 40075 Rev 1407

Leland Legacy Quick Guide
Terms »
Star button 
• Scrolls through run time data and Setup options
Up and down arrow buttons 
• Toggle between display choices and increase or decrease sampling parameters in Setup
Button sequence
= press buttons individually
[] = press simultaneously
= security code, always press in sequence
Security code 
• Prevents unauthorized changes to the pump’s sampling program
Programming Sequences »
• To activate pump (e.g., to change pump from Sleep to Hold):
Press any button.
• To change pump from Hold to Run or Run to Hold:
Press [].
• To reset accumulated data:
Press [], then . Press until CLr displays then press []; press until End
displays then press [].
• To set pump flow rate:
Press [], then . Flow rate and SET flash. Press or to change flow rate. Press 
until End appears then press [] to save setting and place pump in Hold.
• To calibrate flow rate with standard calibrator:
Press [], then . Flow rate and SET flash. Press or to change flow rate. Press 
once. ADJ displays. Press or until desired flow rate is indicated on calibrator. When finished,
press until End displays then press [] to save new setting and place pump in Hold. For CalChek
Calibration, see operating instructions.
• To change temperature scale from F to C or C to F:
Press [], then . Press until temperature displays. Press or to switch units;
press until End displays then press [] to save new setting.
• To change atmospheric pressure scale (mm, mb, In):
Press [], then . Press until pressure displays then press or to switch units;
press until End displays then press [] to save new setting.
• To change time scale (12 Hr/24 Hr/Dela):
Press [], then . Press until 12 Hr, 24 Hr, or Dela displays then press or to
switch units; press until End displays then press [] to save new setting. To set delayed start
(Dela), see operating instructions.
• To change clock:
Press [], then . Press until clock displays then press or to change flashing
hour; press to move to minutes and or to change setting. Press until End displays then
press [] to save new setting.
• To change the sampling time function:
Press [], then . Press until ST L/min displays then press to change flashing digit;
press until End displays then press [] to save new setting. To delete, follow above steps and
press until 0 appears. Exit Setup.
Note: When in Setup, choosing Esc instead of End will exit Setup without saving new settings.
SKC Inc., 863 Valley View Road, Eighty Four, PA 15330 • www.skcinc.com

Table of Contents
Description............................................................................................... 1
Performance Profile................................................................................. 2
Battery Charging...................................................................................... 4
Charging the Battery .................................................................................................... 4
Reading the Charging Status LED on the Single Charger ........................................... 5
Determining Pump Battery Status ................................................................................ 5
Low Battery Fault ......................................................................................................... 5
Pump Setup............................................................................................. 6
Keypad Basics.............................................................................................................. 6
Turning the Pump On/Off ............................................................................................. 6
Entering and Navigating Setup..................................................................................... 6
Setup Options............................................................................................................... 6
Resetting Run Time Data ............................................................................................. 8
Setting a Sampling Time .............................................................................................. 8
Setting a DataTrac Program......................................................................................... 8
Setting a Delayed Start ................................................................................................ 9
Setting Pump Flow Rate............................................................................................. 10
Calibration ............................................................................................. 11
Verifying Flow Rate Using a Primary Standard Calibrator ......................................... 11
Verifying Flow Rate Using CalChek Automatic Calibration Feature........................... 12
Sampling................................................................................................ 17
Sampling .................................................................................................................... 17
Scrolling Through Data............................................................................................... 17
Resetting Run Time Data ........................................................................................... 17
Deleting a DataTrac Program or Delayed Start.......................................................... 18
Deleting a Sampling Time .......................................................................................... 18
Flow Fault................................................................................................................... 18
Volume Display .......................................................................................................... 18
Battery Replacement............................................................................. 19
Removing and Replacing the Battery Pack................................................................ 19
Programming the Pump Using a PC ..................................................... 20
Optional Accessories............................................................................. 21
Warranty................................................................................................ 22
Indicates a reminder or note
Indicates a warning or caution

1
The Leland Legacy®dual diaphragm sample pump is designed specifically
to provide constant airflows from 5 to 15 L/min with minimum power
requirements and low noise. Diaphragm and valve design minimizes power
requirements and reduces noise. Incoming and outgoing airflow is pulsation
dampened. The lightweight Leland Legacy is housed in a thermoplastic
material for strength and features an overmolding of sorubber that protects
against damage and reduces noise. Powered by a rechargeable Li-Ion baery
pack, the Leland Legacy provides 24-hour run times at 10 L/min and 12 inches
water back pressure. The pump’s patented internal flow sensor measures flow
directly and acts as a secondary standard, constantly maintaining the set flow
rate. Built-in sensors automatically correct flow for variations in temperature
and atmospheric pressure. Advanced programming features are available when
used with a PC and DataTrac®for Leland Legacy Soware. The performance of
the Leland Legacy pump with the Sioutas Impactor has been verified through
EPA-ETV.
Leland Legacy Sample Pump
Description
Soft Rubber
Overmolding
protects against
damage
Liquid
Crystal
Display
(LCD)
Keypad
with large
operating
buttons
Flashing LED
Run Indicator
Battery
Status
Icon
Li-Ion
Battery
Pack
for 24-hour
run times
(included)
Not shown:
Beltclip (back)
Battery Charging
Jack (top)
Computer Interface
Port (top)
Filter Retainer
with protective cover

2
Flow
Flow Range: 5 to 15 L/min
Flow Control System: Closed loop with patented* internal flow sensor
Compensation Range: 15 L/min at 5 inches water back pressure
10 L/min at 12 inches water back pressure
5 L/min at 20 inches water back pressure
Typical Back Pressure of Sampling Media (inches water)
Compare the information in this table to pump compensation range to determine appropriate applications.
Accuracy: Flow Rate: ± 5% of set-point after calibration to desired flow
Timing: 1 min/month at 25 C
Atmospheric Pressure: ± 0.3 in Hg
Flow Fault: If the pump is unable to compensate for > 15 seconds due
to excessive back pressure, a flow fault icon displays and
flashes, the pump enters Hold mode, and the pump retains
historical data. Auto-restart is attempted every 20 seconds
up to 10 times. Adjustable with DataTrac for Leland Legacy
Software. See pages 18 and 20.
Flow Control: An internal isothermal flow sensor measures flow directly
and continuously. Sensor readings are used in a flow
monitoring algorithm to maintain calibrated volumetric flow.
In addition, built-in atmospheric temperature and pressure
sensors provide readings to correct volumetric flow for
these parameters when they vary from point of calibration.
Tubing: Requires 3/8-inch ID tubing
Operation
Display: LCD displays pump serial number, pump software revision
level, flow rate, volume, temperature, atmospheric
pressure, time of day, run time, and pump status, i.e., Hold
and run as well as Setup information.
Volume Display: Continually updated, based on corrected flow rate
multiplied by sampling time. When volume exceeds
99,999 liters, the pump will continue to run normally but
an O_FLO Error will appear on the LCD.
Time Display: Time of day in hours and minutes (12 or 24-hour clock)
with AM and PM indicators
Timer Display Range: 1 to 99,999 minutes (69 days). If the run time exceeds
69 days, the timer display rolls over.
Operating Temp. Range: 32 to 113 F (0 to 45 C)
Protect sample pump from weather when
in use outdoors.
Altitude: The pump can apply correction to volumetric flow during
sampling for weather-related or altitude variations from
the atmospheric pressure established at calibration up to
at least 7500 feet above and 5000 feet below sea level.
Operating Humidity: 0 to 95% non-condensing
Performance Profile
Flow Rate (L/min) 5.0 8.0 10.0 12.0 15.0
Filter/Pore Size (μm)
37-mm MCE/0.8 11 18 22 28 36
37-mm PVC/5.0 4 7 9 11 15

3
Performance Profile
Typical Run Time:†• Sioutas Impactor (approx. 13 in water bp): 24 hrs at
9 L/min
• PEM with 37-mm, 2.0-μm PTFE filter 225-1709‡:
24 hrs at 10 L/min
• Low-volume PUF Tube: 24 hrs at 5 L/min
• DPS Sampler (PM2.5 or PM10): 24 hrs at 10 L/min
• 8 L/min Respirable PPI: 24 hrs at 8 L/min
• For extended run times, the pump may be operated
while attached to the approved charger.
Noise Level: 62.5 dBA - pump without case
52 dBA - pump housed in noise-reducing case (optional
accessory Cat. No. 224-89, see page 21)
Measured 3-ft (1-m) distance from pump operating at
10 L/min and 12 inches water back pressure
User-adjustable Values: Sample run time, calibration, clock display, flow rate,
time of day, delayed start, and temperature and
atmospheric pressure display
Recorded Values: Start date and time, stop date and time, total sample
time, flow rate, sample volume, temperature,
atmospheric pressure, and pump mode transitions
Adjustable Logging Records pump history from 3 seconds (15.4 min of data)
Interval: up to 8 hours (over 102 days of data) depending on setting.
Option available when using DataTrac Software.
Power
Power Supply: • Battery: Removable, rechargeable lithium-ion (Li-Ion)
,
7.4 V, 12-Ah capacity, 88.8 Wh
• Charger/AC adapter: Input voltage 100 to 240 V AC
Battery Recharge Time: 15 hrs
(with SKC-approved chargers;
varies with baery capacity and
level of discharge)
Charging Temp. Range: 32 to 113 F (0 to 45 C)
Storage Temp. Range: -4 to 95 F (-20 to 35 C)
Physical
Size: 8 x 3.9 x 2.6 in (20 x 10 x 7 cm)
Weight: 36 oz (1 kg)
Case: Thermoplastic with soft rubber overmolding
RFI/EMI Shielding CE marked
Approvals: Leland Legacy with Sioutas Impactor performance has
been verified by EPA-ETV.
* U.S. Patent No. 5,892,160
† Results when tested with a new pump and new fully charged battery. Pump performance may vary.
‡ Back pressure on PTFE filters can vary within the same lot. PTFE filter Cat. No. 225-1709 contains a
PMP support ring with a maximum operating temperature of 464 F (240 C).
Cautions:
• Use only SKC-approved parts to ensure reliable performance and to
maintain any warranty.
• Failure to follow warnings and cautions voids any warranty.

4
Charging the Battery
Completely charge the baery pack before operating the pump. It may be
necessary to charge the baery a few times before maximum capacity is
achieved. Shown with single charger (Cat. No. 223-241). A five-station charger
is available; see Optional Accessories on page 21. Follow charger instructions.
For a complete charge, ensure the pump is not running during charging.
• Use of a non-approved charger may damage the battery and pump and
VOIDS ANY WARRANTY.
• Using a repaired or rebuilt battery pack VOIDS ANY WARRANTY.
• Do not charge or operate pump with or without the charger in hazardous
locations.
• Ensure proper orientation of charging cable before plugging it into the
charging jack. Improper orientation/contact will short circuit the battery
and VOID ANY WARRANTY.
• Short circuiting the battery pack will render it immediately inoperative.
• Failure to follow warnings and cautions voids any warranty.
1. Insert the plug on the charging unit into the
baery charging jack on top of the pump
(underneath the protective cover).
2. Insert the plug on the power supply into the
jack on the charging unit.
3. Slide the appropriate wall plug into the
power supply and plug the power supply
into a wall outlet. The baery will recharge
in approximately 15 hours.
Aer charging the baery pack, it is good practice to run the pump for
approximately 5 minutes before calibrating. This ensures the baery is
in more steady-state conditions and improves the agreement in pre and
post-sampling calibrations.
For more information on SKC pump batery packs,
go to www.skcinc.com/instructions/1756.pdf.
The baery pack may be kept on the SKC-approved charger for an
indefinite time.
Leland Legacy charging train with
single charger
Battery charging jack
Power
supply
Charging
unit
Jack
Battery Charging

5
Battery Charging
Reading the Charging Status LED on the Single Charger
The Li-Ion Charging Unit (Cat. No. P22300) indicates baery charge status
via an LED on the unit that blinks in specific paerns. Observe the LED
steadily for > 5 seconds to read charge status.
LED Action Charge Status
ON

steady
Charge in progress
ON

2 sec
OFF

.25 sec
ON

2 sec
(Repeats) Approximately
80% charged
OFF

2 sec
ON

.25 sec
OFF

2 sec
(Repeats) Charge completed
The baery pack may be kept on SKC-approved Li-Ion baery
chargers for an indefinite time.
Caution:
• Use only the SKC-approved charger for this pump. Use of an
unapproved charger may damage the battery and pump and
VOID ANY WARRANTY.
• Tampering with the battery pack VOIDS ANY WARRANTY.
• Do not charge in hazardous locations.
• Do not operate the pump with or without the charger in hazardous
locations.
• Do not open, disassemble, short circuit, crush, incinerate, or expose
the battery to fire or temperatures in excess of 212 F (100 C).
• Failure to follow warnings and cautions voids any warranty.
For more information on SKC pump batery packs,
go to www.skcinc.com/instructions/1756.pdf.
Determining Pump Battery Status
Three bars indicate a full charge (normally appears aer charging),
approximately 75 to 100%.
Two bars indicate that the baery is charged enough to operate the
pump, approximately 25 to 75%.
One bar indicates baery charge is low (charge baery),
approximately 1 to 25%.
Low Battery Fault
No bars and a flashing outline indicate a Low Baery Fault mode
(pump will go into Hold).
Power supply
jack
Charge status
LED

6
Keypad Basics
Scrolls through run time data
and Setup options
Increases values such as flow
rate
Decreases values such as flow
rate
[] When pressed simultaneously,
displayed item is selected or
entered.
Security code that must be
pressed in sequence to enter
Setup
Turning the Pump On/Off
• Press any buon to turn on the power.
• Press [] to run the pump or to place a running pump in Hold.
• Manual O: from Hold, press and hold .
• Auto Oturns othe pump aer 5 minutes in Hold.
Entering and Navigating Setup
Entering: Press [], then press the security code
in sequence. Setup should appear
briefly on the LCD.
Navigating: Press to scroll through parameters. Once
the LCD shows End, parameters will repeat
until the user exits Setup.
Exiting: Press until End appears on the LCD. Press
[]. The pump is now in Hold.
Setup Options
Aer entering Setup, go to:
1. Flow Set: Press or to increase or decrease pump
flow rate. Pump will start running. Press to move to
next parameter.
2. ADJ: Used during calibration with primary standard
calibrator (not for use with CalChek feature). Press 
or to increase or decrease flow adjustment until
desired flow is indicated on calibrator. Press until End
appears. Press [] to save new flow and adjustment
seings and exit Setup.
Down
arrow
button

Button
Up
arrow
button
Pump Setup

7
If changing other parameters, do not press [] but continue
pressing aer End appears and the remainder of the menu
items will appear. Once all changes are entered, press until End
appears, then press [] to save new seings and exit Setup.
Pressing [] when Esc appears will exit Setup without saving
new seings.
3. CALCh: Use for CalChek calibration feature only.
Pressing [] initiates single-point calibration.
Pressing seven times initiates a full calibration.
See CalChek Calibration instructions on pages 12 to 16.
4. 12 Hr/24 Hr Clock and Delayed Start (factory
default is 12 Hr clock): Press or to move
between standard (12 hour), military (24 hour), and
Dela (delayed start). Press to select. If Dela (delayed
start) is selected, follow instructions on page 9.
5. Time of day: Press or to increase or decrease
flashing hour. Press to move from hours to
minutes. Press or to increase or decrease
flashing minutes. Press to move to next parameter.
6. ST (Sampling Time): Allows the user to program
a specific run time. Press or to increase or
decrease the time in minutes (up to 99,999 minutes).
Press to move to next parameter. See pages 8 and 18
for Seing and Deleting a Sampling Time.
7. Temperature (factory default is Celsius): Press 
or to toggle between Fahrenheit (F) and Celsius
(C). Press to move to next parameter.
8. Atmospheric Pressure (factory default is mm):
Press or to toggle between inches of mercury
(In), millibars (mb), and millimeters of mercury
(mm). Press to move to next parameter.
9. CLr: Press [] to reset accumulated run time and
volume data to zero
(see Reseing Run Time Data on page 8).
Pump Setup

8
10. ESC: Press [] to exit Setup without saving new
seings.
11. End: Press [] to save new seings and exit Setup.
PrOFF: Appears only when a program is loaded into pump memory.
See DataTrac for Leland Legacy Soware Operating Instructions
(Form 40085, included on soware CD) for seing a program.
See page 18 for Deleting a DataTrac Program or Delayed Start.
Resetting Run Time Data
To reset accumulated volume and run time data to zero:
1. Press [], then press the security code in
sequence. Setup will display briefly.
2. Press until Clr appears, then press [].
3. Press until End appears, then press [] to exit
Setup. The accumulated data is cleared and the pump
is now in Hold.
CLr does not clear previously set sampling time
(ST). See Deleting a Sampling Time on page 18.
Setting a Sampling Time (ST)
Program the Leland Legacy from the integral keypad or a PC using DataTrac
soware to sample from 1 to 99,999 minutes.
1. Press [], then press the security code in
sequence. Setup will display briefly.
2. Repeatedly press until ST L/min and a flashing time
and Set appear on the display.
3. Set the sampling time by pressing or to increase
or decrease it to the desired time in minutes.
4. Press repeatedly until End appears.
5. Press [] to save the new sampling time and exit
Setup.
6. Press [] to begin sampling. The time display will
count down in minutes and the pump will go to Hold.
The total sampling time will display.
7. To delete a set sampling time, see Deleting a Sampling
Time on page 18.
Setting a DataTrac Program
See DataTrac for Leland Legacy Software Operating Instructions (included on
software CD).
Pump Setup

9
Setting a Delayed Start
A delayed start can be programmed using the pump
keypad or from a PC using DataTrac Soware. The
following instructions are for keypad only. See DataTrac
for Leland Legacy Operating Instructions (included on soware
CD) for programming from a PC.
When seing the pump for sampling from 1 to 99,999
minutes to begin within the next 12-hour period, follow this
procedure:
1. Press [], then press the security code in
sequence. Setup will display briefly.
2. Press until the display reaches the 12 Hr/24 Hr clock.
If delayed start is already programmed, the display will show Dela
(delayed start) in place of 12 Hr. If no delay is programmed, press or
until the display shows a flashing Dela (delayed start).
3. Press until the time of day (flashing hours) displays. Select the hour
(time of day) that the pump is to begin sampling (within the next 12
hours) by pressing or until the desired hour displays. Press and
the minutes will flash. Press or until the desired minutes display.
The time of day entered will be the next occurrence of this time
within the next 12-hour period aer the delayed start is entered.
There is no a.m. or p.m. designation.
4. Press until the ST displays. Press or to set the desired run time
in minutes. A delayed start cannot be run unless a sampling time (ST)
is programmed.
5. Press until End appears.
6. Press [] to save seings and exit Setup.
7. Prog and a flashing Hold will appear in the upper
lecorner of the display. The pump is now set for
delayed start.
Once a program is set in the pump, the pump cannot be run
manually. To return to manual pump operation, let the program
run its course or delete the program (see Deleting a DataTrac Program
or Delayed Start on page 18).
Display for
delayed start
Pump Setup

10
Setting Pump Flow Rate
1. Press [], then press the security code in sequence.
2. The flow rate and Set will flash on the LCD. Press to increase flow
rate. Press to decrease flow rate. The pump will run while flow is set.
3. Once the desired flow rate is displayed, press until End appears on
the display. The pump will stop running.
4. Press [] to save the new flow rate and exit Setup.
Pump Setup
Flow Rate and Volume Display
Flow Rate displayed on the pump LCD is the flow to which the pump has been
calibrated. To maintain flow as displayed, the pump automatically adjusts flow
during sampling for changes in temperature and atmospheric pressure* that
may differ from the temperature and atmospheric pressure present at the time of
calibration. The flow rate display does not change from the calibrated flow rate.
The pump will fault if it is unable to maintain the calibrated flow rate.
Volume displayed on the pump LCD is “corrected” in that it is the result of a
continual calculation of corrected flow rate multiplied by sample time. Volume
does not display after 99,999 liters. See Volume Display on page 18.
* The pump can apply correction to volumetric flow during sampling for weather-related or altitude
variations from the atmospheric pressure established at calibration up to at least 7500 feet above and
5000 feet below sea level.

11
Verifying Flow Rate Using a Primary Standard Calibrator
Before use, allow pump to equilibrate after moving it from one
temperature extreme to another.
1. Ensure the pump has run for 5 minutes before performing calibration.
2. Connect the pump inlet to a calibrator with representative media in line
(see photo below).
3. Press [], then press the security code in sequence. The flow
rate and Set will flash.
4. Set the flow on the pump display by pressing or 
to increase or decrease flow to the desired rate.
5. Press . Adj will appear.
6. If the calibrator reads a higher flow rate than the
pump is set for,
press until they
are in agreement
(within 10 ml).
If the calibrator
reads a lower flow
rate, press until
they agree (within
10 ml). When
pressing or ,
the pump display
will indicate the
adjustment (or correction) made in L/min.
7. Press until End appears.
8. Press [] to save new flow rate and Adj and exit Setup. Reset run
time data (see page 8).
If the pump has been programmed with DataTrac Soware and
switched to manual operation, a program may remain in pump
memory. Prog will display in the upper lecorner of the pump
display. See page 18 for Deleting a DataTrac Program or Delayed Start.
Calibration train with sample
medium in line
Calibration

12
Verifying Flow Rate Using the CalChek Automatic
Calibration Feature
The CalChek automatic calibration
feature is available when calibrating
a Leland Legacy with a Defender
calibrator (Cat. No. 717-510H). A
CalChek Communication Cable
(Cat. No. 210-502) is required
for communication between the
pump and the calibrator. Optional
DataTrac for Leland Legacy
Soware can be used to expand
the documentation capabilities of
this feature. The CalChek feature
provides single-point calibration to set and verify flow at a single point before
and aer sampling and multiple-point (full) calibration to calibrate flow to a
primary standard at multiple flow rates within the pump flow range. Both
calibration options bring flow to within ± 5%.
For optimum accuracy, do not perform single-point or multiple-point
calibration until the pump has remained at ambient temperature for
several hours.
Single-point Calibration Using CalChek
The CalChek feature provides correction at a single flow seing and usually
takes less than one minute to complete. Use it to set the desired flow rate
before sampling and to verify flow aer sampling.
Before use, allow pump to equilibrate after moving it from one
temperature extreme to another.
Calibrate with representative sampling media in line.
1. Ensure the pump has run for 5 minutes before starting calibration. Leave
the pump on.
2. Use two pieces of 1/4-inch tubing, one to connect the Defender suction
port to the inlet of the representative sample medium and the other to
connect the medium outlet to the Leland Legacy pump inlet.
3. Select the Defender data port:
a. Press and hold the Defender power buon to turn on the flowmeter.
b. Press the right arrow to highlight Setup; press Enter.
c. Press the right arrow to highlight Preferences; press Enter.
d. Press the down arrow to navigate to Data Port.
e. Press the leor right arrow to toggle to SKC.
f. Press the down arrow to highlight Confirm; press Enter.
Calibration
Single-point calibration train with CalChek

13
4. Enter Defender calibration mode:
a. Press the right arrow and then the down arrow to highlight Measure;
press Enter.
b. Press the right arrow to highlight Cont.; press Enter.
5. Aach the female end of the CalChek Communication Cable to the serial
port (RS-232) on the back of the Defender calibrator.
6. Insert the male end of the CalChek Communication Cable into the data
port on the pump.
7. Press the security code in sequence on the pump keypad to
enter Setup.
8. Set the pump to the desired flow rate.
9. Press on the pump keypad until CALCh appears on
the pump display.
Note: If “no” is flashing on the pump LCD, the pump
has not equilibrated. Wait until the “no” display
disappears before proceeding with calibration.
10. Press [] to initiate single-point calibration.
11. The Defender calibrator will begin to automatically
calibrate the pump. Initial flow measurements are
taken without flow from the pump and the pump flow
rate is adjusted automatically. The pump will display
1Cal. During calibration, the pump will briefly display
the flow rates that it is reading from the calibrator.
12. When calibration is completed, the Leland Legacy will
continue to run. If the calibration was successful, the
pump LCD will revert to displaying pump run time as
0.0. If there was failure during the calibration process,
an error code of E4[x] will appear (see CalChek Error
Chart on page 16).
Note: To remove a CalChek error code from the LCD, press .
13. Place the pump in Hold. Disconnect the pump from the representative
sampling medium and the calibrator.
14. Allow the pump to go to sleep.
15. Place a fresh sampling medium in line and sample when ready.
Successful single-point calibration will provide an entry in the
pump history that can be viewed using DataTrac for Leland Legacy
Soware.
Allow pump to go to Sleep mode to write calibration data to pump
history.
Calibration

14
Multiple-point (Full) Calibration Using CalChek
This type of calibration using a Defender calibrator provides flow correction
across the complete operating range of the Leland Legacy (5 to 15 L/min)
in approximately 4 minutes. The operation calibrates each flow rate to a
primary standard. It can also provide a record of calibration for maintenance
and quality purposes if DataTrac for Leland Legacy Soware is used. SKC
recommends that a full calibration be performed during pump maintenance
and aer non-factory repairs.
Do NOT place sampling media in line for full calibration. Ensure the
battery pack is completely charged before starting a full calibration.
Before use, allow pump to equilibrate after moving it from one
temperature extreme to another.
1. Use 1/4-inch tubing to connect the Defender suction port to the Leland
Legacy pump inlet.
2. Follow Steps 1 and 3 through 9 of Single-point CalChek Calibration on
pages 12 and 13.
3. Verify that the baery icon on the pump display shows at least two bars.
If it does not, charge the baery before proceeding.
4. Press on the pump keypad 7 times to place pump in full calibration
mode.
5. The Defender calibrator will begin to automatically
calibrate the pump. Initial flow measurements are
taken without flow from the pump and the pump
flow rate is adjusted automatically. The pump will
display FCAL, CS1, and a brief flow rate. The pump
will continue to display CS2, then a flow rate, CS3, then
a flow rate, etc. until calibration is completed at all flow
rates between 5 and 15 L/min.
Note: CalChek full calibration can be aborted by pressing []. The pump
will go into Hold.
Calibration
Multiple-point calibration train
with CalChek; do not place
sample medium in train.

15
6. CCAL will display during Calibration Check mode and will count down
to 1. The pump will stop running.
7. When calibration is completed, the Leland Legacy
will go to Hold. If the calibration was successful, the
pump LCD will revert to displaying pump run time as
0.0. If there was failure during the calibration process,
an error code of E4[x] will appear (see CalChek Error
Chart on page 16).
Note: To remove a CalChek error code from the LCD, press .
8. Allow the pump to go to Sleep mode to write calibration data to pump
memory.
CalChek Full Calibration Data
Requires DataTrac for Leland Legacy Software
Full calibration completely clears pump history, run time parameters, and the
DataTrac Scheduler. Full calibration data can be viewed and printed by going to
the DataTrac Pump Manager window in DataTrac for Leland Legacy Soware
and clicking on the View menu. Choose Calibration Info. This will display
calibration results, pump serial number, and date of the last full calibration. A
buon allows this data to be printed. The printed report contains pump version,
date printed, and a validation code to perform data verification.
CalChek Full Calibration Data Verification
Requires DataTrac for Leland Legacy Software
To ensure that printed calibration data has not been tampered with, pull
down the Tools menu in the Calibration Info window and choose Confirm
Validation Code. Enter the data from the printed report, including the
validation code. DataTrac Soware will indicate whether the information is
completely valid or if a parameter has been changed.
When entering data to confirm the validation number, enter the
date in the following format: mmm, dd, yyyy (e.g., Aug 18 2009).
Calibration

16
Single-point Calibration Errors
Error Problem Troubleshooting
E41 Correction required too large. A gross
mismatch between the flow setting on
the pump and the reading generated by
the Defender calibrator has occurred.
Perform a full calibration. If this fails,
contact SKC Technical Support at
[email protected].
E48 Could not get a successful single-point
calibration within five flow readings.
Try the calibration again. If problem
persists, perform a full calibration.
Multiple-point (Full) Calibration Errors
Error Problem Troubleshooting
E44 First flow reading greater than
5 L/min. The pump is flowing faster
than it should, even though the
calibration routine delivered only a
very small voltage to the pump.
Check pressure sensor tubing to
ensure that it is not pinched or
blocked, or contact SKC Technical
Support at [email protected].
E45 Pump unable to achieve flow rate of
15 L/min possibly due to a blocked inlet
filter or flow tube or an air leak inside
the pump.
Check pump inlet filter for debris
and flow tube for blockage, or
contact SKC Technical Support at
[email protected].
E46 or E49 Analysis error in the data (rare). Try full calibration again. If problem
persists, contact SKC Technical
Support at [email protected].
E47 Less than two bars appear in the
battery icon on the pump display
indicating that the battery is too low.
There must be at least two bars to
begin a full calibration.
Recharge the battery.
—— At conclusion of full calibration, pump
does not verify to within 5%.
Pump not at ambient conditions for at
least 2 hours. Retry calibration after
pump has been at ambient conditions
for 2 hours.
Pump not running for 5 minutes prior
to calibration. Run pump for 5 minutes
and retry calibration.
Errors That Can Occur During Both Calibration Modes
Error Problem Troubleshooting
E42 Unstable average. There is too much
variation in the flow readings.
Try the calibration again. If problem
persists, contact SKC Technical
Support at [email protected].
E43 Serial time out. The calibrator is not
communicating with the pump.
Check adapter connection. If loose or
disconnected, connect properly.
E4A Calibration has been initiated before
pump has equilibrated. Press . Allow pump to run until “no”
disappears from display. If problem
persists, contact SKC Technical
Support at [email protected].
CalChek Error Chart

17
Sampling
1. Following setup and calibration, replace representative
sampling medium with a new unexposed sampling
medium.
Protect sample pump from weather when in use
outdoors.
2. To begin sampling, press [] to run the pump. Record
the start time.
3. Sample for the time specified in the method used.
4. To stop sampling, press [] to place the pump in Hold.
Record the stop time.
5. When sampling is complete, pump data is retained in
memory for recovery. Data can be viewed on the LCD by
using the buon to scroll through it.
If the pump has been programmed with a PC,
Prog will display in the upper lecorner of
the pump display. The pump will not operate
manually. To restore manual operation, delete
the program. See Deleting a DataTrac Program or
Delayed Start on page 18.
Scrolling Through Data
Repeatedly press to view run time or sample time (ST)*, sample volume,
flow rate, temperature, atmospheric pressure, and time of day.
* If the pump is started and stopped manually, the pump LCD will
count up run time and display cumulative run time at the end
of sampling. If a sampling time (ST) has been programmed, the
pump will count down from the set time to zero, then display
completed sampling time (ST).
Resetting Run Time Data
To reset accumulated volume and run time data to zero:
1. Press [], then press the security code in sequence. Setup
will display briefly.
2. Press until Clr appears, then press [].
3. Press until End appears, then press [] to exit Setup. The pump is
now in Hold.
CLr does not clear previously set sampling time (ST). See Deleting a
Sampling Time on page 18.
Leland Legacy
pump with filter
cassette in
holder
Sampling
