SKC TOUCH Operating instructions

Pocket Pump TOUCH
Installation/Operation Caution Guide
The SKC Pocket Pump TOUCH (Model 220-1000TC) Intrinsically Safe/Sécurité
Intrinsèque personal air sample pump was evaluated in accordance with the
following standards:
•UL 913 STANDARD FOR INTRINSICALLY SAFE APPARATUS AND
ASSOCIATED APPARATUS FOR USE IN CLASS I, II, III, DIVISION 1,
HAZARDOUS (CLASSIFIED) LOCATIONS - Edition 8 (2015)
•CSA C22.2 NO. 157-92 INTRINSICALLY SAFE AND NON-INCENDIVE
EQUIPMENT FOR USE IN HAZARDOUS LOCATIONS - Edition 3 (2003)
•CENELEC EN 60079-0 EXPLOSIVE ATMOSPHERES - PART 0: EQUIPMENT
- GENERAL REQUIREMENTS - Edition 7 (2018)
•CENELEC EN 60079-11 EXPLOSIVE ATMOSPHERES - PART 11:
EQUIPMENT PROTECTION BY INTRINSIC SAFETY “I” - Edition N/A (2012)
•
IEC 60079-0 EXPLOSIVE ATMOSPHERES - PART 0: EQUIPMENT GENERAL
REQUIREMENTS - Edition 7 (2017)
•IEC 60079-11 EXPLOSIVE ATMOSPHERES –PART 11: EQUIPMENT
PROTECTION BY INTRINSIC SAFETY “I” - Edition 6 (2014)
MARKINGS*
* UKCA mark and UL22UKEX2584 added based on previously issued ATEX/IECEx
certificates
220-1000TC PocketPump, SKC Inc. SN YY9999
Class I, Groups A, B, C, D; Class II, Groups E, F, G; Class III, T4;
Class I, Zone 0, Group IIC T4; Exia -20oC ≤ Ta ≤ 45oC
II 1G Exia IIC T4 Ga
IECEx UL 16.0113, DEMKO 16ATEX 1600, UL22UKEX2584
0539 0843

Form 38059 Rev 220810
WARNINGS/AVERTISSEMENT
•WARNING: Substitution of components may impair intrinsic safety.
AVERTISSEMENT: La substitution de composants peut compromettre la
Sécurité Intrinsèque.
•WARNING: To prevent ignition of hazardous atmosphere, batteries must only
be charged (removed and replaced) in an area to be known non-hazardous.
AVERTISSEMENT: Afin de prévenir l’inflammation d’atmosphères
dangereuses, ne changer les batteries que dans des emplacements désignés
non dangereux.
•WARNING: Use only SKC charger Cat. No. 220-300.
•WARNING: Maximum charge input voltage Um = 5.5V DC.
CAUTIONS
•CAUTION: The battery used in this device may present ariskof fire or explosion
when heated above 212 F (100 C) or incinerated. Replace battery with SKC
Battery Pack Cat. No. P76303 only. Use of another battery may present a risk
of fire or explosion.
Battery Pack Replacement
1. Turn off pump by pressing the Power On/Off button located on the top of the
pump. The screen will go dark.
2. Use 1.5-mm hex key to loosen two screws on back of battery pack housing.
3. To remove battery pack, lift it up against belt clip. Once clear of case, pull away
from pump case.
4. To install battery pack, align it with bottom of pump case and push it up
against belt clip until battery pack presses easily into place. Ensure it fits
flush with pump case. Use 1.5-mm hex key to tighten two screws on back of
battery pack housing in alternating fashion.
SKC Inc., Eighty Four, PA •724-941-9701 •skcinc.com
