INTRODUCTION
●This tool is intended for drilling in wood, metal, ceramic
and plastic; tools with electronic speed control and
left/right rotation are also suitable for screwing and
thread cutting
TECHNICAL SPECIFICATIONS 1
SAFETY
●Read and save this instruction manual (pay special
attention to the safety instructions at the back) 3
●Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before
you start working
●Check voltage indicated on nameplate of tool/charger/
battery
●In case of electrical or mechanical malfunction,
immediately switch off the tool or unplug charger from
power source
●SKIL can assure flawless functioning of the tool only
when original accessories are used
●Before using accessories always compare the maximum
allowed r.p.m. of that specific accessory with the r.p.m.
of the tool
●This tool should not be used by people under the age of
16 years
●Be careful not to drill or drive into areas where electrical
wires may be contacted
●Do not activate switch when changing accessories or
carrying the tool
CHARGING/BATTERIES
●Charge battery only with the charger that is supplied
with the tool
●Do not touch the contacts in the charger
●Do not expose tool/charger/battery to rain
●Never charge battery outdoors 4
●Store tool/charger/battery in locations where
temperature will not exceed 40° C or drop below 0° C
●Batteries will explode in fire, so do not burn battery for
any reason
●When damaged, and under extreme usage and
temperature conditions, batteries may start to leak
-if liquid comes into contact with the skin, wash quickly
with soap and water, then with lemon juice or vinegar
-if liquid gets into the eyes, flush eyes with clean water
for a minimum of 10 minutes and seek immediately
medical attention
●When battery is not in tool or charger, it should be kept
away from metal objects such as nails, screws, keys etc.
to prevent short-circuit
●Do not use charger when damaged; take it to one of the
officially registered SKIL Service Stations for a safety
check
●Do not use charger when cord or plug is damaged; cord
or plug should be replaced immediately at one of the
officially registered SKIL Service Stations
●Do not use battery when damaged; it should be replaced
immediately
●Do not disassemble charger or battery
●Do not attempt to recharge non-rechargeable batteries
with the charger
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
●Do not connect the blue (= neutral) or brown (= live) wire
in the cord of the charger to the earth terminal of the plug
●If for any reason the old plug is cut off the cord of the
charger, it must be disposed of safely and not left
unattended
USE
●Charging battery 6
-battery of new tools is not fully charged
-plug charger into power source
-light A will turn on
-insert battery into charger
-light A will blink indicating that the battery is receiving
a charge (6a)
-after approximately 1 hour the battery is fully charged
and light A stays on after blinking, at which time the
charger automatically switches to maintenance-
charging (6b)
!remove battery from charger after charging period
has ended thereby lengthening the service life of
the battery
IMPORTANT:
-if light A does not blink after inserting a battery (6b),
this may mean:
1) that the battery is too cold or too hot (charger only
charges batteries when its temperature is between
0°C and 45°C); the charger then automatically
switches to maintenance-charging, until a
temperature between 0°C and 45°C is reached, at
which time the charger will automatically switch to
normal charging
2) that the battery should be replaced
-while charging, the charger and the battery may
become warm to touch; this is normal and does not
indicate a problem
-ensure that the outside surface of the battery is clean
and dry before inserting into charger
-do not remove battery from tool while it is running
-when you charge the battery for the first time, it only
accepts 80% of its maximum capacity; after several
charges and discharges, however, the batteries
should be at full capacity and deliver maximum
performance
-do not repeatedly recharge the battery after only a
few minutes of operation; this may result in a
reduction of operating time and battery efficiency
-the nickel-cadmium battery must be kept separate from
the natural environment and should not be disposed of
as normal domestic waste (symbol 5will remind you
of this when the need for disposing occurs)
!prior to disposal protect battery terminals with
heavy tape to prevent short-circuit
-if you anticipate long periods of non-use for the tool,
it is best to unplug the charger from its power source
●Combined switch B 2for on/off and speed control
Control the speed stepless from zero to maximum by
putting less or more pressure on the trigger
GB
4

●2 Mechanical speeds 7
Set switch C to desired speed
!change speed while tool is running slowly
1 = LOW SPEED
-high torque
-for screwdriving and drilling large diameters
-for tapping thread
2 = HIGH SPEED
-lower torque
-for drilling small diameters
●Mounting of accessories in chuck
-open the chuck by turning sleeve E 2counter-
clockwise
-insert accessory
-close the chuck by turning sleeve E clock-wise
-firmly tighten sleeve E to ensure accessory is firmly in
place
!insert the accessory as deep as possible in the
chuck
!do not use accessories with a damaged shank
●VariTorque clutch
-the VariTorque clutch limits the amount of output
torque delivered by the chuck
-6clutch settings are possible:
output torque will increase as clutch ring F 2is
rotated from 1 to 5; position G 7will lock up the
clutch to permit drilling or driving heavy duty work
-when turning in a screw, first try VariTorque Control
position 1 and increase until the desired depth has
been reached
●Reversing switch D 28
For changing direction of rotation
●Keep the air vent openings clean and uncovered
APPLICATION ADVICE
●Splinterfree drilling in wood 9
●Only use sharp drill bits of the correct type 0
●Use the correct bit for the corresponding screw head !
●When turning in a screw at/near the cross cut end or an
edge of wood one should pre-drill a hole in order to
avoid cracking of the wood
●For an optimal use of the tool a steady pressure on the
screw is required, especially while removing
●When screwdriving in hard wood one should pre-drill a
hole
●When drilling ferrous metals
-pre-drill a smaller hole, when a large hole is required
-lubricate drill bit occasionally
●For more tips see www.skileurope.com
GUARANTEE / ENVIRONMENT
●Keep tool and charger clean
-the charger may be cleaned most effectively with
compressed air (wear safety goggles)
-clean charging contacts in charger with alcohol or
contact cleaner
!unplug charger from power source before
cleaning
●This SKIL product is guaranteed in accordance with
statutory/country-specific regulations; damage due to
normal wear and tear, overload or improper handling will
be excluded from the guarantee
●In case of a complaint, send the tool or charger
undismantled together with proof of purchase to your
dealer or the nearest SKIL service station (addresses as
well as the service diagram of the tool are listed on
www.skileurope.com)
●Dispose of the tool by sorting tool, charger, battery,
accessories and packaging for environment-friendly
recycling (the plastic components are labeled for
categorized recycling)
INTRODUCTION
●Cet outil est conçu pour le perçage dans le bois, le
métal, la céramique et les matières plastiques; les outils
avec réglage électronique de la vitesse et rotation à
droite/à gauche sont également appropriés pour le
vissage et le filetage
SPECIFICATIONS TECHNIQUES 1
SECURITE
●Lire et conserver ce manuel d'instruction (faire en
particulier très attention aux instructions de sécurité au
dos de ce manuel) 3
●Faites attention aux vis, clous ou autres éléments qui
pourraient se trouver dans la pièce à travailler et qui
risqueraient d’endommager très fortement votre outil;
d'abord les enlever puis travailler
●Vérifier le voltage indiqué sur la plaque du chargeur/ de
l’outil/de la batterie
●En cas d’anomalie électrique ou mécanique, couper
immédiatement l’outil ou débrancher le chargeur du
secteur
●SKIL ne peut se porter garant du bon fonctionnement de
cet outil que s’il a été utilisé avec les accessoires
d’origine
●Avant d’utiliser des accessoires, toujours comparer le
maximum autorisé de tr./min. de l’accessoire avec celui
de votre outil
●Cet outil ne doit pas être utilisé par des personnes en
dessous de 16 ans
●Veillez à ne pas percer ni visser dans des endroits où
vous risqueriez de toucher des fils électriques
●Ne pas appuyer sur l’interrupteur en changeant des
accessoires ou quand vous transportez l’outil
RECHARGE/BATTERIES
●Recharger la batterie uniquement avec le chargeur
fourni avec l’outil
●Ne toucher pas les contacts du chargeur
●Ne jamais exposer l’outil/le chargeur/la batterie à la pluie
●Recharger la batterie uniquement dans la maison 4
●Ranger l’outil/le chargeur/la batterie dans des endroits
où la température n’excède pas 40° C et ne descende
pas au dessous de 0° C
F
5

CE DECLARATION OF CONFORMITY We declare under our sole
responsibility that this product is in conformity with the following
standards or standardized documents: EN 60 335, EN 55 014,
EN 50 260, in accordance with the provisions of the directives
73/23/EEC, 89/336/EEC, 98/37/EEC.
NOISE/VIBRATION Measured in accordance with EN 50 260 the
sound pressure level of this tool is < 70 dB(A) and the vibration
< 2.5 m/s2(hand-arm method).
CE DÉCLARATION DE CONFORMITÉ Nous déclarons sous notre
propre responsabilité que ce produit est en conformité avec les
normes ou documents normalisés suivants: EN 60 335, EN 55 014,
EN 50 260, conforme aux réglementations 73/23/EEC, 89/336/EEC,
98/37/EEC. BRUIT/VIBRATION Mesuré selon EN 50 260 le niveau de
la pression sonore de cet outil est < 70 dB(A) et la vibration < 2,5 m/s2
(méthode main-bras).
CE KONFORMITÄTSERKLÄRUNG Wir erklären in alleiniger
Verantwortung, daß dieses Produkt mit den folgenden Normen oder
normativen Dokumenten übereinstimmt: EN 60 335, EN 55 014,
EN 50 260, gemäß den Bestimmungen der Richtlinien 73/23/EWG,
89/336/EWG, 98/37/EWG. GERÄUSCH/VIBRATION Gemessen
gemäß EN 50 260 beträgt der Schalldruckpegel dieses Gerätes
< 70 dB(A) und die Vibration < 2,5 m/s2(Hand-Arm Methode).
CE CONFORMITEITSVERKLARING Wij verklaren, dat dit product
voldoet aan de volgende normen of normatieve documenten:
EN 60 335, EN 55 014, EN 50 260, overeenkomstig de bepalingen
van de richtlijnen 73/23/EEG, 89/336/EEG, 98/37/EEG.
GELUID/VIBRATIE Gemeten volgens EN 50 260 bedraagt het
geluidsdrukniveau van deze machine < 70 dB(A) en de vibratie
< 2,5 m/s2(hand-arm methode).
CE KONFORMITETSFÖRKLARING Vi intygar och ansvarar för, att
denna produkt överensstämmer med följande norm och dokument:
EN 60 335, EN 55 014, EN 50 260, enl. bestämmelser och
riktlinjema 73/23/EWG, 89/336/EWG, 98/37/EWG.
LJUD/VIBRATION Ljudtrycksnivån som uppmätts enligt EN 50 260
är på denna maskin < 70 dB(A) och vibration < 2,5 m/s2(hand-arm
metod).
CE KONFORMITETSERKLÆRING Vi erklærer under almindeligt
ansvar, at dette produkt er i overensstemmelse med følgende
normer eller normative dokumenter: EN 60 335, EN 55 014,
EN 50 260, i henhold til bestemmelserne i direktiverne 73/23/EØF,
89/336/EØF, 98/37/EØF. STØJ/VIBRATION Måles efter EN 50 260
er lydtrykniveau af dette værktøj < 70 dB(A) og vibrationsniveauet
< 2,5 m/s2(hånd-arm metoden).
CE SAMSVARSERKLÆRING Vi erklærer at det er under vårt
ansvar at dette produkt er i samsvar med følgende standarder eller
standard- dokumenter: EN 60 335, EN 55 014, EN 50 260, i
samsvar med reguleringer 73/23/EWG, 89/336/EWG, 98/37/EWG.
STØY/VIBRASJON Målt ifølge EN 50 260 er lydtrykknivået av dette
verktøyet < 70 dB(A) og vibrasjonsnivået < 2,5 m/s2(hånd-arm
metode).
CE TODISTUS STANDARDINMUKAISUUDESTA Todistamme
täten ja vastaamme yksin siitä, että tämä tuote en allalueteltujen
standardien ja standardoimisasiakirjojen vaatimusten mukainen
EN 60 335, EN 55 014, EN 50 260, seuraavien sääntöjen
mukaisesti 73/23/EWG, 89/336/EWG, 98/37/EWG.
MELU/TÄRINÄ Mitattuna EN 50 260 mukaan työkalun melutaso on
< 70 dB(A) ja tärinän voimakkuus < 2,5 m/s2(käsi-käsivarsi metodi).
CE DECLARACION DE CONFORMIDAD Declaramos bajo nuestra
sola responsabilidad que este producto está en conformidad con las
normas o documentos normalizados siguientes: EN 60 335,
EN 55 014, EN 50 260, de acuerdo con las regulaciones
73/23/CEE, 89/336/CEE, 98/37/CEE. RUIDOS/VIBRACIONES
Medido según EN 50 260 el nivel de la presión acústica de esta
herramienta se eleva a < 70 dB(A) y la vibración a < 2,5 m/s2
(método brazo-mano).
CE DECLARAÇÃO DE CONFIRMIDADE Declaramos sob nossa
exclusiva responsabilidade que este producto cumpre as seguintes
normas ou documentos normativos: EN 60 335, EN 55 014,
EN 50 260, conforme as disposições das directivas 73/23/CEE,
89/336/CEE, 98/37/CEE. RUÍDO/VIBRAÇÕES Medido segundo
EN 50 260 o nível de pressão acústica desta ferramenta é
< 70 dB(A) e a vibração < 2,5 m/s2(método braço-mão).
02 SKIL Europe B.V. J. P. Houben
CE DICHIARAZIONE DI CONFORMITÀ Dichiaramo, assumendo
la piena responsabilità di tale dichiarazione, che il prodotto è
conforme alle seguenti normative e ai relativi documenti: EN 60 335,
EN 55 014, EN 50 260 in base alle prescrizioni delle direttive CEE
73/23, CEE 89/336, CEE 98/37. RUMOROSITÀ/VIBRAZIONE
Misurato in conformità al EN 50 260 il livello di pressione acustica di
questo utensile è < 70 dB(A) e la vibrazione < 2,5 m/s2(metodo
mano-braccio).
CE MINÖSÉGI TANUSITVANY Teljes felelösségünk tudatában
kijelentjük, hogy jelen termék a következö szabványoknak vagy
kötelezö hatósági elöírásoknak megfelel: EN 60 335, EN 55 014,
EN 50 260, a 73/23/EWG, 89/336/EWG, 98/37/EWG elöírásoknak
megfelelöen. ZAJ/REZGÉS Az EN 50 260 alapján végzett mérések
szerint ezen készülék hangnyomás szintje < 70 dB(A) a kézre ható
rezgésszám < 2,5 m/s2.
CE STRVZUJÍCÍ PROHLÅ◊ENÍ Potvrzujeme na odpovπdnost, Ωe
tento v¥robek odpovídå nåsledujícím normåm nebo normativním
podkladüm: EN 60 335, EN 55 014, EN 50 260, podle ustanovení
smπrnic 73/23/EWG, 89/336/EWG, 98/37/EWG.
HLUÇNOSTI/VIBRACÍ Mπ®eno podle EN 50 260 çiní tlak hlukové vlny
tohoto p®ístroje < 70 dB(A) a vibrací < 2,5 m/s2(metoda ruka-paΩe).
CE STANDARDIZASYON BEYANI Ye¤ane sorumlu olarak, bu
ürünün afla¤ıdaki standartlara veya standart belgelerine uygun
oldu¤unu beyan ederiz: EN 60 335, EN 55 014, EN 50 260,
yönetmeli¤i hükümleri uyarınca 73/23/AET, 89/336/AET, 98/37/AET.
GÜRÜLTÜ//T‹TREfiIM Ölçülen EN 50 260 göre ses basıncı bu
makinanın seviyesi < 70 dB(A) ve titreflim < 2,5 m/s2(el-kol metodu).
OÂWIADCZENIE ZGODNOÂCI CE Niniejszym oÊwiadczamy
ponoszàc osobistà odpowiedzialnoÊç, ˝e produkt wykonany jest
zgodnie z nast´pujàcymi normami i dokumentami normalizujàcymi:
EN 60 335, EN 55 014, EN 50 260, z godnie z wytycznymi
73/23/EWG, 89/336/EWG, 98/37/EWG. HA¸ASU/WIBRACJE
Pomiarów dokonano zgodnie z normà EN 50 260 ciÊnienie
akustyczne narz´dzia wynosi < 70 dB(A) zaÊ wibracje < 2,5 m/s2
(metoda d∏oƒ-r´ka).
ЗАЯВЛЕНИЕ О СООТВЕТСТВИИ Мы с полной
ответственностыо заявляем, что это изделие соответствует
следующим стандартам или стандартизованным документам:
EN 60 335, EN 55 014, EN 50 260, в соответсувии с
инструкциями 73/23/EEC, 89/336/EEC, 98/37/EEC.
ШУМНОСТИ/ВИБРАЦИИ При измерении в соответствии co
стандартoм EN 50 260 уровень звукового давления для этого
инструмента составляет < 70 дБ (A) и вибрации - < 2,5 м/с2(по
методу для рук).
CE ∆ΗΛΩΣΗ ΣYMBATOTΗΤΑΣ ∆ηλούµε υπευθύνως τι το
προϊν αυτ είναι κατασκευασµένο σύµφωνα µε τους εξής
κανονισµούς ή κατασκευαστικές συστάσεις: EN 60 335,
EN 55 014, EN 50 260, κατά τις διατάξεις των κανονισµών της
Κοινής Αγοράς 73/23/EEC, 89/336/EEC, 98/37/EEC.
ΘΟΡYΒΟ/ΚΡΑ∆ΑΣΜΟYΣ Μετρηµένη σύµφωνα µε EN 50 260
η στάθµη ακουστικής πίεσης αυτού του εργαλείου
ανέρχεται σε < 70 dB(A) και ο κραδασµς σε < 2,5 m/s2
(µεθοδος χειρς/βραχίονα).
DECLARAØIE DE CONFORMITATE CE Declaråm pe proprie
råspundere cå acest product este conform cu urmåtoarele
standarde sau documente standardizate: EN 60 335, EN 55 014,
EN 50 260, în conformitate cu regulile 73/23/EEC, 89/336/EEC,
98/37/EEC. ZGOMOT/VIBRAØII Måsurat în conformitate cu
EN 50 260 nivelul de presiune a sunetului generat de acest
instrument este de < 70 dB(A) iar nivelul vibraøiilor < 2,5 m/s2
(metoda mînå - braø).
CE ДЕKЛАPAЦИЯ ЗA CБOTВETCTBИE Декларираме на
изцяло наша отговорност, че това изделие е съобразено със
следните стандарти или стандартизирани документи:
EN 60 335, EN 55 014, EN 50 260, в съответствие с
нормативната уредба на 73/23/EEC, 89/336/EEC, 98/37/EEC.
ШУМ/ВИБPAЦИИ Измерено в съответствие с EN 50 260
нивото на звуково налягане на този инструмент е < 70 dB(A) а
вибрациите са < 2,5 m/s2(метод ръка-рамо).
CE PREHLÁSENIE O ZHODE Vÿhradne na na√u vlastnú
zodpovednos† prehlasujeme, Ωe tento vÿrobok zodpovedá
nasledujúcim normám alebo normovanÿm dokumentom:
EN 60 335, EN 55 014, EN 50 260, v súlade s predpismi
73/23/EEC, 89/336/EEC, 98/37/EEC.
HLUKU/VIBRÁCIÁCH Merané pod¬a EN 50 260 je úroveµ
akustického tlaku tohto nástroja < 70 dB(A) a vibrácie sú < 2,5 m/s2
(metóda ruka - paΩa).
GB
I
F
D
NL
S
DK
N
FIN
E
P
H
CZ
TR
PL
RU
GR
BG
SK
RO
