Skope EziCore BCE Series User manual

Page 1 of 4
EziCore TCE and BCE Series
PRN80362 Rev. 1.0 Aug. 2022
User Guide – EziCore TCE and BCE Series
Thank you for purchasing a SKOPE refrigeration product.
Safety
Always observe safety precautions when using any electrical appliance. Read these instructions carefully and retain them for future
reference.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
•Do not use this appliance for other than its intended use.
•Do not insert fingers/foreign objects into any holes.
•Only use this appliance with the voltage specified on the cabinet rating label.
•Ensure the appliance has adequate ventilation as this is essential to economical, high performance.
•Be careful not to touch moving parts and hot surfaces.
•For your own safety and that of others, ensure that all electrical work is done by authorised personnel.
•If the power supply flexible cord becomes damaged, it must be replaced by an authorised service agent or similarly qualified
person in order to avoid a hazard.
•Ensure all necessary safety precautions are observed during installation or removal of the refrigeration unit.
•The appliance is not designed to be stable while in motion. Use extreme caution when moving or transporting it.
•Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
•Do not exceed a maximum load of 20 kg per shelf.
•If the cabinet is to be scrapped, ensure the cabinet is unplugged from the power supply and cut off the mains flex close to the
back of the cabinet. Be mindful of the risk of animals or children becoming trapped in the appliance – either remove or secure
doors if necessary.
•Refrigerant must be removed by a qualified service person and the cabinet recycled/disposed of in accordance with local
regulations.
Service and Support
We know you will get years of satisfaction from your new SKOPE product when you follow a few simple preventative maintenance
guidelines. Helpful information is available on the SKOPE website.
www.skope.com/serviceandsupport
WARNING
•Ensure the appliance is disconnected from the power supply before performing any cleaning or maintenance.
•Do not cover the grilles or block the entry or exhaust of airflow by placing objects up against the refrigeration unit.
•Should manual defrosting be necessary, turn off the refrigeration system and allow the ice to melt by air circulation. Collect ice
and water during defrost to prevent a slip hazard. Do not use mechanical methods to remove ice, as this may damage the
refrigeration circuit.
•Do not use any electrical devices or appliances inside the food storage compartment.
WARNING
•Ensure the doors are held shut when moving or transporting the cabinet.
This cabinet is designed to operate within a specific climatic class
environment.
See the cabinet rating label inside the cabinet for climate class number.
The cabinet includes relevant hazard symbols that may be
associated with the cabinet. Refer to the information below for
symbol description.
Climate class Ambient
temperature
Relative humidity WARNING
The refrigeration system contains flammable R290
refrigerant. Do not tamper with it.
The refrigeration system must only be serviced by qualified
personnel.
3 25°C 60%
4 30°C 55%
5 40°C 40%
7 (tropical) 35°C 75%

Page 2 of 4
EziCore TCE and BCE Series
PRN80362 Rev. 1.0 Aug. 2022
Installation Guidelines
Ensure you consider and meet the installation guidelines.
Shelves
The wire shelves each sit on shelf clips which slide up and down the shelf support strips inside the cabinet. The shelves may be
positioned at different heights to suit various products. The retention clip which sits on the shelf clip doesn’t need to be unlocked
to move the shelf clip. Use the numbers on the shelf support strips to set the shelf clips at the same height.
To move a shelf clip To reposition a shelf
1. Unclip the metal lock by pulling it
forwards.
1. Unload and remove the shelf.
2. Move the clip:
•To go upwards, slide the clip to the
required position.
•To go downwards, push the tab up
and slide down to the required
position.
2. Move each shelf clip to the required
position.
3. When the clip is at the correct height,
push the metal lock in to set the clip.
3. Sit the shelves on the shelf clips, and
reload with product.
Ventilation
Ensure a minimum of
300 mm clearance
above the cabinet.
Door Opening
Allow adequate space
for the door/s to open
and close properly.
Sunlight
Do not install the
cabinet in direct
sunlight.
Uneven Surface
Do not install the
cabinet on an uneven
surface.
Surface
The installation
surface must be
capable of supporting
the loaded cabinet.
Power Supply
Do not overload the
power supply.
Climate Class
The cabinet must be
installed in an
environment within its
climate class.
The climate class is stated
on the cabinet rating label
inside the cabinet, and
specified on the back page
of this user guide.
Blocking Ventilation
Do not store boxes or
items in front or on
top of the cabinet.
Metal lock
Tab
Retention
clip

Page 3 of 4
EziCore TCE and BCE Series
PRN80362 Rev. 1.0 Aug. 2022
Automatic Start-up
After the cabinet has been installed, plug it in and check the following activity.
Lights
The cabinet lights have a manual on/off switch. Lights are all non-serviceable, and must not be tampered with. If you suspect a
light of being faulty, arrange a service call.
Loading Product
Let the fridge run for 30 minutes before loading it with product for the first time. When loading the shelves with product :
Electronic Controller
The electronic controller regulates the cabinet’s temperature, signals alarms and captures operational information. The temperature is
set at the factory to stay between 1.5°C and 3.5°C.
Messages and Alarms
Item Activity
Electronic
controller
An electronic controller runs the fridge and is visible in a cutout below the sign. The display panel on the electronic controller
shows the cabinet’s internal temperature.
Lighting The lights that illuminate the sign and cabinet interior will come on a few seconds after the cabinet is turned on. If the lights
do not come on, check the light switches on the front panel of the sign and switch them on.
Refrigeration
system
The refrigeration system will start a few seconds after the fridge is turned on. To verify, listen for the compressor and check
that the refrigeration system light is lit on the electronic controller.
Note: If the cabinet is powered on and off repeatedly, the compressor may enter protection mode and stay off for 5 minutes.
Display Description
The cabinet’s internal temperature. The temperature is what the sensor inside the fridge detects, and not necessarily the
product temperature. However, they may be very close depending on how the controller is set to sense temperature.
Note: The display does not have a decimal point.
Compressor indicator. On when the compressor starts. Off when the compressor stops.
Defrost indicator. On when the defrost is activated. Off when the defrost is over.
Temperature sensor fault. This indicates a fault with the temperature sensor. Arrange a service call.
Shelf Loading
Do not overload the
shelves.
Shelf Flexing
Remove product if
the shelf is flexing.
Shelf Overhang
Do not let product
overhang the shelves.
Front
Top
Back
MAX
20kg
per shelf
Internal Airflow
Leave adequate space
around each item to
ensure even cooling,
and efficient operation.
Cabinet Floor
Do not load product
on the cabinet floor.
Use the shelves.
Controller faceplate

Page 4 of 4
EziCore TCE and BCE Series
PRN80362 Rev. 1.0 Aug. 2022
Cleaning
Ensure the cabinet is unplugged from the power supply before cleaning.
Wipe the inside and outside of the cabinet with a damp cloth, taking care to keep moisture away from electrical parts.
The condenser coil must be kept clean. SKOPE strongly urges cleaning the condenser coil every month.
Do NOT use hard or sharp tools to clean the coil as these may cause damage.
TCE cabinets BCE cabinets
Troubleshooting
Clean the condenser coil Clean the condenser coil
1. Unplug the fridge from the power supply. 1. Unplug the fridge from the power supply.
2. Unplug the lit sign panels, and
remove the front panel from the
top of the cabinet.
2. Remove the kick panel from the
front of the cabinet.
3. Brush the condenser coil with a
soft brush to remove any dust
and fluff.
3. Brush the condenser coil with a
soft brush to remove any dust
and fluff.
4. Refit the sign assembly and
reconnect to the power supply.
Important
When refitting, ensure the tabs on the
back of the sign are located in the
notches on top of the cabinet, and
that the sign is pushed fully in and
secure.
4. Refit the kick panel, and
reconnect to the power supply.
Problem Possible Cause Suggestions
•Cabinet not operating. •Loss of power supply. •Check the mains power supply.
•Controller alarm. •See “Messages and Alarms” above.
•No controller display. •Loss of power supply. •Check the mains power supply.
•Lights not on. •Lights switched off. •Switch light/s on (see page 2 above).
•Failed light. •Arrange a service call.
•Power consumption is higher than
expected.
•Refrigeration cartridge
operating too hot.
•Clean the condenser (see above).
•Ensure the cabinet is in a cool spot.
•Ensure the cabinet has good ventilation around the
refrigeration cartridge.
•Cabinet doors are opened
excessively.
•Ensure the doors are closed more often.
•Product is too warm. •Restricted airflow to cabinet. •Ensure product is not blocking the airflow slots.
•Ensure there is space around individual product
pieces.
•Warm cabinet temperature.
•Compressor operating for long
periods (more than 1 hour).
•Blocked condenser. •Clean the condenser (see above).
•Poor ventilation around
refrigeration cartridge.
•Ensure the cabinet has good ventilation around the
refrigeration cartridge.
Condenser coil Condenser coil
