Skope TME ActiveCore User manual

TME/SKT ActiveCore
SKOPE Top Mount Vertical Fridge
Service Manual MAN11097 Rev. 4.4 Nov. 2023

TME/SKT ActiveCore
SKOPE Top Mount Vertical Fridge
Service Manual
MAN11097
Rev. 4.4 Nov. 2023
© 2015 SKOPE Industries Limited. All rights reserved.
SKOPE Industries Limited reserves the right to alter specifications without notice.
is a registered trademark of SKOPE Industries Limited.
SKOPE INDUSTRIES LIMITED
Head Office
PO Box 1091, Christchurch
New Zealand
A.B.N. 73 374 418 306
AU: 1800 121 535
NZ: 0800 947 5673
E-mail: [email protected]
Website: www.skope.com
Trademark Infringement
The SKOPE trademark on this product is infringed if the owner, for the time being, does
any of the following:
• Applies the trade mark to the product after its state, condition, get-up or packaging
has been altered in any manner.
• Alters, removes (including part removal) or obliterates (including part obliteration) the
trade mark on the product.
• Applies any other trade mark to the product.
• Adds to the product any written material that is likely to damage the reputation of the
trade mark.
Notice of the above contractual obligations passes to:
• Successors or assignees of the buyer.
• Future owners of the product.

SKOPE TME/SKT ActiveCore
Service Manual iii
Contents
1 Specifications
Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Installation
Positioning the Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Climate Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Fridge Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Fitting Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Removing Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Shelf Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Repositioning Shelves. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Top Shelf Light and Ticket Strip Adjustment . . . . . . . . . . . . . . . . . . . . .9
3 Electronic Controller
Electronic Controller Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Running the Fridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Compressor and Fans. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Temperature Probes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Door Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Defrost Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Messages and Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Controller Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
No-downward Tendency Protection . . . . . . . . . . . . . . . . . . . . . . . . . .14
High Pressure Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Cold Climate Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Hardware Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Hardware Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Temperature Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Temperature Probe Readings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Wiring Termination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Programming the Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . .15
Normal and Energy Saving Modes . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Temperature Setpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Parameter History. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
4 Replacement Procedures
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
LED Tube Side Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Modular Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Sign Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Alignment Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Height Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Replacing the Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Removing and Refitting the Door . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Adjusting Door Tension. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Replacing the Torsion Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Reversing the Hinges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

SKOPE TME/SKT ActiveCore
Service Manual
iv
Refrigeration Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Refrigeration Unit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
ActiveCore Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Compressor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Servicing and Diagnosis Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Removing the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Replacing the Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Unit Electrics Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Unit Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Evaporator Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Compressor Electrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Pressure Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Electronic Controller Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Door Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
NTC Probe Resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Evaporator Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
5 Maintenance
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Condenser Coil and Optional Filter. . . . . . . . . . . . . . . . . . . . . . . . . . .44
6 Wiring
Model: TME650 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Model: TME1000 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Model: SKT650 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Model: SKT1000 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Model: TME1500 Series and SKT1500 Series . . . . . . . . . . . . . . . . . .49
7 Spare Parts
Cabinet Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
TME650 Series, SKT650 Series – Cabinet Assembly . . . . . . . . . . . .50
TME1000 Series, SKT1000 Series – Cabinet Assembly . . . . . . . . . .52
TME1500 Series, SKT1500 Series – Cabinet Assembly . . . . . . . . . .54
Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Glass Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Solid Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Modular Light Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Side Light Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Lit Sign Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Unit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
UTHCCI-0002 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
UTHCCI-0004 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
UTSCCR-0001 (Remote) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Unit Electrics Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
8 Troubleshooting
Controller Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Cabinet and Refrigeration Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

5
SKOPE TME/SKT ActiveCore
Specifications
Service Manual
1 Specifications
Models
This service manual is applicable to the SKOPE TME and SKT ActiveCore top mount fridges
listed in the table below. Refer to the relevant product specification sheet (available on the
SKOPE website: www.skope.com) for specifications.
Table 1: Specifications
Series Model Type Series Model Type
TME650
ActiveCore
TME650-A SM65GV SKT650T
ActiveCore
Tropical
SKT650T-A MT65DY
TME650-AC SM65BV SKT650T-AC MT65TY
TME1000
ActiveCore
TME1000-A SM10GV SKT650T-ACX MT65TX
TME1000-AC SM10BV SKT1000T
ActiveCore
Tropical
SKT1000T-A MT10DY
TME1500
ActiveCore
TME1500-A MT15GV SKT1000T-AC MT10TY
TME1500-AC MT15BV SKT1000T-ACX MT10TX
SKT650
ActiveCore
SKT650-A MT65GY SKT1500T
ActiveCore
Tropical
SKT1500T-A MT15DY
SKT650-AC MT65BY SKT1500T-AC MT15TY
SKT650-ACX MT65BX SKT1500T-ACX MT15TX
SKT1000
ActiveCore
SKT1000-A MT10GY SKT600S
ActiveCore
Solid Door
SKT650S-A
MT65SZ
SKT1000-AC MT10BY MT65SY
SKT1000-ACX MT10BX SKT1000S
ActiveCore
Solid Door
SKT1000S-A
MT10SZ
SKT1500
ActiveCore
SKT1500-A MT15GY MT10SY
SKT1500-AC MT15BY SKT1500S
ActiveCore
Solid Door
SKT1500S-A
MT15SZ
SKT1500-ACX MT15BX MT15SY

6Installation
Service Manual
SKOPE TME/SKT ActiveCore
2 Installation
Positioning the Cabinet
Climate Class The fridge is designed to operate within a climate class 5 environment (40°C @ 40% relative
humidity). We recommend that you put the fridge in the coolest place possible because it will
use less power and last longer.
Fridge
Location
The location of the fridge may be the single most important decision that will extend its life and
ensure economical, high performance. Allow adequate space for the door/s to open and close
properly. Self-closing doors have internal torsion bars pretensioned at the factory. Ensure the
cabinet sits on a level surface so that the door shuts and correctly seals, and that the doors
are unobstructed. Level footing also prevents the condensate tray from overflowing.
Power Cord The power cord exits from the top rear of the cabinet and is fitted with a 3-pin plug. Pull the
power cord around so that it’s not trapped before you position the cabinet.
Ventilation For efficient operation, it is essential that adequate ventilation is provided above the
refrigeration unit. Never store cardboard cartons or other items on top of the refrigeration unit.
Minimum ventilation clearances vary depending on whether the fridge is installed free-standing
or built-in. Free-standing fridges are fridges that are installed with free space around the sides
and top of the cabinet and unit. Built-in fridges are fridges that are enclosed within cabinetry
or confined spaces. Ensure the minimum clearances below are met when installing the fridge.
No clearance is required behind the fridge.
Free-standing ventilation clearance
A minimum 300 mm space is required above the refrigeration unit. Free-standing fridges may
be installed in environments up to 43°C.
Built-in ventilation clearance
A minimum 300 mm space is required above the refrigeration unit. Built-in fridges may be
installed in environments up to 40°C.
IMPORTANT
To ensure efficient and reliable operation, ensure minimum
ventilation clearances are met.
Min. 300 mm above Min. 300 mm above
Free-standing Built-in

7
SKOPE TME/SKT ActiveCore
Installation
Service Manual
Door Handles
Fitting Door
Handles
For transit purposes door handles may be packed separately inside the cabinet. If the door
handle/s are packed separately, follow the procedure below.
Removing
Door Handles
The door handles can be removed for transporting and moving the cabinet through doorways,
or for refitting.
Procedure 1: To fit a door handle
1. Remove the handle/s from inside the cabinet by carefully cutting the cable ties securing the
handle, and remove the packaging.
A metal spring clip is fitted inside the handle mounts
at each end of the handle.
2. Ensure that the spring clips point up.
3. Place BOTH handle mounts simultaneously
onto both door brackets.
4. Push the handle down onto the brackets until
the handle locks into place.
Troubleshooting
• If the handle does not lock into place, ensure the spring clips are pointing up and try again.
• If only one end of the handle locks into place, unscrew the door handle (See “To remove a door
handle” on page 8), and refit, ensuring both the handle mounts are placed onto the brackets before
pushing the handle down and locking into place.
Handle mount
Spring clip
(pointing up)
Handle
Bracket
Front of
door
Bracket
CAUTION
Ensure BOTH handle mounts are in position before pushing down.

8Installation
Service Manual
SKOPE TME/SKT ActiveCore
Shelves
The fridge is fitted with five wire shelves per door, which may be positioned at different heights
to suit various products
Shelf Clips Each wire shelf is held in place with four shelf clips, which engage in the shelf support strips
and slide up and down to the desired shelf position.
The support strips are numbered for easy location of shelf clips. View the numbers in the
bottom left hand corner of the shelf clip.
Procedure 2: To remove a door handle
1. Open the door, and peel back the door gasket from behind the handle mounts on the inside of the
door frame.
2. Unscrew the handle mounts through the holes on the inside of the door frame (top and bottom
screws only), and remove the handle.
3. Remove the bracket/s from the handle mount by
pressing the bracket in and down until it unclips
from the handle mount.
4. Fit and screw the bracket/s back onto the door.
Ensure the catches are pointing up as pictured.
5. Refit the door gasket by clipping it back into place on the inside of the door frame.
6. If the gasket is out of shape after refitting it, use a hair drier to heat and reshape it.
Bracket
Handle mount
Handle
Bracket
Catch
Catch
Procedure 3: To fit a shelf clip
1. The shelf clip twists onto the shelf support
strip. Position the shelf clip with the flat side up
against the shelf support strip and the two
prongs pointing up. Twist the top of the clip
anticlockwise onto the shelf support strip until it
locks in place. Shelf
support
strip
Prongs
Shelf clip

9
SKOPE TME/SKT ActiveCore
Installation
Service Manual
Repositioning
Shelves
When repositioning standard shelves, unload and remove the shelf, establish the desired
position and slide the shelf clip in each of the shelf support strips to the desired position (see
Procedure 4 above). Sit the shelves on the shelf clips.
When repositioning shelves fitted with shelf lights, the height is adjusted as per normal with the
shelf clips. The shelves can be repositioned as far as the shelf light cable reasonably allows
via the fixed cut out in the side channel cover (see procedure below).
Top Shelf Light
and Ticket
Strip
Adjustment
Cabinets fitted with shelf lights are supplied with additional grey coloured shelf light clips. If
required, these can be fitted in place of the existing standard top shelf light clips to lower the
top shelf light and ticket strip, providing greater visibility to the top shelf.
Follow the procedure below to fit the grey clips.
Procedure 4: To slide a shelf clip up and down
1. Pull the shelf clip tab up and slide the shelf clip
up or down as required. Once in position,
ensure the shelf clip is locked into place.
Procedure 5: To remove a shelf clip
1. Pull the shelf clip tab up and twist the top of the clip clockwise off the shelf support strip.
Shelf clip
Tab
Procedure 6: To reposition shelves fitted with lights
1. Isolate the fridge from the power supply (see “Replacement Procedures” on page 23).
2. Remove product from the shelf required to be moved, and from the shelf immediately above it.
3. Establish the desired shelf position.
4. Support the weight of the shelf and lift it up off the shelf clips. Be careful not to damage the
connected shelf light cables running through the front shelf clips.
5. Slide the shelf clip in each of the shelf support strips to the desired position (see “” on page 9). The
shelves can be repositioned as far as the shelf light cable reasonably allows.
6. After the shelves have been securely positioned, connect cabinet to the power supply and check for
correct operation.
7. Reload the shelves with product.

10 Installation
Service Manual
SKOPE TME/SKT ActiveCore
Procedure 7: To lower the top shelf light and ticket strip
1. Isolate the fridge from the power supply (see “Replacement Procedures” on page 23).
2. Unclip the shelf light assembly from the front of
the shelf.
3. Take care of the wires while handling the shelf
light.
4. Slide the ticket strip off the clips.
5. Detach the two standard clips from the light, and
replace with two grey clips.
6. Slide the ticket strip onto the grey clips.
7. Fit the shelf light assembly onto the front of the shelf.
8. Connect cabinet to the power supply and check for correct operation.
Ticket strip
Standard clip
Grey clip
Light

11
SKOPE TME/SKT ActiveCore
Electronic Controller
Service Manual
3 Electronic Controller
Electronic Controller Operations
Introduction The fridge is fitted with a CAREL S4 or a CAREL S4 Evo electronic controller, which is visible
on the front panel and is housed inside the electronic controller box assembly at the front of
the refrigeration unit.
The electronic controller controls and displays the fridge temperature, signals temperature
alarms, and switches the fridge between Normal and Energy Saving modes depending on
usage. During normal operation, when the cabinet door is being opened and closed, the fridge
is in Normal mode with the lights on. If the door is not opened for a period of time, the fridge
will automatically enter Energy Saving mode and the lights will switch off. See page 12 for
more information on operating modes.
To ensure efficient operation, the electronic controller automatically forces a defrost cycle
when required.
The electronic controller is pre-programmed. SKOPE does not recommend that settings be
changed unless it is absolutely necessary.
Faceplate Because the electronic controller plays such an important role, it’s helpful to know the parts of
the faceplate you may use.
ES
1 2
3
4
5
6 8
7

12 Electronic Controller
Service Manual
SKOPE TME/SKT ActiveCore
Running the Fridge
Operating
Modes
The electronic controller will automatically switch the fridge between Normal and Energy
Saving modes depending on usage. During Normal mode, the lights are on and product is fully
chilled. During Energy Saving mode the lights are off and the product temperature is
moderated.
Note: Normal and Energy Saving mode are both suitable for perishable product (all shelves
maintain temperature below 5°C).
If the door is not opened for 3 hours (parameter r6), the fridge will automatically enter Energy
Saving mode and the sign and interior lights will switch off. To manually switch the fridge
between Normal and Energy Saving modes, press and hold the Energy Save (up) button on
the electronic controller faceplate. If not manually bought into Normal mode (by pressing
Energy Save up button or opening door), the electronic controller will automatically bring the
fridge into Normal mode after 9 hours (parameter r7) in Energy Saving mode.
During some refrigeration system alarms, the electronic controller will shut down the lights and/
or refrigeration system. Refer to “Messages and Alarms” on page 13 for alarm information.
Compressor
and Fans
The compressor and condenser fan will start approximately one minute after the fridge is
turned on. During Normal mode, the compressor and condenser fan will turn off when the
control probe temperature reading reaches 2°C (parameter St), and on again when it reaches
4°C (parameter St + rd). During Energy Saving mode, the compressor and condenser fan will
turn off when the control probe temperature reading reaches 3°C (parameter St + r4), and on
again when it reaches 5°C (parameter St + r4 + r5).
Table 2: Controller faceplate
No. Item Description
1
Digital display of cabinet temperature or messages.
The temperature is what the sensor inside the fridge detects, and not necessarily
the product temperature. However, they may be very close depending on how the
controller is set to sense temperature.
2
Energy Save (up): Press and hold for 3 seconds to switch the fridge between
‘Energy Save’ and ‘Normal’ mode.
Press to display mode that the fridge will switch to. ‘ECO’ = Energy Saving and
‘nor’ = Normal.
3Set (mute): Press to mute the alarm. Press and hold to access parameters.
4Light (down): Press and hold to switch the cabinet lights on and off.
5Defrost: ON when the defrost is activated. Flashes when the activation of the
defrost is temporarily delayed due to procedures in progress.
6Compressor: ON when the compressor and condenser fan starts. Flashes when
activation of the compressor is temporarily delayed.
7Fan: ON when the internal cabinet fans are activated. Flashes when activation of
the fans is temporarily delayed.
8Alarm: ON when alarm is signalled.
ES

13
SKOPE TME/SKT ActiveCore
Electronic Controller
Service Manual
The evaporator fan starts approximately 3 seconds (parameter F0) after the compressor and
condenser fan. To verify, check that the FAN light is lit on the electronic controller.
Temperature
Probes
Two temperature probes feed data to the electronic controller: the control probe and the
evaporator probe. The control probe monitors and controls the fridge temperature, provides
the fridge temperature for the electronic controller to display, and notifies the electronic
controller of any erratic or abnormal temperatures that could identify an issue within the
refrigeration system. The evaporator probe controls the refrigeration system defrost initiation
and termination.
Door Switch The fridge is fitted with a door switch below each door. A small magnet in the door frame
activates the switch. The door switch tells the electronic controller to turn off the evaporator fan
motor (when door opened) and compressor (if door left open for 2 minutes [parameter A10])
during normal run operation, initiate Energy Saving mode if the door is not opened for 3 hours
(parameter r6), and to reactivate Normal mode if the door is opened during Energy Saving
mode.
Defrost Cycle The defrost cycle will begin after 2 hours (parameter dl) of cumulative compressor run time (not
real time) or during no-downward tendency protection (see over page). During the defrost
cycle the compressor stops and the evaporator fan runs continuously. The defrost cycle will
terminate when the evaporator probe reaches 4.5°C (parameter dt), or after the defrost cycle
has been running for 90 minutes (parameter dP).
Lighting Depending on the model, the cabinet may be fitted with an LED lit sign, LED interior sidelights
and/or LED module shelf and side lights.
The electronic controller will automatically switch the lights on when the fridge enters Normal
mode, and off when the fridge enters Energy Saving mode. Press the Light button on the
electronic controller faceplate to manually switch the lights on and off.
Messages and Alarms
Controller
Display
The following table explains messages and alarms that the electronic controller displays.
Alarms signal unexpected operational changes in the fridge and can be muted by pressing the
alarm set (mute) button on the electronic controller faceplate (see page 11).
Refer to “Controller Alarms” on page 70 for alarm diagnostics and actions.
Table 3: Messages
Display Description
The fridge is in Normal mode and the electronic controller displays the fridge
temperature.
Message: The fridge is in Energy Saving mode. When in Energy Saving mode the
temperature inside the fridge is moderated and the cabinet lights turn off. The lights can
be switched on and off by pressing the light button on the controller faceplate, and the
fridge can be switched into Normal mode by pressing the Energy Saving button on the
electronic controller faceplate.
Alarm: The front door has remained open for over two minutes. An alarm sounds, and the
compressor and evaporator fan turn off.
The fridge is in Cold Climate Protection mode. The fridge enters cold climate protection
mode if the room ambient temperature gets too cold. The lights remain on and cannot be
switched off.

14 Electronic Controller
Service Manual
SKOPE TME/SKT ActiveCore
No-downward
Tendency
Protection
The electronic controller initiates No-downward Tendency Protection (NDTP) when the
compressor has been running for 200 minutes (parameter d12) and the control probe
temperature has not decreased. This will force a standard defrost cycle (see page 13). If the
electronic controller is required to force consecutive defrost cycles due to NDTP, the
refrigeration system error alarm will start (E3) and the fridge will shut down indicating a fault
within the refrigeration system.
High Pressure
Switch
The refrigeration unit is fitted with a high pressure switch which protects the refrigeration unit
from damage due to over-pressure (high temperature) conditions. When activated, the high
pressure switch cuts power to the electronic controller, the controller display goes blank and
the cabinet lights turn off. Refer to page 41 for service information.
Cold Climate
Protection
The fridge will enter cold climate protection (CCP) mode if the ambient temperature becomes
too cold. This happens if the control probe (at the evaporator air out) detects the interior
temperature below 0°C (parameter St - CCt) for more than 30 minutes (parameter CCd). The
lights will stay on and cannot be switched off while the fridge is in CCP mode. The fridge will
return to its previous mode (Normal or Energy Saving mode) once the control probe reading
raises to parameter St temperature.
Table 4: Alarms
Display Description
Refrigeration system error. An alarm sounds. The controller turns the fridge off to avoid
damage. Investigate fault with refrigeration system.
Control probe fault. An alarm sounds.
Evaporator probe fault. An alarm sounds.
Door switch fault. An alarm sounds.
Low temperature alarm. An alarm sounds. The temperature inside the fridge is too cold
and an alarm sounds. The controller will automatically reset the alarm once the
temperature inside the fridge raises.
High temperature alarm. An alarm sounds. The temperature inside the fridge is too warm
and an alarm sounds. The controller will automatically reset the alarm once the
temperature inside the fridge drops.
Low voltage alarm. An alarm sounds. The mains voltage is low. An alarm sounds and the
controller switches off the compressor. The controller will automatically reset the alarm
once the mains voltage raises.
High voltage alarm. An alarm sounds. The mains voltage is high. An alarm sounds and
the controller switches off the compressor. The controller will automatically reset the
alarm once the mains voltage drops.
Electronic controller fault.

15
SKOPE TME/SKT ActiveCore
Electronic Controller
Service Manual
Hardware Setup
Hardware
Inputs
The controller has three hardware inputs as detailed in the table below. All use pin 9 as
common.
Temperature
Settings
The standard temperature settings for this fridge are set up for perishable product. All product
temperatures are continuously below 5°C in Normal and Energy Saving mode. The Normal
mode temperature can be altered by changing the setpoint (parameter St), and the Energy
Saving mode temperature altered by changing the Energy Saving mode setpoint delta
(parameter r4).
Temperature
Probe
Readings
Control probe
If parameter /4 is set to 1, the control probe temperature reading is displayed on the controller
faceplate during normal operation. If parameter /4 is not set to 1, it can be changed to 1 to view
the control probe temperature reading.
Evaporator probe
To view the evaporator probe temperature reading, press and hold the Energy Save (up) and
Set (mute) buttons. The temperature reading will display on the controller faceplate.
Wiring
Termination
Refer to the diagram below for controller termination details.
Programming the Electronic Controller
The electronic controller parameter configuration program is set by SKOPE at the factory. A
label on the controller box indicates the parameter configuration program number (e.g. the
ActiveCore Series use program ‘081’).
The electronic controller parameters can be modified using the keypad. Frequent parameters
can be access and changed without entering a password (e.g. change normal and energy save
Table 5: Electronic controller hardware inputs
Pins (on rear of controller) Hardware description
9-8 Control probe
9-10 Evaporator probe
9-11 Door switch
Door switch (11)
Evaporator probe (10)
Common (9)
Control probe (8)
Supply (6, 7)
Compressor/fans (2, 4, 5)
Lights (1)

16 Electronic Controller
Service Manual
SKOPE TME/SKT ActiveCore
times, temperature setpoint). Locked parameters are protected by a password to prevent
accidental or unauthorised modifications.
Normal and
Energy Saving
Modes
To change the default times for automatic switching between Normal mode and Energy Saving
mode, follow the procedure below.
Temperature
Setpoint
The fridge temperature setpoint is factory set at 2.5°C for storage of perishable products (all
shelves maintain temperatures below 5°C). The cabinet setpoint can be adjusted between 1°C
and 15°C for other specialist applications if required (see below).
SKOPE do not recommend that the setpoint be changed unless it is absolutely necessary, and
then only by small increments at a time.
Procedure 8: To change the time between Normal and Energy Saving modes
1. Press and hold the set button for 3 seconds until PS is shown on the
display, indicating entry into the controller settings menu.
2. Press the down button to scroll the menu until r6 is shown on the display.
The r6 value is the time (in hours) without the door being opened. When this
time is reached (during store closing hours or quiet periods) the electronic
controller will switch the fridge from ‘Normal’ mode to ‘Energy Saving’ mode.
The r6 value must be ≥1 hour.
IMPORTANT
Do not set r6 to 0.
3. Press the set button. The current r6 value (in hours) is shown on the display.
4. Press the up or down button to increase or decease the value (in hourly increments).
5. Press the set button to temporarily save the new r6 value.
6. Press the down button to scroll the menu until r7 is shown on the display.
The r7 value is the maximum time (in hours) that the fridge will stay in ‘Energy
Saving’ mode. When this time is reached the electronic controller will switch
the fridge from ‘Energy Saving’ mode to ‘Normal’ mode.
7. Press the set button. The current r7 value (in hours) is shown on the display.
8. Press the up or down button to increase or decease the value (in hourly increments).
9. Press the set button to temporarily save the new r7 value.
10. Press and hold the set button for 3 seconds to permanently save the new values and exit the
controller settings menu.
Procedure 9: To view and adjust the temperature setpoint
1. Press and hold the set button for 3 seconds until PS is shown on the
display, indicating entry into the controller settings menu.
2. Press the up or down button to scroll the menu until St is shown on the
display.
3. Press the set button. The current setpoint value is shown on the display.
4. Press the up or down button to increase or decease the setpoint value to the required temperature.
5. Press the set button to temporarily save the setpoint value.
6. Press and hold the set button for 3 seconds to permanently save the setpoint value and exit the
controller settings menu.

17
SKOPE TME/SKT ActiveCore
Electronic Controller
Service Manual
Parameters Follow the steps below to access the locked parameters.
Parameter
History
To see if the parameters have changed from the factory settings, check the H5 parameter. If it
is a positive value the parameters are still at factory settings. If H5 is a negative value, the
parameters have been changed and are not at factory settings.
Procedure 10: To access the locked parameters
1. Press and hold the Set (mute) button for 5 seconds until the display shows ‘PS’.
2. Press the Set (mute) button to access the password parameter, ‘0’ is displayed.
3. Use the Energy Save (up) and Light (down) buttons to display the password ‘22’ (default
password).
4. Press the Set (mute) button to confirm the password. The display shows ‘PS’.
5. Use the Energy Save (up) and Light (down) buttons to scroll the parameter codes and locate the
required parameter.
Parameter categories can be identified by the initial symbol or letter of the code, and the icon
displayed on the electronic controller faceplate:
6. Press the Set (mute) button to display the value associated with the parameter code.
7. Use the Energy Save (up) and Light (down) buttons to increase or decrease the value of the
parameter.
8. Press the Set (mute) button to temporarily save the new value. The display shows the parameter
code.
IMPORTANT
If no buttons are pressed for 60 seconds or the power is disconnected before the
temporarily saved values are permanently saved, the temporarily saved values
will be cancelled and the previous setting will be restored.
9. If necessary, repeat steps 5 to 7 to change other parameters as required.
10. Press and hold the Set (mute) button for 3 seconds to permanently save the parameters and exit
the parameter menu.
Table 6: Parameter categories
Category Initial Icon Category Initial Icon
Probe parameters / – Defrost parameters d
Control parameters r – Alarm parameters A
Compressor parameters c Fan parameters F

18 Electronic Controller
Service Manual
SKOPE TME/SKT ActiveCore
Parameter list – Program 081: S4 ActiveCore Series
081 - SET0 - ActiveCore Top/Bottom Mount Revision: 1.1
This sheet is only for use in SKOPE product(s) ActiveCore Top & Bottom Mount
Controller Type SKOPE S4
Controller Model & Revision PZSKC0H001K (Rev 1.211)
SKOPE Part Number
ELZ11042P-081
Setting
Unit
Access
Description of Parameter
Level
Min
Max
Probe Parameters
PS 22 -F
0
200
Password
/2 4 -C
1
15
Probe measurement stability
/4 1
-
C
1
3
Select probe displayed
/5 0 -C
0
1
Select °C/°F (0 = °C, 1 = °F)
/6 0 -C
0
1
Disable decimal point
/C1 0.0 °C/°F C -12.7°C 12.7°C
Probe 1 off set
/C2 0.0 °C/°F C -12.7°C 12.7°C
Probe 2 off set
Control Parameters
St 2.0 °C/°F F r1 r2
Set point
rd 2.0 °C/°F C 0.0°C 19°C
DAY differential
r1 1.0 °C/°F C -50.0°C r2
Minimum set point value
r2 15.0 °C/°F C r1 150°C
Maximum set point value
r4 1.0 °C/°F C 1°C 50°C
Night Mode set point delta
r5 2.0 °C/°F C 0°C 19.0°C
Night differential
r6 3 hrs F 0 90
Automatic Day to Night Mode: Time Period with Door Closed
r7 9 hrs F 1 90
Automatic Night to Day Mode: Time Period in Night mode
r8 10 sec C 0 90
Time allowed for door closure after entering Night mode via keypad
CCt 2.0 °C/°F H 0.1°C 20.0°C
CCP Mode: Temperature Delta
CCd 30 min H 0 199
CCP Mode: delay
Compressor Parameters
c0 1 min C 0 200 Compressor start delay on power-up
c1 0 min C 0 100 Minimum time between consecutive compressor starts
c2 5 min C 0 100 Minimum compressor off time
c3 5 min C 0 100 Minimum compressor on time
c4 7 min C 0 100 Compressor on time with duty setting
Defrost Parameters
d0 1 - C 0 2 Type of defrost
dI 2 hrs C 0 199 Compressor Runtime between Defrosts
dt 4.5 °C/°F C -50.0°C 127°C Defrost Termination Temperature
dP 90 min C 1 199 Maximum defrost duration
d4 1 - C 0 1 Defrost when switching the instrument on (0:no 1:yes)
d5 0 min C 0 199 Defrost delay on power-up (when d4=1)
d6 1 - C 0 1 Freeze temperature display during defrost
dd 0 min C 0 15 Dripping time
d8 0 hrs C 0 15 Bypass high and low temperature alarms (AH,AL) after defrost
d9 0 - C 0 1 Defrost priority over compressor protectors
d/ - °C/°F C - - Defrost probe reading
d10 -10.0 °C/°F C -50.0°C 127°C Start defrost condition: evaporator temperature threshold
d11 127 °C/°F H -50.0°C 127°C Enabling defrost condition: Control probe threshold
d12 200 min C A10 200 No Downward Tendency Defrost - Start Delay
d20 20 min H 0 200 Sample time of Tendency evaluation (minutes)
d21 1 - H 1 5 Number of allowed defrost before RSF alarm
d22 0.1 °C/°F H 1.0°C 5.0°C Temperature gap of Tendency evaluation (°C/°F)
Alarm Parameters
A0 2.0 °C/°F C -20°C 20°C Temperature Alarm Differential
AL 4.0 °C/°F C
-50°C
150°C
Low Temperature Alarm Setpoint. (Absolute if A0
≤0, relative A0>0)
AH 8.0 °C/°F C -50°C 150°C High Temperature Alarm Setpoint. (Absolute if A0≤0, relative A0>0)
Ad 180 min C 0 199 Temperature Alarm Delay
A10 2 min C 0 10 Open Door Alarm Delay
Fan Parameters
F0 3 sec C 1 100 Start delay when FAN ON is required by the Regulation
Fd0 100 min C 1 100 Fan DAY Duty Cycle : ON time
FdF 1 min C 1 100 Fan DAY Duty Cycle : OFF time
Fn0 2 min C 1 100 Fan NIGHT Duty Cycle : ON time
FnF 2 min C 1 100 Fan NIGHT Duty Cycle : OFF time
Configuration Parameters
H0 1 - C 0 207 Supervisor Serial address
H4 0 - C 0 1 Disable buzzer
H5 81 - C 0 199 ID code (read-only)
Warning:
1. Only make program modifications with reference to relevant Operating Manual.
2. This parameter sheet is exclusively for SKOPE refrigeration systems with its dedicated Carel controller.
3. Any alteration from this program may adversely affect the SKOPE Refrigeration System operation.
4. Specification may change without notice. Please check with Skope Customer Service for latest version.
15 April 2016
Electronic Controller Parameter Sheet
Parameter
Range
Last Revised on
081
Full List
SET0
CPS1016-081-SET0

19
SKOPE TME/SKT ActiveCore
Electronic Controller
Service Manual
Parameter list – Program 101: ActiveCore Series S4 EVO (continued over page)
Revision: 2.0
Application
ActiveCore Top & Bottom Mount
Controller Type
SKOPE S4 EVO
Controller Model & Revision
PZSKC0H002K (Rev 1.414)
SKOPE Part Number
ELZ11478-101
Setting Unit
SET0 Min Max
Probe Parameters
PS 22 F0200
Password (Read Only)
/2 4 C115
Measurement stability (Applies to all probes)
/4 1 C15
Select probe displayed
/5 0 C01
Select °C/°F ( 0=°C ; 1=°F )
/6 0 C01
Disable decimal point
/8 0.0 °C C -99.00 99.0 Display Offset (Only if /E > 0)
/9 0.0 °C C -40.0 /A Minimum Display value (Only if /E > 0)
/E 1 C050
Display Dampening Coefficient
/C1 0.0 °C C -50.0 50.0 Probe 1 Calibration Offset
/C2 0.0 °C C -50.0 50.0 Probe 2 Calibration Offset
/C3 0.0 °C C -50.0 50.0 Probe 3 Calibration Offset
Regulation Parameters
St 2.0 °C F r1 r2 Set point
rd 2.0 °C C 0.0 19.0 DAY differential
r1 1.0 °C C -50.0 r2 Minimum set point value
r2 15.0 °C C r1 150 Maximum set point value
r3 1 C01
Enable Auto Day/Night Mode Switching
r4 1.0 °C C -50.0 50.0 Night Mode set point delta (added to St)
r5 2.0 °C C 0.0 19.0 Night differential
r6 3 hrs F 0 90 Night Mode Start Delay (time period with no door openings)
r7 9 hrs F 1 90 Night Mode Timeout (time period in night mode)
r10 0 hrs C 0 24 Light Delay On Time after entering DAY mode
Cold Climate Protection Parameters
CCt 2.0 °C C 0.1 20.0 Cold Climate Protection Temperature Delta
CCd 30 mins C 0 199 Cold Climate Protection Delay
Pull Down Mode Parameters
Pt 127 °C C 0 127 Pull-down Mode - Activation Temperature
Pd 250 hrs C 0 250 Pull-down Mode - Maximum Duration
Compressor Parameters
c0 1 mins C 0 200 Comp. and Fan start delay at power-up.
c1 0 mins C 0 100 Minimum time between consecutive compressor starts
c2 5 mins C 0 100 Minimum compressor off time
c3 5 mins C 0 100 Minimum compressor on time
c4 7 mins C 0 100 Compressor on time with duty setting
c5 1 C01
Enable mains voltage protection (0 = disabled, 1 = enabled)
Defrost Parameters
d0 0 C01
Type of defrost ( 0 = Electric, 1 = Hot Gas)
dI 2 hrs C 0 199 Defrost interval time (Time between defrosts)
d2 1 C01
Run defrost interval timer only when compressor running
dt 4.5 °C C -50.0 127 Defrost Termination temperature
dP 90 mins C 1 199 Maximum defrost duration
d4 1 C01
Defrost request at power-on: (0 = no, 1 = yes)
d5 0 mins C 0 199 Defrost delay on power-up (when d4=1)
d6 1 C01
Display during defrost (0 = "dEF", 1 = Temperature at start of defrost)
dd 0 mins C 0 15 Dripping time (compressor and fans stopped after defrost)
d8 0 mins C 0 199 Bypass high temperature alarm after defrost or door opening
d9 0 C01
Defrost priority over compressor protectors
d/1 - °C F - - Probe reading on 2nd Input (read only)
Parameter
101
CPS1017-101-SET0
Last revised on
7-Dec-2017
Full List
SET0
Access
Level
Range
Description
Electronic Controller Parameter Sheet
Page 1 of 2

20 Electronic Controller
Service Manual
SKOPE TME/SKT ActiveCore
Parameter list – Program 101: ActiveCore Series S4 EVO (continued from previous
page)
Revision: 2.0
Application
ActiveCore Top & Bottom Mount
Controller Type
SKOPE S4 EVO
Controller Model & Revision
PZSKC0H002K (Rev 1.414)
SKOPE Part Number
ELZ11478-101
Setting Unit
SET0 Min Max
Parameter
101
CPS1017-101-SET0
Last revised on
7-Dec-2017
Full List
SET0
Access
Level
Range
Description
Electronic Controller Parameter Sheet
d/2 - °C F - - Probe reading on 3rd Input (read only)
d10 -50.0 °C C -50.0 127 On demand defrost Start Temperature
d11 0 mins C 0 60 On demand defrost: start delay
d12 127 °C C -50.0 127 Enabling defrost condition: Control probe threshold
d13 1 C01
Evaporator Fans During Defrost (0 = Off 1 = ON)
d19 200 mins C 0 200 No Downward Tendency Defrost - Start Delay (0 = function disabled)
d20 20 mins C 1 < d19 No Downward Tendency Evaluation (Sample Time)
d21 1 C05
Number of NDT defrosts before R.S.F. "Err" alarm (0 = function disabled)
d22 0.1 °C C 0.0 5.0 No Downward Tendency Evaluation (Temperature Delta)
Alarm & Input Configuration Parameters
A0 2.0 °C C -20.0 20.0 Temperature Alarm Differential
AL 4.0 °C C -50.0 150 Low temperature alarm setpoint. (Relative if A0>0, Absolute (A0≤0)
AH 8.0 °C C -50.0 150 High temperature alarm setpoint. (Relative if A0>0, Absolute (A0≤0)
Ad 180 mins C 0 199 Temperature alarm delay ( 0 = AL and AH alarms disabled)
A10 2 mins C 0 10 Door Open Alarm delay (0 = door open alarm disabled)
A11 1 C05
2nd Input Configuration
A12 3 C016
Number of cA alarm events to trigger manual reset 'CA' alarm
A13 24 hrs C 0 240 cA alarm counter reset delay
A14 60 mins C 0 240 cA alarm reset delay
A15 1 C01
Lights switched OFF when CHt, cA or CA alarm occurs
A18 1 C01
Allow power cycle to reset CA alarm
A20 4 mins C A10 60 Faulty door/curtain switch E2 alarm delay
Ac 70.0 °C C -50.0 250 High condenser temperature alarm set point
AE 5.0 °C C 0.1 20.0 High condenser temperature alarm differential
Acd 0 mins C 0 250 High condenser temperature alarm delay
Acr 1 C02
High condenser temperature alarm reset method
A21 2 C05
3rd Input Configuration
Evaporator Fan Parameters
F0 3 secs C 1 100 Loads Activation Delay
Fd0 20 mins C 1 100 Fan DAY Duty Cycle : ON time
FdF 0 mins C 0 100 Fan DAY Duty Cycle : OFF time
Fn0 2 mins C 1 100 Fan NIGHT Duty Cycle : ON time
FnF 2 mins C 0 100 Fan NIGHT Duty Cycle : OFF time
Other Parameters
H0 1 C0207
Supervisor Serial address
H01 1 C01
Baud Rate (0 = 9600, 1 = 19200)
H02 2 C02
Stop Bits
H03 0 C02
Parity ( 0 = None, 1 = Odd, 2 = Even)
H2 1 C03
Enable Keypad
H4 0 C01
Disable buzzer (0 = Buzzer Enabled, 1 = Buzzer Disabled)
H5 101 F0199
ID code (read-only)
Warning
1. Only make program modifications with reference to relevant Operating Manual.
2. This programming sheet is exclusively for SKOPE refrigeration systems with its dedicated Carel controller.
3. Any alteration from this program may adversely affect the SKOPE Refrigeration System operation.
4. Specification may change without notice. Please check with SKOPE Customer Service for latest revision.
Page 2 of 2
