Skope B Series User manual

B Series (R290)
SKOPE Gen3 Vertical Fridge
Service Manual MAN80155 Rev. 1.9 Nov. 2023

B Series (R290)
SKOPE Gen3: Glass Door Vertical Fridge
Service Manual
MAN80155
Rev. 1.9 Nov. 2023
© 2019 SKOPE Industries Limited. All rights reserved.
SKOPE Industries Limited reserve the right to alter specifications without notice.
is a registered trademark of SKOPE Industries Limited.
SKOPE INDUSTRIES LIMITED
Head Office
PO Box 1091, Christchurch
New Zealand
A.B.N. 73 374 418 306
AU: 1800 121 535
NZ: 0800 947 5673
E-mail: [email protected]
Website: www.skope.com
Trademark Infringement
The SKOPE trademark on this product is infringed if the owner, for the time being, does
any of the following:
• Applies the trade mark to the product after its state, condition, get-up or packaging
has been altered in any manner
• Alters, removes (including part removal) or obliterates (including part obliteration) the
trade mark on the product
• Applies any other trade mark to the product
• Adds to the product any written material that is likely to damage the reputation of the
trade mark
Notice of the above contractual obligations passes to:
• Successors or assignees of the buyer
• Future owners of the product

SKOPE B Series (R290)
Service Manual CCEP iii
Contents
1 Specifications
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
B600N-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
B600N-3U . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
B600N-3W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
B1200N-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
B1200N-3U . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
B1200N-3W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2 Installation
Positioning the Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Climate Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cabinet Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Rear Spacers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Shelf Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Repositioning a Shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3 Electronic Controller
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Controller Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Buttons and Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Service Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
SCS Connect Field App. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
App Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Faults and Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
4 Replacement Procedures
Electrical Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Sign Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Shelf Front Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Sign Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Replacing the Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Removing and Refitting the Door . . . . . . . . . . . . . . . . . . . . . . . . .25
Adjusting Door Tension. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Replacing the Torsion Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Hinge Reversal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Refrigeration System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Before Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
On-site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Off-site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Refrigeration Cassette. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Refrigeration Cassette Assembly . . . . . . . . . . . . . . . . . . . . . . . . .32
Cassette Electrics Box Assembly . . . . . . . . . . . . . . . . . . . . . . .33
Cassette Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

SKOPE B Series (R290)
Service Manual CCEP
iv
Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Evaporator Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Compressor Electrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Cassette Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Refrigeration Cassette Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . 38
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
QC Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Electronic Controller Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Replacing the Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Door Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
PIR Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Evaporator Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Condenser Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5 Wiring
Model: B600N-3 Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Model: B1200N-3 Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6 Spare Parts
Cabinet Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
B600N-3 (Side Lighting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
B600N-3U (Shelf Lighting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
B600N-3W (Side Lighting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
B1200N-3 (Side Lighting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B1200N-3U (Shelf Lighting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
B1200N-3W (Side Lighting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Glass Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Sign Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Cassette Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
B600N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
B1200N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7 Maintenance
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Condenser Coil and Optional Air Filter . . . . . . . . . . . . . . . . . . . . . 66
8 Troubleshooting
Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

5
SKOPE B Series (R290)
Specifications
Service Manual CCEP
1 Specifications
Overview
This cabinet uses hydrocarbon (HC) R290 as its refrigerant. R290 is a natural refrigerant that
has a very low environmental impact.
Special service requirements are needed, as R290 is a flammable refrigerant.
Safety hazards
The main hydrocarbon safety hazards are:
• Flammability
• Venting of hydrocarbon and compressor oil
• Asphyxiation
Service requirements
Do not interfere with the refrigeration system. All refrigeration maintenance and repairs must
be undertaken according to the SKOPE HC Service Requirements. See the “SKOPE HC
Service Requirements” below for more information, including examples of hazardous
activities.
Electrical safety precautions
Correct wiring routing is as important as using correct components for compliance with safety
and radio interference regulations. In order to maintain safety and compliance with regulations,
any wiring that is disturbed during servicing must be replaced and secured in its original
position.
Models
This service manual is applicable to the SKOPE Gen3 cabinets detailed below. The model
code is used to distinguish between different models.
Table 1: Model specifications
Model Type Description
B600N-3 B60BYN R290, side lighting, gravity matting
B600N-3U B60BXN R290, shelf front lighting, gravity matting
B600N-3W B60BWN R290, side lighting, standard wire shelves
B1200N-3 B12BYN R290, side lighting, gravity matting
B1200N-3U B12BXN R290, shelf front lighting, gravity matting
B1200N-3W B12BWN R290, side lighting, standard wire shelves

6Specifications
Service Manual CCEP
SKOPE B Series (R290)
B600N-3
Table 2: B600N-3 Cabinet
Description
R290, side lighting, gravity matting
Construction
Insulation 50 mm thick, polyurethane foam. Cyclo-iso pentane
blowing agent: C5H10/C5H12
Doors 1 × self-closing, lockable, double-glazed, double low-e,
argon-filled, toughened safety glass
Dimensions External Internal
Height 2200 mm (cabinet + sign) 1455 mm
Width 740 mm 640 mm
Depth 825 mm 605 mm
Floor area 0.61 m2
Internal volume 600 litres
Shelves
4 × adjustable height wire shelves (618 mm × 525 mm)
and 1 × fixed in place bottom tray (622 mm × 515 mm),
with gravity feed system
Product loading 5 layers of 600 ml PET bottles: 8 facings × 7 deep
280 per cabinet
Operating conditions
Operating temp. range: +1°C to +5°C
TCCC class: C
Climate class: 5
Electrical 220-240 volts a.c. 50 Hz, single phase supply. Supplied
with 10 amp 3-pin plug
Current draw: 2.0 amps (includes cassette 1.6 amps)
Sign lighting 1 × 7 W LED module strip sign light
Internal lighting 1 × 15 W LED module strip side light
Table 3: B600N-3 cassette
Description Coca-Cola R290 small global cassette
Cassette model UBHCNI-0013
Refrigerant R290/50 g
Compressor Embraco EM2X3125U
Controller AoFrio SCS Connect
Connectivity interface Bluetooth
Nominal capacity 570 watts

7
SKOPE B Series (R290)
Specifications
Service Manual CCEP
B600N-3U
Table 4: B600N-3U cabinet
Description
R290, shelf front lighting, gravity matting
Construction
Insulation 50 mm thick, polyurethane foam. Cyclo-iso pentane
blowing agent: C5H10/C5H12
Doors 1 × self-closing, lockable, double-glazed, double low-e,
argon-filled, toughened safety glass
Dimensions External Internal
Height 2200 mm (cabinet + sign) 1455 mm
Width 740 mm 640 mm
Depth 825 mm 605 mm
Floor area 0.61 m2
Internal volume 600 litres
Shelves
4 × adjustable height wire shelves (618 mm × 525 mm)
and 1 × fixed in place bottom tray (622 mm × 515 mm),
with gravity feed system
Product loading 5 layers of 600 ml PET bottles: 8 facings × 7 deep
280 per cabinet
Operating conditions
Operating temp. range: +1°C to +5°C
TCCC class: C
Climate class: 5
Electrical 220-240 volts a.c. 50 Hz, single phase supply. Supplied
with 10 amp 3-pin plug
Current draw: 2.0 amps (includes cassette 1.6 amps)
Sign lighting 1 × 7 W LED module strip sign light
Internal lighting 5 × LED shelf front lighting assemblies. Total 33 W
Table 5: B600N-3U cassette
Description Coca-Cola R290 small global cassette
Cassette model UBHCNI-0013
Refrigerant R290/50g
Compressor Embraco EM2X3125U
Controller AoFrio SCS Connect
Connectivity interface Bluetooth
Nominal capacity 570 watts

8Specifications
Service Manual CCEP
SKOPE B Series (R290)
B600N-3W
Table 6: B600N-3W cabinet
Description
R290, side lighting, standard wire shelves
Construction
Insulation 50 mm thick, polyurethane foam. Cyclo-iso pentane
blowing agent: C5H10/C5H12
Doors 1 × self-closing, lockable, double-glazed, double low-e,
argon-filled, toughened safety glass
Dimensions External Internal
Height 2200 mm (cabinet + sign) 1455 mm
Width 740 mm 640 mm
Depth 825 mm 605 mm
Floor area 0.61 m2
Internal volume 600 litres
Shelves 4 × adjustable height wire shelves (618 mm × 525 mm)
and 1 × fixed in place bottom tray (622 mm × 515 mm)
Product loading 5 layers of 600 ml PET bottles: 8 facings × 7 deep
28 per cabinet
Operating conditions
Operating temp. range: +1°C to +5°C
TCCC class: C
Climate class: 5
Electrical 220-240 volts a.c. 50 Hz, single phase supply. Supplied
with 10 amp 3-pin plug
Current draw: 2.0 amps (includes cassette 1.6 amps)
Sign lighting 1 × 7 W LED module strip sign light
Internal lighting 1 × 15 W LED module strip side light
Table 7: B600N-3W cassette
Description Coca-Cola R290 small global cassette
Cassette model UBHCNI-0013
Refrigerant R290/50 g
Compressor Embraco EM2X3125U
Controller AoFrio SCS Connect
Connectivity interface Bluetooth
Nominal capacity 570 watts

9
SKOPE B Series (R290)
Specifications
Service Manual CCEP
B1200N-3
Table 8: B1200N-3 cabinet
Description
R290, side lighting, gravity matting
Construction
Insulation 50 mm thick, polyurethane foam. Cyclo-iso pentane blowing
agent: C5H10/C5H12
Doors 2 × self-closing, lockable, double-glazed, double low-e,
argon-filled, toughened safety glass
Dimensions External Internal
Height 2200 mm (cabinet + sign) 1455 mm
Width 1280 mm 1180 mm
Depth 825 mm 565 mm
Floor area 1.06 m2
Internal volume 1050 litres
Shelves
8 × adjustable height wire shelves (575 mm × 475 mm) and
2 × fixed in place bottom shelves (582 mm × 475 mm),
with gravity feed system
Product loading 5 layers of 600 ml PET bottles: 14 facings × 6 deep
420 per cabinet
Operating conditions
Operating temp. range: +1°C to +5°C
TCCC class: C
Climate class: 5
Electrical 220-240 volts a.c. 50 Hz, single phase supply. Supplied with
10 amp 3-pin plug
Current draw: 3.2 amps (includes cassette 2.7 amps)
Sign lighting 1 × 13.5 W LED module strip sign light
Internal lighting 2 × 15 W LED module strip side light
Table 9: B1200N-3 cassette
Description Coca-Cola R290 medium global cassette
Cassette model UBHCNI-0009
Refrigerant R290/72 g
Compressor Wanbao FN90M
Controller AoFrio SCS Connect
Connectivity interface Bluetooth
Nominal capacity 740 watts

10 Specifications
Service Manual CCEP
SKOPE B Series (R290)
B1200N-3U
Table 10: B1200N-3U cabinet
Description
R290, shelf front lighting, gravity matting
Construction
Insulation 50 mm thick, polyurethane foam. Cyclo-iso pentane
blowing agent: C5H10/C5H12
Doors 2 × self-closing, lockable, double-glazed, double low-e,
argon-filled, toughened safety glass
Dimensions External Internal
Height 2200 mm (cabinet + sign) 1455 mm
Width 1280 mm 1180 mm
Depth 825 mm 565 mm
Floor area 1.06 m2
Internal volume 1050 litres
Shelves
8 × adjustable height wire shelves (575 mm × 475 mm) and
2 × fixed in place bottom shelves (582 mm × 475 mm), with
gravity feed system
Product loading 5 layers of 600 ml PET bottles: 14 facings × 6 deep
420 per cabinet
Operating conditions
Operating temp. range: +1°C to +5°C
TCCC class: C
Climate class: 5
Electrical 220-240 volts a.c. 50 Hz, single phase supply. Supplied
with 10 amp 3-pin plug
Current draw: 3.2 amps (includes cassette 2.7 amps)
Sign lighting 1 × 13.5 W LED module strip sign light
Internal lighting 10 × LED shelf front lighting assemblies. Total 60 W
Table 11: B1200N-3U cassette
Description Coca-Cola R290 medium global cassette
Cassette model UBHCNI-0009
Refrigerant R290/72 g
Compressor Wanbao FN90M
Controller AoFrio SCS Connect
Connectivity interface Bluetooth
Nominal capacity 740 watts

11
SKOPE B Series (R290)
Specifications
Service Manual CCEP
B1200N-3W
Table 12: B1200N-3W cabinet
Description
R290, side lighting, standard wire shelves
Construction
Insulation 50 mm thick, polyurethane foam. Cyclo-iso pentane
blowing agent: C5H10/C5H12
Doors 2 × self-closing, lockable, double-glazed, double low-e,
argon-filled, toughened safety glass
Dimensions External Internal
Height 2200 mm (cabinet + sign) 1455 mm
Width 1280 mm 1180 mm
Depth 825 mm 565 mm
Floor area 1.06 m2
Internal volume 1050 litres
Shelves 8 × adjustable height wire shelves (575 mm × 475 mm) and
2 × fixed in place bottom shelves (582 mm × 475 mm)
Product loading 5 layers of 600 ml PET bottles: 14 facings × 6 deep
420 per cabinet
Operating conditions
Operating temp. range: +1°C to +5°C
TCCC class: C
Climate class: 5
Electrical 220-240 volts a.c. 50 Hz, single phase supply. Supplied
with 10 amp 3-Pin plug
Current draw: 3.2 amps (includes cassette 2.7 amps)
Sign lighting 1 × 13.5 W LED module strip sign light
Internal lighting 2 × 15 W LED module strip side light
Table 13: B1200N-3W cassette
Description Coca-Cola R290 medium global cassette
Cassette model UBHCNI-0009
Refrigerant R290/72 g
Compressor Wanbao FN90M
Controller AoFrio SCS Connect
Connectivity interface Bluetooth
Nominal capacity 740 watts

12 Installation
Service Manual CCEP
SKOPE B Series (R290)
2 Installation
Positioning the Cabinet
Climate Class The cabinet has been designed to operate safely in an environment up to climatic class 5
(40.0°C @ 40% relative humidity), and is also designed to achieve TCCC C-Pass performance
within a 32.2°C @ 65% environment.
Cabinet
Location The location of the cabinet may be the single most important decision that will extend its life
and ensure economical, high performance.
Allow adequate space for the door to open and close properly. Self-closing doors have internal
torsion bars pre-tensioned at the factory, and must be unobstructed. Ensure the cabinet sits
on a level surface so that the door shuts and correctly seals. Level footing also prevents the
condensate tray from overflowing.
Ventilation Ensure there is always at least a 50 mm gap around the back, top and underside of the
cabinet. Keep the ventilation slots in the front panel clear at all times. Never store cardboard
cartons or other objects in front of the cabinet.
Rear Spacers Before operating the cabinet, ensure both rear spacers are rotated outwards and fully
tightened. This will provide the necessary air gap at the rear of the cabinet for correct
operation.
Power Cord The cabinet has a flexible power cord fitted with a 3-pin plug, which exits the rear of the cabinet
at floor level. Pull the power cord around so that it’s not trapped before you position the cabinet.
CAUTION
To prevent over-heating and conserve energy, ensure air flows
freely all around the cabinet – including front, back, top and
underside (minimum 50 mm gap).
Back of cabinet
Rear spacer
(rotated out)

13
SKOPE B Series (R290)
Installation
Service Manual CCEP
Shelves
The cabinet is fitted with wire shelves which may be positioned at different heights to suit
various products, and one or two solid bottom shelves. Each solid bottom shelf is held in place
by brackets attached to the floor of the cabinet. It is important that the bottom shelves are
always in place as they direct the interior air circulation.
Shelf front lit cabinets incorporate cabinet interior lights on the front of each shelf (see
“Lighting” on page 22).
Shelf Clips Each wire shelf is held in place with four shelf clips, which clip in the shelf support strips and
slide up and down to the required shelf position.
The support strips are numbered to help place the shelf clips. You can see the numbers in the
bottom left hand corner of the shelf clip.
Repositioning
a Shelf
IMPORTANT
For correct cabinet operation, the bottom shelf must always be in
place at the bottom of the cabinet.
Procedure 1: To fit a shelf clip
The shelf clip twists onto the shelf support strip.
1. Position the shelf clip with the flat side against
the shelf support strip and the two prongs
pointing up.
2. Twist the top of the clip anticlockwise onto the
shelf support strip until it locks in place.
Procedure 2: To slide a shelf clip up and down
1. Pull the shelf clip tab up and slide the shelf clip
up or down as required.
2. Once in position, ensure the shelf clip is locked
into place.
Procedure 3: To remove a shelf clip
1. Pull the shelf clip tab up.
2. Twist the top of the clip clockwise off the shelf support strip.
Shelf
support
strip
Prongs
Shelf clip
Shelf clip
Tab
Procedure 4: To reposition a standard shelf
1. Unload the shelf and remove it from the cabinet.
2. Slide each shelf clip to the new position in the shelf support strips.
3. Replace the shelf back in the cabinet, and sit it on the shelf clips.

14 Installation
Service Manual CCEP
SKOPE B Series (R290)
Procedure 5: To reposition a lit shelf
1. Disconnect the cabinet from the mains power supply (see page 22).
2. Remove product from the shelf required to be moved, and from the shelf immediately above it.
3. Work out the shelf’s new position, making sure
that there is enough cable in the fixed cut out in
the side channel to reach.
4. Support the weight of the shelf and lift it up off
the shelf clips.
5. Slide the shelf clip in each of the shelf support
strips to the desired position (see page 13).
6. After the shelves have been securely positioned, switch the power back on and check for correct
operation.
7. Reload the shelves with product.
Procedure 6: To remove a lit shelf
1. Disconnect the cabinet from the mains power supply (see page 22).
2. Remove the side light channel cover by squeezing it until it is released from the aluminium
housing, and then move the cover out of the way.
3. Unplug the light assembly from the main wire
loom, and remove the shelf from the cabinet.
4. Remove the shelf clips (see page 13).
5. Refit the side light channel cover, ensuring that all main wire loom sockets and cables are tucked
behind the cover.
Shelf
Light
cable
Shelf support strip
Shelf clip

15
SKOPE B Series (R290)
Electronic Controller
Service Manual CCEP
3 Electronic Controller
Overview
The cabinet is fitted with an AoFrio SCS Connect electronic controller. The controller located
behind the front kick panel.
The controller is pre-programmed. SKOPE does not recommend that settings be changed
unless it is absolutely necessary. To ensure efficient operation, the controller automatically
forces a defrost cycle when required.
Controller servicing can be performed via the controller faceplate, or the SCS Connect Field
app.
Controller Faceplate
Buttons and
Display The faceplate includes the front display panel and interface buttons.
IMPORTANT
The controller must only be adjusted by an authorised service
agent.
12 3 4 5
8 7
11
10
96
Table 14: AoFrio controller faceplate
No. Description
1Night Mode: Indicator. On during Night mode.
2
Display: Indicator. Digital display of cabinet air temperature or messages. The temperature is
what the sensor inside the cabinet detects, and not necessarily the product temperature. However,
they may be very close depending on how the controller is set to sense temperature.
3Light Switch - Night Mode (back/abort): Button. Press to switch the lights on or off. Press and
hold to switch the cabinet between Day and Night mode. Used during programming.
4Up: Button. Used for programming.
5Bluetooth: Indicator. On when ready to connect to a device. Flashing when connected to a
device.
6Defrost Cycle (next/enter): Button. Press and hold to initiate manual defrost. Used during
programming.
7Down: Button. Used for programming.
8Fault - Alarm: Indicator. On during fault or alarm. Note: Alarm message is also shown on the
display during alarm.
9Compressor: Indicator. On when the compressor is running.
10 Defrost Mode: Indicator. On during defrost cycle.
11 Fan: Indicator. ON when fans running.

16 Electronic Controller
Service Manual CCEP
SKOPE B Series (R290)
Service Mode Service mode can be accessed and used via the controller faceplate, or the SCS Connect
Field app.
Follow the steps below to access and use service mode via the controller buttons.
Note: A 9 digit pin code is required to access service mode via the controller buttons. Contact
your User Manager to receive your activation code.
Service mode includes:
Parameters
Provides access and editing of individual controller parameters.
It is not recommended that parameters are changed unless absolutely necessary. If incorrect
parameter settings are suspected, reload the complete parameter set.
Reset
Returns the controller back to factory or default settings.
Manual test
Allows inspection of input values from sensors, and check the effects of output adjustments to
peripherals, and to run preset test routines.
Statistics
Displays logged values and event counts to assist with fine tuning and diagnostics.
About
Lists the properties of the refrigeration system and the controller, including cabinet model
codes, firmware, hardware and software versions.
SCS Connect Field App
Connecting The SCS connect field app allows authorised Service Technicians wireless access to the
controller from mobile devices with Bluetooth capability. The app provides information on data
logging, alarm notification and diagnostic control.
Procedure 7: To enable and use service mode via the controller faceplate
1. Press and hold the up and down buttons simultaneously until prompted to enter the 9 digit pin
code.
2. Enter service mode pin code.
3. Use the up, down, back/abort and next/enter buttons to navigate to the desired category.
Procedure 8: To install the SCS Connect Field app
1. Download and install the SCS Connect Field app from Google Play or Apple Store
(search for “scs wellington” to find it).
2. When you first run the app, you will be requested to enter an activation code. Contact your User
Manager to receive your activation code (you must be connected to the internet at the time of
activation).
3. Your activation code is unique to you, and should NEVER be shared with anyone else, as it
determines your personal access level for the app. The same code will give you access to all SCS
apps you are authorised to use.
4. Once activation is complete, you must define a 4 digit PIN code. This can be any code unique to
you. Each time you start the app, you will be required to enter this same PIN code. This is to
prevent other people accessing the app from unlocked phones.
5. You can see which databases you are activated against from the “Settings” screen. You can be
connected to more than one database at the same time. Simply select ACTIVATE ANOTHER
DATABASE, and enter the new databases unique activation code, as in Step 2.

17
SKOPE B Series (R290)
Electronic Controller
Service Manual CCEP
App
Categories Various options are available in the app menu to provide information about the connected
controller and its cabinet.
Home screen
The home screen shows a graphic representation of the current state of the cabinet being
controlled.
Output control
Provides control of the controller input sensors and switches, and output relays.
Edit parameters
Provides access and editing of individual controller parameters.
Note: Parameter changes must be recorded on warranty/job card.
It is not recommended that parameters are changed unless absolutely necessary. If incorrect
parameter settings are suspected, reload the complete parameter set.
Note: Updated parameters are not applied until DISCONNECT has been selected from the
menu (after loading new parameter set).
Load parameter file
Allows reloading of cabinet default parameter set or changing to new parameter set.
Note: Updated parameters may not be applied until DISCONNECT has been selected from
the menu (after loading new parameter set).
Statistics
Information from the past seven days on the cabinet’s activity including temperatures, door
openings and alarms.
Procedure 9: To connect to a controller
1. Check that the Bluetooth logo on the top right of the controller faceplate is lit, indicating that the
controller is ready to connect to a device.
Note: A flashing Bluetooth logo indicates that the controller is currently connected to a device.
2. Open the SCS Connect Field app.
3. Select a controller to connect to from the list of visible controllers.
Note: This list is filtered by your activation permissions, so devices you are not authorised to connect
to will not be displayed.
4. Select “Connect” to connect to the controller.
5. Check that the Bluetooth logo on the top right of the controller faceplate is flashing, indicating that
the controller is connected.

18 Electronic Controller
Service Manual CCEP
SKOPE B Series (R290)
SCS info
Controller version and the cabinet’s asset information.
SCS setup
Add or change SCS info (see above).
Disconnect
Disconnect from currently connected controller.
Settings
Change app general settings.
Faults and Alarms
The following table explains faults and alarms that the electronic controller may log and
display.
If a fault occurs, the fault - alarm indicator is lit on the controller faceplate, but no message is
displayed. Faults do not affect product temperature, and require no action from the shop
owner.
Alarms are logged and the alarm message is displayed on the controller faceplate. Alarms may
result in abnormal product temperature.
Some faults and alarms can be cleared by the shop owner, and others can only be cleared by
a service technician.
If the cabinet is connected to the power supply and has warm product, check the SCS Connect
Field app for active fault or alarm, and investigate. If the cabinet does not have an active fault
or alarm, check the app statistics to determine if and when the controller signalled a fault or
alarm.
Refer to the tables below for faults and alarm descriptions and possible causes and actions.
Table 15: AoFrio controller faults
Description Possible root cause
Door left open.
The door has been open for several minutes.
• Door not self closing (torsion fault)
• Door switch or circuit
• Controller
Excessive door open counts
Over-voltage protection
The maximum allowable mains supply voltage has been exceeded. The
cabinet has temporarily shut down to prevent damage and will restart once
the supply voltage decreases.
Should be a one off; if continues, consider:
• line voltage/rural
• voltage setting parameter
• controller
Under-voltage protection
The mains supply voltage has dropped below the minimum allowable level.
The cabinet has temporarily shut down to prevent damage and will restart
once the supply voltage increases.
Should be a one off; if continues, consider:
• power supply overloaded / multibox
• line voltage / rural.
• voltage setting parameter
• controller
High condensing temperature protection
The system was operating at an elevated temperature and has temporarily
shut down to prevent damage. Extended operation in this condition may
result in ALARM 15, increased energy consumption and a reduction in
cabinet life. This alarm may be caused by very high ambient temperature.
NO swap cassette required.
• Condenser not clean
• Door installation / ventilation
• Condenser fan motor / blade
• Controller

19
SKOPE B Series (R290)
Electronic Controller
Service Manual CCEP
Excessive compressor cycling protection
The system has been turning on and off too frequently.
Take a spare cassette in case of refrigeration system fault.
• Condenser blocked (or bad installation or ventilation)
• Door installation or ventilation
• Cabinet or cassette gasket seals leaking
• Door not self-closing or gasket leaking
• Product hot or blocking cabinet airflow
• Overloaded from excess door openings/ambient
• Fan motor or blade
• Controller
• Compressor or gas leak = SWAP cassette
Table 15: AoFrio controller faults (continued)
Description Possible root cause
Table 16: AoFrio controller alarms
Code Description Possible root cause
dor
Door left open.
The door has been open for several minutes. Will revert to door left
open FAULT after 10 minutes (see faults table on previous page).
• Door not self closing (torsion fault)
• Door switch or circuit
• Controller
8
Estimated product temperature below allowable range
The estimated product temperature has been below the allowable
range for longer than the permissible time. Potential causes are: an
empty or partially filled cabinet, or low ambient temperature.
• Low ambient
• App settings
• Controller
9
Estimated product temperature above allowable range
The estimated product temperature has been above the allowable
range for longer than the permissible time. Potential causes are:
excessive door openings, door being left open, or warm product
loaded into cabinet.
NO swap cassette required to be taken (but fault could still
be with sealed refrigeration system).
• Condenser blocked (or bad installation or ventilation)
• Poor installation or ventilation
• Frozen blocked evaporator coil
• Cassette gasket leaking (to cabinet or lid seal)
• Door leaking air (bad gasket or door not self-closing)
• Product hot or blocking cabinet airflow
• Overloaded from excess door openings/ambient
• Fan motor or blade (condenser or evaporator)
• App settings
• Controller
• Compressor or gas leak = arrange SWAP cassette
15
Excessive condensing temperature protection
The system was operating at an excessive temperature and has shut
down to prevent permanent damage. This alarm may occur due to
very high ambient temperature.
NO swap cassette required.
• Condenser not clean
• Poor installation or ventilation
• Condenser fan motor or blade
• Controller
17
Control probe failure
A critical system sensor has failed and the cabinet can no longer
operate.
NO swap cassette required.
• Control probe or circuit
• Controller
18
Electrical over-current protection activated
The compressor was drawing too much current and has shut down to
prevent permanent damage.
Take a spare cassette in case of refrigeration system fault.
• Condenser blocked (or bad installation or ventilation)
• Poor installation or ventilation
• Cabinet or cassette gasket seals leaking
• Door not self-closing or gasket leaking
• Product hot or blocking cabinet airflow
• Overloaded from excess door openings/ambient
• Fan motor or blade (condenser or evaporator)
• Controller
• Compressor or gas leak = SWAP cassette

20 Electronic Controller
Service Manual CCEP
SKOPE B Series (R290)
19
Failed to reach set temperature
The refrigeration system has been operating continuously for a long
period without reaching the set temperature.
Take a spare cassette in case of refrigeration system fault.
• Condenser blocked (or bad installation or ventilation)
• Poor installation or ventilation
• Frozen blocked evaporator coil
• Cabinet, door or cassette seal leaking
• Product hot or blocking cabinet airflow
• Overloaded from excess door openings/ambient
• Fan motor or blade (condenser or evaporator)
• Controller
• Compressor or gas leak = SWAP cassette
20
Over-cooling product
The internal temperature is too low. The system has temporarily shut
down until the temperature has returned to normal. This can occur if
the set temperature has been raised by a large amount.
Confirm if really too cold; change parameters accordingly.
22 Evaporator fan over-current protection
The current supplied to the evaporator fan motor is too high.
NO swap cassette required.
• Faulty fan motor
• Fan blade fault (imbalance, debris, blockage)
• Controller
23 Condenser fan over-current protection
The current supplied to the condenser fan motor is too high.
NO swap cassette required
• Faulty fan motor
• Fan blade fault (imbalance, debris, blockage)
• Controller
24 Controller communication error
Controller has lost communication channels.
• App
• Controller or circuit
25 Controller update failed
Controller update could not be completed.
• App
• Controller or circuit
26 Controller hardware failure
Controller hardware has failed.
• App
• Controller or circuit
27
Probe failure
A non-critical system probe has failed. The cabinet will continue to
operate with partial function but requires service.
NO swap cassette required.
• Evaporator probe or connections
• Controller
28 No downward tendency
The temperature is no longer decreasing.
Take a spare cassette in case of refrigeration system fault.
• Condenser blocked (or bad installation or ventilation)
• Poor installation or ventilation
• Cabinet or cassette gasket seals leaking
• Door not self-closing or gasket leaking
• Product hot or blocking cabinet airflow
• Overloaded from excess door openings/ambient
• Fan motor or blade (condenser or evaporator)
• Controller
• Compressor or gas leak = SWAP cassette
29 Compressor cutting out
The compressor cut out on its internal protection or pressure switch.
Take a spare cassette in case of refrigeration system fault.
• Condenser blocked (or bad installation or ventilation)
• Poor installation or ventilation
• Cabinet, door or cassette seal leaking
• Product hot or blocking cabinet airflow
• Overloaded from excess door openings/ambient
• Fan motor or blade (condenser or evaporator)
• Controller
• Compressor or gas leak = SWAP cassette
Table 16: AoFrio controller alarms (continued)
Code Description Possible root cause
