sks rehab Swiss VIVA User manual

Instruction Manual
Power Wheelchairs
Swiss VIVA
Swiss VIVA Plus
Swiss VIVA Grand
Swiss VIVA Grand M
Swiss VIVA Grand S
Swiss VIVA Junior
Swiss VIVA Junior S

2
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
Preliminary note.............................................................................................6
1. Introduction............................................................................................7
1.1. Intended use ..............................................................................................7
1.2. Declaration of Conformity...........................................................................7
1.3. Indications / contraindications ....................................................................7
1.4. Safety instructions for supervisors and users.............................................8
1.5. Signs and symbols...................................................................................11
1.6. Registration of your wheelchair & contact details.....................................12
1.7. Type plate ................................................................................................13
1.8. Scope of supply and product overview.....................................................14
Swiss VIVA / VIVA Plus...............................................................................14
2. Adjusting and operating the wheelchair ...........................................18
2.1. Adjusting for seating comfort....................................................................18
2.2. Adjusting front and rear seat height..........................................................18
2.3. Adjusting the seat depth...........................................................................20
2.4. Adjusting the seat width ...........................................................................24
2.5. Adjusting the backrest..............................................................................27
2.6. Adjusting the leg rests..............................................................................27
2.6.1. Adjusting the longitudinal footrest position........................................30
2.7. Adjusting the armrests and side cushions................................................34
Push-in armrest......................................................................................................35
2.7.1. Swing-back armrest ..........................................................................35
2.7.2. Armrest with back length compensation............................................36
2.7.3. Construction of the armrest insert for Swiss Viva Grand S ...............38
2.7.4. Retractable armrests.........................................................................39
2.7.5. Adjusting the position of a fixed armrest ...........................................39
2.8. Adjusting the seat and chassis suspension..............................................39
2.9. Setting the parallel guide of the control panel ..........................................42
2.9.1. Changing the ease of movement ......................................................42
2.9.2. Changing the end position ................................................................43
2.9.3. Changing the end position locking force ...........................................45
2.9.4. Changing from swing-right to swing-left............................................45
2.10. Adjusting the headrest..............................................................................46
2.11. Setting the control unit / driving parameters.............................................47
2.12. Adjusting the back length compensation..................................................47
2.13. Controls and displays...............................................................................47

3
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
2.13.1. Control unit........................................................................................48
2.13.2. Immobilizer (only enabled on special request)..................................49
2.13.3. LCD display.......................................................................................50
2.13.4. Setting the time.................................................................................55
2.13.5. Odometer..........................................................................................56
2.13.6. Operating the wheelchair ..................................................................57
2.14. Your first drive..........................................................................................61
2.14.1. Getting in and out..............................................................................64
2.14.2. Lights, turn signals, hazard warning lights ........................................65
2.14.3. Driving, steering, braking ..................................................................65
2.14.4. Driving on uphill and downhill slopes ................................................66
2.14.5. Overcoming obstacles.......................................................................67
2.14.6. Using the power wheelchair in vehicles ............................................68
2.14.7. Anti-tipping wheels............................................................................68
2.14.8. Manual steering fork lock ..................................................................68
2.14.9. Stopping, parking and getting out......................................................69
2.14.10. Pushing by hand ...............................................................................69
2.14.11. Driving with a gyro (gyrator)..............................................................71
2.15. Additional options.....................................................................................71
2.15.1. Adjusting the leg rests.......................................................................72
2.15.2. Adjusting the backrest.......................................................................74
2.15.3. Adjusting the back with length compensation ...................................74
2.15.4. Adjusting the seat height...................................................................74
2.15.5. Adjusting the seat angle....................................................................74
2.15.6. Limit switch system / limited lift and tilt functions...............................75
2.15.7. Electric & manual steering fork lock..................................................75
2.15.8. Note on the standing process............................................................76
3. Your wheelchair in detail ....................................................................76
3.1. Leg rests ..................................................................................................76
3.1.1. Swinging out and removing the leg rests ..........................................76
3.1.2. Mounting the leg rests.......................................................................78
3.2. Seat part...................................................................................................78
3.2.1. Taking off the seat cushion ...............................................................78
3.2.2. Putting on the seat cushion...............................................................79
3.3. Back part..................................................................................................79
3.3.1. Armrests............................................................................................80

4
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
3.3.2. Removing armrests...........................................................................80
3.4. Lap belt ....................................................................................................80
3.5. Additional loads........................................................................................81
3.6. Lights system ...........................................................................................81
3.7. Batteries...................................................................................................82
3.7.1. General information...........................................................................83
3.7.2. Charging the batteries with installed charger type P .........................84
3.7.3. Maintenance instructions ..................................................................85
3.7.4. Safety regulations .............................................................................85
3.7.5. Main fuse ..........................................................................................86
3.8. Wheels.....................................................................................................87
3.9. Transporting.............................................................................................89
3.9.1. Functional description of the Dahl Docking Station...........................91
3.9.2. Dahl Docking Station –installation / mounting..................................93
3.10. Holding points ..........................................................................................97
5. Technical data......................................................................................98
5.1. Data..........................................................................................................98
5.2. Weights..................................................................................................101
5.3. Driving characteristics............................................................................102
5.4. Tires & tire pressure...............................................................................104
5.5. Electrics..................................................................................................105
5.6. Charger..................................................................................................105
5.7. Actuating forces......................................................................................106
5.8. Materials.................................................................................................107
6. Cleaning and disinfecting the wheelchair.......................................108
6.1. Cleaning.................................................................................................108
6.2. Disinfecting.............................................................................................108
7. Wheelchair maintenance...................................................................108
7.1. Technician / service manuals.................................................................110
7.1.1. Testing the batteries........................................................................110
7.1.2. Limit switch system / limited lift and tilt functions.............................111
8. Reuse of the wheelchair....................................................................111
9. What to do in case of malfunctions and error messages?............111
9.1. Malfunction and its remedy ....................................................................111
9.2. Programming..........................................................................................114
10. Notes on disposal..............................................................................114

5
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
11. Warranty .............................................................................................114
12. Appendix ............................................................................................115
13. Notes...................................................................................................116

6
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
Preliminary note
Congratulations on the purchase of your new SKS power wheelchair and thank you
for the confidence you have placed in our product and services. We are convinced
that you have made a good choice by giving preference to a Swiss product of well-
known high quality standard.
The SKS power wheelchairs combine state-of-the-art technology and solid
construction with an attractive, modern design. Thanks to its many adjustment
options, your SKS power wheelchair offers you, as a standard:
–High comfort
–Maximum personalization
–Accessible usability for the disabled
–High degree of independence and security
This user manual refers to the Swiss VIVA, Swiss VIVA Plus, Swiss VIVA Junior (S),
and Swiss VIVA Grand (S) models of power wheelchairs. These wheelchairs are very
similar to each other in their construction. The special features of each individual
wheelchair model are explained separately in the various parts of the manual.
This instruction manual contains important information on safety,
operation and maintenance. Please read the instructions carefully before
first use and familiarize yourself with the many possibilities and
advantages of your new mobility device.
You can also download this instruction manual in electronic form from
www.sks-rehab.com.
Questions? Please feel free to contact your customer service center if you have
any questions or problems in connection with your power wheelchair
or if you would like any further information.
Trouble? If there are any malfunctions, please contact your specialist dealer
and provide as much information as possible. In this way, you will
help to have any faults in your mobility device remedied as quickly
and professionally as possible.
You will find the appropriate details in chapter 9
page 111.
We wish you a safe journey with your SKS power wheelchair.
Your SKS Rehab AG

7
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
1. Introduction
1.1. Intended use
Your power wheelchair serves as an assistive device to help persons with reduced
mobility to get around indoors and outdoors. It is sufficiently compact and
maneuverable for indoor use and can overcome obstacles according to category B of
EN 12184. Which power wheelchair should be selected and how it should be used is
decided by the doctor or therapist together with the user. The power wheelchair may
only be used within the limits set by the doctor or therapist and the SKS consultant.
The Swiss VIVA Junior S is a standing power wheelchair for children and
adolescents.
1.2. Declaration of Conformity
SKS Rehab AG, as the manufacturer, declares under its sole responsibility that the
power wheelchairs of the Swiss VIVA series comply with the requirements of MDR
2017/745 and ISO 7176-14. See the supplement in the appendix starting on page
115.
The upholstery has been tested for flammability according to DIN 1021-1 & 2 and has
been classified as flame retardant.
1.3. Indications / contraindications
Indication
Contraindication
• Inability to walk or severe
walking impairment due to:
- Paralysis
- Limb loss
- Limb defects/deformity
- Joint contractures
- Other illnesses
• Inability to use hand-powered wheelchairs
due to disabilities
• For performing prescribed standing training if
this cannot be done with other standing aids
and if there are no contraindications to
performing standing training (for example,
low bone density, damage to cardio-vascular
function, increased spasticity).
• If tasks/activities relevant to everyday life are
regularly performed in a protected standing
position and no contraindications exist
• Severe balance disorders
• Impaired or low vision
• Severe limitations of cognitive capacity
• Standing training: low bone density
• Standing training: impaired cardiovascular
function
• Standing training: increased spasticity

8
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
1.4. Safety instructions for supervisors and users
Read and follow the safety instructions below to ensure that you are not exposed to
any hazards when using your power wheelchair and that your mobility device has the
longest possible service life:
•For your own safety, do not set up, maintain or operate the wheelchair without
reading the operating instructions.
•Before using the wheelchair, please check that all removable parts are properly
attached.
•The power wheelchair is designed for one person only; carrying passengers or
loads is not permitted.
•Never use the wheelchair under the influence of alcohol or drugs.
•The power wheelchair is built for indoor and outdoor use. For indoors, you should
select the "Soft" speed level.
•Observe the maximum permissible payload.
•Before getting into or out of the power wheelchair, make sure the control unit is
switched off.
•Turn off the control unit when you are not using it.
•Always fold up the footplates when getting on and off the machine; do not use
them as a footboard.
•Do not lean your body over side panels or the over top of the back. Danger of
tipping!
•Do not lean forward between your knees, e.g. to pick up an object; otherwise you
may slip out of the power wheelchair.
•Do not reach for something in front of you if you have to shift forward on the seat
to do so.
•When driving on roads, never drive in standing position.
•Always drive up as close as possible to an object in order to reach it. Turn off the
control unit and use the reach of your arms to reach the object.
•When making adjustments and settings, be aware of the risk of trapping body
parts. When making powered adjustments, make sure that no third parties are
within the operating range of the wheelchair; this would increase the risk of
trapping and injury for the user and third party.
•When driving over obstacles, the anti-tipping wheels may touch down. Make sure
you always use a ramp to overcome such height differences.
•Always drive in a straight line over slopes, curbs and obstacles. Drive over the
obstacle in one go; do not stop in between. If necessary, raise the seat position to
avoid grazing the obstacle with the leg rests.
•While driving up onto obstacles, always make sure that the backrest is adjusted
forward and that the seat tilt and seat lift are adjusted down. There is a danger of
tipping over!

9
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
•If an abrupt braking maneuver could affect your sitting stability, then wearing a
seat belt is recommended. Ask a specialist; they can install the accessories
professionally for you.
•The control unit is fully programmable. We have set the unit at our factory to tested
default settings that are correct for most users. However, if you do not like the
handling of the chair, you can and should adapt it to your preferences and your
environment.
•For a model with standing function, please ensure that the knee pads and upper
body restraint are correctly positioned and engaged.
•Note that additional support wheels are lowered down at the front during the
stand-up process (Grand S). Avoid obstacles, uneven terrain, and ramps when
driving in standing position. There is a distinct danger of tipping. In particular, do
not drive on ramps while standing because there would be no way of putting on
the brakes and the wheelchair could therefore roll down.
•Contact your specialist dealer if any modifications need to be made. Choose a
safe driving program that suits you and your environment.
•Never operate the control unit if it behaves erratically or if it is giving off unusual
heat, smoke or sparks. In such a case, switch off the control unit immediately and
contact your specialist dealer without delay.
•If your chair is equipped with a gyro, switch to the lowest driving profile when using
your chair in vehicles (train, streetcar, bus, etc.). Otherwise, unwanted error
messages may appear on your control panel.
•Despite compliance with all applicable EMC directives and standards, it is still
possible that the power wheelchair may interfere with or be disturbed by other
electrical equipment (e.g. mobile phones). If you notice any behavior of this kind,
turn off either the third-party device or your wheelchair. Have your power
wheelchair moved out of range of the source of interference.
•Never use a water jet or pressure washer for cleaning.
•Please note that upholstery parts exposed to direct sunlight can heat up and
cause skin injuries when touched. Therefore, cover these parts or protect the
wheelchair from sunlight.
•In low temperature conditions, the wheelchair, especially the metal parts, may cool
down to chilly temperatures. Be careful not to touch them with bare skin; wear
protective clothing if necessary.
•When driving on roads, the road traffic regulations must be observed.
•Make sure that the active and passive lights on the wheelchair are always clearly
visible. It is advisable to wear bright, conspicuous clothing while in road traffic in
order to be more visible to other road users.
•We would like to point out that brakes and lights comply with the German Road
Traffic Licensing Regulations (StVZO; see declaration in the appendix). As soon
as you stop, the parking brake engages automatically.
•Be aware that the wheelchair can possibly come to a sudden, unexpected stop.
•Only use accessories and original parts approved by SKS Rehab AG.

10
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
•The Swiss VIVA wheelchairs are approved for transport inside vehicles. Please
observe the securing instructions in chapter 3.9.
•Regarding the "Dahl Docking Station" transport securing mechanism, observe the
warnings described by the manufacturer on page 33 in the assembly and
operating instructions (https://dahlengineering.dk/).

11
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
1.5. Signs and symbols
Attention! Important notes. Observe the operating instructions!
Notes! Recommendations for safe use of the wheelchair
Attention! Slip hazard
Type dependent information

12
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
1.6. Registration of your wheelchair & contact details
Your wheelchair is registered with us as follows:
Type: .........................................................................
Chassis no: ..............................................................
Date of purchase: ....................................................
Notes:
........................................................................................................................................
........................................................................................................................................
...................
Specialist dealer / service center:
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………

13
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
1.7. Type plate
Type plate under seat board
- Swiss VIVA
- Swiss VIVA PLUS
- Swiss VIVA GRAND
- Swiss VIVA GRAND M
Type plate on standing mechanism
- Swiss VIVA Grand S
- Swiss VIVA Junior S

14
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
1.8. Scope of supply and product overview
Your wheelchair is supplied with:
- Power wheelchair
- Charger
- Instruction manual
- Optional accessories
- Set of batteries
1
Backrest
8
Charging socket
2
Push handle
9
Luggage rack
3
Joystick and control unit
10
Footrests
4
Armrest (side panel)
11
Caster
5
Seat cushion
12
Lights
6
Transportation fixtures
13
Headrest
7
Drive wheel
Swiss VIVA / VIVA Plus
13
2
13
4
5
6
7
10
11
12
3/8

15
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
Swiss VIVA Junior
Swiss VIVA Junior S
13
13
2
2
3/8
3/8
4
4
5
5
6
6
7
7
10
10
11
11
12
12
13

16
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
Swiss VIVA Grand
Swiss VIVA Grand M
13
13
2
2
3/8
3/8
4
4
5
5
6
6
7
7
10
10
11
11
12
12
13

17
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
Swiss VIVA Grand S –rear-wheel drive
Swiss VIVA Grand S –mid-wheel drive
13
2
3/8
4
5
6
7
10
11
12
13
13
13
4
12
6
7
11
10
5
3/8

18
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
2. Adjusting and operating the wheelchair
The power wheelchair comes to you fully assembled from your specialist dealer. The
specialist dealer also adjusts the settings and familiarizes you with the chair.
Before using the wheelchair for the first time, please read the following
instructions carefully so that you can control your wheelchair safely right
from the start.
2.1. Adjusting for seating comfort
Adjust the seat tilt, seat height and seat depth according to the personal needs of the
occupant of the chair. All appropriate adjustments must be made upon supply to the
end customer.
The seat adjustments can and may only be made with no load on the
seat; otherwise there is a risk of injury to the person working.
2.2. Adjusting front and rear seat height
These settings affect the stability of the wheelchair and can increase the
risk of tipping. The seat heights indicated refer to the height without
cushion.
Swiss VIVA
Swiss VIVA Plus
Swiss VIVA Junior
Position at rear
Rear seat
height (mm)
Position at front
Front seat
height (mm)
1st position
450
1st position
450
2nd position
470
2nd position
470
3rd position
490
3rd position
490

19
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
Adjusting the rear seat height
- Loosen and remove the two
hexagon socket screws (1).
- Attach the perforated plates at the
desired height.
- Replace the two hexagon socket
screws (1) and tighten them.
Adjusting the front seat height
- 3 Support the seat part at the front.
Loosen the screws (2), move the
seat part to the new position and
tighten the 3 screws again.
.
Fig. 2
Swiss VIVA Grand S
Swiss VIVA Grand M
Swiss VIVA Junior S
You can conveniently and continuously adjust the seat height electronically from the
control console. The height adjustment can be paused at any height and the
selected position will remain secured. In addition, the seat height can be finely
adjusted at the factory.
1
2
Fig. 1
Pos 1
Pos 2
Pos 3

20
SKS Rehab AG
In the Wyden
CH-8762 Schwanden
SKS Power Wheelchairs
Instruction Manual
T: [phone]
E-mail: [e-mail]
www.sks-rehab.com
20220201_Gebrauchsanleitung_SKS_Swiss_Viva_Familie_en
Fig. 3
Fine adjustment
- Lift the seat cushion and loosen the
two lock nuts (6).
- Turn the adjusting screw (5) in or
out by the same amount on both
sides to adjust the seat height and
seat tilt.
- Tighten both nuts (2) again.
2.3. Adjusting the seat depth
When adjusting seat depths, the seat cushion must be replaced. These
settings affect the stability of the wheelchair and can increase the risk of
tipping.
Swiss VIVA
Swiss VIVA Plus
Swiss VIVA Junior
The seat depth on the Swiss VIVA is adjusted by:
1. Adjusting the mount of the seat lift tube.
2. Changing the attack position of the back drive.
3. For a seat depth of 525 mm, an additional extension lug must be
attached onto the back drive at the front.
Fig. 4 Seat depth 525 mm
1. Seat lift tube mount
- Moving the back lift tube forward
one hole at a time results in a
change of 25 mm. To do this, loosen
the two hexagon socket screws on
the left and right using an SW 5 hex
key and move the seat lift tube
mount to the desired position and
retighten the screws.
6
5
