Skyjack SJ82 T User manual

.
TELESCOPIC BOOMS
MODELS SJ82T SJ86T
169368AJA November 2018
OPERATING MANUAL (ANSI/CSA)
To order go to Discount-Equipment.com

We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,
Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power
Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,
Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac,
MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec,
Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S. Curtis, Gehl Pavers, Heli,
Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin, Rice, CH&E, General Equip-
ment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent, Stanley, Tamco, Toku, Hatz,
Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air, APT, Wylie, Ingersoll Rand /
Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith Surface Prep,Small Line,
Wanco, Yanmar
Discount-Equipment.com is your online resource for
commercial and industrial quality parts and equipment sales.
561-964-4949
visit us on line @ www.discount-equipment.com
TO PURCHASE THIS PRODUCT PLEASE CONTACT US
Select an option below to find your Equipment
Equipment Financing and
Extended Warranties Available

This manual is based on Serial Number(s):
SJ82T SJ86T 97 100 001 & Above
To order go to Discount-Equipment.com

DANGER
DANGER indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. It may also be used to alert against
unsafe practices.
IMPORTANT
IMPORTANT indicates a procedure essential for safe operation and which,
if not followed, may result in a malfunction or damage to the aerial platform.
The Safety Alert Symbol identies important
safety messages on aerial platform, safety
signs in manuals or elsewhere. When you
see this symbol, be alert to the possibility of
personal injury or death. Follow the instructions
in the safety message.
This Safety Alert Symbol means attention!
Become alert! Your safety is involved.
SJ 82T & SJ 86T Page 3
To order go to Discount-Equipment.com

Table of Contents
Section 1 - About Your Aerial Platform ................................................................................................. 5
Read and Heed .....................................................................................................................................................5
Safety Rules ...........................................................................................................................................................6
Section 2 - Familiarization ................................................................................................................... 13
2.1 Familiarization of Telescopic Boom Series ......................................................................................13
2.2 Component Identication ................................................................................................................14
2.3 Visual & Daily Maintenance Inspections .........................................................................................22
2.4 Function Tests ..................................................................................................................................31
2.5 Winching and Towing Procedure ....................................................................................................47
2.6 Emergency Lowering Procedures ...................................................................................................49
Section 3 - Operation ........................................................................................................................... 51
3.1 General ............................................................................................................................................51
3.2 Major Components ..........................................................................................................................52
3.3 Major Assemblies ............................................................................................................................53
3.4 Serial Number Nameplate ...............................................................................................................53
3.5 Component Identication (Optional Equipment/Attachments) .......................................................54
3.6 Operator’s Responsibility ................................................................................................................57
3.7 Start Operation ................................................................................................................................58
3.8 Refueling Procedure ........................................................................................................................65
3.9 Loading/Unloading ..........................................................................................................................66
3.10 Chassis Tilt .......................................................................................................................................68
3.11 Technical Diagrams .........................................................................................................................69
Section 4 - Tables .................................................................................................................................. 73
Table 4.1 Standard and Optional Features .....................................................................................................73
Table 4.2a Specications and Features ............................................................................................................74
Table 4.2b Specications and Features ............................................................................................................75
Table 4.3 Owner’s Annual Inspection Record .................................................................................................76
Table 4.4 Maximum Platform Capacities .........................................................................................................76
Table 4.5 Tire/Wheel Specications ................................................................................................................77
Table 4.6 Floor Loading Pressure ...................................................................................................................78
Table 4.7 Operator’s Daily Inspection Checklist .............................................................................................79
Section 5 - Labels .................................................................................................................................. 81
Page 4 SJ 82T & SJ 86T
To order go to Discount-Equipment.com

SKYJACK is continuously improving and expanding product features on its equipment. Therefore, specications
and dimensions are subject to change without notice.
Aerial Platform Definition
A mobile device that has an adjustable position platform supported from ground level by a structure.
Purpose of Equipment
The SKYJACK Telescopic Boom Series (Model SJ 8XT) aerial platform is designed to transport and raise personnel,
tools and materials to overhead work areas.
Use of Equipment
The aerial platform is a highly maneuverable, mobile work station. Work platform elevation and elevated driving
must only be done on a rm, level surface. It can be driven over uneven terrain only when the platform is fully
lowered.
Manual
The operating manual is considered a fundamental part of the aerial platform. It is a very important way to
communicate necessary safety information to users and operators. A complete and legible copy of this manual
must be kept in the provided weather-resistant storage compartment on the aerial platform at all times.
Operator
The operator must read and completely understand both this operating manual and the safety panel label located
on the platform and all other warnings in this manual and on the aerial platform. Compare the labels on the aerial
platform with the labels found within this manual. If any labels are damaged or missing, replace them immediately.
Service Policy and Warranty
SKYJACK warrants each new SJ 8XT series work platform to be free of defective parts and workmanship for the rst
24 months. Any defective part will be replaced or repaired by your local SKYJACK dealer at no charge for parts or
labor. Contact SKYJACK Service Department for warranty statement extensions or exclusions.
Optional Accessories
The SKYJACK aerial platform is designed to accept a variety of optional accessories. These are listed under
“Standard and Optional Features” in Table 4.1. Operating instructions for these options (if equipped) are located
in Section 3 of this manual.
For non-standard components or systems, contact the SKYJACK Service Department at:
( : 800 275-9522
7 : 630 262-0006
Include the model and serial number for each applicable aerial platform.
Scope of this Manual
a. This manual applies to the ANSI/SIA and CSA versions of the Telescopic Boom aerial platform models listed
on Table 4.1.
- Equipment identied with “ANSI” meets the ANSI/SIA A92.5-2006 standard.
- Equipment identied with “CSA” meets the CSA B354.4-02 standard.
b. CSA (Canada)
Operators are required to conform to national, territorial/provincial and local health and safety regulations
applicable to the operation of this aerial platform.
c. ANSI/SIA (United States)
Operators are required by the current ANSI/SIA A92.5 standards to read and understand their responsibilities
in the manual of responsibilities before they use or operate this aerial platform.
1
SJ 82T & SJ 86T Page 5
Section 1 - About Your Aerial Platform Read and Heed
To order go to Discount-Equipment.com

WARNING
Failure to comply with your required responsibilities in the use and operation of the aerial platform
could result in death or serious injury!
Operator Safety Reminders
A study conducted by St. Paul Travelers showed that most accidents are caused by the failure of the operator to
follow simple and fundamental safety rules and precautions.
You, as a careful operator, are the best insurance against an accident. Therefore, proper usage of this aerial
platform is mandatory. The following pages of this manual should be read and understood completely before
operating the aerial platform.
Common sense dictates the use of protective clothing when working on or near machinery. Use appropriate safety
devices to protect your eyes, ears, hands, feet and body.
Any modications from the original design are strictly forbidden without written permission from SKYJACK.
Page 6 SJ 82T & SJ 86T
Safety Rules Section 1 - About Your Aerial Platform
To order go to Discount-Equipment.com

Electrocution Hazard
This aerial platform is not electrically insulated. Maintain a Minimum Safe Approach Distance (MSAD) from energized
power lines and parts as listed below. The operator must allow for the platform to sway, rock or sag. This aerial
platform does not provide protection from contact with or proximity to an electrically charged conductor.
Per ANSI A92.5-2006 8.10(7)
“The operator shall perform only the work for which he or she is qualied, in compliance with all applicable safety
related work practices intended to prevent electric shock covered by the Code of Federal Regulations (CFR) 1910.333.
The operator’s level of competence shall be established only by persons qualied to do so. Operators shall
maintain the appropriate minimum approach distance (MAD) from energized power lines and parts covered by
CFR 1910.333 (c).”
Unqualied persons must maintain a minimum approach distance of 10 feet from any energized power line up to
50 kV. Energized power lines over 50 kV require a greater minimum approach distance to be maintained. Refer to
CFR 1910.333.
As per CSA B354.4-02
“The operator shall maintain the minimum safe approach distance (MSAD) from energized conductors at all times
in accordance with the authority having jurisdiction.”
Refer to CFR 1910.333 or the authority having jurisdiction.
DO NOT USE AERIAL PLATFORM AS A GROUND FOR WELDING.
DO NOT OPERATE AERIAL PLATFORM DURING LIGHTNING OR STORMS.
DO NOT OPERATE THE AERIAL PLATFORM NEAR POWER LINES. MAINTAIN A MINIMUM SAFE
APPROACH DISTANCE (MSAD) FROM ENERGIZED POWER LINES.
Voltage Range Minimum Safe Approach Distance
(Phase to Phase) (Feet)
0 to 300V Avoid Contact
Over 300V to 50KV 10
Over 50KV to 200KV 15
Over 200KV to 350KV 20
Over 350KV to 500KV 25
Over 500KV to 750KV 35
Over 750KV to 1000KV 45
60023AD-ANSI
DANGER
FAILURE TO AVOID THIS HAZARD WILL RESULT IN DEATH OR SERIOUS INJURY!
Avoid Power Lines
Minimum Safe Approach Distance
ANSI/SIA A92.6-2006 & CSA B354.2-01 Requirements
SJ 82T & SJ 86T Page 7
Section 1 - About Your Aerial Platform Safety Rules
To order go to Discount-Equipment.com

Safety Precautions
Know and understand the safety precautions before going on to next section.
WARNING
Failure to heed the following safety
precautions could result in tip over,
falling, crushing, or other hazards leading
to death or serious injury.
• KNOW all national, state or territorial/provincial
and local rules which apply to your aerial platform
and jobsite.
• TURN main power disconnect switch “ ” off when
leaving the aerial platform unattended. Remove
the key to prevent unauthorized use of the aerial
platform.
• WEAR all the protective clothing and personal
safety devices issued to you or called for by job
conditions.
• DO NOT wear loose clothing,
dangling neckties, scarves,
rings, wristwatches or other
jewelry while operating this
aerial platform .
• AVOID entanglement with
ropes, cords or hoses.
• AVOID falling. Stay within the
boundaries of the guardrails.
Maintain rm footing on the
platform oor at all times while
working thereon.
• ENSURE all occupants wear
personal fall protection equipment.
• DO NOT raise the aerial
platform or operate elevated in
windy or gusty conditions that
exceed the limits specied in
Section 4, Table 4.4.
• DO NOT increase the lateral
surface area of the platform.
Increasing the area exposed
to the wind will decrease aerial
platform stability. Avoid tenting.
• DO NOT elevate the aerial platform if it is not on
a rm, level surface.
• DO NOT drive elevated near
depressions or holes of any
type, loading docks, debris,
drop-offs and surfaces that
may affect the stability of the
aerial platform.
• DO NOT elevate or drive
elevated on a slope. Elevated
driving must be done on a rm,
level surface.
• If operation in areas
with holes or drop-offs
is absolutely necessary,
elevated driving shall not be
allowed. Position the aerial
platform horizontally only with
the platform fully lowered.
After ensuring that all 4 wheels
or outriggers (if equipped)
have contact with a rm, level
surface, the aerial platform can
be elevated. After elevation,
the drive function must not be
activated.
• DO NOT drive elevated on a
soft or uneven surface.
• DO NOT ascend or descend a
grade steeper than 45% (4WD).
Boom elevated driving must
only be done on rm, level
surfaces.
Page 8 SJ 82T & SJ 86T
Safety Rules Section 1 - About Your Aerial Platform
To order go to Discount-Equipment.com

Safety Precautions (Continued)
Know and understand the safety precautions before going on to next section.
• DO NOT operate an aerial
platform that has ladders,
scaffolding or other devices
mounted on it to increase its size
or work height. It is prohibited.
• DO NOT exert horizontal
(manual) force on aerial
platform that exceeds the limits
specied in Table 4.4.
• DO NOT use the aerial platform
as a crane. It is prohibited.
• DO NOT climb on boom arm
assembly. It is prohibited.
• DO NOT sit, stand or climb on
the guardrails. It is prohibited.
• AVOID overhead obstructions.
Be aware of overhead
obstructions or other possible
hazards around aerial platform
when lifting or driving.
• AVOID crushing hazards. Be
aware of crushing hazards when
lifting or driving. Keep all body
parts inside the aerial platform.
• BE AWARE of blind spots when
operating the aerial platform.
• ENSURE that there are no
personnel or obstructions in
the path of travel, including
blind spots.
• DO NOT lower the platform
unless the area below is clear
of personnel and obstructions.
• DO NOT use boom to push,
pull other objects or to lift the
chassis.
• DO NOT raise the aerial
platform while it is on a truck,
forklift or other device or vehicle.
• STUNT driving and horseplay are prohibited.
• DO NOT use with improperly
inated/damaged tires or
wheels. Refer to Section 2:
Wheel/Tire Assembly.
• DO NOT alter or disable limit switches or other
safety devices.
• DO NOT use the aerial platform without
guardrails, locking pins and the entry gate/drop
bar in place.
SJ 82T & SJ 86T Page 9
Section 1 - About Your Aerial Platform Safety Rules
To order go to Discount-Equipment.com

Safety Precautions (Continued)
Know and understand the safety precautions before going on to next section.
• DO NOT exceed the rated
capacity of the aerial platform.
• DO NOT distribute load
unevenly.
• DO NOT use under inuence
of alcohol or drugs.
• DO NOT attempt to free a snagged platform with
lower controls until personnel are removed from
the platform.
• DO NOT position the aerial platform against
another object to steady the platform.
• DO NOT place materials on the guardrails or
materials that exceed the connes of the guardrails
unless approved by Skyjack.
• DO NOT operate if aerial
platform is not working properly
or if any parts are damaged or
worn.
• DO NOT leave aerial platform
unattended with key in key
switch.
Page 10 SJ 82T & SJ 86T
Safety Rules Section 1 - About Your Aerial Platform
To order go to Discount-Equipment.com

Safety Precautions (Continued)
Know and understand the safety precautions before going on to next section.
Fall Protection
WARNING
Failure to wear personal fall protection
equipment may result in death or serious
injury.
All occupants of this aerial platform must wear
personal fall protection equipment.
As per the ANSI A92.5-2006 standard, “Principal
fall protection is provided by the guardrail system.
The user shall direct and monitor the operator to
ensure that all components of the guardrail system
are in place. The user shall direct and monitor
the occupants of the work platform to ensure that
they wear a personal fall arrest system to protect
against the potential effects of ejection or a fall
restraint system to prevent a free fall.”
Fall restraint and fall arrest systems are dened
within the ANSI A92.5 Manual of Responsibilities
shipped with this aerial platform.
Skyjack recommends the use of a fall restraint
system to keep an occupant within the connes
of the platform, and thus not expose the occupant
to any fall hazard requiring a fall arrest.
CSA B354.4-02 requires the use of a fall arrest
system, therefore Canadian users must use
personal fall arrest protection as opposed to fall
restraint.
All personal fall protection equipment must comply
with applicable governmental regulations and must
be inspected and used in accordance with the
manufacturer’s recommendations.
All personal fall protection equipment must be
attached only to approved anchorage points within
the platform of the aerial platform.
WARNING
Entering and exiting the aerial platform
should only be done using the three
points of contact.
• Use only equipped access openings.
• Enter and exit only when the aerial
platform is in the fully retracted position.
• Do use three points of contact to enter and exit
the platform. Enter and exit the platform from
the ground only. Face the aerial platform when
entering or exiting the platform.
• Three points of contact means that two hands
and one foot or one hand and two feet are in
contact with the aerial platform or the ground at
all times during entering and exiting.
WARNING
An operator should not use any aerial platform that:
• does not appear to be working properly.
• has been damaged or appears to have worn
or missing parts.
• has alterations or modications not approved
by the manufacturer.
• has safety devices which have been altered
or disabled.
• has been tagged or locked out for non-use or
repair.
Failure to avoid these hazards could result in death
or serious injury.
Jobsite Inspection
• Do not use in hazardous locations (see NFPA 505).
• Perform a thorough jobsite inspection prior to
operating the aerial platform, to identify potential
hazards in your work area.
• Be aware of moving equipment in the area. Take
appropriate actions to avoid collision.
SJ 82T & SJ 86T Page 11
Section 1 - About Your Aerial Platform Safety Rules
To order go to Discount-Equipment.com

Section 2 - Familiarization SJ TB Series
FAMILIARIZATION
It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
2.1 Familiarization of Telescopic Boom Series
2
2
WARNING
Aerial Platform Familiarization should be given only to individuals who are QUALIFIED/
COMPETENT and TRAINED to operate an aerial platform.
Do not operate this aerial platform without proper authorization and training. Failure to avoid
this hazard could result in death or serious injury.
It is the responsibility of the operator to read, completely understand and follow all
instructions and warnings contained in this operating manual and on the aerial platform.
Footswitch
Platform Control
Console
Base Control
Console
Manual
Box
Main Power
Disconnect
Switch
Drive Bypass
Valve
Brake Hand
Pump
Brake Auto Reset
Valve Plunger
SJ 82T & SJ 86T Page 13
To order go to Discount-Equipment.com

It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATION
2.2 Component Identification
The following descriptions are for identification,
explanation and locating purposes only.
NOTE
This aerial platform is equipped with dual
platform capacity. Select desired platform
capacity (“high” of “low”) using platform
capacity selector switch.
2.2-1 Main Power Disconnect Switch
This switch is located in the engine compartment near
the battery.
1
Figure 2-1. Main Power Disconnect Switch
1. Main Power Disconnect Switch - This switch,
when in “ ” off position, disconnects power to
all circuits. Switch must be in “ ” on position to
operate any circuit. Turn switch “ ” off when
transporting aerial platform.
2.2-2 Tilt Switch
The tilt switch is located within the base control console.
It is designed to prevent driving when the aerial platform
is on a slope greater than a predetermined limit.
WARNING
If aerial platform becomes tilted causing
alarm to sound, the platform must be
fully lowered immediately. Ensure that
aerial platform is on a rm, level surface
before operating the aerial platform. Refer
to Section 3.10 for instructions regarding
recovery from an inclined position.
2.2-3 Drive Bypass Valve
This valve is located on the inboard side of the drive
pump and can be identied with a yellow paint mark
on it.
1
Figure 2-2. Drive Bypass Valve
1. Drive Bypass Valve with Override Stems - This
valve, when loosened 90 degrees clockwise, is
used to override drive relief valves so that the aerial
platform can be loaded or unloaded from a trailer
using a winch line.
2.2-4 Brake System
The brake system is located in the control compartment.
The brakes must be manually disengaged before
pushing, winching or towing. Refer to Section 2.5-1
for procedure on how to release brakes manually. The
system contains the following controls:
1
2
Figure 2-3. Brake System
1. Brake Hand Pump
2. Brake Auto Reset Valve Plunger
Page 14 SJ 82T & SJ 86T
Control Functions Section 2 - Familiarization
To order go to Discount-Equipment.com

It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATION
2.2-5 Differential Lock Switch
This switch is located on the platform control console.
The differential locking system provides more traction
by providing equal drive to each wheel regardless of
traction. Differential locks are used to prevent from
getting stuck when driving on loose, muddy, or rocky
terrain. Refer to Section 2.4-3 for instructions regarding
testing differential lock switch.
WARNING
Before engaging differential lock, ensure
drive/steer controller is in neutral position.
2.2-6 All Motion Alarm
This alarm produces an audible sound when any boom
function is activated. On aerial platforms with certain op-
tions, a ashing amber light will accompany this alarm.
2.2-7 Turret Transportation Lock
This locking device is located in the turret.
1
Figure 2-4. Turret Transportation Lock
1. Turret Transportation Lock - This locking device
is used to lock turret in place during shipping only.
Refer to Section 3.9-2 for procedure on how to lock
the turret.
2.2-8 Footswitch
The footswitch is located on the oor of the platform.
When depressed and held, it enables controls on
platform control console.
Figure 2-5. Footswitch
NOTE
The footswitch is equipped with a 15-second
anti-tiedown feature that deactivates
footswitch when operator depresses it for
15 seconds without activating any function.
2.2-9 Manual Storage Box
This weather-resistant box is
mounted under the control console
on the platform. It contains operating
ma nual and oth er im por tant
documents. The operating manual
for this make and model of aerial
platform must remain with the aerial
platform and should be stored in
this box.
SJ 82T & SJ 86T Page 15
Section 2 - Familiarization Control Functions
To order go to Discount-Equipment.com

It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATION
2.2-10 Base Control Console
This control console is located in the panel mounted in the control compartment.
23
13
4
7
10
9
1112
8
6
5
14
15
17
16
1
18
Figure 2-6. Base Control Console
1. Hourmeter - This gauge records accumulated
operating time of engine.
2. Circuit Breakers - In the event of a power overload
or positive circuit grounding, the circuit breaker
pops out. Push breaker back in to reset.
3. Engine Diagnosis Switch - When held in either
direction, this switch “ ” enables an error blink
code for engine control unit (ECU).
4. Platform Rotation Switch - This switch controls
“” left or “ ” right rotation of platform.
5. Turret Rotation Switch - This switch controls
“” left or “ ” right rotation of turret.
6. Platform Leveling Override Switch - This switch
overrides automatic leveling of platform and
controls “ ” tilting up or “ ” tilting down
of platform.
7. Jib Up/Down Switch (If Equipped) - This switch
controls “ ” up or “ ” down movement
of jib.
8. Boom Extend/Retract Switch - This switch
controls “ ” extension or “ ” retraction of
y boom.
9. Main Boom Raise/Lower Switch - This switch
controls “ ” raising or “ ” lowering of
main boom.
10. E m e r g e n c y S t o p B u t t o n - T h i s r e d
“mushroom-head” “ ” pushbutton disconnects
power to control circuit and shuts engine off.
Page 16 SJ 82T & SJ 86T
Control Functions Section 2 - Familiarization
To order go to Discount-Equipment.com

It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATION
11. Status Indicator Pilot Lights - These lights
indicate operational status and errors in any
function in the controls/engine.
AB C D E F
A. Water In Fuel Light - This light indicates water
separator is full. Open drain to release water.
Engine damage could occur if ignored for
excessive length of time.
B. Engine Oil Pressure - This light indicates low
engine oil pressure.
C. Engine Coolant Temperature/Level - This
light indicates overheating of engine coolant
and low level of engine coolant.
D. Engine - This light indicates failure in engine
control system.
E. Fuel - This light indicates low fuel level.
F. Glow Plug (Diesel) - This light illuminates
until glow plugs have completed their timed
cycle. When the lamp goes out, the engine is
ready to be started.
12. Off/Base/Platform Key Switch - This three-way
selector switch allows operator to “” turn off
power to aerial platform or to activate either “ ”
base or “ ” platform control console.
13. Start/Function Enable/Emergency Power
Switch - This momentary switch, when held in
“” start position, starts engine. When held in
“” function enable position, allows base control
functions to operate. Engine speed increases
when selected. With engine off, and when held
in “ ” emergency power unit position,
allows base control functions to operate using
emergency power unit.
14. Capacity Zone Border Light - Indicates aerial
platform is at limits of travel for high capacity zone.
Lower “ ” and “ ” extend functions are not
available.
15. High Capacity Zone Indicator Light - Indicates
aerial platform is in “high” platform capacity zone.
Refer to Table 4.4.
2.2-10 Base Control Console (Continued)
23
13
4
7
10
9
1112
8
6
5
14
15
17
16
1
18
Figure 2-6. Base Control Console
SJ 82T & SJ 86T Page 17
Section 2 - Familiarization Control Functions
To order go to Discount-Equipment.com

It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATION
2.2-10 Base Control Console (Continued)
23
13
4
7
10
9
1112
8
6
5
14
15
17
16
1
18
Figure 2-6. Base Control Console
16. Low Capacity Zone Indicator Light - Indicates
aerial platform is in “low” platform capacity zone.
Refer to Table 4.4.
17. Platform Capacity Selector Switch - This two
position switch allows the operator to select either
“high” or “low” platform capacity.
18. Positive Air Shutoff Switch (If Equipped) - This
switch allows the operator to shut off the air supply
to the engine if the engine continues running after
the main power is shut down.
Page 18 SJ 82T & SJ 86T
Control Functions Section 2 - Familiarization
To order go to Discount-Equipment.com

It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATION
2.2-11 Platform Control Console
This metal control console is mounted at front guardrail of the platform. It has the following controls:
4678
1214 1020
93
1722
5
21 13
2
11
1619 18 15
1
Figure 2-7. Platform Control Console
1. Secondary Guarding Electrical (SGE) Reset
Button (If Equipped) - This button, when
depressed, shuts off the audible/visual alarm from
the SGE.
2. Work Light Switch (If Equipped) - This switch
turns on work light.
3. Engine Start/On/Off Switch - This switch, when
held momentarily in “ ” start position, starts
engine. Once started, the switch returns to “ ”
on position. When in “ ” off position, it turns
engine off.
4. Horn Pushbutton - This “ ” pushbutton sounds
an automotive-type horn.
5. Status Indicator Pilot Lights - These lights
indicate operational status and errors in any
function in the controls/engine.
AB C D E
A. Footswitch - This light illuminates when
footswitch is depressed. A 15-second anti-
tiedown feature deactivates footswitch when
operator depresses it for 15 seconds without
activating any function.
B. Chassis Tilt - This light illuminates when the
aerial platform chassis is at an inclination that
activates the tilt sensor. At this inclination, an
audible alarm will sound at the platform. Refer
to Section 3.10 for instructions regarding
recovery from an inclined position.
C. Engine - This light indicates failure in engine
control system.
D. Fuel - This light indicates low fuel level.
E. Glow Plug (Diesel) - This light illuminates
until glow plugs have completed their timed
cycle. When the lamp goes out, the engine is
ready to be started.
6. Emergency Stop Button - This red “mushroom-
head” “ ” pushbutton disconnects power to
control circuit and shuts engine off.
7. Emergency Power Unit - This switch “”
enables emergency power unit when engine is off.
SJ 82T & SJ 86T Page 19
Section 2 - Familiarization Control Functions
To order go to Discount-Equipment.com

It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATION
2.2-11 Platform Control Console (Continued)
4678
1214 1020
93
1722
5
21 13
2
11
1619 18 15
1
Figure 2-7. Platform Control Console
8. Torque Switch - This switch selects “ ” low
or “ ” high torque. Select “ ” low torque
(higher speed) or “ ” high torque (lower
speed). Select “ ” high torque when driving
on a slope.
9. Low/High Throttle Switch - This switch allows
selection between “ ” low and “ ” high
engine throttle speeds.
10. Drive/Steer Controller - This single-axis lever
controls driving “ ” forward or “ ” backward.
The rocker switch controls steering “ ” left or
“” right. Internal springs return it to neutral
when released.
11. Differential Lock Switch - This momentary switch,
when pushed forward and then released, engages
“” differential lock and turns differential light
on. When pulled backward and then released,
disengages “ ” differential lock and turns
differential light off.
12. Jib Up/Down Switch - This switch controls
“” up or “ ” down movement of jib.
13. Function Speed Adjuster Dial - This variable-
speed adjuster “ ” controls speed of y boom
extension/retraction, jib raising/lowering and
platform rotation movements. This is used with
switches 12, 14 and 20.
14. Boom Extend/Retract Switch - This switch
controls “ ” extension or “ ” retraction of
y boom.
15. Low Capacity Zone Indicator Light - Indicates
aerial platform is in “low” platform capacity zone.
Refer to Table 4.4.
16. Platform Capacity Selector Switch - This two
position switch allows the operator to select either
“high” or “low” platform capacity.
17. Platform Leveling Override Switch - This switch
overrides automatic leveling of platform and
controls “ ” tilting up or “ ” tilting down
of platform.
Page 20 SJ 82T & SJ 86T
Control Functions Section 2 - Familiarization
To order go to Discount-Equipment.com
