SkylinkHome TB-318 User manual

1. INTRODUCTION
Wall Mount Transmitter
Wall Mount
Transmitter
Model TB-318
Accessories
Lithium
battery
Double-sided
Foam Tape
TM
Thank you for your purchase of a SkylinkHome Lighting Automation,
Wall Mount Transmitter, Model TB-318. This transmitter allows you to
TM
wirelessly operate different lighting fixtures with the SkylinkHome
lighting receiver modules.
TM
All wireless signal communications within the SkylinkHome lighting
system are based on rolling code technology to ensure highest security
is used.
You will find the following in this package:
- Wall Mount Transmitter
- Mounting Accessories & Double-sided Foam Tape
- Lithium Battery CR-2032
- User's Instructions
Before you can control the lights with the transmitter, you need to program
it to a receiver module. Follow the instructions below to program the trans-
mitter to a receiver module.
2. PROGRAMMING TRANSMITTER TO RECEIVER MODULE
4. ON / OFF OPERATION
In order to operate the receiver module remotely with a transmitter, it
must be programmed to the receiver module.
To program a transmitter into the receiver module, follow the instructions
below.
1. Remove the wall plate from the Wall Mount
Transmitter by loosening up the 2 screws.
2. Insert the battery to the Wall Mount Transmitter
as shown. Please note on the polarity, positive
side up. When the battery is installed, the red
LED on the transmitter will be on for 1 second.
3. Put the receiver module that you plan to program
into programming mode. Refer to the User's
Instructions of that receiver module.
4. Once the receiver module is in programming mode,
you may transmit the programming signal from the
transmitter by pressing the “SET” button on the
transmitter. The red LED on the transmitter will be
on.
5. Activate the Wall Mount Transmitter by pressing
the pad on the front. Its red LED will flash then off.
6. Once the transmitter is programmed, the receiver
module will quit from programming mode.
7. You may operate the light with the programmed
transmitter.
+
Loosen up
2 screws
Battery
(Positive side up)
Red
LED
SET
Button
Pad
Push pad to
turn on / off
Push
Hold
Toggle the light on / off
Brightness Control
Push
Hold
OR
CR 2032
Tighten
2 screws
Place
double-sided
foam tape
3. INSTALLATION
Pushing the pad from one position to the other will toggle the light,
i.e. when the light is off, pushing the pad will turn on the light, vice versa.
5. BRIGHTNESS CONTROL OPERATION
Besides turning on and off the light, you may also control the brightness
of the light if the receiver module and the light bulb is dimmable, i.e. either
incandescent light and designated dimming compact fluorescent light.
To change the brightness, first turn on the light by pushing the pad.
Press and hold the pad after the light is on will change the brightness of
the light. Hold onto the button until the desired brightness is reached,
then release the pad.
Press and hold the pad again to alter the brightness (from dim to brighten,
and from brighten to dim), until the desired brightness is reached, then
release the pad.
Slide in
Push
Down
20 32
+
2
+
After programming, you are now ready to install
the Wall Mount Transmitter .
You may use double sided foam tape to stick the
transmitter on the wall, or you may use screws
to mount the transmitter.
Using double sided foam tape:
Place the 2 double sided foam tape on the back
of the back plate. Clean the surface of the wall
where you plan to install the back plate. Peel
off the foam tape and stick it to the wall surface.
Using screws:
If you are using screws, tighten the back plate of the wall mount trans-
mitter by the 2 screws provided. If you are installing the back plate to an
]existing wall switch with gang box, no need to use the anchors. Other-
wise, drill 2 small pilot holes based on the 2 mounting screw positions
and insert the anchors before tightening the back plate with screws.
After securing the back plate, either by double sided foam tape or screws,
tighten the 2 screws on the front to secure the front plate.
Existing Gang Box
(No Anchor)
Drill 2 pilot holes
& insert anchors

8. FCC
9. CUSTOMER SERVICE
The Remote Control is approved by the FCC and it complies with Part 15 of the
FCC Rules. Its operation is subject to the following two conditions :
1. This device may not cause harmful interference.
2. This device must accept any interference that may cause undesired operation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible
of compliance could void the user’s authority to operate the equipment.
If you would like to order Skylink’s products or have difficulty getting them to work
or download latest information and user manual, please :
1. visit our FAQ section at www.skylinkhome.com, or
2. email us at [email protected], or
3. call our toll free at 1-800-304-1187 from Monday to Friday, 9 am to 5 pm EST.
Fax [phone]
CUSTOMER SERVICE
17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3
Email:[email protected]
http://www.skylinkhome.com
P/N. 101A396
Patent Pending
©2010 SKYLINK GROUP
10. ACCESSORIES
The Skylink Lighting System consists of many other devices from
multiple button transmitters, Motion Sensor, various receivers such as
Wall Switch Receiver, Plug-in Receiver with Repeater, Outdoor Receiver,
Dimmer Module etc. Please visit Skylink website at www.skylinkhome.com
for more information.
TM
Home
7. BATTERY
When the operating range is reduced, or when the red LED does not
flash during operation, it is time to replace the battery. Follow the same
procedure as installing the battery in section 2 of this manual to replace
the battery.
Note: Dispose of old batteries promptly and properly.
