Skymsen FWD1-33 User manual

MODEL: FWD1-33
Instruction Manual
UG0099-August/2011
FOOD WARMER DISPLAY CASE
Office
Phone: [phone]
Fax: [phone]
Warehouse
Phone: [phone]
Fax: [phone]
www.skyfood.us[email protected] -
TOLL FREE 1-800-503-7534

SUMMARY
1 - CONGRATULATIONS
2 -
3 - WARNING
4 - USING YOUR NEW HEATED
DISPLAY CASE
5 - HOW TO SET THE THERMOSTAT
6 - CLEANING YOUR SKYNSEN
HEATED DISPLAY CASE
7- TECHNICAL SPECIFICATION
8 -
HOW TO SET UP YOUR NEW
HEATED DISPLAY CASE
GENERAL SAFETY PRACTICES
1
1
1
1
1
2
4
5

01
1- CONGRATULATIONS
You have just acquired a Skymsen product.
We thank you for choosing our technology. Our main objective is to offer you a
high quality, lasting, safe and easy to fix product.
We hope it will be profitable to you and your business.
2- HOW TO SET YOUR NEW HEATED DISPLAY CASE
-Place your new heated display case on a firm, solid surface. If you put it on
something unsteady, it may fall and be damaged.
-Make sure it is turned off- “desligado” position.
-Each country or state has its own electricity system. Before using your oven
check if the power supply from your location matches the power adapter in your
equipment.
-Use your heated display case with the supplied AC power within 127 V - 230 V
AC in a grounded outlet.
3- WARNING
Your heated display case must be plugged into a grounded outlet only. Skyfood
shall not be responsible for any damages caused by plugging this product into a not
grounded outlet or plug.
- Set the thermostat switch “OFF” or “DESLIGADO”.
- First Use: Keep your heated display case empty and set the thermostat switch
at the highest position for two (2) hours. This procedure will allow your heated display
case warm up before first use. Remove the protecting cover from the element. The
heating part in your equipment.
- For future uses you just need to set the thermostat switch at the desired
temperature position and it will outomatically regulate its operation always within the
desired temperature.
4- USING YOUR NEW HEATED DISPLAY CASE
The main objective of the heated display case is to keep food warm and safe
while they are exposed. Skymsen heated display case has a heating equipment
responsible for the automatic control of the temperature inside the chamber.
5- HOW TO SET THERMOSTAT SWITCH
The reference match for its initial position is the red Flash light.
Every painted graduation corresponds to 33°F approximately.

02
EXAMPLE:
-Setting the thermostat swtich at the 3rd position the operational
temperature would be at 99°F. aproximatelly.
-Flash Light ON means the heating element is on.
-Flash light OFF means the temperature inside the chamber
matches the degree and the heating element is off.
6-CLEANING YOUR SKYMSEN HEATED DISPLAY CASE
Risk of electric shock.
-Make sure your oven is turned off and disconnected from a wall outlet.
-Set the thermostat swtich off- “Desligado” position.
-Remove the power cord from the wall outlet.
We recommend to clean the body with a soft cloth lightly moistened with a mild
detergent solution.
Do not use any type of solvent or abrasive material, which may damage the
equipment.
W.a.r.n.i.n.g
This heated display case is a professional equipment. Keep it away from
children and pets.
This heated display case is basically built up with glass, stainless steel and
electronic devices.
1-Electric Devices
-Make sure your wall outlet is grounded. Skufood shall not be responsible for
any damages caused by plugging it in a not-grounded wall outlet or similar power supply.
2- Glass
-Do not use your heated display case if there is a brokem glass or missing parts.
-Clean it carefully wearing resistant gloves and use a soft cloth and mild
detergent solution.

03
-In case of broken glass, avoid contact to spare parts of glass.
Remove it carefuly wearing appropriated gloves and dispose of properly
in order to avoid contact and the risk of injury.
3-Stainless Steel
-Stainlees steel with folded edges helps to prevent cuts.
7-TECHNICAL SPECIFICATION
MODEL
VOLTAGE POWER FREQUENCY SIZE
NET WEIGHT
SHIPPING WEIGHT
(V)
110
FWD1-33 518 60
17” 5/8x33”3/9x18” 1/2
44 51
(W) (Hz) (inches) (lb) (lb)

8-General Safety Practices
The following safety instructions are addressed to both the operator of the
machine as well as the person in charge of maintenance.
The machine has to be delivered to the operator in perfect conditions of use by
the Distributor to the user. The user shall operate the machine only after being well
acquainted with the safety procedures described in the present manual. READ THIS
MANUAL WITH ATTENTION.
Basic Operation Practices
Dangerous parts
Some parts of the electric devices are connected to high voltage points.
These parts when touched may cause severe electrical shocks or even be fatal.
Never touch commands such as buttons, switches and knobs with wet hands, wet
clothes and/or shoes. By not following these instructions operator could be exposed to
severe electrical shocks or even to a fatal situation.
Warnings
The operator has to be well familiar with the position of ON/OFF Switch to make
sure the Switch is easy to be reached when necessary. Before any kind of maintenance,
physically remove plug from the socket.
Provide space for a comfortable operation thus avoiding accidents.
Water or oil spilled on the floor will turn it slippery and dangerous. Make sure the floor is
clean and dry.
Before giving any manual command (switch, buttons, turn keys or lever) be sure
the command is the correct one. Check this manual for further details if necessary.
Never use a manual command (switch, buttons, lever) unadvisedly.
If any work is to be made by two or more persons, coordination signs will have to be given
for each operation step. Every step of the operation shall be taken only if the sign has
been made and responded.
Advices
In case of power shortage, immediately turn the machine OFF.
Use recommended or equivalent lubricants, oils or greases.
Avoid mechanical shocks as they may cause failures or malfunction.
Avoid penetration of water, dirt or dust into mechanical or electrical components
of the machine.
DO NOT modify original characteristics of the machine.
DO NOT remove, tear off or maculate any labels stuck on the machine. If any
label has been removed or is no longer legible, contact your nearest dealer for
replacement.
IMPORTANT
If any item from the GENERAL SAFETY NOTIONS section is not applicable to
your product, please disregard it.
04
service company ("Service Company"). Products held at commercial facilities and weighing
less than seventy (70) lbs. must be taken or shipped, shipping charges are prepaid, either
to SKYFOOD's facility or to a Service Company. Mileage or travel time will NOT be paid.
SKYFOOD offers a limited on-site warranty for products ONLY held at commercial
facilities, whose net weight exceeds seventy (70) lbs., provided they are installed in a
location that is within a thirty (30) mile radius of a Service Company. End Users are
responsible for all extra travel and mileage rates. In this case, warranty services will be
provided during regular business hours.
This product will be replaced or repaired under warranty, for a period of (1) year,
beginning from the date of purchase by the original purchaser/user (“End User”).
Accessories will be replaced or repaired under warranty, for a period of (30) days,
beginning from the date of purchase by the original purchaser/user (“End User”).
This warranty shall not take effect until a properly completed and executed WARRANTY
REGISTRATION form has been received by SKYFOOD EQUIPMENT, LLC, wit hin thirty
(30) days from the date of purchase. The WARRANTY REGISTRATION is available either
in the Instruction Manual of every Product or at SKYFOOD’s website www.skyfood.us. The
End User must fill out the WARRANTY REGISTRATION form and send it to SKYFOOD
according to the instructions posted on the referred website. Failure to do so will VOID
the warranty.
For questions or assistance, do not return the product or accessories to the store, please
call Toll Free 1 -800-503-7534 for Customer Support, or visit the Customer Service section
of www.skyfood.us. For faster service please have the items name, serial number, and
proof of purchase for the operator to assist you.
SKYFOOD reserves the right to change the terms of its limited warranty at any time
without any prior notice. It also reserves the right to change the design and
specifications of its equipment or any related documentation at any time. The end
user is not entitled to upgrades or refunds resulting from these changes.
Updates
These Terms and Conditions were last updated on August 22th, 2011.

SAFETY PROCEDURES AND NOTES BEFORE SWITCHING ON
IMPORTANT
Carefully read ALL INSTRUCTIONS of this manual before turning the machine ON.
Be sure to be familiar with the instructions and that you have well understood all
information contained in this manual. If you have any question contact your
supervisor or your nearest Dealer.
Danger
An electric cable or electric wire with damaged jacket or bad insulation could
cause electrical shocks as well as electrical leak. Before use, check conditions of all
wires and cables.
Advices
Be sure ALL INSTRUCTIONS in this manual have been thoroughly understood.
Every function and operational procedure have to be very clear to the operator.
Contact your nearest Dealer for further questions.
Any manual command (switch, button or lever) shall be given only after being
sure it is the correct one.
Precautions
The electric cable has to be compatible with the power required by the machine.
Cables touching the floor or close to the machine need to be protected against short
circuits.
AFTER THE WORK ENDS
Cares
Always clean the machine, to do the cleaning SWITCH IT OFF, AND TAKE
OUT THE PLUG FROM THE ELECTRICITY SUPPLY SOCKET .
Never clean the machine BEFORE IT IS COMPLETELY STOPED.
Fit all the machine components in their due places, before switching it on
again.
MAINTENANCE
Dangers
Any maintenance is dangerous if made with the machine switched on.
SWITCH IT OFF AND TAKE OUT THE PLUG FROM THE SOCKET, DURING
ALL THE MAINTENANCE OPERATION.
IMPORTANT
In any emergency situation, always take the plug out of its socket.
ADVICES
Electrical or mechanical maintenance shall be made by qualified persons.
The person in charge of the maintenance performances shall check the machine works
under TOTAL SAFETY CONDITIONS.
05
SKYFOOD EQUIPMENT LLC - SERVICE
For questions or assistance with products FLEETWOOD by SKYMSEN and SKYMSEN,
call SKYFOOD EQUIPMENT Toll Free : 1-800-503-7534, 24h Customer support, or visit
the Customer Service section of www.skyfood.us.
SKYFOOD’S LIMITED WARRANTY
Unless otherwise specified,new FLEETWOOD by SKYMSEN and SKYMSEN products,
excluding accessories, sold by SKYFOOD EQUIPMENT, LLC. (“SKYFOOD”), for use only
in the continental United States (collectively, “Products” or singularly, “Product”), are
warranted to be free from defects in materials and workmanship for a period of one (1)
year from the date of purchase by the original purchaser/user (“End User”). Several new
products and accessories may be warranted for a period other than one (1) year while
others may be subject to travel limitations, as specified on the products Instruction Manual.
Proof of purchase must be presented; if not this warranty will be VOID. No warranty is
given or implied to a subsequent transferee or any other third party. This warranty is
expressly conditional upon SKYFOOD being notified of any defects in materials or
workmanship within five (5) days of its occurrence, within the warranted time period. If a
notice of a claim under this warranty is timely made by the End User, SKYFOOD or a
SKYFOOD’s designated service company (“Service Company”), will repair or replace the
Product, at SKYFOOD’s discretion, subject to the additional conditions hereinafter
described.
This warranty shall not apply if damage occurs from improper installation or maintenance
performed by an unauthorized service company (“Service Company”), wrong voltage, nor
to the extent that Products or parts have been used other than in conformance with
operating and maintenance instructions, subjected to misuse or abuse or damaged by
accident, acts of God, abnormal use, stress or any other matter unrelated to SKYFOOD,
and beyond its reasonable control. This warranty does NOT cover service labor and
travel to perform adjustments on products and/or accessories. In addition to wear and
tear of certain items, such as, but not limited to; glass parts, blades, stones, chopper
cutting knives, plates, slicing knives, cutting disc, gaskets, oil changes, sealing tape, heat
seal wires, worm gears, self-lubricating bushings, carbon brushes for electric motors, and
other parts expendable by nature and that need to be replaced frequently. Electrical
components are subject to natural wear and tear, and are NOT covered by this
warranty. THIS WARRANTY EXCLUDES ALL ORAL, STATUTORY, EXPRESS OR
IMPLIED WARRANTIES WHICH MAY BE APPLICABLE TO SKYFOOD, INCLUDING,
BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE. Under no circumstances shall SKYFOOD be
liable for loss of use, revenue or profit or for incidental or consequential damages.
SKYFOOD shall under no circumstances be liable for any loss, damage, concealed
damage, expense or delay of goods for any reason when said goods are in the custody,
possession or control of third parties selected by SKYFOOD to forward, enter, clear,
transport, or render other services with respect to such goods. The sole and exclusive
remedy for breach of any warranty is limited to the remedies provided in the paragraph
above.
All products held at non-commercial facilities or domiciles, must be taken or shipped,
shipping charges prepaid, either to SKYFOOD's facility or a SKYFOOD's designated
