Airframe Installation Manual
2013/14 Skywalker Edition
Lay aircraft flat on belly. Draw a line straight down 9.5mm in front of wing support.
Measure back 3mm from line drawn and add another line down.
Using a suitable cutting tool cut between the lines from inner ceiling to top of
fuselage floor. This will create a vertical slot for the bulkhead fitting. Perform
same steps on opposite side of aircraft.
Ceiling
Floor
Insert plywood bulkhead through the cut out slots with triangle end down.
Glue in place.
Using dimensions shown mark aft door cut out. Bottom line should be flushed
114mm
114mm
89mm
Reattach front side foam cutout door with tape hinges.
Insert battery tray through cut out door and secure with screws to bulkhead.
Trim upper lip in areas marked red.
Continue to trim areas marked red or as needed. Nose cover will also be
trimmed as needed.
Insert gimbal with quick release hooks into plywood bulkhead. Adjust left/right
for clearance. Cut out belly for camera lens travel as needed.
