SkyZone SKY01 User manual

SKY01
FPV GOGGLES
USER MANUAL

System Content
FPV GOGGLE Carry case
Futaba ata cable JR ata cable WFLY ata cable
AV cable Power cable 5.8G 2 Bi antenna X 2

Function Diagram
Operation Instruction
Wireless
The FPV Google with Built-in 5.8Ghz Diversity Receiver an iversity Antenna inputs for best reception. It working in
iversity mo e to achieve goo signal utilization an improve the image quality.
It supports 4 Ban s an total 32channels (Ban s selection an Resulting Frequencies see etails in Specifications ）
））
）
Ban s Setup
· Long Press Button "BAND" to enter Bands setup (beeps indicating the current band) and press the Button "Band"
again within 3 seconds to select the Bands. Different beeps refer to different Bands.
· It ll return to normal working mode after 1 short beep if there is no operation within 3 seconds.
·
Beep Receiver BAND
1 short beep Band 1
2 short beep Band 2
3 short beep Band 3
4 short beep Band 4
Channel Setup

· Press Button "CH" once to select from CH1 to CH8. Different beeps refer to different channels.
Beep Receiver Channel
1 short beep CH1
2 short beep CH2
3 short beep CH3
4 short beep CH4
5 short beep CH5
6 short beep CH6
7 short beep CH7
8 short beep CH8
Hea Tracker
PPM Channel Setup
· Press and Hold Button "TRACK", then connect power to enter Head Tracker Setup Menu (Release as soon as beep).
Head Tracker beeps indicating the current PPM Channel. See details below.
· Short Press "TRACK" Button to select different PPM Channels. Long Press the button to enter Pan Tracking Range
setting mode.
·
Beep PPM Channel
1 short beep Pan CH5,Tilt CH6 (Factory default)
2 short beep Pan CH5,Tilt CH7
3 short beep Pan CH5,Tilt CH8
4 short beep Pan CH6,Tilt CH7
5 short beep Pan CH6,Tilt CH8
6 short beep Pan CH7,Tilt CH8
Pan Tracking Range Setting
· 1 long beep refers to 90 degrees, 2 long beeps refer to 180 degrees
· Short Press "TRACK" button to change the working Range with corresponding beep
· Long press "TRACK" to return (with 1 short beep) PPM channel setup mode.
Please isconnect the power after setup an then reconnect to enter normal working mo e.
Short press "TRACK" button is ok to setup hea tracker into Center position while working.
Front Camera
· The Front Camera is Wide-Angle Camera with 680X480(VGA) Resolution and good low Illumination. It s very
convenient to view around without taking off the Goggles.
· Press "Camera" button to open the Front Camera.
Volume
· Each boot is automatically set to the lowest volume to avoid sudden loud boot.
· A long beep indicates that you have reached the MAX or MIN Volume. .
Display Setup

Interpupillary istance（
（（
（IPD）
））
） A justable
· Pull the IPD Adjuster to adjust the interpupillary distance
Brightness/ contrast settings
· It s easy to setup the Brightness/Contrast with the 5-direction switch. Short press is to adjust gradually, long
press is to adjust continuously. It will auto saved if there is no operation within 5 seconds.
· Press Center button 3 seconds to setup Brightness/Contrast to factory default.
AV input
· The goggles support AV IN. The wireless model will close when the AV IN is connected to save power.
· The Front Camera is ok for use under AV IN mode.
AV output
· AV Out is the diversity Video and Audio output
· Earphone port is audio output for connecting earphones.

Specifications
Binocular Display
FOV 30 egrees (Diagonal)
Resolution 854X480(WVGA), 1,229,760 color sub-pixels
Brightness 350c /
㎡
㎡㎡
㎡
Interpupillary
istance （
（（
（ IPD ）
））
）
60-68mm A justable
Wireless Receiver
ISM 5.8GHz 32 Channel, Diversity receiver.
Ban
CH 1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
1 5865M 5845M 5825M 5805M 5785M 5765M 5745M 5725M
2 5733M 5752M 5771M 5790M 5809M 5828M 5847M 5866M
3 5705M 5685M 5665M 5645M 5885M 5905M 5925M 5945M
4 5740M 5760M 5780M 5800M 5820M 5840M 5860M 5880M
Sensitivity
-90 Bm ±
±±
± 1 Bm
Antenna port
2 X SMA,50ohm
Vi eo Stan ar
NTSC/PAL
Vi eo output level
1.0Vp-p Typ / 75ohm
Au io output level
1.0Vp-p Typ / 10Kohm
Front Camera
FOV 120 egrees (Diagonal)
Resolution 640X480(VGA)
FOCAL LENGTH
f=0.95mm
F/NO
F/NO=2.0
Hea Tracker Sensor Magnetic, Inertial an gyro
Output
PPM 8 channel, Optional 5-6CH,5-7CH,5-8CH,6-7CH,6-8CH,7-8CH
AV Port
Div. AV OUT(3.5mm4P)
Diversity Vi eo 、
、、
、 Au io output
EAR OUT(3.5mm3P)
32 Ω
ΩΩ
Ω /75mW or 16 Ω
ΩΩ
Ω /105mW, With volume control
AV IN(3.5mm4P)
Vi eo 、
、、
、 Au io input
Power Supply
DC IN
DC 7 ～
～～
～ 28V/ 1A
Power Consumption 12V input: 4.3W
Dimensions
168(L)X92.5(W)X41(H)mm (Not inclu e prominent part)
Weight
g
Operating Temperature
0 ℃～
℃～℃～
℃～ +55 ℃
℃℃
℃
