Slackers Ninjaline Pro Kit User manual

b4 Adventure 4040 Holly Street Unit 10 • Denver Colorado 80216 • 1-844-834-4334
QUESTIONS? [e-mail] · www.slackersline.com/help-center/ 303-339-0482 - DC:062716
www.b4adventure.com
1
For Ages 5+
Weight Limit: 250 LBS (113kg)
SLA.789 PRO KIT
Thank you for your purchase of the slackers™NINJALINE™ PRO KIT. This product was engineered to
provide safe fun for ages 5 and up. For best and safe results, please read instruc ons carefully when
installing and using your NINJALINETM. Read and obey all rules. We are sure that this product will
provide you with years of fun, fitness and enjoyment.
NOTE: THIS NINJALINE CAN BE USED AS A SLACKLINE TOO! SEE INSTRUCTIONS ON PAGE 5
KIT CONTAINS:
A. (1) NINJALINE™ with 12 sewn posi onsand ratchet.
B. (2) NINJAPIPE™ with locking delta clips.
C. (3) NINJABALLS™ with locking delta clips.
D. (2) NINJACONES™with locking delta clips.
E. (1) Gear carrying bag
Items Required (Not Included):
Step ladder
Warranty: (1) one year on all
Parts and workmanship.
1. BE SAFE! - ALWAYS FOLLOW THESE RULES
THIS PRODUCT IS INTENDED FOR USE BY AGES 5+.
•Adult supervision is required at all mes.
•Maximum user weight is 250 LBS (113kg).
•Maximum height(clearance) from NINJALINE™ user’s feet to
the ground when they are hanging from the lowest
NINJALINE™obstacle is 12 inches (31cm). Be safe, stay low.
•Every me you use the NINJALINE™, make sure everything is
installed correctly and check for wear before using.
•If worn or damaged parts are found, contact b4Adventure for
replacement parts - Do not subs tute with other, non-b4 Adventure parts or failure resul g in injury
could result.
•One person only at a me. Wear close fing, athle c style clothing, NO scarves or other loose clothing that
could become entangled.
•Never use the line when it is wet or if there is rain or lightning in the area.
•As with any type of exercise or athle c ac vity, you should consult your physician BEFORE engaging in the
ac vity.
FAILURE TO FOLLOW THESE RULES COULD RESULT IN SERIOUS INJURY
ADULT: SUPERVISION REQUIRED
SERIOUS INJURY OR DEATH MAY RESULT-
Always exercise extreme cau on when
using the NINJALINE™. Be sure to perform
MANDATORY load stress test before using
the line.
ADULT: ASSEMBLY REQUIRED –This
product should be unpacked and
assembled by an adult, including site and
tree selec on as well as the secure and
proper installa on.
WARNING: Un-Healthy Tree Hazard –
Do not a ach or use a tree that is not
healthy, diseased or damaged. It may fail
causing serious injury or death.
B
A
C
D
E

b4 Adventure 4040 Holly Street Unit 10 • Denver Colorado 80216 • 1-844-834-4334
QUESTIONS? [e-mail] · www.slackersline.com/help-center/ 303-339-0482 - DC:062716
www.b4adventure.com
2
ALWAYS SET YOUR NINJALINE™ UP IN BROAD DAYLIGHT. NEVER AT NIGHT!
2. CHOOSING THE NINJALINE™COURSE
Use extreme care when selecng a course.
•Choose a clear area for the NINJALINE™ with a sturdy anchor point, a healthy tree 38” (97cm) in
circumference or 12” (30.48cm) in diameter is recommended.
•If you are unsure about the health of your selected trees, consult with an arborist. Tip: One good
place start lookingfor an arborist - Visit: hp://www.isa-arbor.com/findanarborist/findanarborist.aspx.
•If you select a pole or post, it must be able to handle at least 2,500 lbs. (1134 kg) on both ends.
•Cauon: We recommend a so, grass course underneath that is clear of ALL obstacles: bushes,
rocks, or anything else that could cause injury. If the grass course becomes hard-packed over me,
move course to a soer locaon.
•It is also recommended that you place cushioningmaterials in and around your course - See Public
Playground Safety Handbook: Visit: www.cpsc.gov//PageFiles/122149/325.pdf. for specificaons.
•Select a locaon that is easily viewed from your house to allow for supervision and observaon.
•Do not setup course over swimmingpools, ponds, streams or rivers as drowningmay result.
3. NINJALINE™COURSE SET UP
YOU MUST INSTALL YOUR OBSTACLES WITH DELTA LOCKS IN YOUR NINJALINE BEFORE YOU TENSION
YOUR LINE!
•Layout your NINJALINE™, note the sewn in DELTA CLIP ½ inch (13mm) SLEEVES (12 each), these
are where you can insert and aach your obstacles. DO NOT ATTACH YOUR OBSTACLES
ANYWHERE ELSE ON THE LINE.
•DO NOT MODIFY YOUR NINJALINE™ OR OBSTACLES, USE ONLY b4Adventure NINJALINE™ Parts.
•Aach the obstacles keeping in mind the reach length your users will have. You may have to do
several different “layouts” to have a workable course. Note: Do not remove Delta Clips when the
line is under tension as you may damage your line.
HINTS FOR THE LAYOUT OF YOUR OBSTACLES:
For beginners: To get them started, install the obstacles closer together, so they are easier to reach.
For intermediate users:Aer some pracce, re-install the obstacles further apart from each other.
For experienced users: Space them even further apart. Add more NINJALINE™
obstacles to your line, up to 12 obstacles-Sold Separately. Go to slackersline.com
•To open the Delta clip simply twist open the locking poron of the clip. Fig.1
Insert the clip into the desired NINJALINE™, sewn line sleeve. Twist to close clip.
Note: the short, flat side of the clip is inserted for proper acon of the clip
CORRECT DELTA CLIP POSITIONNO! INCORRECT NO! INCORRECT
WARNING: Un-Healthy Tree Hazard –
Do not aach or use a tree that is not
healthy, diseased or damaged.It may fail
causing serious injury or death.

b4 Adventure 4040 Holly Street Unit 10 • Denver Colorado 80216 • 1-844-834-4334
QUESTIONS? [e-mail] · www.slackersline.com/help-center/ 303-339-0482 - DC:062716
www.b4adventure.com
3
4. INSTALLING YOUR NINJALINE™
DIAGRAM OF A NINJALINE™ SETUP
8 Tension sec on Obstacle course line sec on with 13 Clip openings Looped End sec on
1 2 3 4 5 6 7 8 9 10 11 12
Ratchet
Tree with ratchet line Tree with NINJALINE™ End
wrapped around. wrapped around
NOTE: YOUR RATCHET WILL ONLY TAKE UP ABOUT 1 foot of line!-READ INSTRUCTIONS CAREFULLY!
TO PROTECT YOUR TREES BARK FROM
POSSIBLE DAMAGE-Tree Huggerz
SLA.814 is available from b4Adventure
(Sold separately)
Step 1: Determine your course height.
WARNING: LINE HEIGHT SHOULD BE SET TO WHERE YOUR SHORTEST (HEIGHT) NINJALINE™ USER’S FEET
ARE ONLY 12 INCHES(31cm) MAXIMUM FROM THE GROUND AS THEY HANG FROM THE LOWEST
NINJALINE™ OBSTACLE.
•As a star ng height to set you line at, have the shortest (height) user reach up above their head as
high as they can, measure that height (from the ground to the ps of their outstretched hands) and
then add an addi onal 24 inches(62cm) which is 12 inches for clearance plus 12 inches for the
NINJALINE™ sagging towards the ground with the user’s weight. For example, your shortest Ninja is
72 inches (from the ground to their outstretched finger ps), add 24 inches, and your first line height
to test should be 86 inches from the ground.
•This may take one or two adjustments to get the desired 12 inches of clearance for the Ninja above
the ground.
Step 2: Wrap the ratchet and its line around your smaller diameter of the two trees you have selected for your course.
Thread the ratchet through the looped end. TIP: to keep you line flat, pinch the line to form a U-shape sec on where it
feeds through the looped end. See Figure 1 Pull the ratchet so the line is snug. See Figure 2.
Step 3: Take NINJALINE™ course line and using a stable step ladder, wrap around the other tree and ghten keeping
line flat and not twisted-see TIP in Step 2 on using a pinch line sec on. Pull the course line through (Figure 3).
FIGURE 1
FIGURE 2
FIGURE 3

b4 Adventure 4040 Holly Street Unit 10 • Denver Colorado 80216 • 1-844-834-4334
QUESTIONS? [e-mail] · www.slackersline.com/help-center/ 303-339-0482 - DC:062716
www.b4adventure.com
4
FIGURE 8
5. TIGHTENING YOUR NINJALINE™
Check to make sure you have both ends at the same, correct height.
Step 1: Feed the end of the NINJALINE through the ratchet, taking up
ALL the slack.Make sure the line is not twisted. YOU MUST Pull the
line ght before using the ratchet. The ratchet should befacing down.
See photo. You should be finished with ghtening when you cannot
ratchet anymore. The ratchet should be hidden under the line. YOUR
LINE SHOULD BE TIGHT.
Note: Make sure theline is threadedstraightthrough theratchet (not at an angle).
Failure to do this will weaken the ratchet and may cause it to break.
6. RELEASING THE RATCHET:
To remove or reposion your NINJALINEobstacles OR to take down your line, you will have to loosen your line first!
Step1: Toreleasetheratchet,pullupthevinylcoatedgateinsidethe
ratchethandleandopenallthewayunlFLAT .EXPECTA“POP”
Step2: Thesecondreleasegateshouldopen,releasingthespooland theline
tensionshould “pop” openwithNINJALINE releasing.
Step3: Connuetopullonthelinellthereisliletensionle. You can now
reposion or remove your obstacles.
Slidetheremaininglineoutoftheratchet.
Note: To release all gates, open ratchet flat.
Webbing will be free to unwind.
7. MANDATORY LOAD STRESS TEST
Step 1: Make sure all your connecons are ght –
See INSTALLING YOUR NINJALINE™ secon
Step 2: MANDATORY LOAD STRESS TEST YOUR
LINE. Using either a 250 LBS(113kg) weight or
person, have them test the NINJALINE™ by
suspending the weight 5 feet(152cm) from each end.
Step 3: Keep your course clear - Bystanders and pets should maintain a safe distance from the NINJALINE™ to
prevent impacts by person’s jumping down from the line. Always check for obstacles on the course.
FIGURE 5
FIGURE 6
FIGURE 7
FIGURE 4
WARNING: POSSIBLE INJURY OR DEATH – Remember a NINJALINE™ can be a potenally
dangerous piece of equipment and can cause serious injury or even death. Always use adult
supervision.

b4 Adventure 4040 Holly Street Unit 10 • Denver Colorado 80216 • 1-844-834-4334
QUESTIONS? [e-mail] · www.slackersline.com/help-center/ 303-339-0482 - DC:062716
www.b4adventure.com
5
8. USING YOUR NINJALINE™ WITH OBSTACLES
The NINJALINE™ course is a condioning course: You will
only improve over me. Do not expect to be able to
complete it the first couple of mes you try the course.
•Provide a stable, step ladder or short plaorm, for the users
to easily reach the first obstacle and start their way
down the course.
•For the first couple of mes, you may want to set the course
line height at a level where the users can be on their “ppy toes” taking some of their weight offtheir grips
on the obstacles. This way they can get used to compleng the course providing a sense of accomplishment,
and give their muscles me to condion and develop for greater challenges.
•Then gradually raise the line (and obstacle) height over me, unl the users areactually suspended above the
ground.
•Once the users have mastered a certain order of obstacles, change them up! Try spacing them further apart
too. Remember, you can add up to 12 obstacles on the course.
•Be paent and enjoy your NINJALINE™ course.
9. USING YOUR NINJALINE™ AS A SLACKLINE COURSE
Your NINJALINE™ can also be used as a basic slackline course, which is great for balance and core
condioning.
NOTE: Due to the double web construcon, the NINJALINE™ in only intended for basic slackline walking
and balancing. If you want to have a more challenging slackline, see b4 Adventure for the complete line of
slacklines visit: www.b4Adventure.com
•Remove all obstacles and Delta clips from your NINJALINE™. DO NOT ATTEMPT TO SLACKLINE WITH
ANYTHING ATTACHED TO YOUR NINJALINE™.
•Use the same precauons and instructions for aaching the NINJALINE™ EXCEPT the height for your
slackline setup will be only as high as the knee height of your shortest user-DO NOT EXCEED 3 feet in height
from the ground!
FIRST TIME SLACKLINER’S “THREEWORDS”:
SHORT- Use a short (and more stable)
Distance between posts/trees.
LOW- Set Slackline just above the height of the knee (standing on the ground) of the shortest person
using the line. This way it’s easy to step onto the line and begin.
TIGHT- By having the line tension a lile ghter, you gain more stability. Later, you can adjust
tension to fit your perfect LT-Line Tension.
SLACKLINE BASICS: Step onto the line with your feet while keeping your elbows up by your ears. Fix your
eyes down the line. DON’T LOOK DOWN! Looking at your feet will throw you offbalance even more.
Instead, by looking down the line or at the connecng posts/trees it helps your balance perspecve. RELAX
and
keep yourself loose, being rigid and upght prevents you from balancing properly. Your movement on the line
should be as fluid as possible.
WARNING: Adult Supervision Required –
SERIOUS INJURY OR DEATH MAY RESULT-Always
exercise extreme cauon when slacklining. Only
one person slacklining at a me.
