Installation Manual
SMA SPEEDWIRE/WEBCONNECT DATA MODULE
FA: xxxxx
SER: xx
SPWDM-10.BG1
FA: xxxxx
SER: xx
SPWDM-10.BG1
B
A

Legal Provisions SMA America, LLC
2 SWWEBCONDM-IA-US_en-14 Installation Manual
Legal Provisions
Copyright © 2014 SMA America,LLC. All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form
or by any means, be it electronic, mechanical, photographic, magnetic or otherwise, without the prior
written permission of SMA America, LLC.
Neither SMA America,LLC nor SMA Solar Technology Canada Inc. makes representations, express
or implied, with respect to this documentation or any of the equipment and/or software it may
describe, including (with no limitation) any implied warranties of utility, merchantability, or fitness for
any particular purpose. All such warranties are expressly disclaimed. Neither SMA America,LLC nor
its distributors or dealers nor SMA Solar Technology Canada Inc. nor its distributors or dealers shall
be liable for any indirect, incidental, or consequential damages under any circumstances.
(The exclusion of implied warranties may not apply in all cases under some statutes, and thus the
above exclusion may not apply.)
Specifications are subject to change without notice. Every attempt has been made to make this
document complete, accurate and up-to-date. Readers are cautioned, however, that
SMAAmerica,LLC and SMA Solar Technology Canada Inc. reserve the right to make changes
without notice and shall not be responsible for any damages, including indirect, incidental or
consequential damages, caused by reliance on the material presented, including, but not limited to,
omissions, typographical errors, arithmetical errors or listing errors in the content material.
All trademarks are recognized even if these are not marked separately. Missing designations do not
mean that a product or brand is not a registered trademark.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by SMA America,LLC and SMA Solar Technology Canada Inc. is under
license.
Modbus® is a registered trademark of Schneider Electric and is licensed by the Modbus
Organization, Inc.
Phillips® and Pozidriv® are registered trademarks of Phillips Screw Company.
Torx® is a registered trademark of Acument Global Technologies, Inc.
SMA America, LLC
3801 N. Havana Street
Denver, CO 80239 U.S.A.
SMA Solar Technology Canada Inc.
2425 Matheson Blvd. E
7th Floor
Mississauga, ON L4W 5K4
Canada

SMA America, LLC IMPORTANT SAFETY INSTRUCTIONS
Installation Manual SWWEBCONDM-IA-US_en-14 3
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions for the following product:
• SMA Speedwire/Webconnect Data Module
This manual must be followed during installation and maintenance.
The product is designed and tested according to international safety requirements, but as with all
electrical and electronic equipment, certain precautions must be observed when installing and/or
operating the product. To reduce the risk of personal injury and to ensure the safe installation and
operation of the product, you must carefully read and follow all instructions, cautions and warnings
in this manual.
Warnings in this document
A warning describes a hazard to equipment or personnel. It calls attention to a procedure or practice,
which, if not correctly performed or adhered to, could result in damage to or destruction of part or all
of the SMA equipment and/or other equipment connected to the SMA equipment or personal injury.
Symbol Description
DANGER indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
NOTICE is used to address practices not related to personal injury.

General Warnings SMA America, LLC
4 SWWEBCONDM-IA-US_en-14 Installation Manual
General Warnings
All electrical installations must be made in accordance with the local and NationalElectrical Code®
ANSI/NFPA 70 or the Canadian Electrical Code® CSAC22.1. This document does not and is not
intended to replace any local, state, provincial, federal or national laws, regulations or codes
applicable to the installation and use of the product, including without limitation applicable
electrical safety codes. All installations must conform with the laws, regulations, codes and
standards applicable in the jurisdiction of installation. SMA assumes no responsibility for the
compliance or noncompliance with such laws or codes in connection with the installation of the
product.
The product contains no user-serviceable parts.
For all repair and maintenance, always return the unit to an authorized SMA Service Center.
Before installing or using the product, read all of the instructions, cautions, and warnings in this
manual.
Wiring of the product must be made by qualified personnel only.

SMA America, LLC Table of Contents
Installation Manual SWWEBCONDM-IA-US_en-14 5
Table of Contents
1 Information on this Document. . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Validity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Target Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4 Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.5 Typographies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6 Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.7 Illustrations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4 Supported Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 Scope of Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1 Speedwire/Webconnect Data Module . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Possible Network Topologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3 Type Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.4 Cable Gland . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1 Mounting Position and Cable Route . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.2 Cable Requirements and Information on Cable Routing . . . . . . . . . . 16
5.3 Installing the Speedwire/Webconnect Data Module . . . . . . . . . . . . 17
5.4 Connecting the Speedwire/Webconnect Data Module . . . . . . . . . . 19

Table of Contents SMA America, LLC
6 SWWEBCONDM-IA-US_en-14 Installation Manual
6 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.1 Commissioning a Large-Scale PV Power Plant with
Cluster Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.2 Commissioning a Small-Scale PV System. . . . . . . . . . . . . . . . . . . . . . 22
6.3 Managing Small-Scale PV Systems with Sunny Explorer. . . . . . . . . . 23
6.3.1 Functions and Parameter Settings in Sunny Explorer . . . . . . . . . . . . 23
6.3.2 Creating a Small-Scale PV System in Sunny Explorer . . . . . . . . . . . 23
6.4 Configuring the Modbus Function . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.5 PV System Registration in Sunny Portal . . . . . . . . . . . . . . . . . . . . . . . 24
6.5.1 Registering a Large-Scale PV Power Plant with
Cluster Controller in Sunny Portal . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.5.2 Registering a Small-Scale PV System in Sunny Portal. . . . . . . . . . . . 24
7 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.1 Disassembling the Speedwire/Webconnect Data Module. . . . . . . . 26
7.2 Packaging the Speedwire/Webconnect Data Module for Shipping 26
7.3 Disposing of the Speedwire/Webconnect Data Module . . . . . . . . . 26
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
10 Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
11 Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

SMA America, LLC 1 Information on this Document
Installation Manual SWWEBCONDM-IA-US_en-14 7
1 Information on this Document
1.1 Validity
This document is valid for device type "SWDM-10.GRUS" (Speedwire/Webconnect data module)
from hardware version A and firmware version 1.00.20.R.
1.2 Target Group
The tasks described in this document must only be performed by qualified persons. Qualified persons
must have the following skills:
• Training in the installation and commissioning of electrical devices and systems
• Knowledge of how to deal with the dangers and risks associated with installing and using
electrical devices and systems
• Knowledge of all applicable standards and directives
• Knowledge of how an inverter works and is operated
• Knowledge of and compliance with this document and all safety precautions
1.3 Additional Information
Links to additional information can be found at www.SMA-Solar.com:
1.4 Symbols
Document title Document type
Firmware Update with SD Card Technical description
SMA Speedwire Fieldbus Technical information
SMA Modbus® Interface Technical description
SunSpec® Modbus® Interface Technical description
Symbol Explanation
Information that is important for a specific topic or goal, but is not
safety-relevant
☐ Indicates a requirement for meeting a specific goal
☑ Desired result
✖ A problem that might occur

1 Information on this Document SMA America, LLC
8 SWWEBCONDM-IA-US_en-14 Installation Manual
1.5 Typographies
1.6 Nomenclature
1.7 Illustrations
The illustrations in this document have been created for Sunny Boy inverters so there may be slight
deviations in the case of Sunny Tripower inverters.
Typography Explanation Example
Bold • Display texts
• Elements on a user interface
•Terminals
• Elements to be selected
• Elements to be entered
• The value can be found in the
field Energy.
• Select Settings.
•Enter the value 10 in the
Minutes field.
>• Connects several elements to
be selected
• Select Settings > Date.
[Button/Key] • Button or key to be selected or
pressed
• Select [Next].
Complete designation Designation in this document
Photovoltaic system PV system
Small-scale photovoltaic system Small-scale PV system
Large-scale photovoltaic power plant Large-scale PV power plant
SMA America Production, LLC SMA
SMA Solar Technology Canada Inc. SMA
SMA Cluster Controller Cluster Controller
SMA Speedwire Speedwire
SMA Speedwire/Webconnect data module Speedwire/Webconnect data module
SMA Webconnect function Webconnect function
SMA inverter Inverter

SMA America, LLC 2 Safety
Installation Manual SWWEBCONDM-IA-US_en-14 9
2 Safety
2.1 Intended Use
The Speedwire/Webconnect data module is a Speedwire communication interface with Webconnect
function for inverters.
Speedwire is a cable-based type of communication based on the Ethernet standard and the
communication protocol SMA Data2+. This enables inverter-optimized 10/100 Mbit data
transmission between Speedwire devices in PV systems. The Webconnect function enables direct data
transmission between the inverters of a small-scale PV system and the Internet portal Sunny Portal
without any additional communication device and for a maximum of four inverters per Sunny Portal
system. For this, a Speedwire/Webconnect data module must be installed in each of the inverters.
You can access your Sunny Portal system from any computer with an Internet connection.
The inverter still complies with the applicable standards after the product has been installed.
For safety reasons, it is not permitted to modify the product or install components that are not explicitly
recommended or distributed by SMA for the product.
The type label must remain permanently attached to the product.
Use the Speedwire/Webconnect data module only in accordance with the enclosed documentation
and with the local standards and directives. Any other application may cause personal injury or
property damage.
The enclosed documentation is an integral part of this product.
• Read and observe the documentation.
• Keep the documentation in a convenient place for future reference.
2.2 Safety Precautions
This section contains safety precautions that must be observed at all times when working on or with
the product. To prevent personal injury and property damage and to ensure long-term operation of
the product, read this section carefully and follow all safety precautions at all times.
Danger to life due to electric shock when opening the inverter
High voltages are present in the conductive components of the inverter. Touching live components
results in death or serious injury.
• Prior to performing any work on the inverter, always disconnect the inverter from all voltage
sources on both AC and DC sides (see inverter installation manual). Observe the waiting time
to allow the capacitors to discharge.

2 Safety SMA America, LLC
10 SWWEBCONDM-IA-US_en-14 Installation Manual
2.3 Operating Instructions
Risk of burns due to hot enclosure parts
Some parts of the inverter enclosure can get hot during operation. Touching these enclosure parts
can result in burn injuries.
• Do not touch any parts other than the lower enclosure lid of the inverter during operation.
Damage to the inverter or the Speedwire/Webconnect data module due to electrostatic
discharge
The internal electronic components of the inverter or the Speedwire/Webconnect data module can
be irreparably damaged by electrostatic discharge.
• Ground yourself before touching any electronic component.
High costs possible due to inappropriate Internet tariffs
When using the Webconnect function, a constant Internet connection is required.
Depending on the quality of the Internet connection, the data transfer volume for an inverter is
between 150 MB and 550 MB per month. If the system overview in Sunny Portal with live data
display is used, there will be an additional data volume of 600 kB per hour.
• Since the Internet connection to Sunny Portal is permanent, time-based billing systems should
be avoided. High costs could be incurred. SMA recommends using an Internet flat rate.
If UMTS is used, VoIP is required
If UMTS is used, VoIP (Voice over IP) is required to use the Webconnect function.
• Make sure that the UMTS provider can also provide a VoIP service.

SMA America, LLC 2 Safety
Installation Manual SWWEBCONDM-IA-US_en-14 11
2.4 Supported Products
SMA Inverters
The Speedwire/Webconnect data module can only be installed in the following SMA inverters from
the specified inverter firmware version:
Additional SMA Products
The Speedwire/Webconnect data module can be configured with the following communication
products:
• SMA Cluster Controller from firmware version 1.0
• Sunny Explorer from software version 1.06
• SMA Connection Assist from software version 1.00.8.R
Sunny Explorer and SMA Connection Assist are available free of charge at www.SMA-Solar.com.
SMA inverter*
* For information on which of these SMA inverters with Speedwire/Webconnect data module support the mode interface of
the Speedwire/Webconnect data module, refer to the datasheet "SMA_Modbus-DB-en.xlsx" at www.SMA-Solar.com.
From inverter firmware version
SB 3000TL-US-22 2.60**
** If the firmware version of the inverter is less than 2.60, you must perform a firmware update for this inverter to version 2.60
or higher. For information on performing a firmware update, refer to the technical description "Firmware Update with
SD Card" at www.SMA-Solar.com.
SB 3800TL-US-22
SB 4000TL-US-22
SB 5000TL-US-22
SB 6000TL-US-22 All
SB 7000TL-US-22
SB 7700TL-US-22
STP 12000TL-US-10 All
STP 15000TL-US-10
STP 20000TL-US-10
STP 24000TL-US-10

3 Scope of Delivery SMA America, LLC
12 SWWEBCONDM-IA-US_en-14 Installation Manual
3 Scope of Delivery
Check the scope of delivery for completeness and any visible external damage. Contact your
distributor if the scope of delivery is incomplete or damaged.
Order Option: Speedwire/Webconnect Data Module Pre-Installed in the Inverter
Figure1: Components of the order option "Speedwire/Webconnect data module pre-installed in the inverter"
Order Option: Speedwire/Webconnect Data Module as Retrofit Kit
Figure2: Components of the order option "Speedwire/Webconnect data module as retrofit kit"
Position Quantity Designation
A1 Installation manual
B 1 Cable gland
C 1 Label with PIC (Product Identification Code, identification key for
registering devices in Sunny Portal) and RID (Registration Identifier,
registration code for registering devices in Sunny Portal)
Position Quantity Designation
A 1 Speedwire/Webconnect data module (SWDM-US-10)
B1 Installation manual
C 1 Cable gland
D 2 Label with PIC and RID for registration of a small-scale PV system in
Sunny Portal
Sunny Portal Registration
PIC: xxxxxxxxxxxxxxx
RID: XXxXXX
ABCD
XXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXX
A
B

SMA America, LLC 4 Product Description
Installation Manual SWWEBCONDM-IA-US_en-14 13
4 Product Description
4.1 Speedwire/Webconnect Data Module
The Speedwire/Webconnect data module is a Speedwire communication interface with Webconnect
function for inverters.
Speedwire is a cable-based type of communication based on the Ethernet standard and the
communication protocol SMA Data2+. This enables inverter-optimized 10/100 Mbit data
transmission between Speedwire devices in PV systems.
The Webconnect function enables direct data transmission between the inverters of a small-scale
PV system and the Internet portal Sunny Portal without any additional communication device and for
a maximum of four inverters per Sunny Portal system. For this, a Speedwire/Webconnect data
module must be installed in each of the inverters. You can access your Sunny Portal system from any
computer with an Internet connection.
The Speedwire/Webconnect data module performs the following tasks:
• Setup of a Speedwire network in small-scale and large-scale PV systems
• Data exchange with Sunny Portal:
– In small-scale PV systems via a router with Internet connection
– In large-scale PV power plants via the Cluster Controller
• Data exchange with Sunny Explorer from software version 1.06
• The Modbus interface* of the Speedwire/Webconnect data module is designed for industrial
use and offers the following functions:
– Remote querying of measured values
– Remote setting of parameters
– Specification of setpoints for PV system control
The Speedwire/Webconnect data module is available as a retrofit kit or pre-installed in the inverter.
Figure3: Design of the Speedwire/Webconnect data module
* For information on which of the supported SMA inverters (see Section 2.4) support the Modbus interface of the Speedwire/
Webconnect data module, refer to the datasheet "SMA_Modbus-DB-en.xlsx" at www.SMA-Solar.com.

4 Product Description SMA America, LLC
14 SWWEBCONDM-IA-US_en-14 Installation Manual
Label with PIC and RID for registration of a small-scale PV system in Sunny Portal
To activate the Speedwire/Webconnect data module of a small-scale system in Sunny Portal, you will
need the PIC and RID numbers printed on the supplied label. After installation of the Speedwire/
Webconnect data module, one label should be attached to the exterior of the inverter in the vicinity
of the type label. Keep the other label in a safe place for future reference.
4.2 Possible Network Topologies
The possible network topologies depend on the devices used and on the number of network ports.
The Speedwire/Webconnect data module has two network ports. For further information on network
topologies, refer to the technical information "SMA Speedwire Fieldbus" at www.SMA-Solar.com.
4.3 Type Label
The type label clearly identifies the product. The type label is located in the right-hand top corner on
the front of the product. You can read the following data from the type label:
• Device type (Type)
•Serial number
• Hardware version (Version)
•PIC
•RID
•MAC address
You will require the information on the type label to use the product safely and when seeking customer
support from the SMA Service Line.
Symbols on the Type Label
Position Designation
A Hexagon socket screw (AF 3)
BNetwork port A
CNetwork port B
DRibbon cable plug
ERibbon cable
FType label
Symbol Designation Explanation
FCC marking The product complies with the requirements of the
applicable FCC standards.
Data matrix code 2D code for device-specific characteristics

SMA America, LLC 4 Product Description
Installation Manual SWWEBCONDM-IA-US_en-14 15
4.4 Cable Gland
The cable gland is used to fix the network cables to the inverter enclosure. The cable gland also
protects the interior of the inverter from dust intrusion and moisture penetration.
Figure4: Components of the cable gland
Position Designation
AFiller plug
BSeal
CSwivel nut
DCounter nut

5 Connection SMA America, LLC
16 SWWEBCONDM-IA-US_en-14 Installation Manual
5 Connection
5.1 Mounting Position and Cable Route
Figure5: Mounting position and cable route in the inverter with the lower enclosure lid open and the display
flipped up
5.2 Cable Requirements and Information on Cable Routing
The cable length and cable quality affect the signal strength in the Speedwire network. Observe the
following cable requirements and the cable routing information.
Position Designation
A Flipped up display
B Cable route to the network ports
C Inverter enclosure opening for cable gland or conduit fitting and conduit
•Size for Sunny Boy inverters (SB): 3⁄4 in (19 mm)
• Size for Sunny Tripower inverters (STP):
1 3⁄32 in (27.8 mm) to 1 7⁄64 in (28.0 mm)
D Mounting position of the Speedwire/Webconnect data module in the inverter
Interference in data transmission due to unshielded energy cables
If unshielded power cables are used, they generate an electromagnetic field during operation
which may induce interference in network cables during data transmission.
• When laying network cables, observe the following minimum clearances to unshielded
energy cables:
– For installation without separating strip: at least 8 in (200 mm)
– For installation with aluminum separating strip: at least 4 in (100 mm)
– For installation with steel separating strip: at least 2 in (50 mm)

SMA America, LLC 5 Connection
Installation Manual SWWEBCONDM-IA-US_en-14 17
Cable requirements:
☐ UV-resistant for outdoor use
☐ Number of conductor pairs and conductor cross-section: at least 2 x 2 x 24 AWG
(2 x 2 x 0.22 mm2)
☐ External diameter of cable:
– When using conduits: the maximum diameter of the cable depends on the size of the
enclosure opening at the bottom of the inverter and the number of network cables to be
inserted through the opening (see Section5.1 "Mounting Position and Cable Route",
page16).
– If using the supplied cable gland: max. 17⁄48 in (9 mm)
☐ Cable category: Cat5, Cat5e, Cat6, Cat6a, Cat7
☐ Cable shield: SF/UTP, S/UTP, SF/FTP, S/FTP
☐ Plug type: RJ45 for Cat5, Cat5e, Cat6, Cat6a
☐ Cable length between two nodes: max. 164 ft (50 m) with patch cable, max. 328 ft (100 m)
with installation cable
SMA recommends the following cable types:
• For outdoor use: SMA COMCAB-OUTxxx
• For indoor use: SMA COMCAB-INxxx*
The cables are available in the lengths xxx = 328 ft (100 m), 656 ft (200 m), 1,640 ft (500 m) and
3,280 ft (1,000 m).
5.3 Installing the Speedwire/Webconnect Data Module
2. Release the screw of the display far enough to
allow the display to be flipped up.
3. Flip the display up until it clicks into place.
1.
Danger to life due to electric shock when opening the inverter
High voltages are present in the conductive components of the inverter. Touching live
components results in death or serious injury.
• Disconnect the inverter from voltage sources on the AC and DC sides and open it (see the
inverter installation manual). Observe the waiting time to allow the capacitors to
discharge.

5 Connection SMA America, LLC
18 SWWEBCONDM-IA-US_en-14 Installation Manual
4. Push the pre-mounted filler plug out of the second
hole from the left in the inverter enclosure and retain
it for future decommissioning.
5. Attach the cable gland to the enclosure opening
using the counter nut.
6. Insert the Speedwire/Webconnect data module
and push the ribbon cable upwards behind the
display. The key on the top edge of the Speedwire/
Webconnect data module must fit into the hole in
the plastic retainer in the inverter.
7. Fasten the Speedwire/Webconnect data module
hand-tight with a torque of 13 in-lb (1.5 Nm) using
the hexagon socket screw (AF 3).
8. Flip the display down.
1
2

SMA America, LLC 5 Connection
Installation Manual SWWEBCONDM-IA-US_en-14 19
9. Plug the ribbon cable plug onto the center
connector strip.
10. Stick one of the labels with the data for registration in Sunny Portal (PIC and RID) on the outside
of the inverter in the vicinity of the type label.
11. If you do not wish to proceed immediately with the connection of the Speedwire/Webconnect
data module, close the inverter (see inverter installation manual).
5.4 Connecting the Speedwire/Webconnect Data Module
Depending on the system topology you require, you will need to connect either one or two cables to
the Speedwire/Webconnect data module.
Requirements:
☐ All electrical installations must be carried out in accordance with the electrical standards
applicable on site and the National Electrical Code® (NE, ANSI/NFPA 70).
☐ Installations in Canada must comply with the applicable Canadian standards.
☐ The network cables must be pre-assembled in accordance with the system topology and the
cable requirements (see Section5.2, page16).
Additionally required material (not included in the scope of delivery):
☐ Network cable (see Section5.2 "Cable Requirements and Information on Cable Routing",
page16)
☐ If cables are routed in a conduit:
– 1 rain-tight or wet-strength conduit fitting (diameter: 3/4 in)
– 1 conduit (diameter: 3/4 in)
Procedure:
2. Flip the display up until it clicks into place.
1.
Danger to life due to electric shock when opening the inverter
High voltages are present in the conductive components of the inverter. Touching live
components results in death or serious injury.
• If the inverter has not yet been opened, disconnect the inverter from voltage sources on
the AC and DC sides and open it (see the inverter installation manual). Observe the
waiting time to allow the capacitors to discharge.

5 Connection SMA America, LLC
20 SWWEBCONDM-IA-US_en-14 Installation Manual
3. Push the pre-mounted filler plug out of the second
hole from the left in the inverter enclosure.
4. If a conduit is to be used, proceed as follows:
• Insert one rain-tight or wet-strength conduit fitting into the enclosure opening and fasten from
the inside using a counter nut.
• Install one conduit at the enclosure opening.
• Lead one or two cables through the conduit into the inverter.
• Insert the network cables into the network ports. This can be done in any order.
5. If no conduit is to be used, proceed as follows:
• Attach cable gland to the enclosure opening
using the counter nut.
• Unscrew the swivel nut of the cable gland on
the inverter.
• Press the seal out of the cable gland from the
inside.
