  9. Smappee EV One Home User manual

Smappee EV One Home User manual

EV One HOME
Quick Install Guide
What’s in the box?
Safety warning
Carrying out electrical work within the home or
workplace can be dangerous and must be conducted
according to the appropriate national safety standards
and executed by a certified electrician.
For safety purposes, it is also necessary to power off
the installation before proceeding with the physical
installation.
For further safety instructions
and more detailed information,
please consult the full manual at
smappee.com/downloads
or via the QR code:
How to install EV One HOME
1Prepare the installation. Foresee a power supply &
communication cable between the EV One and the
distribution panel. Dig a hole for the anchor and ensure
the bottom is flat and stable.
2Take the EV One out of its packaging. Unscrew the two
bottom screws and slide the outer housing upwards, off
the internal structure. Take the anchor out and assemble
the anchor onto the main unit as shown in the diagrams.
If desired, the top half of the EV One can be temporarily
removed and set aside.
3Place the anchor n the ground. Route the power supply
and communication cable through the anchor and into
the EV One. Make sure it is level and the bottom of the EV
One will be flush with the ground level. Fill the hole with
concrete.
4Connect the power supply cable according to
the connection diagram. Connect the CAT 5/6
communication cable to the ‘A+B’ port.
In case of 3-phase delta (3*230 V), please consult the
full manual online.
5Connect the EV One modules as indicated in the diagram.
The Connect, the Splitter, the CT Hub and CTs are
installed inside the distribution panel. These components
communicate with the charging station via the CAT 5/6
communication cable.
6Switch on the power using the circuit breaker.
7Download the Smappee App and follow the instructions
to configure your Smappee charging station.
8Once Smappee Connect shows a green pulsing light,
validate the installation by verifying that the real-time
bubbles show correctly measured values in the Smappee
App/Dashboard.
9Slide the housing onto the EV One and tighten the
screws. Attach the door.
10 Use the Smappee app to send an invite to your
customer’s email address to share the newly created
location with them. This user account will be used for the
Smappee App and Dashboard and to set smart charging
preferences. Lastly, hand over the Quick Starter Guide.
EN
DIN mounting
plate
Wall mounting
plate
Splitter
Connect
CT Hub
CT 50A
RJ10 cable
40 cm
RJ10 cable
150 cm
Bus termination
plug
EV One HOME
Three phase
Connection diagram
Distribution Panel
Please don’t litter. Responsible publisher: Stefan Grosjean © Smappee nv - Evolis 104 -8530 Harelbeke, Belgium.
QIG – EV One Home Three phase Installers – 70-0180 – 2023/06
Manual
Connect the CT to measure
solar to the correct phase.
Adjust the configuration
in the Smappee App when
this is not the L1 phase.
When the solar installation
is 3-phased, you need to
purchase and install the
EV One solar add-on.
In case of 3-phase delta
(3*230 V), consult the full
manual via the QR code:
Installer
PE
NL1L2L3
RCD
RFID reader
Socket
Lock
Relay board
A+B
AB B
Power
box
1. 3.2. 4.
Quick Install
Guide
Door
QR code sticker Smart Charge
Card
Quick Starter
Guide
EV One Home
Door screw
×2
×4
25 cm
25 cm
17,6 cm
Sicherheitshinweis
Die Ausführung von Elektroarbeiten im Haus oder am
Arbeitsplatz kann gefährlich sein und muss gemäß den
entsprechenden nationalen Sicherheitsnormen und von
einem zertifizierten Elektriker durchgeführt werden. Aus
Sicherheitsgründen ist es außerdem notwendig, die Anlage
auszuschalten, bevor man mit der physischen Installation
fortfährt.
Weitere Sicherheitshinweise und
detailliertere Informationen finden
Sie in der vollständigen
Bedienungsanleitung unter
smappee.com/downloads
oder über den QR-Code:
So wird die EV One HOME installiert
1Bereiten Sie die Installation vor. Verbinden Sie bitte ein
Ethernet-Kabel mit stabiler Internetverbindung und ein
Stromversorgungskabel zwischen dem Verteilerkasten und
der EV One vor. Graben Sie ein Loch für den Anker und
stellen Sie sicher, dass der Boden flach und stabil ist.
2Nehmen Sie das EV One aus der Verpackung. Lösen
Sie die beiden unteren Schrauben und schieben Sie das
äußere Gehäuse nach oben von der inneren Struktur ab.
Nehmen Sie den Dübel heraus und montieren Sie ihn
auf der Haupteinheit wie in den Abbildungen gezeigt.
Falls gewünscht, kann die obere Hälfte des EV One
vorübergehend entfernt und beiseite gelegt werden.
3Setzen Sie den Anker in den Boden. Führen Sie das
Stromversorgungs- und Kommunikationskabel durch den
Anker und in das EV One. Vergewissern Sie sich, dass das
Loch eben ist und die Unterseite des EV One bündig mit
dem Boden ist. Füllen Sie das Loch mit Beton auf.
4Schließen Sie das Stromversorgungskabel gemäß
dem Anschlussplan an. Schließen Sie das CAT
5/6-Kommunikationskabel an den Anschluss 'A+B' an.
Im Falle von 3-Phasen-Dreieck (3*230 V) konsultieren Sie bitte das
vollständige Online-Handbuch.
5Schließen Sie die EV One-Module wie im Diagramm
angegeben an. Der Connect, der Splitter, der CT Hub und
die Stromwandler werden in der Verteilertafel installiert.
Diese Komponenten kommunizieren mit der Ladestation
über das CAT 5/6 Kommunikationskabel.
6Schalten Sie den Strom über den Schutzschalter ein.
7Laden Sie die Smappee App herunter und folgen Sie
den Anleitungen, um Ihre Smappee Ladestation zu
konfigurieren.
8Sobald Smappee Connect ein grünes pulsierendes
Licht anzeigt, validieren Sie die Installation, indem Sie
überprüfen, ob die Echtzeitblasen in der Smappee App/im
Dashboard korrekt gemessene Werte anzeigen.
9Schieben Sie das Gehäuse auf das EV One und ziehen Sie
die Schrauben fest. Bringen Sie das Türchen an.
10
Erstellen Sie ein Benutzerkonto für den Kunden und geben Sie
den Standort mit diesem neuen Benutzernamen frei. Notieren
Sie den Benutzernamen, das Passwort und die E-Mail-Adresse
auf dem Dokument Quick Starter Guide (welches mit dem Quick
Install Guide in der Verpackung enthalten ist) und geben Sie das
Ihrem Kunden. Dieses Benutzerkonto kann in der Smappee App
und im Dashboard verwendet werden, um smarte Ladepläne
einzurichten.
Veiligheidswaarschuwing
Elektrische werkzaamheden in huis of op het werk
kunnen gevaarlijk zijn en moeten worden uitgevoerd
volgens de geldende nationale veiligheidsnormen en
door een erkende elektricien. Om veiligheidsredenen
is het ook nodig de stroom van de installatie uit
te schakelen voordat u verder gaat met de fysieke
installatie.
Voor verdere veiligheidsinstructies
en meer gedetailleerde informatie
kunt u de volledige handleiding
raadplegen op
smappee.com/downloads
of via de QR-code:
Hoe EV One HOME te installeren
1Bereid de installatie voor. Voorzie een ethernetkabel met
stabiele internetverbinding, en voedingskabel tussen de
zekeringskast en de EV One. Graaf een gat voor het anker
en zorg ervoor dat de bodem vlak en stabiel is.
2Haal de EV One uit de verpakking. Draai de twee onderste
schroeven los en schuif de buitenste behuizing omhoog,
van de interne structuur af. Neem het anker eruit en
monteer het anker op de hoofdunit zoals aangegeven in de
diagrammen. Indien gewenst kan de bovenste helft van de
EV One tijdelijk verwijderd worden en opzij gezet worden.
3Plaats het anker in de grond. Leid de voedings- en
communicatiekabel door het anker en in de EV One. Zorg
ervoor dat het gat vlak is en dat de onderkant van de EV
One gelijk ligt met het maaiveld. Vul het gat met beton.
4Sluit de voedingskabel aan volgens het aansluitschema.
Sluit de CAT 5/6 communicatiekabel aan op de poort 'A+B'.
Raadpleeg in het geval van 3-fase delta (3*230 V) de volledige
online handleiding.
5Sluit de EV One modules aan zoals aangegeven in het
schema. De Connect, de Splitter, de CT Hub en de CT's
worden geïnstalleerd in het zekeringskast.
Deze componenten communiceren met het laadstation
via de CAT 5/6 communicatiekabel.
6Schakel de stroom in met behulp van de
stroomonderbreker.
7Download de Smappee App en volg de instructies om uw
Smappee laadpaal te configureren.
8Zodra Smappee Connect een groen pulserend licht toont,
valideert u de installatie door te controleren of de real-time
bollen correct gemeten waarden tonen in de Smappee App
/ Dashboard.
9Schuif de behuizing op de EV One en draai de schroeven vast.
Bevestig het deurtje.
10 Gebruik de Smappee-app om een uitnodiging te
sturen naar het e-mailadres van uw klant om de
nieuw aangemaakte locatie met hen te delen. Dit
gebruikersaccount zal worden gebruikt voor de Smappee
App en Dashboard en om slimme laadvoorkeuren in te
stellen. Overhandig tot slot de Quick Starter Guide.
Avertissement de sécurité
Les travaux électriques à domicile ou sur le lieu de
travail peuvent être dangereux et doivent être effectués
conformément aux normes de sécurité nationales
appropriées et exécutés par un électricien certifié.
Pour des raisons de sécurité, il est également
nécessaire de mettre l’installation hors tension avant
de procéder au montage.
Pour d’autres consignes de
sécurité et des informations
plus détaillées, veuillez consulter
le manuel complet sur:
smappee.com/downloads
ou via le code QR:
Comment installer EV One HOME
1Préparez l'installation. Prévoyez un câble Ethernet avec une
connectivité internet stable, et un câble d'alimentation entre
le panneau de distribution et l’EV One. Creuser un trou pour
l'ancrage et s'assurer que le sol est plat et stable.
2Sortez l'EV One de son emballage. Dévissez les deux vis
inférieures et faites glisser le boîtier extérieur vers le haut,
hors de la structure interne. Sortez l'ancre et montez-la
sur l'unité principale comme indiqué sur les schémas. Si
vous le souhaitez, la moitié supérieure de l'EV One peut
être temporairement retirée et mise de côté.
3Placez l'ancre dans le sol. Faites passer le câble
d'alimentation électrique et le câble de communication par
l'ancrage et dans EV One. Veillez à ce qu'il soit de niveau
et que le fond du EV One soit au même niveau que le sol.
Remplissez le trou avec du béton.
4Raccordez le câble d'alimentation électrique conformément
au schéma de raccordement. Raccordez le câble de
communication CAT 5/6 au port 'A+B'.
Dans le cas d'une alimentation triphasée en triangle (3*230 V),
veuillez consulter le manuel complet en ligne.
5Connectez les modules EV One comme indiqué sur le
schéma. Le Connect, le Splitter, le CT Hub et les TC sont
installés à l'intérieur du panneau de distribution. Ces
composants communiquent avec la station de charge via le
câble de communication CAT 5/6.
6Mettez l'appareil sous tension à l'aide du disjoncteur.
7Téléchargez l'application Smappee App et suivez les
instructions pour configurer votre borne de recharge
Smappee.
8Une fois qu'une lumière verte clignote au niveau de
Smappee Connect, validez l'installation en vérifiant que les
bulles en temps réel montrent des valeurs correctement
mesurées dans l'application Smappee App / Dashboard.
9Glissez le boîtier sur l'EV One et serrez les vis.
Fixez la petite porte.
10 Utilisez l'application Smappee pour envoyer une invitation
à l'adresse e-mail de votre client afin de partager avec lui
l'emplacement nouvellement créé. Ce compte utilisateur
sera utilisé pour l'application Smappee et le tableau de
bord, ainsi que pour définir les préférences de recharge
intelligente. Enfin, remettez le Quick Starter Guide.
DENLFR

Other manuals for EV One Home

4

Other Smappee Automobile Accessories manuals

Smappee EV Base User manual

Smappee

Smappee EV Base User manual

Smappee EV Base User manual

Smappee

Smappee EV Base User manual

Smappee EVB-2332-B-E User manual

Smappee

Smappee EVB-2332-B-E User manual

Smappee EV Base Ultra User manual

Smappee

Smappee EV Base Ultra User manual

Smappee EV Base Ultra User manual

Smappee

Smappee EV Base Ultra User manual

Smappee EV Base User manual

Smappee

Smappee EV Base User manual

Smappee EV One Home User manual

Smappee

Smappee EV One Home User manual

Smappee EV One Home User manual

Smappee

Smappee EV One Home User manual

Smappee Infinity User manual

Smappee

Smappee Infinity User manual

Popular Automobile Accessories manuals by other brands

Cruz 913-356 Assembly instructions

Cruz

Cruz 913-356 Assembly instructions

DELTA PLUS EZ-COM user manual

DELTA PLUS

DELTA PLUS EZ-COM user manual

OEM Tools 25896 Installation and operation manual

OEM Tools

OEM Tools 25896 Installation and operation manual

MetaSystem FrontPlate4 manual

MetaSystem

MetaSystem FrontPlate4 manual

NAV TOOL NAVRGB6.0-VI+MBCIRC installation manual

NAV TOOL

NAV TOOL NAVRGB6.0-VI+MBCIRC installation manual

FormFit Tough Guard TG 6M10 installation instructions

FormFit

FormFit Tough Guard TG 6M10 installation instructions

pro user BRILJANT Assembly instruction and safety regulations

pro user

pro user BRILJANT Assembly instruction and safety regulations

Eelink TK419 Series user manual

Eelink

Eelink TK419 Series user manual

TypeS MICRO LIGHT KIT instruction manual

TypeS

TypeS MICRO LIGHT KIT instruction manual

Silvercrest SBTF 10 B2 operating instructions

Silvercrest

Silvercrest SBTF 10 B2 operating instructions

HandyTech SPEED & BRAKE user manual

HandyTech

HandyTech SPEED & BRAKE user manual

Omegalink CRIMESTOPPER OL-HRN-RS-HA7 install guide

Omegalink

Omegalink CRIMESTOPPER OL-HRN-RS-HA7 install guide

GreenValley EVASION 2 instructions

GreenValley

GreenValley EVASION 2 instructions

MRHANDSFREE CAR KIT GENIUS datasheet

MRHANDSFREE

MRHANDSFREE CAR KIT GENIUS datasheet

GreenValley EASY ONE 156.035 Assembly and usage instructions

GreenValley

GreenValley EASY ONE 156.035 Assembly and usage instructions

Air Lift 1000 installation guide

Air Lift

Air Lift 1000 installation guide

Nex-tech OBD II instruction manual

Nex-tech

Nex-tech OBD II instruction manual

Horn Tools HUFJIMGJLAD01 Mounting instructions

Horn Tools

Horn Tools HUFJIMGJLAD01 Mounting instructions

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
