SMART-AVI MXWall-LT User manual

1
Made in U.S.A. www.SmartAVI.com 1-800-AVI-2131
MXWall-LT
User Manual
All-in-one video wall and matrix solution with 1080p Full HD resolution output, integrated
converter & scaler, flexible creative configuration modes, and user friendly control
software!
4-Input and Up to 12-Output Video Wall Processor and Matrix Switch

2
TABLE OF CONTENTS Page
WHAT'S IN THE BOX? 2
INTRODUCTION 3
FEATURES 3
APPLICATIONS 3
TECHNICAL SPECIFICATIONS 4
HARDWARE INSTALLATION 5
AVAILABLE CONFIGURATIONS 6
FRONT PANEL CONTROLS 7
SOFTWARE INSTALLATION 8
USING THE SOFTWARE
 First time logging in
 Configuring Settings
 Connecting/Disconnecting LAN
9
USING THE SOFTWARE (Continued)
 Configuring VideoWall 10
USING THE SOFTWARE (Continued)
 Creating Inputs and Views 11
USING THE SOFTWARE (Continued)
 Adding USERS
 Creating Schedules
12
LIMITED WARRANTY STATEMENT 13
WHAT'S IN THE BOX
PART NO. QTY DESCRIPTION
MXWALL-LT-S 1 4-Input 12-Output Video Wall Processor and Matrix Switch
CCPWR06 1 Power supply cord
Manual 1 Quick Start Guide

3
INTRODUCTION
The MXWall-LT is an enhanced and fully scalable video wall controller. The MXWall-LT combines switching
with the high definition capabilities of a converter. Specifically designed and optimized for the most de-
manding environments and applications, the MXWall-LT lets users manage and route up to 12 HDMI or
DVI video sources to as many as 12 HD displays. There are a total of 4 card slots for input and output
cards. Each card has 4 ports. You can add input and output cards in any combination, but there must be
at least 1 input card and 1 output card in the final configuration. Capable of expanding any one HD signal
from as many as 4 to 12 large-scale screens at 1080p (1920x1080 @ 60Hz). Completely compatible with
HDCP and HDMI 1.4, the MXWall-LT reliably transmits HD content across scalable display configurations
in real-time for 24/7 uninterrupted use via HDMI or DVI outputs.
FEATURES
 Android companion applica-
tion for quick switching of lay-
outs from your mobile device.
 Complete hardware solution
 Plug-and-play ready
 Output resolution up to
1080p
 Reliable 24/7 uninterrupted
heavy duty use
 HDCP and HDMI 1.4 compli-
ant
 User-Friendly MXWall Man-
ager Software
APPLICATIONS
 Corporate or Educational
Presentations
 Airport Installations
 Wall Displays
 Digital Signage
 Dealer Rooms
 Control Rooms
 Shopping Centers
 Security
 Corporate Lobbies

4
TECHNICAL SPECIFICATIONS
VIDEO
Video Amplifier Bandwidth 3.2G
Input Video Signal Video (TMDS) 0.5~1.0Vpp
Input DDC Signal 5 volts
Compliances HDMI 1.4 and HDCP
Pixel Rates Clock frequency beyond 165Mpix/second
Format 4:4:4 and 4:2:2 data input formats
Input Resolution 480p, 720p, 1080i, 1080p
Output Resolution Up to 1080p (1920X1080@60Hz)
Input Card Format 4-port HDMI or DVI
Output Card Format 4-port HDMI or DVI
Video Input Up to 3 cards *
Video Output Up to 3 cards *
Video Type RGB/YCBCR : 24/30/36-bits,YCBCR: 8/10/12/16/20/24-bits
CONTROLS
Front 2x8 keyboard with 4x40 LCD
RS-232 DB9 Female, 115200 BPS, N, 8, 1, No flow control
Network RJ45, UDP
OTHER
Working Temp. 32 to 122°F (0 to 50 °C )
Working Humidity Up to 85% RH (no condensation)
Storage Temp. -4 to 149 °F (-20 to 65 °C )
Storage Humidity Up to 90% RH (no condensation)
Weight 20 lbs. Unit Only
Dimensions 17 in (W) x 3.5 in (H) x 15 in (D)
Power Supply 50/60Hz, 100~230 VAC
* There are a total of 4 card slots for input and output cards. You can add input and output cards in any
combination, but there must be at least 1 input card and 1 output card in the final configuration.

5
HARDWARE INSTALLATION
1. Position MXWall-LT conveniently and keep it unplugged.
2. Connect displays to the MXWall-LT and power on the displays.
3. Connect any video source to the MXWall-LT.
4. Optionally connect an RS-232 cable from a PC to the RS-232 port on the unit for additional control.
5. Optionally connect an Ethernet cable to the MXWall-LT for additional control.
6. Turn on the MXWall-LT and wait a few seconds for the unit to initialize.

6
AVAILABLE CONFIGURATIONS
It is easy to create different configurations or modes that are easy to navigate through with the MXWall-LT.
There are endless possibilities. Creating and switching between display modes is simple. Front panel buttons,
on-screen-display, RS-232, and TCP/IP can be used to switch between modes at will.
VIDEO WALL MODE: Users can stretch an input
image across 4 to 12 HD screens with screen
resolution of 1920x1080.
INDIVIDUAL MODE: Users can route individ-
ual input images to each display individually.
QUAD MODE: Create 4
four proportional sec-
tions, each displaying one
of any 4 input images.
User defined custom displays can be created with
supplied software: Users can populate individual
screens with multiple inputs. Add any of the input
signals to play along side others within a single dis-
play.

7
FRONT PANEL CONTROLS
The front panel of the MXWall-LT allows you to quickly set up IP address, Baud Rate, and control input and
outputs.
Press the “Menu” button, and a Menu of items will appear in the green screen. You can use the buttons on
the far right to go up or down or simply press the number next to the option you want.
Baud: Option 1 will allow you to set the BAUD rate. You will have four options.
Simply press the button with of the BUAD rate located to the left or navigate using the two far right buttons.
Press “Enter” once the Baud Rate has been selected.
Mch ID: Option 2 lets you control multiple video walls through 1 computer.
IP Addr: Option 3 will allow you to set your IP address. Once inside IP you will see two options:
Press 2, Then the “Mode” button to enter your IP address manually using
the number buttons on the front panel. Once you have input your IP ad-
dress press the “Enter” button and the “Save” button.
Buzz: Option 4 allows you to turn the Buzzer ON or OFF.
MPort: Option 5 allows you to set your port. Simply use the buttons located on the panel. Then hit “enter”
and “Save”
IMPORTANT: These settings must match what you use in the MXWall-LT software. If you use the default set-
tings or custom settings make a note of them so you can enter them into the MXWall-LT software settings
during software install.

8
SOFTWARE INSTALLATION
1. Run setup.exe (Provided with the MXWallProInstaller software)
2. A Setup window will pop open. Click ‘Next >’ to continue (Figure 8-1). Subsequently select where you
would like to save MxWallPro and who the users will be and click ‘Next >’. (Figure 8-2)
3. You will be asked to confirm the installation. Click ‘Next>‘ to continue. (Figure 8-3)
4. Your System may ask if its ok for the installer to make changes to your computer. Click the Yes button
to continue. (Figure 8-4)
5. When the installation is complete a window will appear stating whether the installation was successful
or not. Click the Close button to exit. (Figure 8-5)
6. Execute the MXWallPro.exe shortcut to start the MXWall Pro software. (Figure 8-6)
Figure 8-1
Figure 8-3
Figure 8-5
Figure 8-2
Figure 8-4
Figure 8-6

9
USING THE SOFTWARE
First Time Logging In
1. Run MxWallPro
2. Log in using the default Account Settings. Username ‘Administrator’ Password ‘admin’, then click
the ‘ENTER’ button. (Figure 9-1)
Figure 9-1
Configuring Settings
1. Click on ‘SETTINGS’ Located in the top blue bar. (Figure 9-2)
2. A pop up window of Settings will appear. Here you can set the Serial port, Baud Rate, IP Address and-
Port number. (Figure 9-3)
3. Once everything is set, Click on ‘Set up’ on Com Port Side and IP Address side and click on the ‘x’ on
the top right corner to close the box
Connecting/Disconnecting LAN
1. Click on ‘LAN’, Once connected the red circle with an X in it will disappear as shown in figure 9-4.
2. To disconnect LAN click LAN again. The red circle with an X indicates that you are not connected as
shown in figure 9-5. Connecting to the RS-232 COM port functions in the same way. See Figure 9-6.
Figure 9-2
Figure 9-3
Figure 9-4 Figure 9-5 Figure 9-6

10
USING THE SOFTWARE (Continued)
Configuring VideoWall
After Logging in, Navigate with your mouse to the top, and click on ‘VideoWall’
On the right side of the VideoWall settings window under ‘Resolution’ you can use the pull down menu to
select the resolution. Click on the + or —buttons to set the number of Rows and Columns in your Video
Wall array. (Figure 10-1)
Figure 10-1
