SMART-AVI SM3-UHX-2D User manual

TECHNICAL SPECIFICATIONS WHAT’S IN THE BOX
VIDEO
Fornat HDMI2.0
Maximum Pixel Clock 165 MHz
Input Interface (2) DisplayPort; (2) HDMI
Output Interface (2) HDMI
Resolution 3840 x 2160 @ 60 Hz
Color Mode 24-bit
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft
Output Cable Length Up to 20 ft
Data Rate 1.65 Gbps per color
Console Monitors Supports both digital and analog
monitors
AUDIO
Input Interface (2) 3.5 mm Stereo Audio
(2) 3.5 mm Stereo Microphone
Output Interface (1) 3.5 mm Stereo Audio
(1) 3.5 mm Stereo Microphone
Impedance 600 Ohm
Frequency Response 20 Hz to 20 kHz
Nominal Level 0-1.0 V
Common Mode Rejection at 60 dB
SOFTWARE COMPATIBILITY
Operating Systems Windows, DOS, Linux, Unix, Mac, etc.
USB
Signal Type USB 3.0, 2.0, 1.1, and 1.0 w/
internal hub
Input Interface (2) USB Type B
Output Interface
(2) USB 1.1 Type A for KM Devices;
(2) USB 3.0 Type A Transparent;
(1) USB Type C
OTHER
Power Input: 100-240 VAC, 50/60Hz, 0.8A
Output: 12V, 2A
Dimensions 6.57”W x 3.31”D x 1.26”H
Weight 0.5 lb
Approvals UL, CE, ROHS Compliant
Operating Temp. +32 to +104°F (0 to +40°C)
Storage Temp. -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (No Condensation)
Emulation Keyboard and Mouse
PART NO. QTY DESCRIPTION
SM3-UHX-2D 1 2-Port Dual Head DP/HDMI to
HDMI KVM Switch with USB 3.0
PS12VDC2A 112VDC, 2A power adapter with
center-pin positive polarity.
1Quick Start Guide
DESIGNED
AND MADE
IN THE USA
NOTICE
The information contained in this document
is subject to change without notice. iPGARD
makes no warranty of any kind with regard
to this material, including but not limited to,
implied warranties of merchantability and
tness for a particular purpose. iPGARD
will not be liable for errors contained
herein, or for incidental or consequential
damages in connection with the furnishing,
performance, or use of this material. No
part of this document may be photocopied,
reproduced, or translated into another
language without the prior written consent
from iPGARD, Inc.
20170518
Toll Free: (888)-994-7427
Phone: [phone]
Fax: [phone]
WWW.iPGARD.COM
A full manual can be downloaded from
www.ipgard.com/SM3-UHX-2D/
SM3-UHX-2D
2-Port Dual-Head DP/HDMI to HDMI
KVM Switch with USB 3.0
Quick Start Guide

HARDWARE INSTALLATION
1. Connect HDMI monitor to the “HDMI Out” console ports on the front panel of the KVM
switch.
2. Connect your USB keyboard and USB mouse directly to the USB keyboard and mouse ports
on the front panel of the KVM switch.
3. Connect the microphone and speaker to the corresponding 3.5 mm Mini Stereo console
jacks on the front panel of the KVM switch.
4. Connect your USB devices into the USB ports. (Optional).
5. Be prepared with the related cables, plug the HDMI, USB, microphone, and speaker
connectors into their corresponding sockets on the back panel of the KVM switch
6. At the other end of the cable set, plug the HDMI, USB, microphone, and speaker connectors
into their respective ports on the rst computer (PC-1).
7. Repeat above steps to add the second computer (PC-2).
8. Connect the power supply to the KVM switch, and then plug it into an appropriate power
source.
9. Turn on the power to all connected devices.
PC Port Switching
There are two ways of accessing computers
and devices connected to the KVM switch:
• Manual Push-button
• Hotkey
Manual Pushbutton
• Press the push-button once to switch
the selected PC port between the two
connected computers cyclically
Hotkey
• Hotkeys are executed using the keyboard
• The following describes the hotkey
functionality availability
Hotkey Execution Procedure:
1. Press [Scroll Lock] key twice continuously
to enter “Hotkey” mode. When entering or
exiting from “Hotkey” mode, the buzzer of
the KVM switch sounds with beep.
2. Pressing [Scroll Lock] key twice
continuously MUST be completed within 5
seconds.
3. Keying hotkey command MUST be
completed with 10 seconds, or it will be
aborted if exceeding
ScLk - Scroll Lock, ENT - Enter
Hotkey Command Description Function
[ScLk][ScLk][ENT]
or
[Ctrl][Ctrl][ENT]
PC-1 ◄ ► PC-2 PC port cyclic
switching
[ScLk][ScLk][B][Num]
or
[Ctrl][Ctrl][B][Num]
Number : 0 / 1
0 : Disable
1 : Enable (Default)
Buzzer switch
ON/OFF
[ScLk][ScLk][S]
or
[Ctrl][Ctrl][S]
How to stop Auto-
Scan when it’s on:
1. Press any key.
2. Press once the
pushbutton.
When Auto-Scan
stops, PC port is
switched to the one
being scanned.
Auto-Scan
enabling
[ScLk][ScLk][I][Num][ENT]
or
[Ctrl][Ctrl][I][Num][ENT]
Number : 5~99
(Default : 8)
Auto-Scan
time interval
setting
OPERATION
HDMI IN
HDMI OUT
DP IN
USB IN
USB K/M OUT
USB 2.0 OUT
AUDIO IN
AUDIO OUT
MICROPHONE IN
