Smart Parking SmartSpot Lite 915-US User manual

COPYRIGHT RESERVED
The Information and Designs as detailed in this document are the property of SmartParking/Car Parking Technologies Limited, and shall be
returned on demand. It is issued on the strict condition that except with our written permission it shall not be reproduced, neither copied or
communicated to any third party, nor be used for any purpose other than that stated in the particular enquiry, order or contract with which it is
issued. The reservation of copyright in this document extends from each date appearing thereon and in respect of the subject matter as it appeared
at that relevant date.
SmartParking Ltd, 2017.
SmartParking
SmartSpot Lite 915-US User Manual
(Internal Use Only)
Date:
30 October 2017
Author:
David Calder
Version:
1.2

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 2 of 11
Table of Contents
1. Document Details................................................................................... 3
1.1. Sign-Off......................................................................................3
1.2. Document Reviewers .................................................................3
1.3. Distribution List...........................................................................3
1.4. Version Information ....................................................................3
1.5. Document Contact......................................................................3
1.6. Support Contacts........................................................................3
2. Federal Communications Commission (FCC) Statement:.................. 4
3. Introduction............................................................................................ 5
3.1. Document Purpose.....................................................................5
3.2. Background................................................................................5
3.3. SmartInstaller Overview .............................................................5
4. SmartSpot Programing.......................................................................... 6
4.1. Flowchart....................................................................................6
4.2. Programming SmartSpots ..........................................................7
4.3. Synchronizing with SmartRep.....................................................8
5. Appendix A –Glossary........................................................................ 10
6. Appendix B –Amendment History..................................................... 11

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 3 of 11
1. Document Details
1.1. Sign-Off
John Heard
Chief Technical Officer
Roly Rogers
Head of R&D
1.2. Document Reviewers
Name
Title
Version
Don Lokuge
Developer - SmartInstaller
0.1
Kin Chan
Developer –SmartSpots & IGS
0.1
1.3. Distribution List
Name
Title
Version
TBD
1.4. Version Information
Version
Date
Description
1.0
1.1 and 1.2
30/10/2017
28/12/2017
Initial Publication
Include updated FCC Statement
1.5. Document Contact
Name:
David Calder
Title:
Technical Writer
Department:
Research & Development
Organisation:
SmartParking Ltd.
Contact:
Davi[email protected]
1.6. Support Contacts
NZ & Australia
Department:
SmartParking Helpdesk
Email:
[e-mail]
Phone:
[phone]
UK & elsewhere
Department:
SmartParking Helpdesk
Email:
[e-mail]
Phone:
[phone]

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 4 of 11
2. Federal Communications Commission (FCC)
Statement:
Rule 15.105(b): This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1) this device may not cause harmful interference and
2) this device must accept any interference received, including interference that may cause
undesired operation of the device.
You are cautioned that changes or modifications not expressly approved by Smart Parking
Technology Ltd could void the user’s authority to operate the equipment.
Radio Characteristics:
The operating frequency range is 902MHz to 928MHz, factory default is 915MHz. Oscillating
frequency is 32MHz, GFSK modulation. Texas Instruments CC1310 chipset.

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 5 of 11
3. Introduction
3.1. Document Purpose
The purpose of this document is to provide the step-by step-instructions for using the
SmartInstaller to program V3 SmartSpots. No other User operations are possible as operation the
V3 SmartSpot is entirely automatic once programmed.
3.2. Background
This document was created as part of the documentation of V3 of the SmartParking System,
which includes the on-site SmartSpot and IGS VDS equipment, the 3G network connecting it to the
SmartParking Cloud components, the SmartRep reporting user interface, and in this case; the
system configuration capability.
3.3. SmartInstaller Overview
SmartInstaller is a SmartParking Limited application that runs on a device running both the Android
Operating system and OTG (USB On The Go.), (i.e. a Samsung Galaxy 3 or later Smartphone,
Galaxy Note Tablet, etc.).
Also required is a SmartParking Limited proprietary dongle capable of rf communication with the
firmware on the SmartSpots.
An example using a Samsung Galaxy Smartphone is shown below:
The dongle connects to the Smartphone via the mini-USB port. Once connected, the LED on the
dongle should flash and the Smartphone will state that a USB device is connected.
Dongle Functionality
- RF –This is the same 915MHz radio equipment and protocol as used in the IGS
- LED –These are the TX/RX indicators for the RF

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 6 of 11
-
4. SmartSpot Programing
4.1. Flowchart
Start SmartSpot
Programing
SmartSpots Installed
(IGS commissioning
can begin)
Use the SmartInstaller to check
the SmartSpot is online and
write parameters to it
SmartSpot is
operating
normally?
Yes
No
SmartSpot must
be operating
normally before
moving on
Move to next location and
install and configure next
SmartSpot
All SmartSpots
installed and
operating?
No
Synchronise the SmartInstaller
SmartSpot information with
SmartRep
Yes
OUT OF SCOPE: Refer to the
IGS Installation and
programing manuals for
instructions
Follow instruction for
connecting to mains and
powering on
SmartSpot
powered up?
SmartSpot must
be working
Yes
No

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 7 of 11
4.2. Programming SmartSpots
This is done at the SmartSpot immediately after it is first powered up.
The SmartInstaller V2.3.4 application configures each SmartSpot and connects it to the site
network.
Step
Instructions
Example
1.
On the Select Mode screen, choose
SmartSpot:
2.
On the SmartLink Mode screen,
choose Validate SmartSpot:
3.
The SmartSpot Validate screen will
open:

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 8 of 11
Step
Instructions
Example
4.
Make sure the site and site code are
present and correct:
5.
Make sure the handheld is
connected to the server:
6.
Enter the SmartSpot id found in the
case (e.g. 54-36) into the two Device
Identity Fields
7.
Press Validate and Reset (magnet
or power) the SmartSpot, then wait
for SmartSpot validate success
message (process will take up to
5min to finish.)
8.
On the SmartLink Mode screen,
open the Test SmartSpot screen.
9.
Press Test SmartSpot and reset the
SmartSpot.
The SmartInstaller will keep
requesting SmartSpot Connection
status (minimum 5min) until it gets a
result.
If the installer returns FAIL:
At least one of the connection modules failed
to connect to SmartRep servers
10.
If the process failed, repeat step 9
until successful.
When the installer returns SUCCESS:
All Connection modules (SIM, Ethernet if
any) are connected to SmartRep Servers
4.3. Synchronizing with SmartRep
Once at least one SmartSpot has been correctly installed, SmartInstaller will be storing the
information to be uploaded to or synchronized with SmartRep. This can be done as often as you
like; any new parameters will override the old ones each, but MUST be done when all SmartSpots
on site have been validated and tested.

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 9 of 11
IMPORTANT:
Syncronisation cannot be reversed, only redone as many times as required to populate
SmartRep with complete and accurate information
Step
Description
1.
On the SmartLink Mode screen, choose Send Changes
to SmartRep:
2.
On the next screen choose Sync with SmartRep:
3.
When you press the ‘Sync with SmartRep’ button you
will be asked to confirm you wish to send all data to
SmartRep.
If confident in your programing work, choose ‘Yes.’
SmartRep will be updated with all the data of the
SmartSpots validated and tested during this session.
If SmartRep detects any issues, you will see the
following screen:
You must remedy these issues right away, and then re-
attempt synchronising with SmartRep.

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 10 of 11
5. Appendix A –Glossary
This section contains a full list of all the terms and abbreviations used throughout this document.
Term
Description
Dongle
A small device that plugs into a computer and serves as an adapter or
as a security measure to enable the use of certain software
OTG
USB On-The-Go allows USB devices such as digital audio players or
mobile phones to act as hosts, so other USB devices like a USB flash
drive, digital camera, mouse, or keyboard can be attached to them
SmartDongle
See Dongle
SmartSpot
Version 3.0 of the previous Zone controller –the sensor-to-internet
gateway..
V3 IGS
Version 3.0 of the parking bay vehicle sensor.
WIFI
1. Ameans allowing computers, smartphones, or other devices to
connect to the Internet or communicate with one another
wirelessly within a particular area.

SmartParking Ltd
R&D Department
Auckland, New Zealand
www.smartparking.com
V3 IGS Programing Manual v01
Page 11 of 11
6. Appendix B –Amendment History
This section contains a full listing of all amendments made to previous versions of this document
Version
Section
Description
0.1
Initial Draft.
1.0
Published
1.1
2.
Federal Communications Commission (FCC) Statement
1.2
2
Add 15.21 to FCC Statement
