Smart Witness SVC-P User manual

SVC-P
720P AHD Vehicle Camera
User Manual

Safety Advice
Please unpack the box carefully and identify that all the
parts are present.
Make sure you use the recommended power input. Damage caused
to the camera by incorrect voltage is not covered by the warranty.
Do not attempt to open the casing to access the camera. Damage
caused to the camera by tampering with the camera casing is not
covered by the warranty.
What’s in the box
•Camera
•Small screw tool

Introduction
The SVC-P is a 720P AHD Dome Camera.
It features a 3.6mm lens and has a viewing angle between 90-100°.
Adjusting the Camera
To adjust the angle of the dome camera, use the screw tool provided and unscrew
the screws located on the sides of the camera. There are 3 in total.
To unscrew, turn anticlockwise to open the screw from the base.
Then adjust the camera, remove the protective bracket holding it in place.

Adjusting the Camera Continued
Then adjust the camera manually with your hand to your preferred position.
After you have completed your adjustment, replace the protective bracket
Then close the casing of the camera and screw back the screws.

Video System
PAL
Pick Up Element
1/4” CMOS Image Sensor
Image Signal Process
Digital Signal Processing System
Lens / Viewing Angle 3.6mm Lens/120 Degree
Number Of Pixel
1280x720
Effective Pixels
Approximately 3 Megapixel
Resolution
AHD 720P
Power Supply
DC 12 ± 1A, Aviator connector to MDVR
Power Consumption
80mA
Scanning System
2:1 Interlace
Sensitivity
0.01 Lux (IR 10m)
S/N Ratio
Max 50 dB
Auto Gain Control
Auto
Mirroring
Optional (BV)
White Balance
Auto
Electronic Shutter
Auto: 1/50 S to 1/100,000 S (Pal)
Output
1 Vp-p Composite Video Output, 75
OHMS, Aviator connector to MDVR
Operating Temperature
-10°C ~ +60°C
Dimensions (HxWxD)
63 x 55 x 118 mm
Weight
270g
Specifications
SVC-P
Aviator connector
IR Range 10m
Video cable length 40cm
