(*1) Definition of HD: More than 720p with H.264 streaming capability at more than 30 fps.
IPELA ENGINE EX™V Series Cameras
IPELA ENGINE EX™V Series Cameras
Model name SNC-VM631 SNC-VM630 SNC-VM601 SNC-VM600 SNC-VM601B SNC-VM600B SNC-VM632 SNC-VM602 SNC-VB630 SNC-VB600 SNC-VB600B
Video compression format H.264 (High/Main/Baseline Profile)/JPEG
Codec streaming capability Triple streaming (any combination with H.264/JPEG, including multiple streams of the same format), CBR/VBR (selectable)
Computer display format (*1) (*1) (*1) (*1) (*1) (*1) (*1)
Maximum resolution 1920 x 1080 1920 x 1080 1280 x 1024 1280 x 1024 1280 x 1024 1280 x 1024 1920 x 1080 1280 x 1024 1920 x 1080 1280 x 1024 1280 x 1024
Outdoor use/Ingress protection No No No No No No IP66 IP66 No No No
Vandal resistant IK10 No IK10 No IK10 No IK10 IK10 N/A N/A N/A
IR illuminators No No No No No No Yes Yes No No No
Horizontal viewing angle 105.2° to 35.4° 105.2° to 35.4° 93.0° to 31.6° 93.0° to 31.6° 93.0° to 31.6° 93.0° to 31.6° 105.2° to 35.4° 93.0° to 31.6° 114.2° to 40.0° 100.0° to 35.7° 100.0° to 35.7°
Optical zoom ratio 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 2.9x optical zoom 2.9x optical zoom 2.9x optical zoom
Focal length f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f = 3.0 mm to 9.0 mm f = 3.0 mm to 9.0 mm f = 2.8 mm to 8.0 mm f = 2.8 mm to 8.0 mm f = 2.8 mm to 8.0 mm
Lens Mount Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens CS mount CS mount CS mount
Imager 1/2.9-type progressive
scan Exmor™ CMOS
sensor
1/2.9-type progressive
scan Exmor™ CMOS
sensor
1/3-type progressive
scan Exmor™ CMOS
sensor
1/3-type progressive
scan Exmor™ CMOS
sensor
1/3-type progressive
scan Exmor™ CMOS
sensor
1/3-type progressive
scan Exmor™ CMOS
sensor
1/2.9-type progressive
scan Exmor™ CMOS
sensor
1/3-type progressive
scan Exmor™ CMOS
sensor
1/2.9-type progressive
scan Exmor™ CMOS
sensor
1/3-type progressive
scan Exmor™ CMOS
sensor
1/3-type progressive
scan Exmor™ CMOS
sensor
Minimum illumination
Color: 0.1 lx, B/W: 0.07 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
Color: 0.1 lx, B/W: 0.07 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx, B/W:
0.04 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx, B/W:
0.04 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx, B/W:
0.04 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx, B/W:
0.04 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
Color: 0.1 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
B/W:0 lx (IR ON)
Color: 0.05 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
B/W:0 lx (IR ON)
Color: 0.1 lx, B/W: 0.07 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON, 1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx, B/W:
0.04 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx, B/W:
0.04 lx
(F1.2,View-DR OFF,
VE OFF, AGC ON, 1/30 s,
50 IRE, 30 fps)
Maximum frame rate 60 fps (H.264) at
1920 x 1080,
60 fps (JPEG) at
1280 x 720
60 fps (H.264) at
1920 x 1080,
60 fps (JPEG) at
1280 x 720
60 fps (H.264/JPEG)
at 1280 x 1024
60 fps (H.264/JPEG)
at 1280 x 1024
30 fps (H.264/JPEG)
at 1280 x 1024
30 fps (H.264/JPEG)
at 1280 x 1024
60 fps (H.264) at
1920 x 1080,
60 fps (JPEG) at
1280 x 720
60 fps (H.264/JPEG)
at 1280 x 1024
60 fps (H.264) at
1920 x 1080,
60 fps (JPEG) at
1280 x 720
60 fps (H.264/JPEG)
at 1280 x 1024
30 fps (H.264/JPEG)
at 1280 x 1024
Day/Night Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N)
Wide-D/Dynamic Range Yes / 90dB Yes / 90dB Yes / 130dB Yes / 130dB Yes / 130dB Yes / 130dB Yes / 90dB Yes / 130dB Yes / 90dB Yes / 130dB Yes / 130dB
Visibility Enhancer (VE) Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Noise reduction XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™
Image stabilization Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Card slot(s) SC card x 1; SDXC type SC card x 1; SDXC type SC card x 1; SDXC type SC card x 1; SDXC type SC card x 1; SDXC type SD card x1 SC card x 1; SDXC type SC card x 1; SDXC type SC card x 1; SDXC type SC card x 1; SDXC type SC card x 1; SDXC type
Wireless capability No No No No No No No No No No No
Composite video output Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
DEPA™ (Intelligence)
Audio capability Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC Yes, bi-directional AAC
ONVIF conformance (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S)
Power requirement PoE (IEEE 802.3af),
AC 24 V, DC 12 V
PoE (IEEE 802.3af),
AC 24 V, DC 12 V
PoE (IEEE 802.3af),
AC 24 V, DC 12 V
PoE (IEEE 802.3af),
AC 24 V, DC 12 V
PoE (IEEE 802.3af),
AC 24 V, DC 12 V
PoE (IEEE 802.3af),
AC 24 V, DC 12 V
HPoE (IEEE 802.3at),
AC 24 V, DC 12 V
HPoE (IEEE 802.3at),
AC 24 V, DC 12 V
PoE (IEEE 802.3af),
AC 24 V, DC 12 V
PoE (IEEE 802.3af),
AC 24 V, DC 12 V
PoE (IEEE 802.3af),
AC 24 V, DC 12 V
Power consumption 6.0 W max. 6.0 W max. 6.0 W max. 6.0 W max. 6.0 W max. 6.0 W max. TBD TBD 6.0 W max. 6.0 W max. 6.0 W max.
Dimensions ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø6 5/8 x 5 1/8 inches
(ø166 x 129 mm)
ø6 5/8 x 5 1/8 inches
(ø166 x 129 mm)
2 7/8 x 2 1/2 x 7 7/8
inches (72 x 63 x 197
mm) with lens
2 7/8 x 2 1/2 x 7 7/8
inches (72 x 63 x 197
mm) with lens
2 7/8 x 2 1/2 x 7 7/8
inches (72 x 63 x 197
mm) with lens
Quick Reference

©2013 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.Weights and measurements are approximate. Sony, IPELA ENGINE EX, DEPA,
Onvif, Exmor, XDNR, View-DR and the Sony make.believe logo are trademarks of Sony.All other trademarks are the trademarks of their respective owners.
MK11037V1OHB13MAR
IPELA ENGINE EX™ E Series Cameras
Model Name SNC-EB630 SNC-EB600 SNC-EB630B SNC-EB600B SNC-EM630 SNC-EM600 SNC-EM631 SNC-EM601 SNC-EM632 SNC-EM602
Video compression format H.264 (High/Main/Baseline Profile)/JPEG
Codec Streaming Capability Triple streaming (any combination with H.264/JPEG,including multiple streams of the same format), CBR/VBR (selectable)
Computer Display Format
(*1) (*1) (*1) (*1)
(*1)
Maximum Resolution 1920 x 1080 1280 x 1024 1920 x 1080 1280 x 1024 1920 x 1080 1280 x 1024 1920 x 1080 1280 x 1024 1920 x 1080 1280 x 1024
Infrared Illuminators No No No No No No No No Yes Yes
Ingress Protection No No No No No No No No IP66 IP66
Vandal Resistant No No No No No No IK10 IK10 IK10 IK10
Horizontal Viewing Angle 114.2° to 40.0° 100.0° to 35.7° 114.2° to 40.0° 100.0° to 35.7° 105.2° to 35.4° 93.0° to 31.6° 105.2° to 35.4° 93.0° to 31.6° 105.2° to 35.4° 93.0° to 31.6°
Zoom Ratio 2.9x optical zoom 2.7x optical zoom 2.9x optical zoom 2.7x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom 3.0x optical zoom
Focal Length f = 2.8 mm to 8.0 mm f = 3.0 mm to 8.0 mm f = 2.8 mm to 8.0 mm f = 3.0 mm to 8.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm f=3.0 mm to 9.0 mm
Lens CS mount vari-focal lens CS mount vari-focal lens CS mount vari-focal lens CS mount vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens Built-in vari-focal lens
Image Device 1/2.9-type progressive scan
Exmor™ CMOS sensor
1/3-type progressive scan
Exmor™ CMOS sensor
1/2.9-type progressive scan
Exmor™ CMOS sensor
1/3-type progressive scan
Exmor™ CMOS sensor
1/2.9-type progressive scan
Exmor™ CMOS sensor
1/3-type progressive scan
Exmor™ CMOS sensor
1/2.9-type progressive scan
Exmor™ CMOS sensor
1/3-type progressive scan
Exmor™ CMOS sensor
1/2.9-type progressive scan
Exmor™ CMOS sensor
1/3-type progressive scan
Exmor™ CMOS sensor
Wide-D/Dynamic Range Yes/ 90 dB Yes/ 90 dB Yes/ 90 dB Yes/ 90 dB Yes/ 90 dB Yes/ 90 dB Yes/ 90 dB Yes/ 90 dB Yes/ 90 dB Yes/ 90 dB
Image Enhancement
Visibility Enhancer (VE) Visibility Enhancer (VE) Visibility Enhancer (VE) Visibility Enhancer (VE) Visibility Enhancer (VE) Visibility Enhancer (VE) Visibility Enhancer (VE) Visibility Enhancer (VE) Visibility Enhancer (VE) Visibility Enhancer (VE)
Minimum Illumination Color: 0.1 lx,
B/W: 0.07 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx,
B/W: 0.04 lx
(F1.0,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
Color: 0.1 lx,
B/W: 0.1 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx,
B/W: 0.05 lx
(F1.0,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
Color: 0.1 lx,
B/W: 0.07 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx,
B/W: 0.04 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
Color: 0.1 lx,
B/W: 0.07 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
Color: 0.05 lx,
B/W: 0.04 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON,1/30 s, 50 IRE,
30 fps)
Color: 0.1 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
B/W:0 lx (IR ON)
Color: 0.05 lx
(F1.2,View-DR OFF,
VE OFF,AGC ON,1/30 s,
50 IRE, 30 fps)
B/W: 0 lx (IR ON)
Maximum Frame Rate 30 fps (H.264/JPEG) at
1920 x 1080
30 fps (H.264/JPEG) at
1280 x 1024
30 fps (H.264/JPEG) at
1920 x 1080
30 fps (H.264/JPEG) at
1280 x 1024
30 fps (H.264/JPEG) at
1920 x 1080
30 fps (H.264/JPEG) at
1280 x 1024
30 fps (H.264/JPEG) at
1920 x 1080
30 fps (H.264/JPEG) at 1280 x
1024
30 fps (H.264) at 1920 x 1080,
30 fps (JPEG) at 1280 x 720
30 fps (H.264/JPEG) at
1280 x 1024
Day/Night Yes (True D/N) Yes (True D/N) Yes (Electronic D/N) Yes (Electronic D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N) Yes (True D/N)
Noise Reduction XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™ XDNR™
Image Stabilizer Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Card Slots No No No No No No No No No No
Wireless Capability No No No No No No No No No No
Composite Video Output No No No No No No No No No No
Analog Monitor Output Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Scene Analytics
Intelligent Motion
Detection
Face Detection
Rule-based Filter
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
Yes
Yes
DEPA™ Advanced
ONVIF Conformance (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S) (Profile S)
Audio capability No No No No No No No No No No
Power Requirements PoE (IEEE 802.3af) PoE (IEEE 802.3af) PoE (IEEE 802.3af) PoE (IEEE 802.3af) PoE (IEEE 802.3af) PoE (IEEE 802.3af) PoE (IEEE 802.3af) PoE (IEEE 802.3af) HPoE (IEEE 802.3at), HPoE (IEEE 802.3at)
Power Consumption 6 W max. 6 W max. 6 W max. 6 W max. 6 W max. 6 W max. 6 W max. 6 W max. TBD TBD
Operating Temperature 14°F to 122°F
(-10°C to +50°C)
14°F to 122°F
(-10°C to +50°C)
14°F to 122°F
(-10°C to +50°C)
14°F to 122°F
(-10°C to +50°C)
14°F to 122°F
(-10°C to +50°C)
14°F to 122°F
(-10°C to +50°C)
14°F to 122°F
(-10°C to +50°C)
14°F to 122°F
(-10°C to +50°C)
-40°F to +122°F
(-40°C to +50°C) (*2)
-40°F to +122°F
(-40°C to +50°C) (*2)
Dimensions 2 7/8 x 2 1/2 x 7 7/8 inches
(72 x 63 x 199 mm) with lens
2 7/8 x 2 1/2 x 7 1/2 inches
(72 x 63 x 188 mm) with lens
2 7/8 x 2 1/2 x 7 7/8 inches
(72 x 63 x 199 mm) with lens
2 7/8 x 2 1/2 x 7 1/2 inches
(72 x 63 x 188 mm) with lens
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø5 7/8 x 4 3/8 inches
(ø148 x 108 mm)
ø6 5/8 x 5 1/8 inches
(ø166 x 129 mm)
ø6 5/8 x 5 1/8 inches
(ø166 x 129 mm)
(*1) Definition of HD:Vertical resolution of more than 720 pixels, and streaming capability of more than 30/25 fps at 1280 x 720 pixels. (*2) Operating condition details are not yet finalized.
Quick Reference Preliminary
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/security
