Smarteck Electronics QT-06 User manual

Smart Water Valve
User Manual

Contents
(1) The gateway connects with network tutorial
(2) Add sub-device tutorial
4. The mobile APP interface introduction
3.Network connection instructions
2. Product parameters
1. Product performance and function
Water pipe
Router
Smart water valve
Smart gateway
Smart water valve
Mobile phone/Tablet
812 Hose
Dual-purpose nozzle
Remote control via APP
Water pipe
Large area sprinkler
2.4Ghz

Product performances and functions:
Overview
● Performances
Controller operation: Remote control via APP, manually control on site, timing
control via APP.
Signal distance: The connection distance between the gateway and smart water timer
is about 50 meters
Battery: Standby time reaches 2 years by using 4 *AA alkaline dry batteries
waterproof level:IP66，The smart water timer can be installed and used outdoors.
● Functions
Remote control: The smart water timer can be remote controlled via APP at any time
and anywhere after the success of network connection between controller and mobile
phone.
Real-time feedback: When the smart water timer starts watering, the duration and
water consumption will be fed back to the APP interface in real time
Flow control: Two types of watering models, control the amount and time of watering,
can be switched at will.
Circulating irrigation: Setting of cyclic irrigation in two watering modles, for example:
according to the cyclic irrigation setting of water consumption, turn on the watering
capacity, select cyclic irrigation, set the amount of each watering, enter the number of
cycles and the interval of each watering , then watering can be cycled.
Timed watering: 4 groups of timed watering programs can be set, single time irrigation
or cycle irrigation.
Network disconnected operation: After setting the timing program, even if the
network is disconnected, watering can be performed according to the set timing
program, but the APP cannot be used to control after the network is disconnected.
Intelligent automation: It can be associated with other smart devices to realize
applications in different scenarios. For example: linked with the soil temperature
sensor, when it detects that the soil moisture value reaches the set value, the smart
water timer is automatically opened for watering, and automatically closed when the
task is completed.
Voice watering: support most smart voice devices such as Alexa, Google Assistant,
Tmall Wizard, DuerOS, etc., watering can be done by voice
Shared equipment: Can be shared with family members to use together
Create a group: you can control the devices in the same group at the same time
Historical records: Count the monthly watering time and total water consumption;
record each watering time and water consumption
Smart water timer button function
1.Matching with gateway
Rain and snow days delay: Turn on this function in rain and snow weather, and select
a delay time of 24 hours, 48 hours, or 72 hours to save water resources. This function
can also be cancelled at any time.
2.Operating the switch on site

Product parameters
½"or ¾"&1"
Ip66
0.2~8bar
Power
-10℃~+50℃
Power
DC5V/1A
Pairing/Switch
¾"water inlet
1 inch internal
thread water inlet
Battery slot
¾"external thread outlet
Smart water valve Smart gateway
Product
name
Product
name
Caliber
Waterproof
level
Withstand
water pressure
4*AA alkaline dry battery
Operating
temperature
Working
humidity
Signal
range Open area ≤ 100 meters
0-95%RH
No condensation
½"water inlet

Gateway networking tutorial
1、Press the switch key for 10s, the red indicator light will switch
to the flashing state
2、Open the smart home/Tuya smart APP to register and log in,
3、Click "+" in the upper right corner, or select "Add manually"
4、Click "Other" --- "Connector (WIFI)"
5、Enter the next page and enter the WIFI account and password
(same as the mobile phone connected to WiFi)
6、Click "Next" to go to the next page, tick "Confirm indicator flashes quickly"
7、Click "Next" to display the progress of adding devices
8、The red indicator light of the gateway is always on, and the network configuration
is successful.
①②③④
⑤⑥⑦⑧
The red indicator light is flashing fast

Gateway add sub-device
Fast mobile network distribution through mobile APP
1、Open the APP gateway interface and select "Accessories"
2、Select "Quick Add"
3、Press the power button of the sub-device quickly twice, the gateway
will send out a prompt ringtone, and the addition is successful
4、Add more sub-devices and repeat actions ②、③and ④（As shown).
①②③
④⑤⑥

Mobile APP Interface
It's easy to understand and operate
Water capacity
1.Single irrigation
2.Cycle irrigation
3.Control switch button
1. Real-time feedback
of watering time
2.Real-time feedback
of watering flow
Timing watering
1.Set timing by flow
2.Set timing by duration
Watering history
1.Total monthly watering volume
2.Records of each open
1.Last irrigation time
2.Remaining power
1.Next irrigation time
2.Current weather
Watering time
1.ingle
2
s irrigation
.cycle irrigation
3.Control switch button
Delay watering in rain
and snow weather

APP Download
Can't the mobile APP connect to the gateway?
1.Follow the steps in the operating instructions to restart the
connection once if it is not connected.
2.If you still can't connect, you can check several aspects to
check whether the WIFI and mobile phone network are in
normal use.
3. Confirm whether the WIFI name and wifi password are correct.
4. Whether the indicator of the sprinkler flashes quickly when
connected.
5. Confirm that the connected router is in the 2.4GHz band. If it is
in the 5G band, set it to the 2.4GHz band
Q&A
