Smartoptics DCP-SERIES User manual

QUICK INSTALLATION GUIDE
SMARTOPTICS DCP-SERIES
Before using the product, be sure to read the safety chapter and more
detailed information in the full installation manual. For full manual,
contact [email protected].
© Copyright Smartoptics 2016
DCP-2
Chassi
Slot A Slot B
Redundant
power supply
Communication
ports
Redundant
power supply
DCP-2
fan
COMMUNICATION INTERFACES
There are two ways to communicate with the unit:
- Through one of the five ethernet ports, using SSH
- Through the console port, using serial communication
Default login is
Username: admin
Password: admin
ETHERNET
All the communication ports are located on the back of the unit, DCP-2.
The factory default IP settings are
Eth local: 192.168.0.1
Eth1-4: 192.168.1.1
Netmask: 255.255.255.0
CONSOLE PORT
Serial communication: Connect the serial port of the DCP-2 to a DB9 port
on the computer, or a USB port, using a DB9/USB converter.
Use the following settings for the serial transaction
Baud Rate: 115200
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control: None
GENERAL PURPOSE CLI COMMANDS
SETUP
Type ‘setup’ and then enter the new configuration parameters as
requested, using the format indicated in between parenthesis or just
press enter to leave the parameter unchanged
SHOW STATUS
Show the status of the unit
SHOW ALARM
There are two alarm commands ‘show alarm active’ or ‘show alarm
log’.
SO_DCP_R4.0

SYSTEM STATUS
The chassis will automatically power up as soon as the PSU is connected.
The fan unit starts at maximum speed for a period of a few seconds
before settling down to a lower speed. After power up, the chassis
initiates the software startup sequence. This phase takes from a few
seconds to one minute. Once the startup sequence is completed the
system is now ready for use.
UNPACK AND CHECK THE CONTENTS
- Power cord (model depends on contry/region)
- 2 x Ethernet patch cord
- RJ45 to DB9 adapter
- 2 x rack bracket
- 2 x rack bracket supports
- 12 x screws
- DCP-Series (DCP-2 chassis, PSU, fan)
- Quick installation guide (this guide)
If any part is missing or damaged please contact the distributor!
1 x
1 x
12 x
2 x
MOUNTING OF THE UNIT
1. Fasten the rack angles, with six screws on
each side of the chassis.
2. Fasten securely the rack bracket supports
with four screws to the back. This will support
the weight of the back part of the chassi.
3. Fasten securely the chassis with four screws
to a 19” rack (rack screws not included).
4. Connect the PSU in the back of the unit to the
power source.
