Aboutthismanual
Thismanualincludesallnecessarydocumentationtosafelyinstall,operateandmaintain
thesystem.
Targetaudience
Thismanualisintendedforallusersofthesystem.
Onlineinformation
Allend-userdocumentationcanbedownloadedfromourwebsite.
https://www.kongsberg.com/maritime/
Registeredtrademarks
Observetheregisteredtrademarksthatapply.
Windows®isaregisteredtrademarkofMicrosoftCorporationintheUnitedStatesand
othercountries.
HiPAP®isaregisteredtrademarkofKongsbergMaritimeASinNorwayandother
countries.
cNODE®isaregisteredtrademarkofKongsbergMaritimeASinNorwayandother
countries.
EXrelateddocument
NomodicationpermittedwithoutreferencetotheKMEXresponsible.
Aboutthismanual

6390755/G
cNODEMaxi31Exd
Topics
Important,page7
Systemdescription,page7
Specialconditionsofuse,page8
Generalsupplyconditions,page9
Supportinformation,page10
cNODEMaxi31ExdInstructionManual

390755/G7
Important
Workinginanexplosiveatmosphere,therearesomethingsyoumustbeawareof.
WARNING
ExplosionproofcNODEtranspondersdonothavethesamebatteriesasother
cNODEMaxitranspondersandcannotbeinterchanged.
Thebatteriesmustneverbechangedinanexplosiveenvironment.
Readthelithiumbatteriessafetyprocedurebeforehandlingbatteries.
Systemdescription
Thesetranspondersaredesignedtobeusedinanexplosiveatmosphere.
Thetransponderscomplieswiththefollowingdirective:
•ATEXDirective–2014/34/EU
Thetransponderscomplieswiththefollowingstandards:
•IEC60079-0:2017,7thEdition,ENIEC60079-0:2018,Explosiveatmospheres-Part
0:Equipment-Generalrequirements
•IEC60079-1:2014,7thEdition,EN60079-1:2014,Explosiveatmospheres-Part1:
Equipmentprotectionbyameproofenclosures"d"
•IEC60086-1:2015,Primarybatteries-Part1:General
Thetransducerandendcaparemadeoftitanium.Thetubeandallfastenersaremade
ofSuperDuplexstainlesssteel.
Thebottomendcapisengravedwithinformationaboutthesafetystandards.
cNODEMaxi31Exd

8390755/G
Specialconditionsofuse
Thetransponderwillbeinstalledinanexplosiveatmosphere.Itisveryimportanttoread
andunderstandtheinstructionsfortheuseofthistransponderanditsatmosphere.
Importantconditionsinexplosiveatmospheres
•Fitthetransponderproperlybeforeoperationasthiswillavoidtheignitionhazard
duetoimpactorfriction.
•Groundthetransponderaccordingtolocalregulationsforsuchconditions.
•Neveropenatransponderinanexplosiveatmosphere.
Note
Operationaltemperatureis–5to+55°C.
Storagetemperatureis–30to+70°C
Maximumoperationaldepthis1000m.
1-20≤Tamb≤+55°C
2Titaniumcontentexceededlimit,morethan7.5%,avoidtheignitionhazarddueto
impactorfriction
3Transpondermustbeearthed(byInstaller).Fitthetranspondertothebrackets,at
leastonepartofbracketmustbemetalindirectcontactwithtranspondertube.
cNODEMaxi31ExdInstructionManual

390755/G9
Keeptheequipmentconnectedtoequipotentialbondingfacilitywhenoperatein
hazardousarea
4SpecialfastenersusedtoxtogetherMainTube,BottomEndCapandTopEndCap
withHousingTD80Varemadefromsuper-duplexstainlesssteelwithminimum
yieldstress550MPa
Generalsupplyconditions
GeneralsupplyconditionsapplytothiscNODEMaxi31Exddelivery.
Receipt,unpackingandstorage
Uponacceptingshipmentoftheequipment,theshipyardand/orthedealermustensure
thatthedeliveryiscompleteandinspecteachshippingcontainerforevidenceofphysical
damage.
Iftheinspectionrevealsanyindicationofcrushing,dropping,immersioninwateror
anyotherformofdamage,therecipientshouldrequestthatarepresentativefromthe
companyusedtotransporttheequipmentbepresentduringunpacking.
Allequipmentmustbeinspectedforphysicaldamage,i.e.brokencontrolsandindicators,
dents,scratchesetc.duringunpacking.Ifanydamagetotheequipmentisdiscovered,the
recipientmustnotifyboththetransportationcompanyandKongsbergMaritimesothat
KongsbergMaritimecanarrangeforreplacementorrepairofthedamagedequipment.
Onceunpacked,theequipmentmustbestoredinacontrolledenvironmentwithan
atmospherefreeofcorrosiveagents,excessivehumidityortemperatureextremes.
Theequipmentmustbecoveredtoprotectitfromdustandotherformsofcontamination
whenstored.
Equipmentresponsibility
Unlessotherwisestatedinthecontract,theshipyarddoingtheinstallationand/or
equipmentdealerbecomesfullyresponsiblefortheequipmentuponreceipt.
Thedurationofresponsibilitycover:
•Theperiodoftimetheequipmentisstoredlocallybeforeinstallation
•Theentireinstallationprocess
•Commissioning
•Theperiodoftimebetweencommissioningandthenalacceptanceoftheequipment
bytheenduserorowner
cNODEMaxi31Exd

10390755/G
Unlessotherarrangementshavebeenmadeinthecontract,theKongsbergcNODE
Maxi31Exdwarrantyperiod(asspeciedinthecontract)beginswhentheacceptance
documentshavebeensigned.
Supportinformation
ShouldyouneedtechnicalsupportforyourcNODEMaxi31Exdsystemyoumust
contactaKongsbergMaritimeofce.Alistofallourofcesisavailableonourwebsite.
YoucanalsocontactourmainsupportofceinNorway.
Manualsandtechnicalinformationcanbedownloadedfromoursupportwebsite.
CompanynameKongsbergMaritimeAS
AddressStrandpromenaden50,3183Horten,Norway
Telephone[phone]
Telephone24hsupport+4733032407
Websitehttps://www.kongsberg.com/maritime/
SupportwebsiteProductsupportAtoZ
Emailaddress[email protected]
cNODEMaxi31ExdInstructionManual

390755/G11
Generalacoustic
considerations
Takethisinformationintoconsiderationwhendeployingthetransponders.
Acousticrange
Thedepthratingshouldnotbeconfusedwithacousticrange.Theacousticrangeis
dependentonmanyfactors,andsomeofthefactorsareoutsidecontroloftheuser.
Vesselsystem
Thedirectivityandcoverageareaforthevesselsystemisdifferent,dependingonwhich
systemyouareusing.Somesystemshavehighdirectivityandomnidirectionalcoverage,
whileothersystemshasreducedcoverageandlessdirectivity.Thetranspondershould
alwaysbewithinthecoverageconeofthevesselsystem.
Transducertype
Therearedifferenttypesoftransducersusedonthetransponders.Anomnidirectional
transducer,suchasTD180,coversalargearea,buthaslessacousticpowercomparedto
afocusedtransducer,suchasTD30V .Afocusedsignalgiveslessfootprint/coverage.
Thevesselshouldalwaysbewithinthesignalfootprintofthetransponder.
TxPower
Theabilitytodetectsignalsdependsonthesignalstrength.Thetransmissionpowercan
beadjusted,bothforthevesselsystemandforthetransponder.
Acousticnoise
Acousticnoiseispresentatallvessels.Atgivenconditions,thenoiselevelcanbe
excessive.Acousticnoiseiscausedbymainpropellersandthrusters,andinsome
instancesalsofrommachineryand/orpumpsonboard.Heavypropeller/thrusteruseor
alsowavescanalsogenerateairbubbles,whichcangetinfrontofthevesseltransducer
andblocktheacousticsignal.
Generalacousticconsiderations

12390755/G
Soundvelocityandraybending
Changesinsoundvelocitythroughthewatercolumncausedbychangesinthewater
temperatureand/orsalinitycanbendtheacousticsignalandmakeitimpossibletoreach
thevessel.
cNODEMaxi31ExdInstructionManual

390755/G13
Gettingstarted
Topics
Turningonthetransponder,page14
Closingthetransponder,page15
Turningoffthetransponder,page16
Pre-deploymentchecks,page16
Gettingstarted

14390755/G
Turningonthetransponder
Thetransponderisdesignedforoperationinwateronly.Thetranspondermaybe
operatedinairfortestpurposesoverashortperiodoftime.
Prerequisites
Forsafetyreasons,thetransponderisdeliveredwiththebatteryseparately.Thebattery
mustbeinsertedandconnectedbeforethetransponderisdeployed.
Thefollowingspecictoolisrequiredforthistask:
•5mmHexkey
Procedure
1Removetheboltsthatfastensthetransducer.
2Removethetransducerbyusingtheextractorholes.
3Removethetransportplug.
4Insertthenewbattery.
Note
MakesureyouinsertabatterylabelledcNODEExbattery.
Insertingthebatteryatananglemakesthiseasier.Pressrmlytomakesurethe
batteryisproperlyinserted.
5Switchtheon/offswitchinsidethetoptoon.
cNODEMaxi31ExdInstructionManual

390755/G15
Furtherrequirements
Closingthetransponderisthenextstep.
Closingthetransponder,page15
Closingthetransponder
Closingthetransponderrequiresspecialattention.Itisveryimportantthatthe
transponderisproperlyclosedandwatertightbeforeitissubmerged.
Prerequisites
WARNING
Donotopenwhenanexplosiveatmosphereispresent.
MakesurethebatteryislabelledcNODEExbattery.Makesuretheon/offswitch
isswitchedon.
Thefollowingspecictoolisrequiredforthistask:
•5mmHexkey
•Torquewrench
Procedure
1Replacethetransducer.
2Inspectthebolts.
Iftheyhavenodamagetheycanbeusedagain.Newboltsmustbeofthesame
grade;Super-duplexwithminimumyieldstress550MPa.
3Cleantheboltsandtheholethreads.
4SprayLoctiteactivator7649onthebolt’sthreads.
5AddadropofLoctite243,threadlocktothelowerpartofthethreadsinthetube.
6Fastentheboltswithatorqueof9.4Nm.
Gettingstarted

16390755/G
Turningoffthetransponder
Thiswillleaveyouwiththetransponderturnedoffandnotusingupthebattery.
Prerequisites
WARNING
Removethebatterywhenstoringthetransponderforalongerperiod(months).
Openingthetransponder,page21
Thefollowingspecictoolisrequiredforthistask:
•5mmHexkey
Procedure
1Removetheboltsthatfastensthetransducer.
2Removethetransducerbyusingtheextractorholes.
3Switchtheon/offswitchinsidethetoptooff.
4Removethebattery.
Pre-deploymentchecks
Beforedeployingthetransponder,itisimportanttodothefollowingcheckstomake
suretheoperationgoessmoothly.
Prerequisites
Note
Donotopenwhenanexplosiveatmosphereispresent.
Procedure
1Recordthetransponderserialnumberandchannels.
2PerformanacoustictestusingaTransponderTestandConguration(TTC)unit:
aInterrogatethetransponder.
bReadbatterystatusandconrmthatitwilllastfortheupcomingoperation.
cReadthepowersettingandconrmitiscorrectfortheupcomingoperation.
cNODEMaxi31ExdInstructionManual

390755/G17
InstallingthecNODEMaxi
31Exd
Correctinstallationisessentialforkeepingthetranspondersafeinanexplosive
atmosphere.
Prerequisites
Thepre-deploymentchecksmustbecompletedbeforeinstallationcanbegin.
Procedure
1Mountthetransponderwiththetransducerhavingafreelineofsight.
2
Important
Thetranspondermustbeearthed.
Fitthetranspondertothebrackets.
Atleastonepartofthebracketmustbemetalindirectcontactwiththetransponder
tube.
3Fitthetransponderinsuchawaythatthetransducerdoesnotmove.
Thetransducermustbeatleast0.2mmfromanymetalsurfacetoavoidtheignition
hazardduetoimpactorfriction.
InstallingthecNODEMaxi31Exd

18390755/G
Operatingprocedures
ThetransponderisoperatedfromtheHiPAPoperatorstationAPOS.
•RefertoAPOSonlinehelpfordescriptions.
cNODEMaxi31ExdInstructionManual

390755/G19
Maintenance
Topics
Recoveringthetransponder,page20
Cleaningthetransponder,page20
Openingthetransponder,page21
Changingthebattery,page21
Closingthetransponder,page15
Maintenance

20390755/G
Recoveringthetransponder
Alwaysreadtheemergencyproceduresbeforehandlinglithiumbatteries.
Context
Avoidslammingthetransponderagainstsolidobjectsasitisliftedoutofthewater.
Procedure
1Checkthetransponder’stemperature
Ifthetransducerisoverheatedgodirectlytotheemergencyprocedures.
2Placethetransponderinasafeplaceoutondeck,shieldedfrompeopleandvital
equipment.
3Controlthetransponderforminimumtwohours.
Checkfordamagesthatcouldinvolveawaterleakageandcheckthehousing
temperatureforapossibletemperatureincreaseinthelithiumbattery.
Forbatterieswithpossibledamages,gototheemergencyprocedureschapter.
4Washtheunitthoroughlyinwarmfreshwatertodissolveanysaltdepositsand
cleanoffanysandorsilt.
5Asanextraprecaution,itisrecommendedthattheunitislefttosoakinfreshwater
toallowsalttodissolveanddiffusefromhard-to-reachareas,suchascrevices
betweenmatingparts.
6Dryoff,sonowatercancomeinsidewhenopening.
7Turnthetransponderoffandstorethebatteriesoutsidethehousingifthe
transponderisnotusedforsometime.
Cleaningthetransponder
Thetranspondermustbecleanedafteruse.
Procedure
1Removeanygrowthanddirtwithastiffbrush,orwithawoodenscraperorwith
aplasticscraper.
Becarefulnottodamagetheunit.
2Cleantheunitthoroughlywithalotoffreshwater.
3Dryoff,sonowatercancomeinsidewhenopening.
cNODEMaxi31ExdInstructionManual
