Smartparts 8" User manual

Table of Content
• C:>"t!r"i~~----·········_-_·_-----_··_· __ ···_··_·······_·... :l
•
What's Included---------------------------------------- 3
•
Remote Control--------------------------~------------ 4
•
Getting Started
Internal Memory and
Memory Card Slot---------------------------------- 5-6
The Three Modes----;.------------------------------6-1 0
Vie~ Your Pictures
Listen to Your Music
Vie~ Your Videos
Settings
Copying and Deleting Files~-------------------------I 0
Connecting to aComputer------------------------- l:l
Troubleshooti ng---------------------------------------- I3
Technical Specifications------------------------------14

Overview
•Your new digital picture.frame lets you view photos and
vi~eos and listen to music -all without acomputer.
•An automatic, continuous slide show lets you enjoy all
of
your photos with ease.
•The included remote control makes it simple to select
photos, change settings, and more.
•Photos
can be viewed directly from memory cards or from
the frame's built-in memory.
•The frame
can be connected to acomputer to quickly and
easily transfer pictures
from your hard drive.
Please disposal ofthis product properly to help preserve
the environment.The recycling of materials
will help co-
.nserve natural resources. Please
do not dispose of your
old electrical and electronic equipment with your house-
hold waste. For more detailed information about recycling
ofthis product, please contact your
local government, your
household waste disposal service
or the shop where you
purchased the product.

asMARTPARtS
What's Included
Included in the box should be:
• Digital Picture Frame
•Stand
•
AC power adapter
•Remote control
•User
Manual
• USB cable
CF Card Slot
Mini USB
--
Port
Power input jack
SD/xDIMSI
MMC
Memory
Cards
Slot
Io-o----Power
On/Off
OG()()
©8
0@0
GGG
@GC!)
--- SD/MMC Expansion Slot
0~--'

TPARLS
Remote Control
I
DIGITAL PHOTO FRAME
---·lI··ARTPARLS
I FRARCO REMOTE CO, TROt
I.ZOOM-Zoom in the displayed image.
2.EXIT-
To stop the playback of slideshow/video/music.
3.ROTATE-To rotate the orientation
of images while displaying
photos
for viewing.
4. PLAY- To tart the slideshow.
5.Direction Buttons
6.SLlDESHOW-
To start the slide show.
7.STOP
8.SETUP-I)
To open or close the Brightness/ContrastlTintlColor
bar while viewing asingle image.2)To
access the copy and delete
menu.
9.MUTE-
To mute or unmute the speaker while playing AV files.
I
O.VOl +/- - To adjust the volume while playing AV files.
II.ENTER-
To confirm your selections/To zoom in the image while
viewing asingle
image.
1--~0

Getting Starte~
To begin using your digital picture frame right away,follow
these simple steps.
·1.Connect the
AC power adapter to the frame and plug
the adapter
into an electrical outlet( I 00-240~50-60Hz)
2.1nsert a memory card into the appropriate card slot,or
plug a
USB flash drive into the USB port on the side of
the frame.
3.Turn the frame on by pressing the
On button on the back ..
4. Aslide show will begin automatically.To stop the slide show
press Exit.
Internal Memory and Memory Card Slot
Your digital picture frame includes 128MB of built-in memory,
plus
an Expansion Memory card slot,allow1ng you to increase
your storage capacity whenever you'd like.The Expansion
Memory slot lets you insert an extra SO or MMC memory
card and use it to store photos,music and video files.lt is
labeled SO/MMC on the bottom of the frame.
The slot marked SO/xO/MS/MMC
is meant to be used for
your regular memory card,such as the one you use in your
camera.

Compact Flash(CF) cards are inserted in the slot on the side
of the frame.
USB flash drives can be inserted into the USB port on the
side of the frame.
To select from the various types of memory,press Exit until
the memory devices are highlighted at the bottom of the
screen, and then use the left and right arrow buttons to
select the desired memory type.Press ENTER to access the
selected memory type.
The Three Modes
There are three modes for using your digital picture frame.
To change modes,press the Exit button until the options on
the left side of the screeen are highlighted.Use the up and
down arrows to,highlight
the desired mode and then press
ENTE~ .
View Your Pictures
Highlight View Your Pictures and press ENTER.A screen with
6thumbnail images
will appear. Use the arrow buttons to hig-
hlight the image you ·want to view and press ENTER to view
the image.

While viewing a single image,you can move to the previous
or next image by using the left and right arrows.When a
signle image is displayed,the up and down arrows are 'used
to rotate it .
While viewing a single image you can press SLIDE SHOW/
PLAY to start aslide show, Exit/Stop to return to the thum-
bnails screen. If there are WMA music files stored on the
same memory device
as the images you are viewing,the music
will be played in the background during slide show.
An image can be zoomed in using the ZOOM/ENTER button
on the remote control.Repeatedly pressing this button will
zoom in to various levels and finally return to original image.
During aslide show, an image's display orientation can be
rotated using the ROTATE button on the remote control.
Every time you press this button,the image rotates 90 degrees
clockwise.
While
viewing an image, you can enter the Brightness/Cont-
rastlTin~Color adjustment menu by using the SETUP button.
Use the up and down arrows to highlight the item and use
the right and left arrows to adjust the effects.
Listen to· Your Music
Highlight Listen to Your Music and press ENTER.Use the up
and down arrow buttons to highlight the song and press
ENTER/PLAY to play the song.To stop,press Stop/Exit
0---'

Your digital picture frame can play music files in the WMA
format.lf music files are present,the music will.also be played
in the background during the slide show.
While enjoying the music, you can adjust the volume by
pressing VOL +/-
button on the remote control. Press the
MUTE button on the remote control to mute the sound.
Press STOP
to stop the playback and retuen to the main
menu.
View Your Videos
Highlight View Your Videos and press ENTER.Use the up
and
down arrow buttons to highlight the video clip you
want to enjoy and press ENTER.To stop the video, press
Exit/Stop.Your digital picture frame can play video clips
that
are in the AVI Motion JPEG (WMA) format,up to,800x480
resolution and up to 30 frames per second. While viewing
the video, you can adjust the volume by using VOL+/- button.
Press
MUTE button to mute the sound.
Settings
Highlight Settings and press ENTER.Use up and down arrows
to highlight the setting you would like to change and press
right
arrow to access sub-settings.Use up and down arrows

to highlight the sub-setting and press ENTER to confirm.
Slide Show-Press ENTER to start the slide show.
Multiple Picture Display- Turning this feature on will result
in images being displayed on the screen four at atime during
slide show.
Slide Show Transition-Allows you to choose different styles
of slide snow effects from the available list.
Slide Show Speed-Allows you to change the time delay during
slide show.
Display 'mage Size-Select Original to have your images shown
in their original shape even if they do not match the shape of
the screen.Select Optimal to have your imagesfille the screen
(some cropping may occur).
Repeat- Allows you to choose different repeat mode for
music
or video file playback.
Repeat One: to have each individual video/music files
repeat continuously.
Repeat All :to have all video/music files repeat continuously.
Repeat Ott: to have video /music files played only once.

Clock-Select On to have aclock displayed on the screen.
After choosing On, the year
will be highlighted.Use up and
down arrows to change the numbe~then use right arrow
to move the next item.Continue until the date and time are
correct and then press
ENTER.
Alarm-Select On 'to use the alarm function.The alarm can be
set
to ring at a specific time each day.The hours and minutes
are set
in the same manner as used in setting the clock.
Language-Allows you to choose different on-screen-display
language from the available list.
Reset Settings-Select Yes to restore the settings to the factor)
default.
Copying and Deleting Files
Images,music and video files can be deleted or copied to
another type of memory without acomputer. Make sure
that the memory devices that
YO!J want to transfer files isl
are connected correctly to the digital picture frame. For
example,
you can copy your pictures from the memory
card
you normally use in your camera to the Expansion
Memory or internal memory.
I---_@

To copy an image,highlight the thumbnail and press SETUP
button.Highlight Copy Picture
to and press ENTER. Only.
the available memory types will be shown.Highlight the type
of memory that you want to save your image to and press·
ENTER.The image
will be copied.
To copy multiple images at once you can select them before
accessing
the Copy Picture to function.To select an image
for copying,highlight it in the thumbnail screen and press
Volume +
button on the remote control.Acheck mark will
appear in the corner of the thumbnail. Press Volume -" button
to cancel the selected image. Select all the images you would.
like to copy and then press SETUP and Copy Picture to as
described above.
Copying music and video files
is done in avery similar way.
However;to select multiple files,use right arrow to add the
check mark next to each file.
To delete,highlight the file or files as above and select the
delete option from the menu.
Transcoding the image
Transcoding reduces the size of your images while copying
them,to conserve storage space.
Transcoding an image/multi images
is done in avery similar

similar way as Copying an image.You will have the same'
images
but with smaller size in the memory that you tra-
nscode to.
Connecting to a computer
Using the supplied USB cable,you can connect your digital
picture frame
to a computer to transfer files between the
two devices.
With the frame turned off,connect the small end of the ca-
ble
to the frame and the large end to your computer.Turn
the frame on and allow the comp'uter afew moments to
recognize the device.The frame's internal memory and any
memory cards inserted in the frame will appear as external
storage devices
on the computer.Compatible picture,audio
and video files can be copied
to the internal memory or
memory cards in the frame through normal copy-and-paste
,?r drag-and-drop methods.

Troubleshooting
Symptoms
Reasons Settle method
Displays Check
if correct language Set language selection
in the Setup menu
unr:eeognizable code .option
is set
Cannot insert The card
is being inserted Insert
the cards in correct direction
memory cards
in the wrong direction
Cannot save
files
'The flash capacity is
Restart the unit, delete some files,
not large enough or format the flash memory
Unit does't turn on
or
Check if the unit is turned'on or
Dark screen
AC adapter connection
AC adapter is properly connected
is improper
No sound Volume
is set at 0Press Volume +button
to increase
the volume
Unable
to display or
The file format is not
Make sure the file format is supported
supported
or USB is
or the computer and the player are in
download file
improperly connected or
correct connection or memory card is
memory card is damaged
not damaged
Some
files cannot The card
is not compatible Use another card
or change to acorrect
be displayed with the unit
or the file file
format
format
is incorrect
@----

Technical Specifications
.
Display (800 x480) 8inches TFT full-color
Connecting .
High speed USB 2.0 and 1.1 HOST
Computer
Memory Flash' memory: 128MB
Power Supply
DC 12V IA ACADAPTER
WMA Audio
output 0.8W x2(8 Ohm)
Picture Format
JPEG
Music Format WMA
Video Format Hardware Motion-JPEG up
to VGA@3Ofps
Memory
Card SD/MMC/MS/xD/CF .
Language English,Spanish,French
Selection
Control Mode Remote Control/Buttons
on the rear panel
Supported Windows 2000/XPNistalMAC OS
Operating Systems
Smartparts,lnc.warrants its digital picture frames against
manufacturing defects for aperiod
of 90 days from date
of purchase.For warranty claims,please visit our web site
at www.smartpartsproducts.com or call 1-888-796-2749.

ARTPARts
QUICK START GUIDE
Your new Smartparts digital picture frame has been designed
for ease
of use. Follow these quick steps to get started right away.
~
Insert your memory card into the appropriate card slot on the
side
of the frame. SD, MS, and xD cards should be inserted
ointo the smaller slot, while CF cards go in the larger slot.
~
Connect the AC power adapter to the input jack on the side
of the frame. Plug the power adapter into an active electrical
ooutlet. .
~o Turn the power on using the switch on the back of the frame.
The frame will automatically begin displaying aslide show
of the
photos stored on the memory card. To stop the slide show, press
the Exit button on the remote control.
To use other features
of the frame, please refer to the user manual.
www.smartpartsproducts.com

QsMARTPARtS
ABOUT OPTIPIX PRO
OptiPix Pro is designed to help you find, optimize and transfer pictures to
your frame. The software, residing on your computer, will guide you through
3Easy Steps.
OptiPix Pro will help you:
•View your vertical photos the right way
•Sharpen your photos
•Find and transfer photos to your frame
•Fit more pictures on your frame
OptiPix Pro will not alter your originals -it will create copies that will be
optimized and transferred to your frame. Using OptiPix Pro you can
store up to 2,000 pictures
in your frame!
Use your frame to get the message out. With Smartparts, Inc.'s exclusive
OptiPix Pro software for Windows it's easy to convert and transfer
PowerPoint slides, PDF files, and most picture and graphic files directly to
your digital frame.
HOW TO INSTALL
The software's installation file is preloaded on the frame's
internal memory. To install it
on your Windows computer,
perform the following steps:
1. With the frame turned off, connect it to your computer
using the supplied USB cable.
2. Turn on the frame and wait several seconds for the
computer to recognize it
as anew device.
3. On the computer, click on the Start menu, and select
My Computer.
4. Within the My Computer window, double-click on the
drive with the label that matches the model number
of your digital picture frame. The model number usually
begins with SP.
5. In the window that opens, double-click on the setup file
and follow the on-screen instructions.
After
OptiPix Pro is installed on your computer, remove the setup file from
the frame's memory
to allow more room for photos, videos and music. You
can move the file to your hard drive if you'd like, or simply delete
it.
www.smartpartsproducts.com
