50 WATT UNDERWATER LIGHT (NL50) INSTALLATION/OPERATION MANUAL

TABLE OF CONTENTS

Important Safety Instructions .....................................................................................................................................1

List of Contents..........................................................................................................................................................2

Installing the Bulb(s) ..................................................................................................................................................2

Testing Light Function................................................................................................................................................2

Sealing the Light ........................................................................................................................................................3

Installing the Light......................................................................................................................................................3

Operating the Light ....................................................................................................................................................3

Winterization ..............................................................................................................................................................4

Troubleshooting .........................................................................................................................................................4

Warranty ....................................................................................................................................................................4

IMPORTANT SAFETY INSTRUCTIONS

READ AND FOLLOW ALL INSTRUCTIONS

SA E THESE INSTRUCTIONS

WARNING: To reduce the risk of injury, do not permit children to use this product unless they

are closely supervised at all times

WARNING: If ambient air temperature exceeds 115˚ F., protect the transformer from direct

sunlight with a well ventilated cover.

WARNING: Any modifications to this product will void the warranty.

WARNING: Do not allow children to use, touch, or play near or around the unit’s power pack.

WARNING: Plug only into 110 V receptacles protected by a ground fault circuit interrupter.

WARNING: Do not connect unit to AC power until installation has been completed.

WARNING: Do not use if unit is damaged in any way.

WARNING: Unit must be submerged below the minimum water level or warranty is void.

WARNING: DO NOT USE EXTENSION CORDS - DEATH OR INJURY CAN RESULT.

WARNING: Make sure the light is unplugged from its power supply before opening the unit or

performing any other maintenance.

WARNING: To protect against risk of electrical shock, do not put the transformer in water or other liquid.

WARNING: To avoid damage to the transformer and cord, never carry the transformer by the cord or

pull on the cord to disconnect from an outlet. Instead, disconnect by pulling the plug,

itself, from the outlet. Do not pull cord around sharp corners or edges.

WARNING: Do not operate with a damaged cord or transformer.

WARNING: This unit is not compatible with soft-sided aboveground pools.

CAUTION: Disconnect transformer from outlet when not in use.

CAUTION: If the light is not working as it should or has been dropped or damaged in any way,

contact SmartPool LLC Technical Support before using at (732) 730-9880.

DURING THIS TEST THE BULB WILL QUICKLY BECOME HOT TO THE TOUCH. ONCE THE LIGHT

HAS SUCCESSFULLY PASSED THIS TEST, BE SURE TO TURN THE LIGHT OFF AS PROLONGED

USE OUT THE WATER MAY DAMAGE THE UNIT AND OID THE WARRANTY.

TESTING LIGHT FUNCTION

• Plug the light into a GFI protected outlet and turn the switch to the ON position (red light will illuminate).

o If the light does not illuminate, turn the switch OFF, check the bulb for a secure fit, and try to run the light again.

o If the light still does not turn on, contact

SmartPool Technical Support at (732) 730-9880.

FIGU E 3

INSTALLING THE BULB

• Place the light on a table or a flat, dry surface.

• Insert the latch key into the locking latch, turn the key to the left and hold in position as shown

in Figure 1.

• otate the Seal ing counter clockwise to loosen as shown in Figure 2.

• emove the Seal ing and lens.

• emove the bulb from its box, being careful not to touch the face of the bulb.

•

Insert the legs of the bulb into the ceramic outlet shown in Figure 3.

DO NOT PLUG LIGHT IN UNTIL INSTRUCTED IN MANUAL Locking Latch

FIGU E 1

FIGU E 2

ITEM DESCRIPTION QTY

A LOCKING TOOL 1

B POWE SUPPLY SUPPO T SC EWS 2

C 50 WATT BULB 1

D LIGHT ASSEMBLY 1

E POWE SUPPLY 1

LIST OF CONTENTS

• Carefully install the lens making sure that there is an even, flat fit in the light body.

• Place the Seal ing over the lens. Turn the ring in a clockwise direction until the ring is secure

and the Index Mark is centered with the body of the light as shown

in Figure 4.

NOTE: It is normal for the Seal ing will make a clicking noise during installation. This is a safety

feature of the light to ensure the ring cannot be removed without the use of the Latch Key.

DO NOT O ERTIGHTEN THE SEAL RING OR TURN THE RING IN A COUNTER-

CLOCKWISE DIRECTION DURING INSTALLATION AS THIS COULD CAUSE THE

LIGHT TO LEAK.

SEALING THE LIGHT

FIGU E 4

Index Mark

Seal ing

• emove the top cap of the pool’s vertical post nearest to the point of installation.

• Lift one side of the pool’s top ledge as shown in Figure 5 (screws may have to be removed).

• Slide the light onto the pool wall so that the light is centered in the middle of the top ledge.

• Hold the light so the mounting bracket is flush with the top of the pool wall and turn the Thumb

Wheel in a clockwise direction to secure the light to the wall as shown

in Figure 6.

• Be sure the wire runs through the Wire Channel of the Mounting Bracket.

• einstall the top ledge and cap.

• Ensure the water level is above the minimum water line on the light as shown in Figure 4.

Add water if needed.

• Mount the transformer to a vertical surface that is at least 18 inches from the ground using the

provided screws.

INSTALLING THE LIGHT

FIGU E 6

Wire Channel

Thumb Wheel

FIGU E 5

OPERATING THE LIGHT

USE OF A GFI PROTECTED OUTLET IS REQUIRED. DO NOT USE AN EXTENSION CORD.

• To turn the light on, plug the power cord into a GFI protected outlet and turn the switch to the ON

position.

• To turn the light off, press the switch to the OFF position as shown in Figure 7.

FIGU E 7

• Unplug the power cord from the GFI outlet.

• Using the Hex Key of the Locking Tool, remove the Hex Screws of the Mounting Bracket by

rotating the key in a counter clockwise direction as shown in Figure 8 .

• Store the Locking Tool and Hex Screws in a safe location for use the following season.

• Gently pull on the light body to remove the light from the Mounting Bracket and to expose the

excess cord on the inside of the light body.

• Pull the light out of the water and hang it over the top ledge of the pool.

• Use a string or bungee cord to secure the light for the winter.

FIGU E 8

emove

Hex Screws

WINTERIZATION

FAILURE TO PROPERLY WINTERIZE YOUR LIGHT WILL RESULT IN

TERMINATION OF WARRANTY.

SIX MONTH LIMITED WARRANTY

Six month limited warranty from date of original purchase for manufacturing defects under normal and reasonable use,

and subject to the maintenance requirements and installation guidelines set forth in the product instruction manual.

THIS WARRANTY IS SUBJECT TO THE TERMS, LIMITATIONS AND EXCLUSIONS DESCRIBED BELOW, AND THERE ARE NO OTHER WARRANTIES

OR REPRESENTATIONS, EITHER EXPRESS OR IMPLIED, WHETHER OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR

OTHER, MADE BY THE MANUFACTURER, OTHER THAN THOSE SPECIFICALLY SET FORTH IN THIS WRITTEN WARRANTY

What is Covered: SmartPool LLC warrants its electronic prod ct to be free from defects in material and workmanship when leaving the factory.

What is not Covered: Any type of damage to the prod ct d e to improper installation, maintenance, or fail re to provide necessary and reasonable maintenance; any

damage or inj ry ca sed by mis se and/or nreasonable se of the prod ct; batteries (if applicable); damage d e to or related to improper draining, winterizing, storage or

Acts of God; SmartPool LLC will not honor any claims for damage to any prod cts in transit nless damage to the shipping container is noted at the time of delivery on

the transfer company’s delivery bill.

THE WARRANTY OBLIGATIONS OF SMARTPOOL LLC ARE LIMITED TO REPAIR OR REPLACEMENT OF THE PRODUCT OR OF ANY DEFECTI E COMPONENT, AT

THE OPTION OF SMARTPOOL. UNDER NO CIRCUMSTANCES WILL SMARTPOOL LLC BE LIABLE OR RESPONSIBLE FOR ANY CONSEQUENTIAL OR INCIDENTAL

DAMAGES, AND/OR CHARGES FOR LABOR. SMARTPOOL SHALL NOT BE LIABLE OR RESPONSIBLE UNDER ANY CIRCUMSTANCES OR ANY AMOUNT FOR ANY

CONSEQUENTIAL OR INCIDENTAL DAMAGES, OR FOR ANY INJURIES OR DAMAGES TO PERSON OR PROPERTY USING OR USED IN CONNECTION WITH THE

PRODUCT, OR FOR ANY OTHER LOSS OF PROFITS OR OTHER COSTS OR EXPENSES OF ANY KIND OR CHARACTER. IF SMARTPOOL LLC DETERMINES THAT

EITHER REPAIR OR REPLACEMENT OF THE PRODUCT IS NECESSARY, SMARTPOOL MAY EITHER REPAIR THE PRODUCT AT A NOMINAL CHARGE TO THE OWNER

OR REPLACE THE PRODUCT. THE OWNER BEARS THE SOLE RESPONSIBILITY FOR PRE-PAID RETURN OF THE PRODUCT TO SMARTPOOL, AND ALL REPAIRED OR

REPLACED PRODUCTS WILL BE RETURNED AT THE OWNER’S EXPENSE.

NO PERSON, FIRM, OR CORPORATION IS AUTHORIZED TO MAKE REPRESENTATIONS OR INCUR ANY OBLIGATIONS IN THE NAME OF OR ON BEHALF OF

SMARTPOOL LLC, EXCEPT AS STATED HEREIN. THE REMEDIES SET FORTH IN THIS WARRANTY ARE EXPRESSLY UNDERSTOOD TO BE THE EXCLUSI E REMEDIES

A AILABLE TO THE OWNER, AND THIS WARRANTY CONTAINS THE FULL AND COMPLETE AGREEMENT BETWEEN SMARTPOOL LLC AND THE OWNER. THIS

WARRANTY SETS FORTH THE ONLY OBLIGATIONS OF SMARTPOOL LLC, WITH REGARD TO THIS PRODUCT, AND THERE ARE NO WARRANTIES WHICH EXTEND

BEYOND THE DESCRIPTION ON THE FACE HEREOF.

The representations set forth herein are the only representations made by SmartPool LLC, with respect to the product, and this warranty does not constitute

either a performance or satisfaction guarantee. It is the responsibility of the product owner to regularly test and check the product for proper function and

safety.

This warranty gives the original owner specific legal rights. You may have other rights depending on where you live.

What you must do to file a claim: Call 1-732-730-9880 to initiate a claim.

TROUBLESHOOTING

If the light is not operating correctly, please follow the steps below to help identify

the cause of the issue.

1. Ensure the GFI protected outlet is operational or needs to be ESET.

2. DO NOT use an extension cord. If using an extension cord, please remove and plug the light directly into a GFI

protected outlet.

3. Ensure the bulb is installed securely in the socket of the light.

4. Ensure the bulb is functional. eplace with a new bulb if it is burnt out.

If you are still experiencing an issue with your light, pelase contact SmartPool Technical Support at 732-730-9880.
