SMARTSOUND SKEEPER User manual
USER GUIDE
사용설명서
SKEEPER is a Precise Home Smart Healthcare Device.
Linked with SKEEPER Apps (Skeeper mama, Skeeper baby, Skeeper heart),
the product provides individual heart rate (BPM: Beats Per Minute, Heartbeat
Regularity, Heartbeat Waveform, Heartbeat Sound, etc.) in real time and enables you
to manage individuals’ or family members’ cumulative records easily and convenient-
ly. Also, you can connect a wired earphone/headset directly to the product for use.
The product reads you and your family members’ heart in three
dimensions.
It analyzes heart sounds using “Sound Process Technology,” which is SKEEPER’s
patent technology, and provides multiple measurement results. Through this,
you can check and monitors the changes in heart state according to individual
life patterns such as walking, running, and exercise. Also, you can manage heart
records
according to family members’ lifestyle such as sleep state, activities,
rest-activity cycles and diet fatigue.
You can hear fetal heart sound.
You can find and hear the fetal heart sounds (After 25 weeks into the pregnancy,
varies depending on individuals). Through this, you can sensitively and naturally
commune with your adorable baby before birth.
※ This product is for home use and cannot be used for treatment or medical use.
Cautions
※ Safety Rules
➊ Follow the use methods of the manual for safety.
➋ Do not remodel, repair, or disassemble the product. It can cause unexpected
electric shock or damage. The problems caused by the carelessness of users
are not included in the range of compensation of our company.
➌ Do not use any liquids for cleaning the product.
➍ Do not use the product in a dangerous or noisy environment.
PRODUCT OVERVIEW INTRODUCTION PRODUCT OVERVIEW INTRODUCTION
12
Measurement Results That You Can Easily Understand (Easy Display)
By showing the measurement results as quantified figures or graphs, it enables
people of all ages to understand them easily.
Provision of Analysis Function Through Dedicated Apps
The measurement results can be recorded and analyzed through SKEEPER Apps.
Also, effective management is possible through diary functions and the results can
be sent through SNS or e-mail (Available both in Android and iOS versions)
▶ The “Age/Gender Heartbeat Health Standard’ suggested by the American Heart
Association was applied to the product, so you can compare the measured heart
health state objectively.
▶ Using History Function, you can record the measurement results by types (date,
gender, age, and measurement state) and easily manage the cumulative records
of individuals and family members.
▶ The measurement results can be shared with family, relatives, and friends
through e-mail or various SNS.
Convenience through Wired/Wireless Connection
You can hear various human body sounds, such as fetal heart sound (Fetus
Mode), heart sound (Heart Mode), and lung sound (Lung Mode) by connecting an
earphone or headset to the main body of the product. The product also supports
functions by dedicated apps after connection with a smartphone and Bluetooth.
Safety
It does not input methods that can be harmful to human body, such as
ultrasonic waves or electric current, but collects human body’s sound signals
(sound waves) using the MIC sound collecting principle and processes the
sound signals with SKEEPER’s own specialized “Sound Process Technology” and
wireless transmission methods. Since it has an electromagnetic waves grade that
is harmless to human body, so young children, the sick and elderly can all use it
with an easy mind.
Heart Age
Beat Per Minute (BPM)
Heartbeat Regularity (%)
Mine : Measurement Value
AVG : Average of your own datas
Recmd : Country Heart Standard by
Gender/Age
(Real-Time) Heartbeat Wave Graph
Mine
AVG
Recmd
PRODUCT FEATURE INTRODUCTION PRODUCT FEATURE INTRODUCTION
3 4
SKEEPER Body, USB Charging Cable, Extra Accessory (Diaphragm),
User Guide (Each 1EA)
Before the initial use of the product, or when you have not used the product for
a long time, it is recommended to charge the product fully before use.
➊ Connect the USB charging cable, which is included in the product package, to the
product’s charging terminal.
➋ Connect the opposite side of the cable to the USB port where electricity is
supplied.
➌ Red LED is turned on during charging and Green LED is turned on when charging
is completed.
- When the product is discharged, it takes about one and a half hours to fully
charge. The charging time varies depending on the amount of remaining
power.
- The continuous use time of the product when the battery is fully charged is
about 8 hours.
※ Cautions
- Use a certified charger for safe use of the product.
- Charge the product regularly (every 3 months) for the life of the embedded
battery when you do not use the product for a long time.
- Product cannot be used during charging.
Remove the charging cable before use.
PRODUCT COMPONENTS INTRODUCTION CHARGING PREPARATION
USB
connector
Volume(-)
Audio Jack
Battery LED
Power
Volume(+ )
Lung Mode
Heart Mode
Fetus Mode
Bluetooth(On/Off)
MFB:Multi Funtion Button
56
App Download and Use methods
➊ Search “Skeeper” (in English) or “스키퍼” (in Korean) at smartphone app market
(Playstore, Appstore, etc.)
➋ Download and install app by selecting “Install” on app guide page.
➌ Activate the Bluetooth function on smartphone and turn on the “Skeeper”
➍ Run the downloaded SKEEPER app and press the start button on the measure-
ment screen. The product is connected automatically.
➎ Enjoy SKEEPER’s contents.
※ After downloading the app, sign on the consent form for collecting and utilizing
personal information and input individual profile, the app is now ready for use.
Turn the power On/Off by pressing the power button.
➊
Power On: Press the power button for one second when the power is
off.
Four LEDs are turned on and then only the heart mode LED and Bluetooth LED,
which are the default mode, are turned on. The product is now ready for use.
➋
Power Off: Long press the power button when the power is on. Four LEDs
are turned on and then power is turned off.
TURN ON/OFF PREPARATION APP DOWNLOAD AND BLUETOOTH CONNECTION PREPARATION
7 8
Hearing
Sounds
Changing
Mode
Volume
(Up/Down)
Charging
Alarm
Connect an earphone to the audio jack to hear sounds through
the product in real time. Use the SKEEPER app to save and
analyze the measurement results and share them through SNS.
There are three modes: General (heart), lung, and fetus. The
product’s default setting is the general (heart) mode. The mode
is converted in order of fetus, general (heart) and lung. Short
press the Multi-Function Button on the center of SKEEPER to
change the mode.
Volume changes are noted with a short beep through the
earphone and two beeps indicate the volume has reached its
maximum or minimum.
Battery
Warning
Red battery LED flickers and battery warning sound is heard
through the earphone.
Charge the product using the provided USB charging cable. Red
LED is turned on during charging and Green LED is turned on
when fully charged.
Function Operating Methods
BASIC FUNCTION SKEEPER USE METHOD MEASUREMENT SKEEPER USE METHOD
General (Heart) Mode Measurement
General (heart) mode is for measuring general heart sounds. Refer to fetus mode for
fetal heart sound measurement.
➊ Place and turn on the product.
➋ Set the product to general (heart) mode (See below figure).
➌ Lightly press the “diaphragm” of the product to a location near heart.
➍ Press the App’s “Start Button” (on each of measuring pages)
and measure for 1 minute or 30 seconds.
Put the Skeeper’s
diaphragm on the Heart
and press gently.
Press the App’s “start button”
and measure for one minute.
If you want to stop in
midstream, please press
the same posotion again.
Lung Mode Measurement
Lung mode is for measuring human body’s breathing sounds or movement sound
of intestine.
➊ Place the product and connect it with an earphone/headset.
➋ Set the product to lung mode.
➌ Lightly press the “diaphragm” of the product to an area under the left and right
clavicle or under the left or right armpit and then breathe in and out deeply.
※ Currently, lung mode app is not supported but will be applied later.
9 10
COMMON USE METHOD SKEEPER MAMA
HOW TO USE THE APPLICATIONS HOW TO USE THE APPLICATIONS
Skeeper Mama systematically manages the health of pregnant women and fetuses.
➊ Personalized Health Management for Pregnant Women
As a personalized health management for pregnant women which has been co-developed
by Smartsound Corporation and the world’s best medical experts, this is a total solution
for having a healthy baby. Pregnant women participate in a 5-steps coaching program and
systematically manage their healthy pregnancy both mentally and physically.
➋ Fetal Heartbeat Sound
Hear fetal heart sounds through SKEEPER from 25 weeks into the pregnancy (varies
depending on individuals) and check that the fetal heartbeat is within the normal range.
The results can be shared through Email or SNS.
▶ When you want to commune with your baby inside you
▶ When you suddenly wonder if your baby inside you is well
▶ When you share the sounds of your baby inside you with people far away
➌ Stress Management of Pregnant Women
Measure the health of pregnant women once or twice daily through SKEEPER for tracking
mental and physical health status. The BPM, regularity, stress index, exercise, and dietary
information are provided and changes in health state can be monitored by referring to
history management.
➍ Production of Mom’s Heart Sound Music (Prenatal music & Birth cheering song)
SKEEPER mixes mom’s heartbeat sounds with general tunes for soothing prenatal music.
Patented technology helps to develop the fetal brain.
※ How to Produce Mom’s Heart Sound Music
Touch “Mom’s Lullaby” in side menu. ⇢ Touch in the lower right corner. ⇢ Touch the heart
sound that you want your baby to hear and in the right side of the music. ⇢ Select heart sound
and the music saved on the smartphone and touch the “Done” button in the upper right corner. ⇢
After touching imported heart sound and music, touch the “Save” button in the upper right corner.
⇢ Enter the title of your own lullaby, adjust the balance between heart sound and music, and
touch the “Done” button in the lower right corner.
* Music must be saved in your smartphone.
Measuring
▶ Select “Measurement,” and then select general measurement,
stress measurement, special measurement, or fetus measurement.
Position this product on the appropriate location (Refer to 3-2
measurement) and start measurement by touching the “start” button.
▶ Measurements: BPM (Beat Per Minute), Heartbeat Regularity, Decibel
Providing Apps for the Health Management of All Family Members
We provide smart apps (Smart Algorithms) by purpose of health management of users at home.
▶ Health management of pregnant women/fetuses (Skeeper Mama)
▶ Health management of infants/toddlers/children (Skeeper Baby)
▶ Health management of adults/seniors/cardiovascular patients (Skeeper Heart)
Measurement Results and Save
▶ Measurement results of general mode are BPM, heartbeat, decibel, and
prescription (exercise and dietary).
▶ Data includes your heart age, measurement index, average heart
level and recommended values according to the measurement results
through your profile and information from medical examination by
interview. (Refer to 1-2 Product Features)
▶ Touch the “Save” button in the lower right corner and select the
activity state and input some memos.
▶ Saved information can be shared through Email or SNS.
See Records
▶ Health status information is displayed with digitalized indices for easy monitoring of
health changes.
▶ Measurement results are displayed according to date and saved status.
▶ Select a period to display the trend graph and measurement result list of that period.
▶ Touch “list” to display the health status record table and touch “edit” in the upper right
corner to modify or delete the data.
11 12
SKEEPER BABY SKEEPER HEART
HOW TO USE THE APPLICATIONS HOW TO USE THE APPLICATIONS
➌
Baby Heart and History Management
Check your baby’s health status using SKEEPER, which displays a
digital index, heartbeat sound and graph in real time. The measure-
ment results are recorded by state and time for management, and
health changes and distribution are also provided.
➌
Special
Measurement
Special
Measurement
has
three
functions.
-
“Heart
recovery
checks
and
manages
the
heart
after
exercise
-
“Caffeine
sensitivity”
checks
your
sensitivity
to
caffeine
after
drinking
coffee
-
“Alcohol
sensitivity”
checks
your
sensitivity
to
alcohol
after
drinking
beer.
SKEEPER BABY is a smart application for your adorable baby’s healthcare
➊ Multi-profile Management
Manage multi-profile with SKEEPER BABY app.
Create a profile of your lovely baby by touching the image file
shown in the upper area of the left side of the menu and then
touching below to change the profile during the health check
and management.
SKEEPER HEART is a smart application for your precious family’s healthcare
➊ General Measurement
SKEEPER enables heart management with an experts’ level through
an optimized “Smart Algorithm”. SKEEPER precisely reads and
analyzes the changes and regularity of heart sounds from the
human body.
➋ Mom’s Heart Sound Lullaby
Mom’s heart sound lullaby helps brain development of infants,
sentiment and sleep stability. (It’s the same as producing mom’s
heart sound music of SKEEPER MAMA.)
➋ Stress Measurement
Check and manage individual stress through SKEEPER. The individual
data, which was measured through general measurement, were
averaged and compared with stress measurement. Analysis data
includes burn-out index, BPM, regularity, and personal health
condition through interview score.
13 14
PRODUCT SPECIFICATION / INQUIRY ETC
Specification
Inquiries
If you have any problems or inquiries during the use of the product, you can receive
information and service from the homepage of our company (www.ismartsound.com).
Regarding failures that occur within three months after purchase during normal use, you
can receive free exchange service after confirmation of your purchase details (However,
failures caused by carelessness of consumers or arbitrary disassembly shall not be
included in the range of compensation of our company).
Wireless Connection
Basic Specification
Battery
Compatibility
Bluetooth
Profile
BLE 4.0
HFP
Size (W X D X H)
Weight
Port
Sensor Type
Materials(Upper)
Colors
Power Source
Battery Type
Recharging Time
Hour of Battery Use
Android Models
iphone Models
62mm x 62mm x 35mm, 40
53g
Micro USB, 3.5 Audio Jack
MEMS
Rubber
Baby Pink, Baby Blue
Battery
Built-in Rechargeable Lithium-
Polymer Battery
About 80Min. by Micro USB Cable
About 8 Hours (Measurement)
Support Android 4.1.2 or later version
Support iPhone 5 or later version
15
SMARTSOUND CORPORATION
4F, 171, Yangjaecheon-ro, Gangnamgu, Seoul, Republic of Korea (06302)
h. http: // www.ismartsound.com
e. contact@ismartsound.com
t. +82 2.575.2252 Made in korea
Table of contents
