SMARTWINGS INS-C034 User manual

A-01 Feb 2023
INS-C034

PARTS INCLUDED :
TOOLS YOU WILL NEED :
1x
1x 2x
1x
1x 1x
1x
1x
1x

Motor Installation
The joint assembly of track
Note: The track needs to be engrafted when the length is less the required.
The track needs to be engrafted when inconvenient to transport.
1. Unfold the folded track to install.
Sufficient distance needs to be reserved between the two ends of the track, when you install the track, make
sure to put them on a sufficiently flat surface. (on a large table or on a clean floor).
2. Prepare to install the overlap arm (Fig 2-a), it needs to be in the opposite direction to the pre-installed overlap
arm (Fig 2-b), use the belt buckle (Fig 2-c) at the end of the belt to thread the overlap arm.
Fig 2-a
Fig 2-b
Fig 2-c Fig 2-d

3. Put the belt buckle and overlap arm into the track (Fig 1-a), please align the combined belt buckle and overlap
arm with the designated position on the track (Fig 3-c), and then slide into the track (Fig 3-d).
4. Now you will splice the overlap arm and the slip part on the track, pull the overlap arm and the slip part by hand
to put them together(Fig 4-a), and after joining them (Fig 4-b), the two pieces of track will automatically move
closer together (Fig 4-c).
Fig 3-a
Fig 4-a
Fig 4-b
Fig 3-b
Fig 3-c Fig 3-d

Fig 4-c
Fig 5-a Fig 5-c
Fig 5-d Fig 5-e
5. Align the two round holes of the overlap arm and the slip part (Fig 5-a), put the screws(Fig 5-b) from the kit
into the overlapping round holes (Fig 5-c), and tighten them with a screwdriver (Fig 5-d).
Fig 6-a
Fig 6-b
6. Then splice the two tracks together.
Flip the track over first (Fig 6-a), turn the screw slightly with a screwdriver to make sure the screw is
completely loose (Fig 6-a), then flip it back.
Fig 5-b

Fig 7-a
Fig 7-b
Fig 7-c
7. Align the two sections of track(Fig 7-a), slide the track adapter bracket towards the cut so that it wraps
around the two ends of the track(Fig 7-b), and then let the track adapter bracket be in the middle(Fig 7-c).
Fig 8-a
8. Flip the track over again (Fig 8-a) and tighten the screws on the back with a screwdriver to ensure that the
two sections of the track will not loosen or slip out.
Mount accessories on the track
Fig 9-a Fig 9-b
9. The accessories include end hooks (Fig 9-a), which can be installed at the end of the track (Fig 9-b), so that
your curtain can be hung on it to cover the track and motor, you can install it on the front (Fig 9-c), or you can
install it on the back (Fig 9-d) to allow the curtain to cover the track in a wider range and motor.

Fig 9-c Fig 9-d
Note: that the end hooks cannot be installed after the track is secured to the ceiling (next step).
10. Next, you can install the track to the place you want to install, please make sure the track is parallel to the
wall before installation.
When the curtain leaves the factory, the fixing bracket will be installed in a suitable position (Fig 10-a). When
installing it on the wall or ceiling, please install screws in the 3 screw holes reserved for the fixing bracket (Fig
10-b).
Install the track on ceilings
Fig 10-a
Fig 10-b

Fig 11-a Fig 11-b
11. Follow the direction indicated in the picture(Fig 11-a) and use the screws in the accessory bag to install the
track(Fig 11-b).
Fig 11-c
Fig 11-d

Fig 12-e
12. 如果你需要在墙壁侧面安装轨道，你需要使用延长支架
在将要安装开合帘的墙面上，在水平的位置左上标记，使用水平仪确保线是水平的。用这条线作为安
装螺丝的参考。
使用螺丝将窗帘轨道固定在延长支架上
45mm
(1.77”)
45mm
(1.77”)
Fig 12-a Fig 12-b
Fig 12-c Fig 12-d

Fig 12-f
Fig 12-g
Fig 12-h
使用螺丝，将开合帘固定到墙壁上的延长支架上

安装幔头固定支架
Click! !
13. 为窗帘添加幔头
Fig 13-a Fig 13-b
Fig 13-c Fig 13-d
Fig 13-e

如果想要幔头更好的遮罩住窗帘的轨道，你可以折弯魔术贴支架，确保魔术贴的一面朝外折弯。
Fig 13-f
Fig 13-g
Fig 13-h

Fig 14-c
Fig 15-a
Fig 14-d
Fig 15-b
15. If you want to remove the motor, you need to pull out the toggle button by hand (Fig 15-a), and then turn it
to the original direction (Fig 15-b) to remove the motor.
14. The motor can be installed on any side of the track.
Align the metal shaft of the motor (Fig 14-a) with the slot at the end of the track (Fig 14-b) and insert it with
your hand; then turn the button on the motor to the other side (Fig 14-d), as shown in the figure, until it
clicks.
Install the motor
Fig 14-a Fig 14-b
