SMARTWINGS Drapery User manual

INS-C034-A
A-05 Dec 2023
Quick Installation Guide
Drapery

TABLE OF CONTENTS
1. Track Splicing.............................................3
2. Fabric Hook Installation..............................4
3. Track Installation........................................5
3.1 Ceiling Mount..........................................5
3.2 Wall Mount.............................................7
4. Valance Installation....................................9
5. Motor Installation......................................10
6. Fabric Installation......................................11
7. Remote Holder Installation.........................12

Fixed Brackets
1

Ceiling Mount
Wall Mount
2

Flip the drapery back and tighten the four screws securely.
Loosen the four screws on the track joint bracket connecting the two tracks.
Flip the track over and align the two tracks.
Fig 1-a
Fig 1-b
Fig 1-c
Fig 1-d
Step 1 Loosen Screws
Step 2 Align Tracks
Slide the track joint bracket to the point where the two tracks disconnect. Aim to center
the bracket at the disconnect point.
Step 3 Adjust Position
Step 4 Tighten Screws
Peel off the protective plastic film from both ends of the track. If the track length is less than
102"(2600mm), this step can be skipped and please turn to page 4 because tracks under
102"(2600mm)remain as one piece without the need for joining. For tracks longer than
102"(2600mm), refer to page 3 for guidance, as they will be cut into 2 pieces.
3
Track Splicing

Insert the fabric hook with the hooked end facing up into either of the two smaller holes on the
end (this step cannot be installed after the track is secured to the ceiling (next step)).
With Fabric Hook
Method 1 Method 2
Without Fabric Hook
Fig 2-a Fig 2-b
Fig 2-c
Fig 2-d
Fabric Hook Installation
After installing the fabric hook, use it to elegantly cover the end of the track and conceal the
motor for a more aesthetically pleasing look. The effect shows as Fig 2-c.
4

Rotate the lower metal buckle of the fixed bracket clockwise to the right. Snap the bracket onto the
track. Return the metal buckle to its original position. Tighten the screws securely, ensuring they
are firmly in place. Double-check to ensure the attachment is securely fixed.
* When installing it on the wall or ceiling, please install screws in the 3 screw holes reserved
for the fixed bracket.
Fig 3.1-b
Fig 3.1-c
5
Track Installation
Choose between ceiling or wall installation for your drapery. If installing on the ceiling, fixed
brackets should be used, then the installation steps refer to page 5. For wall installation, install
both fixed brackets and extension brackets according to page 7.
Install the track, the fixed brackets should be used.
Fig 3.1-a
Ceiling Mount
Step 1 Install the Fixed Bracket

Follow the direction indicated in the picture and use the screws in the accessory bag to
install the track.
Fig 3.1-d
6
Step 2 Install track to the Wall

Rotate the lower metal buckle of the fixed bracket clockwise to the right. Snap the bracket
onto the track. Return the metal buckle to its original position. Tighten the screws securely,
ensuring they are firmly in place. Double-check to ensure the attachment is securely fixed.
Align the bend in the extension bracket with the line on the wall you just drew.
Fig 3.2-a
Fig 3.2-b Fig 3.2-c
Install the drapery on the wall, extension brackets should be used.
Wall Mount
7
Fig 3.2-d
Step 1 Install the Extension Bracket
Step 2 Install the Fixed Bracket
Track Installation

Fig 3.2-e
8
Place the extension bracket on top of the fixed bracket, align the two holes and secure with
the screws.
Step 3 Install track to Extension Bracket

Install valance fixed bracket by putting screw in mounting hole and using bolt to Lock.
Fig 4-a Fig 4-b
Fig 4-c Fig 4-d Fig 4-e
Fig 4-f
9
Step 1 Install Valance Fixed Bracket
You can bend the valance fixed sticker with the help of the hard object so that it can better
cover Track.
Step 2 Insert the valance fixed sticker
Step 3 Attach the Valance
Valance Installation
If you haven't purchased the valance or are installing the drapery on the ceiling, you can skip
this step. Proceed to page 10.

If you want to remove the motor, just repeat the last step.
Fig 5-a
Fig 5-b Fig 5-c
10
Motor Installation
Pull down and forward of the knob located under the motor to unlock it. Align the holes at the
end of the track and insert the motor. Turn the pull knob back to its original position to securely
lock the motor in place.

Fig 6-a
Fig 6-b Fig 6-c
11
Fabric Installation
Match the hooks on the drapery fabric with the hanging wheels on the track one by one.
Additionally, you have the flexibility to fine-tune the drapery by adjusting the hooks up or down.

12
Remote Holder Installation
