Extended Range SMCHP1D-USB
EZ ConnectTM 14 Mbps Powerline to USB Desktop Adapter
www.smc.com
The EZ Connect™ 14 Mbps Powerline to USB Desktop Adapter
(SMCHP1D-USB) is the easiest way to create or extend a home
network. The Powerline to USB Desktop Adapter is compatible
with Windows 98, Me, 2000, XP, and is ideal for connecting a
desktop or laptop in another room of the house without having
to run expensive CAT-5 cabling. Combine the EZ Connect
Powerline to USB Adapter with the EZ Connect Powerline to
Ethernet Desktop Adapter (SMCHP1D-ETH) for a complete
Powerline solution from your Router to your PC.
The EZ Connect 14 Mbps Powerline to USB Adapter is compatible
with the HomePlug 1.0 standard to work across all the types of
home wiring. Using auto-sensing and rate-adaptive technology,
the Powerline to USB Adapter insures that your connection
maintains the highest performance available. Combine this
performance with a 56-bit Data Encryption Standard (DES)
with Key Management security feature and you have a
complete solution that is fast and secure.
The EZ Connect 14 Mbps Powerline to USB Adapter comes with
the EZ Configuration Manger utility which is the only Powerline
management software that runs on both the PC and Mac
platforms. This feature-rich utility allows you to manage your
network with a friendly naming option for each Powerline
device in your network, view connection status, and monitor
throughput information. For additional status information, the
SMCHP1D-USB has easy-to-read diagnostic LEDs which will
display if a Powerline network is available as soon as it is
plugged into the power outlet.
As with all SMC products, the EZ Connect™ Powerline products
also ship with the EZ Install Wizard to guide you through a
simple plug-and-play installation. All of these features combined
with our innovative desktop chassis, which allows you to
connect in places where a bulky wall-mounted adapter won’t fit,
and you have the ideal Powerline network solution to extend
the range of your wired or wireless network.
FEATURES
HomePlug 1.0 Compatible
No New Wires Required – uses existing wiring in your home
Data transfer rates up to 14Mbps
Plug-and-Play Installation
Easy-to-Read Diagnostic LEDs
56-Bit Data Encryption Standard (DES)
Innovative Compact Desktop design that goes where bulky wall
mounted adapters won’t fit.
Auto-sensing and rate-adaptive technology to minimize
interference from other household appliances and maintain
high performance.
EZ Install Wizard for easy setup and configuration
Supports up to 16 Powerline devices communicating on
a single network
Save time and money by using the existing power lines in
your house
Up to 14Mbps Data Rate which is faster then 802.11b
Pre-configured hardware for immediate connectivity
Diagnostic LEDs for Data Transfer information and
Powerline network availability.
Protect your information with the 56-Bit DES security option
Stand-Alone Unit Attaches Directly to Broadband Device
and Home Powerline Network for Seamless Integration
Turn each power outlet in a house into a network
connection point
EZ Configuration Manager allows users to independently manage
their Powerline network by supporting friendly names, through-
put information, and connection status.
BENEFITS
OVERVIEW

TECHNICAL SPECIFICATIONS SMCHP1D-USB
NETWORK INTERFACES
• One USB V1.1
• Electrical plug (HomePlug Ethernet)
POWERLINE STANDARDS
• HomePlug v1.01 compatible
LEDs
• Power (PWR)
• HomePlug LINK/ACT (HP)
POWER INPUT
• 100-240VAC @ 50~60Hz (internal) 0.15A
USB STANDARDS
• USB 1.1
ADDITIONAL PROTOCOLS
• Forward Error Correction (FEC)
• Automatic Channel Adaptation
SECURITY
• 56-bit Data Encryption (DES) with
Dynamic Key Management
CONFIGURATION MANAGER SOFTWARE
• Device Detect/Diagnostic
• NEK Password Setup for Local and
Remote Device
CONFIGURATION MANAGER SUPPORT
• Windows 98, 2000, Me, NT, and XP
• Mac OS 9.x and OS X 10.1.x
CERTIFICATIONS
• FCC Part 15 Class B
• CE
FREQUENCY
• 4.3 MHZ – 20.9 MHZ
MODULATION
• OFDM Symbol Modulation,
MODULATION SCHEMES
• DQPSK, DBPSK, ROBO Carrier Modulation
TYPICAL COVERAGE
• Up to 5000 square foot home
USB DRIVER SUPPORT
• Windows 98, 2000, Me, and XP
HUMIDITY
• Operating: 10% to 90% Non-Condensing
TEMPERATURE
• Operating: 32º to 104º F / 0º to 40º C
WARRANTY
• Limited Lifetime
DIMENSIONS
• 3.05 x 4.53 x .98 in
• 77.5 x 115 x 25 mm
WEIGHT
•3.53oz
• 100g
