SMC Networks IDF15E1-10 User manual

IDX-OM-O004E-A
Initial release: February 2011
2th edition: November 2016
PRODUCT NAME
Refrigerated Air Dryer
MODEL
IDF15E1-10 (-A,C,K,L,M,R,S,T)
IDF15E1-20 (-A,C,K,L,M,R,T)
Keep thismanual available whenever necessary.
© 2016 SMC CORPORATION All Rights Reserved.
This manual is intended to explain the installation and operation of the product.
Only people who understand the basic operation of the product, or have basic
knowledge and ability to handle industrial machinery, are allowed to work on the
product.

Foreword
Thank you for purchasing SMC’s refrigerant type air dryer (hereinafter referred to as the “product”).
For safety and long life of the product, be sure to read this Operation Manual (hereinafter referred to as the
“manual”) and clearly understand the contents.
●The instructions described in this manual must be followed in addition to ISO 4414*1) and JIS B 8370*2)
and other safety regulations.
*1) ISO4414: Pneumatic fluid power – Recommendations for the application of equipment to
transmission and control systems.
*2) JIS B 8370: General rules for pneumatic equipment.
●This manual is intended to explain the installation and operation of the product. Only people who
understand the basic operation of the product through this manual, or who install and operate industrial
machinery and have basic knowledge and ability to handle such equipment, are allowed to work on the
product.
●This manual and other documents attached to the product do not constitute a contract, and will not affect
any existing agreements or commitments.
●It is strictly prohibited to copy this manual entirely or partially for use by a third party without prior permission
from SMC.
Note: This manual is subject to change without prior notice.

To Customers
Chapter i Safety Instructions
i . 1 Warning: Before using this product ................................................i - 1
i .1. 1 Danger, Warning and Caution.....................................................................i - 1
i . 2 Hazard classification and locations of hazard labels...............i - 2
i . 2. 1 Hazards.......................................................................................................i - 3
i . 2. 2 Warning related to electricity.......................................................................i - 3
i . 2. 3 Warning related to high temperature..........................................................i - 3
i . 2. 4 Warning related to rotating objects.............................................................i - 3
i . 2. 5 Warning related to pneumatic circuit ..........................................................i - 4
i . 2. 6 Location of hazard label..............................................................................i - 4
i . 2. 7 Caution related to refrigerant......................................................................i - 5
i . 2. 8 Caution related to handling.........................................................................i - 6
i . 2. 9 Other labels.................................................................................................i - 6
i . 3 Waste disposal..........................................................................................i - 7
i . 4 Limited warranty and Disclaimer / Compliance Requirements ......i - 8
Chapter 1 Name and Function of Parts
1 . 1 Name and function of parts................................................................1 - 1
Chapter 2 Transportation and installation
2 . 1 Transportation..........................................................................................2 - 1
2 . 2 Installation .................................................................................................2 - 2
2. 2. 1 Environment...............................................................................................2 - 2
2. 2. 2 Fixing of product ........................................................................................2 - 3
2. 2. 3 Pneumatic piping .......................................................................................2 - 4
2. 2. 4 Draining piping...........................................................................................2 - 4
2. 2. 5 Electric wiring.............................................................................................2 - 5
2 . 3 Reinstallation of the product .............................................................2 - 6
Chapter 3 Start and stop
3 . 1 Before starting .........................................................................................3 - 1
3 . 2 Start...............................................................................................................3 - 1
3 . 3 Stop...............................................................................................................3 - 2
3 . 4 Precautions for restarting operation..............................................3 - 2
3 . 5 Check items after starting...................................................................3 - 2
3 . 6 Precautions for long-term non-operation .....................................3 - 2
Chapter 4 Checks and inspection
4 . 1 Daily check................................................................................................4 - 1
4 . 2 Parts requiring regular maintenance..............................................4 - 1
4. 2. 1 Cleaning the condenser and aftercooler fins.............................................4 - 1
4. 2. 2 Service parts..............................................................................................4 - 1
4. 2. 3 Cleaning the auto drain strainer.................................................................4 - 1
4. 2. 4 Replacement of case assembly.................................................................4 - 2
Table of Contents

Chapter 5 Troubleshooting
5 . 1 Troubleshooting......................................................................................5 - 1
Chapter 6 References
6 . 1 Specification table..................................................................................6 - 1
6 . 2 Refrigerant with GWP reference.......................................................6 - 1
6 . 3 Outer dimensions...................................................................................6 - 2
6 . 4 Electric wiring diagram ........................................................................6 - 2
6 . 5 Pneumatic and refrigerant circuits and their functions........ 6 - 3
Chapter 7 Specification for Option A
7 . 1 Safety instructions.................................................................................7 - 1
7 . 2 Specifications...........................................................................................7 - 1
7 . 3 Air piping....................................................................................................7 - 1
Chapter 8 Specification for Option C
8 . 1 Safety instructions.................................................................................8 - 1
8 . 2 Specifications...........................................................................................8 - 1
8 . 3 Precautions for the installation and handling of the product........8 - 1
Chapter 9 Specification for Option K
9 . 1 Safety instructions.................................................................................9 - 1
9 . 2 Specifications...........................................................................................9 - 1
Chapter 10 Specification for Option L
10 . 1 Safety instructions...............................................................................10 - 1
10 . 2 Specifications.........................................................................................10 - 1
10 . 3 Installation of heavy duty auto drain............................................10 - 2
10 . 4 Maintenance............................................................................................10 - 2
Chapter 11 Specification for Option M
11 . 1 Safety instructions...............................................................................11 - 1
11 . 2 Specifications.........................................................................................11 - 1
11 . 3 Installation of motor type auto drain............................................11 - 2
11 . 4 Electric wiring diagram ......................................................................11 - 2
Chapter 12 Specification for Option R
12 . 1 Safety instructions...............................................................................12 - 1
12 . 2 Specifications.........................................................................................12 - 1
12 . 3 Power supply connection procedure...........................................12 - 1
12 . 4 Cautions for handling the GFCI......................................................12 - 2
12 . 5 Electric wiring diagram ......................................................................12 - 2
Chapter 13 Specification for Option S
13 . 1 Safety instructions...............................................................................13 - 1
13 . 2 Specifications.........................................................................................13 - 1
13 . 3 Electric wiring diagram ......................................................................13 - 2
Chapter 14 Specification for Option T
14 . 1 Safety instructions...............................................................................14 - 1
14 . 2 Specifications.........................................................................................14 - 1
14 . 3 Remote operation.................................................................................14 - 1
14 . 4 How to connect the power and signal cable.............................14 - 2
14 . 5 Electric wiring diagram ......................................................................14 - 3

i Safety Instructions
i - 1
i.1 Warning: Before using this product
This chapter is intended to specifically describe the safety related issues for handling the product. Read this
before handling the product.
- The product is designed to dehumidify compressed air. SMC does not take any responsibility for any
problems that may arise from using the product for other purposes.
- The product is operated at high voltage and contains components which become hot and rotate. If a
component needs to be replaced or repaired, contact a specialized vendor for parts and service.
All personnel who work with or around the product should read and understand the safety related
information in this manual carefully before starting work.
- This manual is not a comprehensive manual covering safety and health related issues. This should be
handled by a person in charge of safety training.
- All personnel who work with or around the product should have sufficient knowledge about the dangers
inherent to the product and be trained in safety measures.
- The safety manager is responsible for strictly observing safety standards, but responsibility in respect to
safety standards during daily work resides with each individual operator and maintenance personnel.
- The operator and maintenance personnel should consider work places and environments for each task
with due consideration of safety issues.
- It is necessary to undergo appropriate general safety training before being trained about this product.
Training without having sufficient knowledge about safety is very dangerous. Training must not be
conducted without consideration to safety.
- This manual must be kept available to the operator whenever necessary.
- If the product is subjected to a short power outage (including voltage sag), it may take a long time to start
operating normally or be unable to restart normally due to the protective equipment triggered after the
power is recovered. In that case, turn off the switch with lamp on the body once, on dryer panel and wait 3
minutes. After this step, turn on the switch to restart. Sudden restart of the product is possible after the
recovery of power, so be sure to turn off the switch with lamp when removing the cover panel of the
product.
i.1.1 Danger, Warning and Caution
The instructions given in this manual aim to assure the safe and correct operation of the product, and to
prevent injury of operators or damage to the product. These instructions are grouped into three categories,
"Danger", "Warning" and "Caution", which indicate the level of hazard, damage and also the degree of
emergency. All safety critical information should be carefully observed at all times.
DANGER, WARNING and CAUTION signs are in order according to severity (DANGER> WARNING>
CAUTION). The signs are explained on the following page.
Danger
"Danger" indicates a hazard with a high level of risk which will result in death or serious
injury if an operator performs incorrect handling during the operation and maintenance of
the product or does not follow the instructions necessary to avoid it.
Before using the product be sure to read and understand all the
important actions highlighted in this manual.
Safety Instructions
ｉ

i Safety Instructions
i - 2
Warning
“Warning” indicates a hazard with a medium level of risk which will result in death or serious
injury if an operator does not follow the specified procedures during the operation or
maintenance of the product or does not follow the instructions necessary to avoid it.
Caution
“Caution” indicates a hazard of a low level of risk which will result in minor and moderate
injury or damage to product and equipment if an operator does not follow the specified
procedures during the operation and maintenance of the product or does not follow the
instructions to avoid it.
i.2 Hazard classification and locations of hazard labels
The product has various potential hazards and they are marked with warning labels. Read this section
before starting any work on the product.
Warning
- Only trained personnel should handle the product.
- Only people who have sufficient knowledge and experience about the product and its
accessories are allowed to carry out transportation, installation and maintenance work.
- Only maintenance personnel or people who have sufficient knowledge and experience are
allowed to open the cover panels of the product.
Warning
If any error occurs, take measures as instructed in this manual.
Warning
- If any error occurs, do not start operating the product.
- If any error occurs, immediately stop the product, and call for the maintenance personnel or
a person who has sufficient knowledge and experience about the product and its
accessories.

i Safety Instructions
i - 3
i.2.1 Hazards
The hazards inherent to the product are as follows.
Warning related to electricity
The product is operated at a high voltage and can cause electrical shock internally. This risk is
indicated with the mark in addition to “Danger”, “Warning” and “Caution” on the product or in this
manual.
Warning related to heat
The product has surfaces that can reach high temperatures during operation, which may cause burns.
This risk is indicated with the mark in addition to “Danger”, “Warning” and “Caution” on the
product or in this manual.
Warning related to rotating objects
The product has parts that will rotate during operation, which may cause fingers to get caught and
injured. This risk is indicated with the mark in addition to “Danger”, “Warning” and “Caution” on the
product or in this manual.
i.2.2 Warning related to electricity
The product is operated at a high voltage and contains the power supply isolated by the cover panel.
Do not operate the product without cover panels fitted.
Only people who have sufficient knowledge and experience are allowed to perform work and
inspections in locations with the power supplied.
Warning
- Fully read and understand the contents of the hazard labels.
- Do not peel or rub off the hazard labels.
- Carefully confirm where the hazard labels are affixed.
i.2.3 Warning related to high temperature
Warning
The product has surfaces that can reach high temperatures during operation, and cause
burns by contact. Even after the power is turned off, there can still be residual heat in the
product, which may cause burns. Do not start work until the temperature of the surfaces
has fallen below 50oC.
i.2.4 Warning related to rotating objects
Warning
The product has parts that can rotate during operation, and cause injury by contact. Also,
the rotating parts might stop rotating temporarily and restart during operation. Do not
perform work during operation.

i Safety Instructions
i - 4
i.2.5 Warning related to pneumatic circuit
Warning
Be sure to release compressed air from the product and ensure the internal pressure is
zero before replacing or cleaning the parts of the product. If the compressed air is left in the
product, when some part is loosened, it may cause sudden lurching or other unexpected
accidents.
i.2.6 Location of hazard label
Warning
- Fully read and understand the contents of the hazard labels.
- Do not peel or rub off the hazard labels.
- Carefully confirm where the hazard labels are affixed.
Front
WARNING 警告
!
1 Remove panelsfor maintenance only.
2 Never insert anything into product to ensure
safety.
3 Cut power prior to maintenance to prevent
electric shock.
4 Settle product to room temp.before main-
tenance toprevent burn or frostbite.
5 Ensure zero air pressure before replacing parts.
1 点検以外はﾊﾟﾈﾙを取り外さないこと。
2 回転物があるので指、棒状の物を差し
込まないこと。
3 感電の恐れがあるので、点検の前には電源を
切ること。
4 火傷の恐れがあるので、点検の前には装置を
常温にすること。
5 部品交換の前には必ず、空気圧力を"0"に
すること。
!

i Safety Instructions
i - 5
Front
i.2.7 Caution related to refrigerant
Caution
- The product uses hydro-fluorocarbon type refrigerant (HFC).
- The product is categorized as category 1 under the fluorocarbon recovery and destruction
law in Japan.
The release of refrigerant into the atmosphere is banned by law. When the product is
serviced, the refrigerant must be recovered using “refrigerant recovery equipment” and
disposed of by a specialist disposal company. Only people who have sufficient knowledge
and experience about the product and its accessories are allowed to recover the
refrigerant.
- Only maintenance personnel or people who have sufficient knowledge and experience are
allowed to open the cover panels of the product.
- The type and necessary amount of HFC can be found on the specification label explained on
page 6 of Section i.

i Safety Instructions
i - 6
i.2.8 Caution related to handling
Warning
- Fully read and understand the contents of the hazard labels.
- Do not peel or rub off the hazard labels.
- Carefully confirm where the hazard labels are affixed.
i.2.9 Other labels
Confirm the model and specifications described in the label.
Front
CAUTION 注意
!
1 Read manual before operation.
2 Ensure vantilation and maintenance
space.
3 Keep water away from the product.
4 Secure In / Out connector with spanner
during piping.
5 Wait 3 minutes before restart.
6 Ensure Running Condition / Evaporating
Temp. in green zone.
1 ご使用前に必ず取扱説明書を読んでください。
2 通風、メンテナンススペースを確保して
ください。
3 雨や水滴がかからないようにしてください。
4 ＩＮ／ＯＵＴポートをスパナで固定して
配管してください。
5 再起動は運転停止３分後に行ってください。
6 ＲＵＮＮＩＮＧ ＣＯＮＤＩＴＩＯＮ・蒸発温度計は
グリーン帯で使用してください。

i Safety Instructions
i - 7
i.3 Waste disposal
When disposing of the product, recover the refrigerant and compressor oil contained in the refrigerant
circuit.
Caution
- The product uses hydro-fluorocarbon type refrigerant (HFC).
- The product is categorized as category 1 under the fluorocarbon recovery and destruction
law in Japan.
- The release of refrigerant into the atmosphere is banned by law. When the product is
serviced, the refrigerant must be recovered using “refrigerant recovery equipment” and
disposed of by a specialist disposal company.
- Only people who have sufficient knowledge and experience about the product and its
accessories are allowed to recover the refrigerant.
- Only maintenance personnel or people who have sufficient knowledge and experience are
allowed to open the cover panels of the product.
- The type and necessary amount of HFC can be found on the specification label.
Caution
- The disposal of the compressor oil must be in compliance with the bylaws or rules of the
local municipality.
- Do not mix the compressor oil with domestic waste for disposal. Also, the disposal of the
waste must only be conducted by specific facilities that are permitted for that purpose.
- Only people who have sufficient knowledge and experience about the product and its
accessories are allowed to recover the compressor oil.
- Only maintenance personnel or people who have sufficient knowledge and experience are
allowed to open the cover panels of the product. If anything is unclear, contact your local
supplier or SMC.

i Safety Instructions
i - 8
i.4 Limited warranty and Disclaimer / Compliance Requirements
The product used subject to the following “Limited warranty and Disclaimer“ and “Compliance Requirements.
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or 1.5 years after the product is delivered.
Also, the product may have specified durability, running distance or replacement parts. Please consult
your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our responsibility, a
replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage incurred
due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers noted in
the specified catalog for the particular products.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are govemed by the relevant
security laws and regulation of the countries involved in the transaction. Prior to the shipment of a SMC
product of a SMC product to another country, assure that all local rules goveming that export are known
and followed.
Caution
The Product is provided use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange
specifications or a contact if necessary.
If anything is unclear, contact your nearest sales branch.

1. Name and Function of Parts
1 - 1
1.1 Name and function of parts
Name and Function of Parts
１
Appearance
Front
Switch with lamp
The switch to start and stop the product,
which will light up in green during operation.
Evaporation thermometer
Displays the
evaporating temperature of
refrigerant.
Normally, it is in the green area.
Drain tube
Discharges drain.
Ventilation air outlet
Hot air will be exhausted from
condenser by fan. No obstacles
shall be allowed to place on top
of it or even close the grille.
Drain confirmation window
From this confirmation window,
confirm the discharge of drain.
Auto drain
It is covered with insulator, which
should not be removed.
Front panel mounting screw
Another one is on the left side.
Front panel removal

1. Name and Function of Parts
1 - 2
Rear panel
You can see the terminal block when you
remove this cover. Connect the power
cable through the membrane grommet.
Terminal connecting screw: M3
Crimped terminal width: 6.5mm or less
Applicable electric wire: 1.25mm2or more
Rear
Rear
Air outlet piping
A port to exhaust air.
Air inlet piping
A port to supply air.
IDF15E1-10 (100V AC specification)
Front
Ventilation air inlet
Breathe in cooling air from
this grille. Do not bung up
with wall and so on.
Front panel mounting screw
Another one is on the right side.
Earth screw
Connect the earth to
this screw.
Power supply cable
Insert the plug to a
100V AC only outlet.
IDF15E1-20 (200V AC specification)
Front
L NPE
（ ）
To the user’s machine
Rubber grommet
Power supply cable entry

2. Transportation and installation
2 - 1
Warning
- Use the product in an appropriate manner, and pay attention to safety, particularly physical
safety of operators, during the installation, operation, maintenance and checks of the product.
- When the product is used for a critical facility or equipment, prepare a spare product or
alternative machine in case of stoppage of the product due to the operation of the protective
equipment or the failure of the product itself.
Caution
- Only people who have sufficient knowledge and experience about the product and system are
allowed to perform the transportation, installation and maintenance of the product, including
dangerous work.
2.1 Transportation
Be sure to follow the instructions below when transporting the product.
- The product is filled with refrigerant. Transport it (by land, sea or air) in accordance with laws and
regulations specified.
- You should lift the product from the base surface with careful attention to prevent tipping over.
- Do not lay the product sideways, or you will damage the product.
- Do not suspend the product from the ceiling or hang from the wall.
- Do not transport the product with any part such as an air filter mounted on the fittings at the air inlet or
outlet port of the product. If it is unavoidable to transport the product with such a part mounted, support
the mounted part with a bracket to prevent the product from being affected by vibration during
transportation.
- Do not lift the product by holding the panel, fittings or piping.
Warning
The product is heavy and has potential dangers in transportation. Be sure to follow the
instructions above.
- To transport the product, a tool like a fork lift must be prepared.
Transportation and installation
２

2. Transportation and installation
2 - 2
2.2 Installation
2.2.1 Environment
(1) Do not use or store the product under the following conditions, as these may cause breakage of the
product as well as a failure of the product to operate.
•In an environment where the product will come into direct contact with rain, wind and snow or with a lot of
moisture (relative humidity 85% or more).
•In a location with a large quantity of dust.
•In a location containing flammable or explosive gases.
•In a location exposed to corrosive or flammable gases or solvent.
•In a location where the ambient temperature is outside the following ranges.
In operation: 2 to 40oC, In storage: 0 to 50°C (with no condensate in piping)
•In a location that is subjected to abrupt changes in temperature.
•In a location that is subjected to strong electromagnetic noise (intense electric field, intense magnetic field,
or surges)
•In a location that is subjected to static electricity, or conditions where static electricity can discharge to the
product.
•In a location that is subjected to strong high frequency radiation (microwaves)
•In a location that is subjected to potential lightning strikes.
•Locations by loading on vehicles, marine vessels, and so on.
•In a location with an altitude of 2,000 metres or higher.
•In a location where the product is affected by strong vibrations or impacts.
•Conditions where external force or weight is applied that could deform the product.
•In a location where there are obstacles blocking the ventilation ports of the product.
•In a location where the dryer is drawing in high temperature air that is discharged from an air compressor
or other dryers.
(2) Contact SMC beforehand and take special consideration of safety measures if the product is to be used in
any of the following conditions.
•Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
•Installation on equipment in conjunction with atomic energy, railways, air navigation, shipping, vehicles,
medical treatment or recreation equipment, or equipment in contact with food and beverages,
emergency stop circuits, clutch and brake circuits in press applications, safety equipment or other
applications unsuitable for the standard specifications described in the product catalog.
•An application which could have negative effects on people, property, or animals requiring special safety
analysis.

2. Transportation and installation
2 - 3
2.2.2 Fixing of product
Mount the product on a flat and stable floor with no vibrations.
- Refer to “6.2 Outer dimensions” on page 6-2 for dimensions.
- Use the foundation bolts to prevent the product from falling over.
The foundation bolts are available separately as a set.
- If there is not enough space around the ventilation ports of the product, loss of the original performance or
failure of the product can result. Follow the conditions shown in the figure below for installation.
∗ 1 The necessary maintenance space is to conduct maintenance and repairs when the product fails. Ensure
that sufficient space can be secured for repair.
Necessary maintenance space ∗1
1. Top 600mm or more
2. Front 600mm or more
3. Right side 600mm or more
4. Left side 600mm or more
5. Rear 600mm or more
1
23
4 5

2. Transportation and installation
2 - 4
2.2.3 Pneumatic piping
- Piping to the compressed air inlet and outlet should be connected with a union of fitting so that it can be
removed.
- Pressing the hexagonal fitting with screw wrench and so on, connect the air piping fittings to the body.
- When mounting any part such as an air filter on the fitting at the compressed air inlet or outlet port,
support the part to prevent excessive force from being applied to the product.
- Be careful not to transmit vibration resulting from the compressor.
- When the compressed air inlet temperature exceeds 50oC, install an aftercooler behind the air
compressor or decrease the temperature of the area where the air compressor is installed to keep it 50oC
or less.
- To prevent foreign matter such as dust from getting in the supply air to the product, flush the piping before
connecting. Dust or oil in the piping can cause cooling failure or other failures of the product. Install a
main line filter to the compressed air source to the product.
- Use a pipe capable of withstanding the specified operating pressure and temperature and connect so
that it will not have leakage.
- Be sure to install a bypass pipe to allow maintenance without stopping the air compressor.
The bypass piping sets
2.2.4 Draining piping
- The drain tube is equipped with a polyurethane tube of outside diameter 10mm. Release the draining end
of the tube to atmosphere to let condensate flow into a water outlet.
- Condensate will be drained regularly using compressed air pressure. Fix the draining end of the tube
firmly to prevent it from vibrating during draining.
- Ensure the drain tube does not rise up.
- Do not bend or crush thedrain tube. When installing the product, take care not to place the product on the
drain tube. Warning
- When draining, follow the user’s own procedure to keep operators safe. (E.g. Wear
protective goggles, apron and gloves to prevent contact with the drained condensate.)
- When oils can enter the drained condensate, waste water treatment is necessary.
Follow the bylaws or rules of the local municipality.
We recommend the bypass piping sets that
we are selling separately as accessories.

2. Transportation and installation
2 - 5
2.2.5 Electric wiring
Warning
Only qualified persons are allowed to wire the product.
- Before wiring, be sure to shut off the power supply. Never perform wiring work while the
product is energized.
- Ensure a stable power supply with no voltage surges.
- Ensure that an ground fault circuit interrupter with appropriate capacity for ground fault and
load is used in the power supply of the product to prevent electrical shock and burnout of the
compressor motor. See “6-1 Specification table” for details.
- Use a power supply suitable for the specifications of the product.
- Be sure to connect the ground connection.
- Grounding should never be connected to a water line, gas line or lightning rod.
- Multiple wiring is dangerous because it may lead to heat generation and cause a fire.
- Do not modify the electrical wiring of the power supply.
- For use in Europe, install a breaker compliant with applicable IEC standards to the power
supply of the prodct.
[Wiring of power supply]
There are two methods depends on model (specified power).
IDF15E1-10 (100V AC specification)
Insert the power plug into an outlet of AC100V.
∗ Be sure to install an ground fault circuit interrupter to the power supply. (To be prepared by the user.)
[Sensitivity of leak current: 30mA or less, Rated current: 10A]
Do not extend the power cable using power strip and so on.
That causes decrease of the voltage and the product cannot be operated.
IDF15E1-20 (200V AC specification)
Remove the terminal block cover or the rear cover in the rear of the product, and connect the power
(AC200V) to the terminal block.
∗ Be sure to install an ground fault circuit interrupter to the power supply. (To be prepared by the user.)
[Sensitivity of leak current: 30mA or less, Rated current: 10A]
Specifications of power supply cable
Prepare the following power supply cable.
Power supply cable: 1.25mm2(16AWG) or larger, Cable outside diameter Approx. 8 to 12mm, 3 cores
(including ground)
Approx. 0.1m is necessary to route the internal wiring of the product.
Power supply cable length
The power supply cable length from the product should be less than 30m.

2. Transportation and installation
2 - 6
Terminal block (refer to “1.1 Name and function of parts” for details).
Connect the power cable and the ground to the terminal block. The connection size is M3.
Be sure to use a round crimped terminal.
Applicable crimped terminal width: 6.5mm or less
[Wiring procedure]
1. Remove the terminal block cover or the rear panel.
2. Insert the cord through the rubber grommet and connect it to the terminal block (refer to the label on the
terminal block).
M3 screw tightening torque: 0.63 to 1Nm
During wiring work, do not touch other sections except terminal block.
3. Re-attach the cover or real panel after wiring is done.
2.3 Reinstallation of the product Caution
- Only people who have sufficient knowledge and experience about the product and its
accessories are allowed to reinstall the product in a different location. Also, be sure to
follow the instructions below.
When moving the product to a different location or reinstalling it after it has been used (including trial run),
follow the whole procedure in Chapter 2 beforehand.
- Disconnection of power supply cable
Be sure to cut the facility power supply before disconnecting the power supply cable.
Removal of pneumatic piping
Clean off any sealant debris after the piping is removed. If any sealant debris gets into the product during
reinstallation, it may lead to cooling failure or other product failures.
Warning
- Only people who have sufficient knowledge and experience are allowed to perform wiring.
- Before wiring, be sure to shut off the power supply. Never perform wiring work while the
product is energized.
Warning
- Only people who have sufficient knowledge and experience are allowed to perform piping work.
- Before removing piping, be sure to shut off the air supply and the product.
- Do not remove piping with any air pressure remaining internally.
