SMC Networks ID20 02 Series User manual

IDX-OM-X004-D
PRODUCT NAME
Heatless Air Dryer
MODEL / Series
ID20□-□02□
ID30□-□04□
ID40□-□04□
ID60□-□06□
Please read this manual prior of using the air dryer. Keep the manual readily available for
reference.

To Customers
Thanks for purchasing SMC Heatless Air Dryer.
This opertion manual must be read and understood throughoutly before handling. It provides all essential
information for maximizing product operating efficiency, as well as, for safe and longer life span operation.
For safety operation of SMC Refrigerated Air Dryer, read thoroughly and follow stated safety instructions, as well
as regulation stated within ISO 4414*1 & JIS B 8370*2.
*1) ISO 4414: Pneumatic fluid power – General rules and safety requirements for systems and their
components
*2) JIS B 8370: Pneumatic fluid power – General rules relating to systems
This manual explains about installation and operation of the product. Only those who have thorough
understanding of the fundamental operating procedure or have basic knowledge and skills of handling industrial
product for the installation and operation of the product are qualified to perform installation and operation.
The contents of the operation manual and the other documents attached to the product cannot become a part of
the contract clause or cannot change and modify existing agreements, promises, and relationship.
Any statements contained in the operation manual cannot be newly guaranteed and modify existing guarantee
certificate.
You are not allowed to copy any part of this operation manual for usage of third person without informing it to us
beforehand.
Caution: Please understand that the contents of this operation manual are subject to
changed without previous notice.

Heatless Air Dryer Table of Contents
Table of Contents - 1
Chapter i Safety Instructions
i -1 Warning: Before Using Air Dryer............................................................................i - 1
i - 1 - 1 Meanings of signs: Danger, Warning, Caution............................................................i - 1
i -2 Danger Classifications / Position of Danger warning label.............................i - 3
i - 2 - 1 Danger Classifications................................................................................................i - 3
i - 2 - 2 Danger of Electricity....................................................................................................i - 4
i - 2 - 3 Danger of CompressedAir Circuit..............................................................................i - 4
i - 3 Limited warranty and Disclaimer / Compliance Requirements.......................i -5
Chapter 1 Name of each Parts
1 - 1 Name of each Parts ....................................................................................................1 - 1
Chapter 2 Transportation / Installation
2 - 1 Transportation............................................................................................................2 - 1
2 - 2 Installation ...................................................................................................................2 - 1
2 - 2 - 1 Location.....................................................................................................................2 - 1
2 - 2 - 2 Anchorage.................................................................................................................2 - 2
2 - 2 - 3 Air piping....................................................................................................................2 - 2
2 - 2 - 4 Electric wiring ............................................................................................................2 - 3
2 -3 Cautions about Reinstallation................................................................................2 - 5
Chapter 3 Operation / Shutdown
3 -1 Check points before operation...............................................................................3 - 1
3 -2 Operation.....................................................................................................................3 - 1
3 -3 Shutdown.....................................................................................................................3 - 2
3 -4 Check points before restart.....................................................................................3 - 2
3 -5 Precautions for long-term non-operation............................................................3 - 2
Chapter 4 Maintenance
4 -1 Daily inspection..........................................................................................................4 - 1
4 -2 Periodical Maintenance............................................................................................4 - 1
4 - 2 - 1Exchange of absorbent.....................................................................................................4 - 1
4 - 2 - 2Service parts.....................................................................................................................4 - 2
4 - 2 - 3Exchange of other parts....................................................................................................4 - 4
4 - 2 - 4Check points book.............................................................................................................4 - 6
Chapter 5 Troubleshooting
5 - 1 Cause and countermeasure of errors ..................................................................5 - 1
5 - 1 - 1Failure diagnosis chart......................................................................................................5 - 1
5 - 1 - 2Breakdown cause investigation points and measures.......................................................5 - 2
Chapter 6 References
6 - 1 Specifications.............................................................................................................6 - 1
6 - 2 Externals dimensional drawing..............................................................................6 - 2
6 - 3 Electrical Circuit.........................................................................................................6 - 3
6 - 4 Structure and operation principles.......................................................................6 - 4
Table of Contents

IDX-OM-X004
Heatless Air Dryer i Safety Instructions
i-1 Warning: Before Using Air Dryer
i- 1
ID Series
Safety Instructions
Before use, read and comprehend important cautionary
notification well on this operattion manual.
i-1 Warning: Before Using Air Dryer
In this chapter, the stated contents are especially about safety way to use the product. for customer.
An Air Dryer is installed on the downstream of the air compressor to remove moisture. We, manufacturer,
cannot take any responsibility if you use it for any other purpose.
An Air Dryer works with high voltage and has some parts that gets hot or rotates during operation. Ask vendor
if you need component replacement and servicing.
Not only people handle the air dryer but every people who perform maintenance on or do works related to it
should read safety instructions on this operation manual before handling.
This operation manual is not a general safety manual which is practiced by safety training representatives.
People who handle this product or work around it need to take training to comprehand inherent risks of it and
master measures for safety.
It is usually responsible for super visor to follow the safety instructions, but each operator or maintemance
representative should do daily operations on their own head.
Operators and maintemance representatives should take the safety of working place and work environment
into account.
It is necessary to think of the safety of working place and work environment for each task
Take enough safety training before the operation training. It is very dangerous to do operation training without
any safety training. Operation training must be paid attention to its safety.
i – 1 – 1 Meaning of Signs: Danger, Warning, Caution
These safety instructions are intended to prevent hazardous situation and/or product damage.
These instructions indicate the level of potential hazard by signs “Danger”, “Warning” or
“Caution”. Contents with these signs state about important instructions concerning safety.
Confirm where those signs are, and read and comprehend notices and cautionary notices well
before handling.
“Danger”, “Warning” or “Caution” is the order of importance (Danger>Warning>Caution).
Followings are the meanings of those signs.
Danger
Statements with the “Danger” sign explain about conditions in which there is a
possible result of serious injury or loss of life if someone handles wrongly during
operation or maintenance and did not follow the procedure to avoid danger.
i

IDX-OM-X004
Heatless Air Dryer i Safety Instructions
i-1 Warning: Before Using Air Dryer
i- 2
ID Series
Warning
Statements with the “Danger” sign explain about possibilities that can result in
serious injury or loss of life if someone handle wrongly during operation or
maintenance and did not follow the procedure to avoid danger.
Caution
Statements with the “Danger” sign explain about possibilities that can result in injury
or product damage if someone handles wrongly during operation or maintenance and
did not follow the procedure to avoid danger.

IDX-OM-X004
Heatless Air Dryer i Safety Instructions
i-2 Danger Classifications / Position of Danger Warning Label
i- 3
ID Series
i-2 Danger Classifications / Position of Danger Warning Label
To protect operator’s sefety, we group danger into some types uniquely and attached labels indicating those types.
Comfirm the contents of the danger types and positions of the labels before operation.
Warning
No one but professionals should operate an air dryer.
Transportation, installation, and maintenance involve risks. These should be done by
someone who have enough knowledge and experience about this product and incidental
devices.
No one but our service personnel or qualified person should open the cover panel of this
product.
Warning
Should any problem occur, address it according to statements on this manual.
•Identify problems according to “Chapter 5 Troubleshooting.”
•Ask repair and maintenance.
Warning
The product should not be operated in the event of any problems.
When the product gets out of order, shutdown it immediatery, and contact our service
person or qualified person.
i – 2 – 1Danger Classifications
Specific danger classification of this product is as follows.
Danger of Electricity
Since this product runs at hign voltage, there is the danger of electric shock. So, we display
a symbol with indications, “Danger”, “Warning” or “Caution,” on the product and this
manual.
Danger of Heat
Since this product becomes hot while driving, there is the danger of burn injury. So, we
display a symbol with indications, “Danger”, “Warning” or “Caution,” on the product
and this manual.

IDX-OM-X004
Heatless Air Dryer i Safety Instructions
i-2 Danger Classifications / Position of Danger Warning Label
i- 4
ID Series
i – 2 – 2 Danger of Electricity
Inside of this product, there is power-supplying section with high voltage separated by the
cover panel. Do not operate the product without the cover panel.
No one but trained qualified person should operate or inspect in the power transmission
sections. Warning
Read with caution and pay attention to the notations on danger warning labels.
Do not remove or rub danger warning labels.
Confirm the positions of danger warning labels.
i – 2 – 3 Danger of High Heat Warning
Since this product has parts that become hot during operation, there is the danger of burn
injury resulting from contact with them. What is more, there is also the danger of burn injury due to
remaining heat after the power supply is cut. Therefore, wait until the temperature of hot parts become
50oCand below.
i – 2 – 4 Danger of Compressed Air Circuit
Warning
Before replacing or cleaning parts, be sure to bleed compressed air remain inside of the
product untill the gauge indicates “0”. If you do not do this air-bleeding, there would be the
great danger of unexpected accident, such as shooting out of parts when they are being unscrewed.

IDX-OM-X004
Heatless Air Dryer i Safety Instructions
i-3 Limited warranty and Disclaimer / Compliance Requirements
i – 5
ID Series
i-3 Limited warranty and Disclaimer / Compliance Requirements
The product used subject to the following “Limited warranty and Disclaimer“ and “Compliance Requirements.
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or 1.5 years after the product is delivered.
Also, the product may have specified durability, running distance or replacement parts. Please consult
your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our responsibility, a
replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage incurred
due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers noted in
the specified catalog for the particular products.


Compliance Requirements

1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction (WMD) or other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are govemed by the relevant
security laws and regulation of the countries involved in the transaction. Prior to the shipment of a SMC
product of a SMC product to another country, assure that all local rules goveming that export are known
and followed.


Caution

The Product is provided use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange
specifications or a contact if necessary.
If anything is unclear, contact your nearest sales branch.


Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval
tests relevant to the metrology (measurement) laws of each country. Therefore, SMC products
cannot be used for business or certification ordained by the metrology (measurement) laws of each
country.

IDX-OM-X004
Heatless Air Dryer 1 Name and Functions Parts
1-1 Name of each Parts
1- 1
ID Series
1 Name of each Parts
1-1 Name of each Parts
・ID20□to 30□
ID20□,30□series

IDX-OM-X004
Heatless Air Dryer 1 Name and Functions Parts
1-1 Name of each Parts
1- 2
ID Series
・ID40□to 60□
ID40□,ID60□series

IDX-OM-X004
Heatless Air Dryer 2 Transportation / Installation
2-1 Transportation
2 - 1
ID SeriesID
2
Transportation / Installation
Warning
Use the product in the right way. During Installation, operation, maintenance, and check,
you should be careful in keeping the safety of human body.
Caution
Transportation, installation, and maintenance including dangerous work must be done by
a personnel who has enough knowledge and experience about the product and the
sysytem.
2-1 Transportation
When you transport the product, you should follow these instructions below.
•You should uplift the product from the base surface with careful attention to prevent falling sideways and drop.
•Do not bring the product lying sideways. If you lay it sideways, it will be broken.
•Do not hang up the product.
•Do not transport the product with any part such as an air filtermounted on the fittings at the air inlet or outlet port
of the product. If it is unavoidable to transport the product with such a part mounted, support the part with a
bracket to prevent the product from being affected by vibration during transportation.
Warning
Those instructions above must be followed because the product is so heavy that it carries
a great risk to transport.
ID20* to 60* are 7 to 25kg . They must be transported by more than 2 person or transport it
by truck.
2-2 Installation
2-2-1 Location
The product should not be used or stored in the circumstances as follows.
Those circumstances will cause not only malfunction but also failures.
•Environment where the product is exposed to rainwater, moisture vapor, salty water, oil and so on.
•Locations where dust or particles are.
•Locations where inflammable or explosive gas are.
•Locations where corrosive gas, solvent, combustible gas are.
•Locations that receive direct sunlight or where radiant heat is generated.
•Locations where ambient temperature is beyond following range:
On-stream: 5 to 50oC
Storage: 0 to 50oC (when there is no drain water inside of the piping)
•Locations where temperature changes rapidly.
•Locations where strong electromagnetic noise is generated.
(locations where electromagnetic field, surge is generated)
•Circumstances where static electricity is produced or discharged through the body of the product.

IDX-OM-X004
Heatless Air Dryer 2 Transportation / Installation
2-2 Installation
2 - 2
ID SeriesID
•Locations where strong high frequency wave is generated.
•Locations where danger of thunder is apparent.
•Locations by loading on vehicles, marine vessels, and so on.
•Locations whose altitude is higher than 2,000 meters.
•Circumstances where strong vibration or impact are transmitted.
•Circumstances where too much force and weight are put on the body of the product that causes it to deform.
•The air used to reproduce the absorbent and air which passed Indicator is exhausted outside of Heatless type
Air Dryer. Please use it in the place without the problem even if it exhausts it.
•Place without problem even if air is exhaust from outlet of product.
•Condition which has sudden pressure/flow rate changes.
Warning
Do not use and store in environment having compressed air or ambinet atmosphere which
includes the following substances. It could result in failure of the product and damage of
components, which leads to injury.
- Corrosive gas, Organic solvent, Chemicals
2-2-2 Anchorage
•The air dryer should be installed on a vibration-free, stable, horizontal flat surface.
•Refer to “Chapter6 6-2 Externals dimensional drawing”for the dimensions.
2-2-3 Air piping
•Connection to the inlet and outlet of compressed air should be made removable by using union and so on.
•When mounting any part such as an air filter on the fitting at the compressed air inlet or outlet port, support the
part to prevent excessive force from being applied to the product
•Be careful not to let the vibration of the air compressor transmit.
•If the temperature of compressed air on the inlet side is higher than 50oC, place an aftercooler after the air
compressor. Or, make the temperature of the place where the air compressor is installed lower than 50oC.
•If the air supply makes high pressure fluctuation (pulsation), take any countermeasures such as installing air
tank.
•Flash the piping sufficiently in order to avoid any foreign substances such as dust, sealing tape, liquid gasket,
etc. when piping before piping connection. Foreign substances in the piping can cause malfunction or drainage
failure.
•Use pipes and fittings that have enough endurance against the operating pressure and temperature. And
connect it firmly to prevent air leakage.
•Please install it on the air pressure line with a supply capacity "Flowing quantity of the necessary outlet air +
flowing quantity of the reproduction air" above-mentioned.
•Please install Mist separator (AM series) at upper stream of the ID.
The capillary organization of the absorbent might be blockaded when the oil mist and
the foreign particles exist in compress air, as the result, the adsorption ability
decreases remarkably and at the same time the life of the absorbent is shortened.
And also the inflow of drain should be avoided as it will make early deterioration of
the absorbent.
Please install Mist separator or Micro mist separator (AMD series) at the down stream
when you want to avoid the contaminants with the powder etc. of the absorbent.

IDX-OM-X004
Heatless Air Dryer 2 Transportation / Installation
2-2 Installation
2 - 3
ID SeriesID
•Please install Bypass circuit with Stop valve when you cannot stop compress air when maintenance is
checked.(exchange of the absorbent etc.)
•Please install it on either of the M4 screws of the IN/OUT piping when you put up the earth.
•Please set up frozen Air Dryer on the first side when you use Z type (low dew point).
•Please install it on the second side of Heatless type Air Dryer when you install the reducing valve. It installs on
the first side, and the dehumidification ability of the air pressure cannot be demonstrated when using it low.
2-2-4 Electric Wiring
Warning
No one but qualified person should do the wiring work.
･Before wiring, you must cut the power off for safety. Do not work under any energized
conditions.
･Supply power from a stable place, which is free from the effect of surge.
･Ensure that a Ground Fault Circuit Interrupter(GFCI) with appropriate capacity for earth
leakage and load is used in the power supply of the product to prevent electrical shock
and burnout. See “6-1 List of specifications” for details.
･Supply power for the product should meet the specifications.
･The product should be grounded for safety.
･Do not connect the earth to a water pipe, a gas pipe, or a lightening rod.
･Do not plug too many leads into a single socket. That causes exothermic heat or fire.
･Do not convert the wiring to use.
IN
OUT

IDX-OM-X004
Heatless Air Dryer 2 Transportation / Installation
2-2 Installation
2 - 4
ID SeriesID
There are two methods depends on model (specified power)
ID200 to 600 / 201 to 601 (100/110V specified)
•Insert the power plug into an outlet of 100/110V AC
•Do not extend the power cable using power strip and so on. That causes decrease of the voltage and
the product cannot be operated.
ID205 to 605 / 206 to 606 (200/220V specified)
•Remove the terminal block cover or the rear cover in the rear of the product, and connect the power
(200/220V AC) to the terminal block.
•Please install it on either of the M4 screws of the IN/OUT piping when you put up the earth.
Specification of power cable
The following power cable is attached.
Power cable: 0.75mm2(18AWG), Two-cores, External diameter: about 2.7 ~ 5.4mm
Length of the power cable
The length of the power cable is from a product to 2m.
IN
OUT

IDX-OM-X004
Heatless Air Dryer 2 Transportation / Installation
2-3 Cautions about Reinstallation
2 - 5
ID SeriesID
2-3 Cautions about Reinstallation
Caution
No one but someone who has enough knowledge about the product and incidental
devices should reinstall in another place. And following instructions must be executed.
If you move the product and reinstall it into another place after some operations (including trial running), instructions
that are not only following ones but also all of those in the chapter 2 should be followed.
Disassembly of the power cable
Cut off the power source when you disassemble the power cable.
Warning
No one but qualified personnel should do the electric wiring.
Cut off the power supply for safety before the wiring. Do not work under energized
condition.
Disassembly of the air piping
Warning
No one but qualified personnel should do the air piping.
Separate the compressor from the product for safety before removing the iping. Do not
remove any piping when there is remaining compressed air pressure inside of it.
Remove the seal tape completely after detaching the piping. Remained tape will cause imperfect cooling
and failure by entering into the body of the product.

IDX-OM-X004
Heatless Air Dryer 3 Operation / Shutdown
3-1 Check points before operation
3- 1
ID Series
3
Operation / Shutdown
Caution
No one but someone who has enough knowledge and experience about the product and
incidental devices should operate or shut down the product.
3-1 Check points before operation
Before a trial running, check following points.
Installed Condition
By visual inspection check that the product is installed horizontally.
Make sure the product is fixed enough with anchor bolts.
Do not place heavy obstacles on the product and add unreasonable loading by piping and so on.
Wiring Connections
Power cord, and the earth should be connected firmly.
Air Piping
Make sure the piping for compressed air is connected correctly. Those valves of IN / Out side and bypass piping
of the product and of the bypass piping should be completely fasten.
3-2 Operation
Start operation according to the procedure below.
Turn on the breaker of the main power supply. Then, turn on the illuminated switch.
Please turn on the power supply of the air dryer after it pressurizes it. If the power supply is turned on before it
pressurizes it (Especially, when pressure is low), abnormally a lot of flowing quantity of the reproduction air of
the starts might become bad the movement of the check valve.
When it does not use on, the absorbent might be damp. Please do the reproduction drive for about 20～30
minutes before closing and using the valve on the second side of the air dryer.
The adsorption column is cut right and left and alternately every about 150 seconds and changes. Please
confirm the change is regularly divided by the flow of the reproduction air.
It can know the outlet air atmospheric pressure dew point of Heatless Air Dryer because of the change in the
color of upper Indicator. The absorbent of Indicator can be used again if not discoloring to crushing (It is
spheroidal usually) and brown, etc.
The outlet air atmospheric
pressure dew point
Color of Indicator (Guide)
Dark blue⇔Light pink
Orange⇔Dark green
-30 oCor less
Dark blue
Orange
-18 oC
Light blue
Slightly cloudy orange
-10oC
Light pink
－
5oC
－
Dark green
At the time of pressure 0.7MPa and 30 oCin temperature of air
Indicator color standard

IDX-OM-X004
Heatless Air Dryer 3 Operation / Shutdown
3-3 Shutdown
3- 2
ID Series
Caution
・Avoid frequent On/Off operation, which can cause troubles.
・Avoid using this product under the condition which has sudden pressure/flow rate changes.
Otherwise, drain (condensed water) may flow out to the secondary piping.
3-3 Shutdown
•Turn off the switch.
•The lamp will go out and then, the operation will be stopped.
3-4 Check points before restart
Check following points before you start operation. If any abnormalities occur, immediately stop the operation. Turn off the
illuminated switch of the product and then the breaker to the power supply.
•There is no leakage of compressed air.
•Compressed air pressure, temperature, flow rate, and ambient temperature meet the specifications.
•There are no abnormal sound, vibration, or smelling.
3-5 Precautions for long-term non-operation
•If the product will not be operated for more than 24 hours, for example at the weekend, turn off the ILS (Switch
with lamp) or power supply, for energy saving and safety. It is also recommended to release the pressure.

Heatless Air Dryer 4 Maintenance
4-1 Daily Inspection
4 - 1
IDX-OM-X004
ID Series
4
Maintenance
4-1 Daily Inspection
Check following points during usual operations. If you find some problems, immediately stop the operation and refer to
“Chapter 5 Troubleshooting”as soon as possible.
There is no air leakage
The running lamp is lighting during operation
The adsorption column is cut right and left and alternately every about 150 seconds and changes. Please
confirm the change is regularly divided by the flow of the reproduction air.
There is no abnormal sound or vibration coming up from the product.
There are no abnormal smell or smoke coming up from the product.
4-2 Periodical Maintenance
Please demonstrate the performance of Air Dryer enough, and check according to the check point’s book on
4-2-4 to prevent the breakdown beforehand. Moreover, please execute maintenance as follows.
4-2-1 Exchange of absorbent
Please exchange the absorbent when the performance decreases by using a long term due to deterioration in the
absorbent etc. It can know the outlet air atmospheric pressure dew point of Air Dryer because of the change in the
color of upper Indicator. The absorbent of Indicator can be used again if not discoloring to crushing (It is spheroidal
usually) and brown, etc.
The outlet air atmospheric
pressure dew point
Color of Indicator (Guide)
Dark blue⇔Light pink
Orange⇔Dark green
-30 oCor less
Dark blue
Orange
-18 oC
Light blue
Slightly cloudy orange
-10oC
Light pink
－
5oC
－
Dark green
At the time of pressure 0.7MPa and 30 oC in temperature of air
Caution
・If oil mist is adsorbed on the indicator silica gel, the color may change to brown or black. In
such a situation, it cannot reused. Replace it with new one. Also, replace the element of mist
separator connected to the inlet side of this product at the same time.
・The outlet air atmospheric pressure dew point indicated by indicator color is not accurate.If you
need accurate dew point, use a dew point meter.
Indicator color standard

Heatless Air Dryer 4 Maintenance
4-2 Periodical Maintenance
4 - 2
IDX-OM-X004
ID Series
4-2-2 Service parts
Adsorption cylinder structural chart
Adsorption cylinder part table
Number Number of the table
1 Case -
2 Pipe -
3 -
4 Filter element
5“O”ring
6 Plug -
7“O”ring -
8 Spring -
9 Panting metal -
10 Filter element
11 Adsorbent
12 Snap ring -
13 “O”ring Table 3
Name of articles
Table 1
Table 2
Circle of stopping Me of E type

Heatless Air Dryer 4 Maintenance
4-2 Periodical Maintenance
4 - 3
IDX-OM-X004
ID Series
Decomposition
1. Please pull out Stop valve of the piping line and pull out the pressure of shutting Air Dryer. Please turn the
adsorption column counterclockwise after confirming pressure came off and remove. (Width of across flat
ID40□:22,ID60□:24)
2. Please make the adsorption column upper and lower and inverted. (Threaded portion is done up.)
3. ⑫please detach C type stop circle for the hole. It is convenient to use a special tool (Snap ring installation Pliers)
to detach C type stop circle for the hole.
4. ⑨please detach Panting metal and ⑩filter element.
5. ①please make the case inverted, and remove an inside absorbent.
6. ②please pull Pipe, and take out internal parts.
7. Please wash each part by Air blow.
8. ④When the air filter has caused stopped up, it is necessary to exchange it.
9. ⑩please exchange filter of ⑪and ⑬“O”ring at each exchange of the absorbent.
Class addition
1. ④please put ⑤“O”ring 2 in the ditch of the filter element. Please install this filter element in ②Pipe.
2. ①please put case and ⑧Spring.
3. Please encase the pipe of clause 1.
4. ⑨please put Panting metal and ⑩filter element sequentially.
5. Please put a new ⑪absorbent from the ditch of C type stop circle for the hole 10mm below. Please fill
the absorbent while lightly giving happen the vibration. When filling the adsorbent, please to come to
the center ②pipe.
6. Please put a new ⑫filter element and ⑬Panting metal sequentially.
7. ⑭please put C type stop circle for the hole in the ditch of ①case.
8. Please confirm the foreign body is not mixed in ②Pipe when the case is made inverted (Threaded
portion is done below).
9. ①Grease is spread on the threaded portion of the case, and the adsorption column must screw in the
main body.
Table 1 Replacement part
ID20* ID30* ID40* ID60*
4 Filter element ID-S0055 ID-S0056 2
5“O”ring KA00072 KA00074 4
quantity
Purchase order number
ID-S0054
KA00066
Number
Name of articles
Table 2 Adsorbent set part
ID20* ID30* ID40* ID60*
ID-200S ID-300S ID-400S ID-600S
ID-200Z ID-300Z ID-400Z ID-600Z
Number
Name of articles
Purchase order number
quantity
10・11
Standard type
1
(Filter element, Adsorbent, “O”ring)
10・11
1
(Filter element, Adsorbent, “O”ring)
Low dew point type
（ID*0*-**-Z）
Table 3 “O”ring
ID20* ID30* ID40* ID60*
13 “O”ring KA00460 KA00462 KA00064 KA00455
2（Note）
Note:
Number
Name of articles
Purchase order number
quantity
Because O-ring in Table 3 is attached when Table 2 does the adsorbent set
arrangements, the simulataneous arrangements are unnecessary.
