SMC Networks AL Series User manual

Doc. No. AL∗-OMQ0006-C
PRODUCT NAME
LUBRICATOR
MODEL / Series / Product Number
AL10-M5(-2,3,6,R,Z)-A
AL20-(F,N)01～(F,N)02(B)(-2,3,6,C,R,Z)-A
AL30-(F,N)02～(F,N)03(B)(-2,3,6,8,R,3W,Z)-A
AL40-(F,N)02～(F,N)04(B)(-2,3,6,8,R,3W,Z)-A
AL40-(F,N)06(B)(-2,3,6,8,R,3W,Z)-A
AL50-(F,N)06～(F,N)10(B)(-2,3,6,8,R,3W,Z)-A
AL60-(F,N)10(B)(-2,3,6,8,R,3W,Z)-A

Contents
Page
1. SAFETY INSTRUCTIONS 1-5
2. APPLICATION 6
3. SPECIFICATIONS 6
4. HOW TO ORDER 7
5. OPTIONAL BRACKET ASSEMBLY 8
6. TROUBLESHOOTING 9
7. CONSTRUCTION / PARTS LIST 10-11
8. SPECIFICATIONS OF BOWL ASSEMBLY 12-17
9. REPLACEMENT PROCEDURE 18-21
10. DISASSEMBLY DRAWING 22-25
11. DIMENSIONS 26

Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition to International Standards
(ISO/IEC) *1) , and other safety regulations.
*1) ISO 4414: Pneumatic fluid power -- General rules relating to systems.
ISO 4413: Hydraulic fluid power -- General rules relating to systems.
IEC 60204-1: Safety of machinery -- Electrical equipment of machines .(Part 1: General requirements)
ISO 10218: Manipulating industrial robots -Safety.
etc.
Caution
Caution indicates a hazard with a low level of risk which, if not avoided, could result
in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if not avoided, will result
in death or serious injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment or
decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
The expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its latest catalog
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may become unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and machinery/equipment until safety is confirmed.
1.The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2.When the product is to be removed, confirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, medical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or
other applications unsuitable for the standard specifications described in the product catalog.
3. An application which could have negative effects on people, property, or animals requiring special safety
analysis.
4.Use in an interlock circuit, which requires the provision of double interlock for possible failure by using a
mechanical protective function, and periodical checks to confirm proper operation.
-1-

Safety Instructions
Caution
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange
specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1.The warranty period of the product is 1 year in service or 1.5 years after the product is
delivered,whichever is first.∗2)
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our responsibility,
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
∗2)
Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum
pad or failure due to the deterioration of rubber material are not covered by the limited
warranty.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass
destruction(WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are governed by the
relevant security laws and regulation of the countries involved in the transaction. Prior to the
shipment of a SMC product to another country, assure that all local rules governing that export
are known and followed.
Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval tests
relevant to the metrology (measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification ordained by the metrology
(measurement) laws of each country.
-2-

！WARNING
①
②
Polycarbonate
Hydrochloric acid
△
Chromic acid
Potash
×
Ammonia water
Carbonate of soda
Sodium sulphide
Sulphate of potash ×
Sulphate of soda
Carbon tetrachloride
Chloroform
Ethylene chloride
Methylene chloride
Benzene
Toluene
Paint thinner
Acetone Photographic film
Methyl ethyl ketone Dry cleaning ×
Cyclohexane Textile industries
Ethyl alcohol
IPA △
Methyl alcohol
Gasoline
Kerosene
Phthalic acid dim ethyl
Phthalic acid diethyl ×
Acetic acid
Methyl ether
Ethyl ether
Cutting oil
Brake oil additives ×
Rubber accelerator
Thread -lock fluid
Seawater ×
Leak tester
When the above factors are present, or there is some doubt, use a metal bowl for safety.
③
④
Other
Oil
Ester
Ether
Amino
Brake oil additives
Synthetic oil
Anti-rust additives
3
－
Avoid the application where charge and discharge of pressure to standard bowl is switched
frequently. This may damage the bowl. For this kind of application, the metal bowl is
recommended.
Protect from ultra violet ray and radiation heat by shield.
Alcohol
Methyl amino
△
×
○
Precautions for design
Acid
×
×
×
－
Sodium hydroxide (Caustic soda)
Calcium hydroxide (Slack lime)
Inorganic
salts
Consult SMC if no leakage is allowed due to the environment, or operating fluid is not air.
External parts including the bowl, sight dome (Material: polycarbonate) are made of resin.
Organic solvents including synthetic fluid, chemicals including acetone, alcohol, ethylene
chloride, sulphuric acid, nitrate, hydrochloric acid, cutting oil, kerosene, gasoline, lock
material of screw are harmful. Do not use the lubricator where containing those.
Chemical data for substances causing degradation (Reference)
Acid washing liquid
for metals
Sulphuric acid, Phosphoric acid
Material
Nylon
Effects organic solvents and chemicals, and where these elements are likely to adhere
to the equipment.
Type Chemical name Application examples
Ketone
×
○
△
○
×
×
Alkaline
Coatings
Dry cleaning
Cleaning liquid for
metals
Printing ink
Dilution
Chlorine
solvents
－
Antifreeze
Adhesives
Degreasing of metals
Industrial salts
Water-soluble cutting
oil
○
○：Essentially safe △：Some effects may occur ×：Effects will occur
△
△
×
Aromatic
series

！
WARNING
①
②
③
④
⑤
！
CAUTION
①
②
③
④
⑤
！
WARNING
①
②
③ On AL10-A, some dripping may occur even when needle is fully opened.
！
WARNING
①
②
③
Recommended torque unit：N･m
Screw M5 1/8 1/4 3/8 1/2 3/4
Torque *1 7～9 12～14 22～24 28～30 28～30
*1: First, tighten it by hand , then give it an additional 1/6 turn with a wrench.
④
⑤
⑥
1
36～38
Consult SMC if using this product for purposes other than its primary use of lubricating air line
equipment.
Selection
Installation
Connect the lubricator ensuring the direction of " " (IN) and " " (OUT) for air direction or
an arrow. Wrong connection may cause malfunction.
The use at high frequency such as the use in press machine may damage internal
components and cause operating failure of the equipments installed to outlet side. Contact
SMC for such a use.
Small air consumption may prevent the oil from dropping. Confirm air flow necessary to
produce the drops required for the correct amount of oil.
Do not supply the air from outlet side (reverse air flow). Otherwise, internal components may
be damaged.
Note that the numbered scale markings are guidelines for adjusting the position, and not
indicators of the dripping amount.(AL20-A～AL60-A)
Do not install in areas of high humid or high temperature. It causes damage of the product
and malfunction.
Make space to provide easy access at the bottom of the product when replacing bowl or
draining. The required space is shown on 「11. DIMENSIONS」(P26).
If piping is branched at inlet side, the oil may flow back. Avoid the reverse flow by installing a
check valve (AKM series) to inlet side.
Adjustment
Adjustment of the oil adjustment valve should be carried out manually. The use of tools, etc.
can result in damage to the unit.(AL20-A～AL60-A)
Install the bowl vertically with bowl facing down. If it is inclined, dripping may not be confirmed.
Do not drop nor apply impact during transportation or installation. This can cause damage to
the product.
Turning the oil adjustment valve counterclockwise increases the dripping amount, and turning
it clockwise reduces the dripping amount. From the fully closed position, three rotations will
bring it to the fully open position. Please do not rotate it any further than this.
Piping
Blow out or clean piping before piping to eliminate swarf, cutting oil, solid foreign material.
Contamination of piping may cause damage or malfunction.
When installing piping, avoid chips and sealing materials from piping screws entering the
inside of equipment. Or malfunction may occur. When use sealing tapes, leave 1.5～2
threads of the end of thread exposed.
4
Hold the female screw side and screw in piping with recommended tightening torque.
Insufficient tightening torque lead to cause loose piping or sealing failure. Excessive torque
may lead to cause screw breakage. Tightening without holding female screw side applies
excessive force to the piping bracket which lead to cause breakage.
Increase the cylinder volume in relation to the tube capacity between the solenoid valve and
the cylinder. If the cylinder capacity is less than that of the tube connecting the cylinder and
solenoid valve, there is a chance that oil may not be carried correctly.
Before using an SMC fitting and S coupler, please refer to "Tightening the threaded portion of
the connection thread" of the Fittings & Tubing Precautions.
Do not apply any torsional moment, or bending moment except the weight of the lubricator itself.
External piping needs to be supported separately. Hard piping like steel tube is susceptible to
excessive moment load or vibration. Insert the flexible tube to cancel the influence.
２
１

！
CAUTION
①
！
CAUTION
①
②
！
WARNING
①
②
③
④
⑤
⑥
⑦
！ 注意
CAUTION
①
②
③
④
The AL30-A, AL40-A, AL50-A and AL60-A have a slight leak from the inside of the case
to the oil supply orifice. Loosen the oil supply plug one turn and wait a short time for
pressure to release then remove the oil supply plug. As there is a slight leak from inside
the case to the oil supply orifice, set the oil supply to “Max Level” slowly, while ensuring
an oil film is not created over the oil supply orifice.
When removing the oil supply plug, pressure within the case will be released, so ensure
that protective goggles are equipped.
After oil is supplied, after ensuring that it is correctly positioned, the oil supply “O” ring can
be returned to its previous state by gently screwing it in.
(For tightening torque, see 9. REPLACEMENT PROCEDURE)
The AL10-A and AL20-A cannot supply oil under pressure.
After releasing the inlet pressure and checking that there is no internal pressure in the
case, remove the oil supply plug slowly and set oil supply to “Max Level” slowly while
ensuring that an oil film is not created in the oil supply orifice.
Perform periodical check to find cracks, flaws or other deterioration on resin bowl and the
sight dome. If any of them is seen, as malfunction is caused, replace with new bowl or the
sight dome.
Check for dirt in resin bowl periodically. If any dirt is seen, replace with new bowl. And if
removing off the dirt by washing instead of using a replacement, never use washing
material other than neutral detergent. Otherwise, the bowl is damaged.
Open and close drain cock manually. Open and close too much may damage the drain
cock.
Discharge drain to avoid that drain exceeds the upper limit of the air filter. Excessive drain
in the lubricator may cause dripping failure.
Use clean oil to avoid dripping failure.
The lubricating amount should be less than the upper limit of oil level.
5
Use class 1 turbine oil (without additives) ISO VG32. Using other lubricant can cause
damage to devices and result in malfunction.
Check the dripping amount once a day. Dripping failure may cause damage to lubricated
objects.
Avoid rising piping and piping branches on secondary side. Otherwise, lubricating failure
may be caused.
Air Source
Maintenance
Use clean air. Compressed air containing chemicals, organic solvent, synthetic oil or
corrosive gas may lead to cause breakage of parts or malfunction.
Air containing too much moisture may cause malfunction. Install the air drier or the
aftercooler before the lubricator.
Maintenance and checks should be done by following the procedure in the operation
manual. Incorrect handling of the product may cause breakage or malfunction of the
equipment or device.
exhaust
Internal case pressure
exhausted
In Use After removal

2. APPLICATION
3. SPECIFICATIONS
AL10-A AL20-A AL30-A AL40-A AL40-06-A AL50-A AL60-A
Port size M5 1/8，1/4 1/4，3/8 1/4，3/8，1/2 3/4 3/4，1 1
Fluid
Proof pressure
Max. operating pressure
Ambient and fluid
temperature
Bowl capacity （cm3）7 25 55
Recommended lubricant
Bowl material
Semi-standard
（Steel plate）
Mass （kg）0.07 0.10 0.20 0.38 0.43 0.94 1.09
Note1
）
This product aims at lubricating compressed air to operate pneumatic actuator and solenoid valve smoothly.
Model
Min. operating flow Note1)
｛L/min(ANR)｝50
1/4：30
3/8：40
1/4：30
3/8：40
1/2：50
15
Air
1.5 MPa
1.0 MPa
-5 ～60℃(Should be no freezing)
4 190 220
6
135
Class 1 turbine oil (ISO VG32)
Polycarbonate
－Standard （Polycarbonate）
The flow rate is 5 drops or greater/min under the following conditions: Inlet pressure of 0.5MPa; Class 1 turbine oil (ISO VG32); Temperature at
20℃; Oil adjustment valve fully opend.
Bowl guard

4. HOW TO ORDER
10 20 30 40 50 60
Meter thread (M5)
● － － － － －
Rc
－ ● ● ● ● ●
N NPT
－ ● ● ● ● ●
F G
－ ● ● ● ● ●
＋
M5 M5
● － － － － －
01 1/8
－ ● － － － －
02 1/4
－ ● ● ● － －
03 3/8
－ － ● ● － －
04 1/2
－ － － ● － －
06 3/4
－ － － ● ● －
10 1
－ － － － ● ●
＋
Nil Without mounting option
● ● ● ● ● ●
B With bracket
－ ● ● ● ● ●
＋
Nil Polycarbonate bowl
● ● ● ● ● ●
2 Metal bowl
● ● ● ● ● ●
6 Nyron bowl
● ● ● ● ● ●
8 Metal bowl with sight glass
－ － ● ● ● ●
C With bowl guard (steel plate)
－ ● － － － －
6C With bowl guard (steel plate)・Nyron bowl
－ ● － － － －
＋
Nil With drain cock
● ● ● ● ● ●
3 With drain cock
● ● ● ● ● ●
3W Drain cock with barb fitting (For φ6xφ4 nylon tube)
－ － ● ● ● ●
＋
Nil Flow direction：Left to right
● ● ● ● ● ●
R Flow direction：Right to left
● ● ● ● ● ●
＋
Nil Name plate and caution plate for bowl in imperial units：MPa, °C
● ● ● ● ● ●
Z Name plate and caution plate for bowl in imperial units：psi, °F ● ● ● ● ● ●
※ Please refer to the catalog when you select the model.
Symbol Description Body size
Thread type
Nil
bLubricant
exhaust port
Port size
Option(Mounting)
cFlow direction
dPressure unit
7
Semi-standard
aBowl
AL 30 -03 BD 1N
-A-
1 3 4 5 2
2
3
4
5
1

5. OPTIONAL BRACKET ASSEMBLY
1）Bracket
1) Installation of bracket
Mount the bracket in the direction as shown in diagram.
2）Tightening of mounting screw
Lubricator Tools Tightening torque
AL20-A Cross pointed driver 0.75 ±0.2 N・m
AL30-A Hexagon spanner：nominal 3 0.75 ±0.2 N・m
AL40-A Hexagon spanner：nominal 4 1.5 ±0.2 N・m
AL50-A
AL60-A
8
Two mounting screws are tightened by cross pointed driver
or hexagon spanner for holding.
Refer to the table below for correct tool and the tightening
torque required.
Hexagon spanner：nominal 5 2.6 ±0.3 N・m
Mounting screws
(2 pcs)
Bracket
Lubricator

6. TROUBLESHOOTING
DEMARCATION PHENOMENON
1. 1.
2. 2.
3. The amount of air is insufficient. 3.
4. The damper is broken. 4. Replace the damper.
5. The oil adjustment valve is closed. 5. Open the oil adjustment valve.
6. 6.
7. The element is clogged. 7.
8. Air leaks from the sight dome. 8. Replace the sight dome assembly.
1. The siphon tube seal is broken. 1.
2. 2.
1. 1.
2. 2.
1. The lubrication plug O ring is broken. 1.
1. 1.
1. 1.
Note) The grease used recommends ENEOS Corporation diamond multipurpose No.2 (AL10-A),
fluorine grease (AL20-A～60-A).
Install piping or lubricator correctly
as shown in manual.
The bowl packing is broken.
Replace the damper retainer
assembly.
The amount of oil is insufficient.
Replace the damper retainer
assembly.
Air is mixed in oil
drops.
The sight dome O ring is broken. Replace the sight dome assembly.
Refer to 「7. CONSTRUCTION / PARTS LIST」(P10 to P11), 「10. DISASSEMBLY DRAWING」(P22 to P25).
TROUBLE POSSIBLE CAUSE REMEDY
Oil drop
The sight dome is broken.
Opposite flow direction or opposite
installation of lubricator.
Air or oil leaks
from the sight
dome.
9
Replace the bowl packing with new
one or grease up after assembly.
Air leaks
Air leaks between
the bowl and the
body.
Replace the sight dome assembly.
Replace the lubrication plug
assembly.
Replace the bowl assembly with new
one or metal bowl.
Air leaks from
lubrication plug.
(AL20-A～60-A)
Oil does not drop
while there is air
flow. Supply the correct amount of oil.
The bowl is broken.
Air leaks from the
bowl.
Select the lubricator whose size
meets the operating flow rate.
Replace the bowl packing or
lubrication plug assembly.
Air leaks from the bowl or the
lubrication plug.
Oil is running out. Supply the correct amount of oil.

7. CONSTRUCTION / PARTS LIST
Component Parts
Option / Replacement Parts
AL10-A AL20-A AL30-A AL40-A AL40-06-A
②Polycarbonate AL10P-080AS
③ － － AL22P-060AS AL32P-060AS
④ － － AL20P-030AS AL30P-030AS
⑤Synthetic resin －AL20P-040S AL30P-040S
⑥NBR C1SFP-260S C2SFP-260S C32FP-260S
⑦Polycarbonate
⑧Steel plate －AF22P-050AS AF32P-050AS AF42P-050AS AF42P-070AS
Note 1）
Note 2）
Note 3）Bracket with mounting screws.(2pcs)
Note 4）
AL20-A～40-A
Part No.
Lubrication plug assembly
Note2）
Damper retainer assembly
Applicable model
AL10-A
AL42P-060AS
AL40P-030AS
AL20P-080AS
No.
Urban white 1
Note
Zinc die cast
MaterialDescription
10
Aluminium die casting Urban white 1
①Body
MaterialNo. Description
Bowl assembly
Note3）
Bracket assembly
The number in the table is corresponding to the number in structural drawing (avobe-mentioned figure) and "8.
SPECIFICATIONS OF BOWL ASSEMBLY" (P12 to P17), "10. DISASSEMBLY DRAWING" (P22 to P25).
Damper
Bowl packing
The product number of damper retainer assembly when metal bowl with sight glass applies "-8" to the part
number suffix. Example：AL20P-030AS-8
The product number of the nylon specification(Material：PA) applies "-6" to the part number suffix.
Example：AL20P-080AS-6
Note1）
Sight dome assembly
Refer to "8．SPECIFICATIONS OF BOWL ASSEMBLY" (P12 to P17)
AL40P-040S
C42FP-260S
ＡＬ３０-A，ＡＬ４０－Ａ
ＡＬ２０－Ａ
②
③
⑧
①
④
⑥
⑦
⑤
①
⑦
②
⑥
ＡＬ１０－Ａ
③
⑧
①
⑥
④
⑦
②
⑤

Component Parts
①Body
⑨
Option / Replacement Parts
②Polycarbonate
③ －
④ －
⑤Synthetic resin
⑥NBR
⑦Polycarbonate
⑧Steel plate
Note 1）
Note 2）
Note 3）Bracket with mounting screws.(2pcs)
Note 4）
11
Housing
Part No.
AL50-A AL50-A
AL20P-080AS
AL42P-060AS
AL50P-030AS
AL50P-040AS
Bowl assembly
Note3）
Bracket assembly
The product number of the nylon specification(Material：PA) applies "-6" to the part number suffix.
Example：AL20P-080AS-6
The product number of damper retainer assembly when metal bowl with sight glass applies "-8" to the part
number suffix. Example：AL20P-030AS-8
The number in the table is corresponding to the number in structural drawing (avobe-mentioned figure) and "8.
SPECIFICATIONS OF BOWL ASSEMBLY" (P12 to P17), "10. DISASSEMBLY DRAWING" (P22 to P25).
Refer to "8．SPECIFICATIONS OF BOWL ASSEMBLY" (P12 to P17)
AF52P-050AS
Note1）
Sight dome assembly
Lubrication plug assembly
Note2）
Damper retainer assembly
Damper assembly
Bowl packing
AL60P-030AS
AL60P-040AS
C42FP-260S
Aluminium die casting Urban white 1
No. Description Material
No. Description Material Note
Aluminium die casting Urban white 1
ＡＬ５０-A，６０－Ａ
③
⑧
①
⑨
④
⑥
②
⑤
⑦

8. SPECIFICATIONS OF BOWL ASSEMBLY
1) Bowl assembly for AL10-A
Semi-standard
Semi-standard 「－」 （Standard）Semi-standard 「3」
Semi-standard 「6」Semi-standard 「36」
Semi-standard
Note 1) B in the table shows the distance from inlet piping centreline to drain port. Refer to "11. DIMENTIONS"（P26）.
Note 2) "Z" of the part with no. ⑦is semi-standard for indicated unit of pressure and temperature, which is psi and °F.
Note 3) The symbol for option and semi-standard are described as "4. HOW TO ORDER" (P7).
C1SL-23-A
12
２ ２３
External
appearance
drawing and
part no.
⑦Part no. ⑦Part no.
C1SL-2-A
External
appearance
drawing and
part no.
⑦Part no. ⑦Part no.
C1SL(-Z)-A C1SL-3(Z)-A
３６
⑦Part no. ⑦Part no.
C1SL-6(Z)-A C1SL-36(Z)-A
－ ６ ３
B
B
B
B

2) Bowl assembly for AL20-A
Semi-standard
Semi-standard 「－」 （Standard）Semi-standard 「3」
Rc Rc
G G
NPT
C2SL(-Z)-A
NPT
C2SL-3(Z)-A
Semi-standard 「6」Semi-standard 「36」
Rc Rc
G G
NPT
C2SL-6(Z)-A
NPT
C2SL-36(Z)-A
Semi-standard
Semi-standard 「C」Semi-standard 「3C」
Rc Rc
G G
NPT
C2SL-C(Z)-A
NPT
C2SL-3C(Z)-A
Semi-standard 「6C」Semi-standard 「36C」
Rc Rc
G G
NPT
C2SL-6C(Z)-A
NPT
C2SL-36C(Z)-A
Semi-standard
Semi-standard 「2」Semi-standard 「23」
Rc Rc
G G
NPT
C2SL-2(Z)-A
NPT
C2SL-23(Z)-A
Note 1) B in the table shows the distance from inlet piping centreline to drain port. Refer to "11. DIMENTIONS"（P26）.
Note 2) The part with no. ⑦includes ⑥Bowl packing. Refer to "10. DISASSEMBLY DRAWING" (P22 to P25).
Note 3) "Z" of the part with no. ⑦is semi-standard for indicated unit of pressure and temperature, which is psi and °F.
Note 4) The symbol for option and semi-standard are described as "4. HOW TO ORDER" (P7).
Port thread
２
６
⑦Part no. ⑦Part no.
C2SL-2-A
⑦Part no.
13
Port thread
Port thread Port thread
Port threadPort thread
３ ３６－
C2SL-3-AC2SL-A
Port thread
⑦Part no.
C2SL-3C-A
C2SL-6-A
３Ｃ
⑦Part no.
C2SL-36-A
Port thread
External
appearance
drawing and
part no.
Port thread
６Ｃ ３６ＣＣ
C2SL-36C-A
External
appearance
drawing and
part no.
External
appearance
drawing and
part no.
⑦Part no. ⑦Part no.
C2SL-23-A
２３
Port thread
⑦Part no. ⑦Part no.
C2SL-C-A
⑦Part no.
C2SL-6C-A
B
B
B
B
B
B

3) Bowl assembly for AL30-A
Semi-standard
Semi-standard 「－」 （Standard）Semi-standard 「3」
Rc Rc
G G
NPT
C3SL(-Z)-A
NPT
C3SL-3(Z)-A
Semi-standard 「6」Semi-standard 「36」
Rc Rc
G G
NPT
C3SL-6(Z)-A
NPT
C3SL-36(Z)-A
Semi-standard
Semi-standard 「3W」
Rc
G
NPT
C3SL-3W(Z)-A
Semi-standard 「36W」
Rc
G
NPT
C3SL-36W(Z)-A
Semi-standard
Semi-standard 「2」Semi-standard 「23」
Rc Rc
G G
NPT
C3SL-2(Z)-A
NPT
C3SL-23(Z)-A
Port thread
Port thread
Port threadPort thread
Port thread
Port thread
２
３６Ｗ
⑦Part no.
External
appearance
drawing and
part no.
⑦Part no.
C3SL-3W-A
⑦Part no.
C3SL-36W-A
⑦Part no.Port thread
C3SL-36-A
⑦Part no. ⑦Part no.
－ ６ ３ ３６
Port thread
14
⑦Part no.
C3SL-23-A
２３
External
appearance
drawing and
part no.
C3SL-A C3SL-3-A
External
appearance
drawing and
part no.
⑦Part no.
C3SL-2-A
C3SL-6-A
３Ｗ
B
B
B
Barb fitting
Applicable tube T0604
B
B

Semi-standard
Semi-standard 「8」Semi-standard 「38」
Rc Rc
G G
NPT
C3LL-8(Z)-A
NPT
C3LL-38(Z)-A
Note 1) B in the table shows the distance from inlet piping centreline to drain port. Refer to "11. DIMENTIONS"（P26）.
Note 2) The part with no. ⑦includes ⑥Bowl packing. Refer to "10. DISASSEMBLY DRAWING" (P22 to P25).
Note 3) "Z" of the part with no. ⑦is semi-standard for indicated unit of pressure and temperature, which is psi and °F.
Note 4) The symbol for option and semi-standard are described as "4. HOW TO ORDER" (P7).
Port thread
15
８ ３８
External
appearance
drawing and
part no.
⑦Part no. ⑦Part no.
C3LL-8-A C3LL-38-A
Port thread
External
appearance
drawing
Metal bowl with sight glass side view
B
B
31.5

4) Bowl assembly for AL40,50,60-A
Semi-standard
Semi-standard 「－」 （Standard）Semi-standard 「3」
Rc Rc
G G
NPT
C4SL(-Z)-A
NPT
C4SL-3(Z)-A
Semi-standard 「6」Semi-standard 「36」
Rc Rc
G G
NPT
C4SL-6(Z)-A
NPT
C4SL-36(Z)-A
Semi-standard
Semi-standard 「3W」
Rc
G
NPT
C4SL-3W(Z)-A
Semi-standard 「36W」
Rc
G
NPT
C4SL-36W(Z)-A
Semi-standard
Semi-standard 「2」Semi-standard 「23」
Rc Rc
G G
NPT
C4SL-2(Z)-A
NPT
C4SL-23(Z)-A
Port thread
Port thread
Port threadPort thread
Port thread
Port thread
２ ２３
C4SL-36-A
C4SL-36W-A
External
appearance
drawing and
part no.
C4SL-A C4SL-3-A
External
appearance
drawing and
part no.
⑦Part no.
C4SL-2-A
C4SL-6-A
３Ｗ ３６Ｗ
⑦Part no.
⑦Part no.
C4SL-23-A
16
⑦Part no. ⑦Part no.
External
appearance
drawing and
part no.
⑦Part no.
C4SL-3W-A
⑦Part no.
－ ６ ３ ３６
Port thread
Port thread ⑦Part no.
B
B
B
Barb fitting
Applicable tube T0604
B
B

Semi-standard
Semi-standard 「8」Semi-standard 「38」
Rc Rc
G G
NPT
C4LL-8(Z)-A
NPT
C4LL-38(Z)-A
Note 1) B in the table shows the distance from inlet piping centreline to drain port. Refer to "11. DIMENTIONS"（P26）.
Note 2) The part with no. ⑦includes ⑥Bowl packing. Refer to "10. DISASSEMBLY DRAWING" (P22 to P25).
Note 3) "Z" of the part with no. ⑦is semi-standard for indicated unit of pressure and temperature, which is psi and °F.
Note 4) The symbol for option and semi-standard are described as "4. HOW TO ORDER" (P7).
External
appearance
drawing
Metal bowl with sight glass side view
External
appearance
drawing and
part no.
８ ３８
⑦Part no.
17
Port thread Port thread⑦Part no.
C4LL-8-A C4LL-38-A
B
B
38

9. REPLACEMENT PROCEDURE
！
WARNING
・Before replacement, ensure that the lubricator is not pressurized.
・Replace refering to "10. DISASSEMBLY DRAWING" （P22 to P25）.
・After replacement, ensure that specified function is satisfied and external leakage is not found before starting operation.
1) Bowl assembly,Sight dome assembly
Applicable
model Process Tool Check item
Disassembly 1. Remove the bowl assembly.
2. Remove the sight dome assembly.
Assembly 3. Mount the bolw assembly.
4. Mount the sight dome assembly.
2) Bowl assembly, Damper retainer assembly, Damper, Sight dome assembly
Applicable
model Process Tool Check item
Disassembly 1. Remove the bowl assembly.
2. Close the oil adjustment valve (sight dome) fully.
3. Disconnect damper retainer assembly.
Nominal：
125 or 150
4.
Assembly 5. Insert the spacer to the sight dome assembly. － －
6.
7. Insert the damper into the holder assembly.
AL10-A
SMC's special
spanner P/N:
1129129
(Recommended)
Refential tightening
torque：1.5 N・m
Hold the bowl assembly by hand and rotate
clockwise. Do not use tool for mounting because the
bowl may be damaged. See check item for
referential tightening torque.
Spanner
Nominal：14
(Torque
wrench)
Tightening torque：
1.4±0.1N・m
Rotate clockwise with spanner to mount the sight
dome assembly. Tightening torque at this time is
shown on controlled item.
Procedure
－
Procedure
（Hook
spanner
Nominal：
25/28）
－
Hold the bowl assembly by hand and rotate
couterclockwise to remove the bowl assembly. If the
bowl assembly is tightened too much to be
removed, use hook spanner until it can be loosened
by hand.
Spanner
Nominal：14 －Rotate counterclockwise with spanner to remove the
sight dome assembly.
－Rotate the oil adjustment valve clockwise manually
until rotation stops, do not over tighten.
Hold the damper retainer assembly by round cutting
pliers and rotate anticlockwise.
Round cutting
pliers
After inserting the steel balls into the path hole of oil
on the holder assembly, put the sight dome
assembly into the holder assembly by meeting zero
point mark of both holder assembly and the sight
dome assembly.
18
－
－
－
－
AL20-A
Hold the bowl assembly by hand and rotate
couterclockwise to remove the bowl assembly. If the
bowl assembly is tightened too much to be
removed, use hook spanner until it can be loosened
by hand.
Connect the sight dome assembly, the steel balls
and the holder assembly.
－
Disconnect O ring, damper, holder assembly, steel
ball, sight dome assembly and spacer.
Push the sight dome assembly forward to the body
by hand for disconnection. The holder assembly and
the sight dome assembly can be separated away by
hand as well, but at the time the attention has to be
paid not to lose the steel balls between them.
Damper can be pulled out by pincette.
Pincette
Zero point mark on
the holder assembly
shall meet with zero
point mark on the
sight dome assembly.
Setting concave on
the damper should
meet with the setting
convex on the holder
assembly.
For insertion, meet the setting concave (damper)
and convex (holder assembly).
