OVERVIEW
The EZ Card™ 1000 (SMC9452TX-2) is a high performance 32-bit 10/100/1000Mbps copper gigabit PCI inter-
face card designed for network connectivity for home or office use. SMC9452TX-2 offers 10/100/1000Mbps
auto-configuration, cross-over detection, auto correction, and full duplex support to maximize the network’s
potential speed while accommodating the existing infrastructure. SMC9452TX-2’s advanced features such
as TCP and UDP Checksum Offload (minimizes CPU utilization), Flow Control, VLAN, Jumbo Frame support
ensures data integrity under heavy loading. Fully IEEE compliant and up to 10 times faster than Fast Eth-
ernet, SMC9452TX-2 is an ideal Gigabit wired networking solution for home or office with Wake-On-LAN,
remote wake-up support, Plug-and-Play installation, and support for major operating systems.
www.smc.com
SMC9452TX-2
EZ Card™ 1000Mbps Copper Gigabit PCI Adapter
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
LEGEND
OFFICE
PC’s with SMC9452TX-2
SMC8150L2
Network
APPLICATION DIAGRAM
KEY FEATURES
Feature 1 Feature 2
Fully compliant with IEEE 802.3ab (1000BASE-T), IEEE 802.3u
(100BASE-TX), and IEEE IEEE802.3 (10BASE-T) standards with
2000Mbps Full-duplex performance.
Supports VLANs and Jumbo Frame for increased network perfor-
mance, improved manageability, and increased security.
Feature 3 Feature 4
Supports Wake-on-LAN and remote wake-up support (including
AMDMagic Packet, Re-LinkOk, and Microsoft® Wake-up frame) for
remote powering of the PCs
Optional bootrom - Serial EEPROM and /or Flash support
SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS
Cable/xDSL
Modem
SMC9452TX-2
Internet
SMCWCB-N2
HOME
SMCWGBR14-N

NETWORK INTERFACES
• 10BASE-T, 100BASE-TX, 1000BASE-T
NETWORK MEDIA
• 10BASE-T: UTP category 3, 4, 5 cable (100m Max)
• EIA/TIA-568 100: STP (100m Max)
• 100BASE-TX: UTP category 5, 5e cable (100m Max)
• EIA/TIA-568 100: STP (100m Max)
• 1000BASE-T: UTP category 5, 5e cable (100m Max)
BUS INTERFACES
• PCI v2.2, 32-bit, 33/66MHz
STANDARDS
• IEEE 802.3 (10BASE-T)
• IEEE 802.3u (100BASE-TX)
• IEEE 802.3ab (1000BASE-T)
• IEEE 802.3x (Flow Control)
• IEEE 802.1P (Priority Queuing Tagging)
• IEEE 802.1Q (VLAN)
• IEEE 802.3 Nway Auto-Negotiation
• PCI v.2.2
• ACPI v1.0/ 2.0
FEATURES
• PCI Local Bus Master 2.1/ 2.2 Support
• Supports PCI 2.1/2.2 ACPI Power Management Wake-On-LAN
• Compliant to PC 99 Standard
(Magic Packet, LinkChg and Microsoft wake-up frame)
• Two independent receive and transmit FIFOs
• Jumbo Frame Support (7680Bytes)
• Plug-and-Play
• Bootrom slot
DATA TRANSFER RATE
• 10Mbps (Half-duplex)
• 20Mbps (Full-duplex)
• 100Mbps (Half-duplex)
• 200Mbps (Full-duplex)
• 1000Mbps (Half-duplex)
• 2000Mbps (Full-duplex)
OPERATING SYSTEMS
• Windows 98
• Windows 98SE
• Windows ME
• Windows NT
• Windows 2000
• Windows XP
• Windows Vista
• Linux 2.2x/ 2.4x/ 2.6x
• Linux 2.4x/ 2.6x
• Netware
• MAC OS 10.x
LED INDICATION
• 1000Mbps/ Link/ Activity
• 100Mbps/ Link/ Activity
COMPLIANCES
• FCC Part 15, Class B
• CE Mark Class B
POWER CONSUMPTION
• 4 Watts (Max)
TEMPERATURE
• Operating: 32 ~ 104 F/ 0 ~ 40C
• Storage: -40 ~ 158F/ -40 ~ 70C
HUMIDITY
• Operating: 10% ~ 90% non-condensing
• Storage: 5% ~ 90% non-condensing
DIMENSIONS
• 120mm x 59mm x 11mm (L x W x D) (Without the bracket)
• 4.72 in x 2.32 in x .43 in (L x W x D) (Without the bracket)
WEIGHT
• 36g (Without the bracket)
• 1.28oz (Without the bracket)
WARRANTY
• Please check www.smc.com for the warranty
terms in your country/region
CONTACT
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local country
contact information
© 2009 SMC Networks. SMC and the SMC logo are registered trademarks
of SMC Networks in the United States or other countries. Other trademarks
or registered trademarks are the property of their respective owners. Infor-
mation is subject to change without notice. All rights reserved.
2/2009
www.smc.com
TECH SPECS - SMC9452TX-2
