Key Features and Benefits
The EZ Connect™ N Wireless PCIe Adapter (SMCWPCIeS-N) is another cutting edge introduction in
2.4GHz wireless communication for desktop computers. Designed for the home and office, this wireless
PCIe adapter provides the speed, coverage and security expected by today’s wireless users. The
SMCWPCIeS-N is Wi-Fi CERTIFIED™ for full compliance with the IEEE802.11b/g standards, and based
on IEEE 802.11n technology to reach wireless speeds of up to 150Mbps, enough to simultaneously
stream video and audio, play online games, transfer large files, make VoIP calls and surf the Internet.
With security being a key consideration, SMCWPCIeS-N supports the latest WPA and WPA2 wireless
encryption standards, which prevent unauthorized access to wireless networks and ensure data is
secure. Wireless security can also be set up easily using Wi-Fi Protected Setup™ (WPS) that using utility
or PIN configuration.
Product Overview
SMCWPCIeS-N
EZ Connect™ N
Wireless PCI-Express Adapter
IEEE802.11b/g WiFi CERTIFIEDTM
Complies with IEEE 802.11g and 802.11b standards,
based on IEEE 802.11n technology.
Support for WEP, WPA and WPA2
Prevents unauthorized access to your wireless network
and insures your data is secure.
Wi-Fi Protected Setup (WPS)
Makes wireless security setup easy with WPS utility for
Windows.
APPLICATION DIAGRAM
150Mbps Wireless Speed
Perfect for streaming video and music, online gaming
and networking multiple PCs.
Wi-Fi Multimedia (WMM)
For traffic prioritization and power saving.
Installation Wizard
Easy installation with step-by-step guidance.

STANDARDS
-IEEE 802.11b
-IEEE 802.11g
-Based on IEEE 802.11n technology
-IEEE 802.11i
-IEEE 802.11e
-IEEE 802.1x
PHYSICAL
- PCI Express (PCIe) v2.0
- Low-profile bracket included
- Link/ Activity status LED
- 1.8dBi detachable omni-directional antenna (RP-SMA)
DATA RATES
- 802.11n: 135/121.5/108/81/54/40.5/27/13.5 Mbps
130/117/104/78/52/39/26/13 Mbps
65/58.5/52/39/26/19.5/13/6.5 Mbps
- 802.11g: 54/48/36/24/18/12/9/6 Mbps
- 802.11b: 11/5.5/2/1 Mbps
WIRELESS OPERATING MODES
- Ad-Hoc (Peer to Peer)
-Infrastructure
MODULATION
- OFDM/ CCK/ 16-QAM/ 64-QAM
SECURITY
- WEP 64-/128-/152-Bit Encryption
- AES, TKIP
- WiFi Protected Access Home Mode (WPA-PSK/WPA2-PSK)
-WiFi Protected Access Enterprise Mode (WPA/WPA2)
-WiFi Protected Setup (WPS)
QUALITY OF SERVICE
- WiFi Multimedia (WMM)
OPERATING CHANNEL
- 11 channels (US, Canada), 2412~2462MHz
- 13 channels (ETSI), 2412~2472MHz
RF POWER
- 15dBm (max)
RECEIVE SENSITIVITY
- 130Mbps: -68dBm@10% PER
- 108Mbps: -68dBm@10% PER
- 54Mbps: -68dBm@10% PER
- 11Mbps: -85dBm@8% PER
- 6Mbps: -88dBm@10% PER
- 1Mbps: -90dBm@8% PER
OPERATING SYSTEMS
- Windows 2000/ XP/ Vista/ Win 7 (Driver)
- Windows 2000/ XP (Utility)
PACKAGING CONTENTS
- 1x Wireless PCIe Adapter
- 1x Low Profile Bracket
- 1x Quick Install Guide
- 1x EZ Installation Wizard & Documentation CD
- 1x SMC Warranty Registration Card
DIMENSIONS
- Unit: 120.8 x 78.5 x 21.5 mm/ 4.8 x 3.1x 0.8 in
- Box: 415 x 365 x 300 mm/16.3 x 14.4 x 11.8 in
WEIGHTS
- Unit: 42 (g)
-Box: 174 (g)
TEMPERATURE RANGE
- Operating Temperature: 0º~40º C/ 32º~104º F
- Storage Temperature: -40º~70º C/ -40º~158º F
HUMIDITY
- Operating Humidity 10%~90% non-condensing
- Storage Humidity 5%~90% non-condensing
SAFETY, EMISSION AND OTHERS
-CE
-FCC
-RoHS
WARRANTY
- Please check www.smc.com for the warranty terms in your
country/region.
