Smeg Classic SFA63M3TVX User manual

Contents
3
EN
1 Instructions 4
1.1 General safety instructions 4
1.2 Appliance purpose 7
1.3 Manufacturer liability 7
1.4 This user manual 7
1.5 Identification plate 7
1.6 Disposal 7
1.7 How to read the user manual 8
2 Description 9
2.1 General Description 9
2.2 Control panel 10
2.3 Other parts 11
2.4 Available accessories 12
3 Use 13
3.1 Instructions 13
3.2 First use 13
3.3 Using the accessories 14
3.4 Cooking advice 16
4 Cleaning and maintenance 18
4.1 Instructions 18
4.2 Cleaning the appliance 18
4.3 Removing the door 18
4.4 Cleaning the door glazing 19
4.5 Vapour Clean (on some models only) 21
4.6 Extraordinary maintenance 23
5 Installation 25
5.1 Electrical connection 25
5.2 Cable replacement 25
5.3 Positioning 26
We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
ORIGINAL INSTRUCTIONS

Instructions
4
1 Instructions
1.1 General safety instructions
Risk of personal injury
• During use the appliance
becomes hot. Care should be
taken to avoid touching heating
elements inside the oven.
• WARNING - Accessible parts will
become hot when in use. Young
children should be kept away.
• Protect your hands by wearing
oven gloves when handling food
inside the oven cavity.
• Never try to put out a fire or flames
with water: turn off the appliance
and smother the flames with a fire
blanket or other appropriate
cover.
• The appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge,
unless they have been given
supervised or instructions
concerning use of the appliance
by a responsible person for their
safety.
• Young children should be
supervised to ensure that they do
not play with the appliance.
• Keep children under eight years of
age at a safe distance if they are
not constantly supervised.
• Do not allow children younger
than 8 years old to come near the
appliance when in operation.
• The appliance must never be
cleaned by unsupervised children.
• The cooking process must always
be monitored. Short cooking
processes must be monitored
continuously.
• Never leave the appliance
unattended during cooking
operations in which fats or oils
could be released that could
overheat and catch fire. Be very
careful.
• Do not insert pointed metal objects
(cutlery or utensils) into the slots in
the appliance.
• Do not pour water directly onto
very hot trays.
• Keep the oven door closed during
cooking.
• If you need to move food or at the
end of cooking, open the door
5 cm for a few seconds, let the
steam come out, then open it fully.
• DO NOT USE OR STORE
FLAMMABLE MATERIALS NEAR
THE APPLIANCE.
• WARNING: Ensure the appliance
is switched off before replacing
the lamp to avoid the possibility of
electric shock.

Instructions
5
EN
• DO NOT SPRAY AEROSOLS IN
THE VICINITY OF THIS
APPLIANCE WHILE IT IS IN
OPERATION.
• Switch the appliance off
immediately after use.
• DO NOT MODIFY THIS
APPLIANCE.
• Always use any necessary/
required personal protective
equipment (PPE) before
performing any work on the
appliance (installation,
maintenance, positioning or
movement).
• Disconnect the main power
supply before performing any
work on the appliance.
• Have authorised personnel carry
out installation and assistance
interventions according to the
standards in force.
• Do not try to repair the appliance
yourself or without the intervention
of a authorised technician.
• Do not pull the cable to remove
the plug.
• If the power supply cable is
damaged, contact technical
support immediately and they will
replace it.
Risk of damaging the appliance
• Do not use abrasive or corrosive
detergents (e.g. scouring
powders, stain removers and
metallic sponges) on glass parts.
Use wooden or plastic utensils.
• Racks and trays must be inserted
as far as they will go into the side
guides. The mechanical safety
locks that prevent them from being
removed must face downwards
and towards the back of the oven
cavity.
• Do not seat on the appliance.
• Do not use a steam cleaner to
clean the appliance.
• Do not obstruct ventilation
openings and heat dispersal slots.
• DO NOT USE THE APPLIANCE
TO HEAT ROOMS FOR ANY
REASON.
• Do not spray any spray products
near the oven.
• Do not use plastic kitchenware or
containers when cooking food.
• Do not put sealed tins or
containers in the oven.
• Remove all trays and racks which
are not required during cooking.
• Do not cover the bottom of the
oven cavity with aluminium or tin
foil sheets.

Instructions
6
• Do not place pans or trays
directly on the bottom of the oven
cavity.
• If you wish to use greaseproof
paper, place it so that it will not
interfere with the hot air circulation
inside the oven.
• Do not use the open door to rest
pans or trays on the internal glass
pane.
• Do not use cleaning products
containing chlorine, ammonia or
bleach on steel parts or parts with
metallic surface finishes (e.g.
anodizing, nickel- or chromium-
plating).
• Do not use rough or abrasive
materials or sharp metal scrapers.
• Do not use harsh abrasive
cleaners or sharp metal scrapers
to clean the oven glass since they
can scratch the surface, which
may result in shattering of the
glass.
Installation
• THIS APPLIANCE IS NOT TO BE
INSTALLED IN MARINE CRAFT
OR IN CARAVANS.
• The appliance must not be
installed on a pedestal.
• Place the appliance into the piece
of furniture with the aid of a
second person.
• Never use the oven door to lever
the appliance into place when
fitting.
• When positioning the appliance
during installation, do not use the
door handle to lift up or move this
appliance.
• Avoid exerting too much pressure
on the oven door when open.
• This oven must not be installed
behind a decorative door in order
to avoid overheating.
• Have authorised persons carry out
installation and assistance
interventions according to the
standards in force.
• Have the electrical connection
performed by authorised persons.
• The appliance must be connected
to earth in compliance with
electrical system safety standards.
• Use cables withstanding a
temperature of at least 90 °C.
• The tightening torque of the screws
of the terminal supply wires must
be 1.5 - 2 Nm.
• Before carrying out any work on
the appliance (installation,
maintenance, positioning or
moving), wear personal protective
equipment.
• Before carrying out any work on
the appliance, disconnect the
mains power supply.

Instructions
7
EN
• If the electrical supply is restricted,
means of all-pole disconnection
must be accessible and
incorporated in the fixing wiring in
accordance with the wiring rules.
For this appliance
• Ensure that the appliance is
switched off before replacing the
bulb.
• Do not rest any weight or sit on the
open door of the appliance.
• Take care that no objects are stuck
in the doors.
1.2 Appliance purpose
• This appliance is intended for
cooking food in the home
environment. Every other use is
considered improper.
• The appliance is not designed to
operate with external timers or with
remote-control systems.
1.3 Manufacturer liability
The manufacturer declines all liability
for damage to persons or property
caused by:
• use of the appliance other than the
one envisaged;
• failure to comply with the
instructions in the user manual;
• tampering with any part of the
appliance;
• the use of non-original spare parts.
1.4 This user manual
This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and in an accessible place for the
whole working life of the appliance.
Read this user manual carefully before using
the appliance.
1.5 Identification plate
The identification plate bears the technical
data, serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
1.6 Disposal
This appliance must be disposed of
separately from other waste
(Directives 2002/95/EC, 2002/
96/EC, 2003/108/EC). The appliance
does not contain substances in quantities
sufficient to be considered hazardous to
health and the environment, in accordance
with current European directives.

Instructions
8
To dispose of the appliance:
• Cut the power supply cable and remove
it along with the plug.
• Deliver the appliance to the appropriate
recycling facility for electrical and
electronic equipment waste, or deliver it
back to the retailer when purchasing an
equivalent product, on a one for one
basis.
Our appliances are packaged in non-
polluting and recyclable materials.
• Deliver the packing materials to the
appropriate recycling facility.
1.7 How to read the user manual
This user manual uses the following reading
conventions:
1. Sequence of instructions for use.
• Standalone instruction.
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the power cable from the
socket.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part
of it unattended.
• Do not let children play with the plastic
bags.
Instructions
General information on this user
manual, on safety and final
disposal.
Description
Description of the appliance and its
accessories.
Use
Information on the use of the
appliance and its accessories,
cooking advice.
Cleaning and maintenance
Information for proper cleaning and
maintenance of the appliance.
Installation
Information for authorised persons:
installation, operation and
inspection.
Safety instructions
Information
Advice

Description
9
EN
2 Description
2.1 General Description
1 Control panel
2 Oven light
3 Seal
4 Door
5 Fan
6 Rack/tray support frames
Frame shelf

Description
10
2.2 Control panel
1 Timer knob
It allows you to use the timer or to perform
manual cooking. For timed cooking, turn the
knob clockwise to the required time. The
oven will stop cooking when time expires.
For manual cooking, turn the knob anti-
clockwise to the hand symbol.
2 Temperature knob
This knob allows you to select the cooking
temperature and the Vapour Clean
temperature (on some models only).
Turn the knob clockwise to the required
value, between the minimum and maximum
settings.
3 Thermostat indicator light
When this indicator light comes on, the
oven is heating up. When the light goes out,
the preset temperature has been reached.
When the light flashes at regular intervals,
the temperature inside the oven is being
kept constantly at the set level.
4 Function knob
The oven's various functions are suitable for
different cooking modes. After selecting the
required function, set the cooking
temperature using the temperature knob.

Description
11
EN
2.3 Other parts
Oven shelves
The oven features shelves for positioning
trays and racks at different heights. The
insertion heights are indicated from the
bottom upwards (see 2.1 General
Description).
Interior lighting
The appliance’s interior lighting comes on:
• When the door is opened.
• When any function is selected.
Cooling fan
The fan cools the oven and comes into
operation during cooking.
The fan causes a steady outflow of air from
above the door which may continue for a
brief period of time even after the appliance
has been turned off.
When the door is open, it is not
possible to turn off the interior
lighting.

Description
12
2.4 Available accessories
Rack
useful for holding cooking containers.
Tray rack
to be placed over the top of the oven tray;
for cooking foods which may drip.
Oven tray (on some models only)
useful for collecting fat from foods placed
on the rack above.
Deep tray
useful for collecting fat from foods placed
on the rack above and for cooking pies,
pizzas and baked desserts.
Some models are not provided
with all accessories.
The oven accessories intended to
come into contact with food are
made of materials that comply with
the provisions of current legislation.
Original and optional accessories
can be requested to Authorised
Assistance Centres. Use only
original accessories supplied by
the manufacturer.

Use
13
EN
3 Use
3.1 Instructions
3.2 First use
1. Remove any protective film from the
outside or inside of the appliance,
including accessories.
2. Remove any labels (apart from the
technical data plate) from the
accessories and from the oven cavity.
3. Remove and wash all the appliance
accessories (see 4 Cleaning and
maintenance).
4. Heat the empty oven cavity at
maximum temperature to burn off any
residues left by the manufacturing
process.
High temperature inside the oven
during use
Danger of burns
• Keep the oven door closed during
cooking.
• Protect your hands by wearing oven
gloves when moving food inside the
oven.
• Do not touch the heating elements inside
the oven.
• Do not pour water directly onto very hot
trays.
• Do not allow children to approach the
appliance when it is in operation.
Improper use
Risk of damage to surfaces
• Do not cover the bottom of the oven
cavity with aluminium or tin foil sheets.
• If you wish to use greaseproof paper,
place it so that it will not interfere with the
hot air circulation inside the oven.
• Do not place pans or trays directly on
the bottom of the oven cavity.
• Do not pour water directly onto very hot
trays.
High temperature inside the oven
during use
Danger of fire or explosion
• Do not spray any spray products near
the appliance.
• Do not use or leave flammable materials
near the appliance.
• Do not use plastic kitchenware or
containers when cooking food.
• Do not put sealed tins or containers in
the oven.
• Do not leave the appliance unattended
during cooking operations where fats or
oils could be released.
• Remove all trays and racks which are
not required during cooking.

Use
14
3.3 Using the accessories
Racks and trays
Racks and trays have to be inserted into the
side guides until they come to a complete
stop.
• The mechanical safety locks that prevent
the rack from being taken out
accidentally have to face downwards
and towards the oven back.
Tray rack
The tray rack has to be inserted into the tray.
In this way fat can be collected separately
from the food which is being cooked.
Functions list
Gently insert racks and trays into
the oven until they come to a stop.
Clean the trays before using them
for the first time to remove any
residues left by the manufacturing
process.
Convection
As the heat comes from above and
below at the same time, this system
is particularly suitable for certain
types of food. Traditional cooking,
also known as static cooking, is
suitable for cooking just one dish at
a time. Perfect for all types of roasts,
bread and cakes and in any case
particularly suitable for fatty meats
such as goose and duck.
Grill
The heat coming from the grill
element gives perfect grilling results
above all for thin and medium
thickness meat and in combination
with the rotisserie (where present)
gives the food an even browning at
the end of cooking. Perfect for
sausages, ribs and bacon. This
function enables large quantities of
food, particularly meat, to be grilled
evenly.

Use
15
EN
Base heat
The heat coming just from the
bottom allows you to complete the
cooking of foods that require a
higher bottom temperature, without
affecting their browning. Perfect for
cakes, pies, tarts and pizzas.
Supercook
The combination of fan-assisted
cooking and traditional cooking
allows different foods to be cooked
on several levels extremely quickly
and efficiently, without odours and
flavours mingling. Perfect for large
volumes that call for intense
cooking.
ECO (energy-saving cooking)
(on some models only)
This low energy consumption
function is particularly suitable for
cooking on a single shelf.
Ideal when cooking meat, fish and
vegetables. It is not recommended
for foods that require proving.
For greater energy savings and to
reduce the time required, it is
recommended to put foods in the
oven cavity without preheating it.
When using the ECO function,
avoid opening the oven door
during cooking.
When using the ECO function,
cooking times (and pre-heating, if
used) are longer.
Fan assisted
The operation of the fan, combined
with traditional cooking, ensures
uniform cooking even with complex
recipes. Perfect for biscuits and
cakes, even when simultaneously
cooked on several levels. (For
multiple-level cooking, we
recommend using the 2nd and 4th
shelves.)
Defrost
Rapid defrosting is helped by
switching on the fan provided and
the top heating element that ensure
uniform distribution of low
temperature air inside the oven.
Fan grill
The air produced by the fan softens
the strong heatwave generated by
the grill, grilling perfectly even very
thick foods. Perfect for large cuts of
meat (e.g. shin of pork).
Fan forced
The combination of the fan and the
circular element (incorporated in the
rear of the oven) allows you to cook
different foods on several levels, as
long as they need the same
temperatures and same type of
cooking. Hot air circulation ensures
instant and uniform distribution of
heat. It will be possible, for instance,
to cook fish, vegetables and biscuits
simultaneously (on different levels)
without mixing odours and flavours.

Use
16
3.4 Cooking advice
General advice
• Use a fan assisted function to achieve
consistent cooking at several levels.
• It is not possible to shorten cooking times
by increasing the temperature (the food
could be overcooked on the outside and
undercooked on the inside).
Advice for cooking meat
• Cooking times vary according to the
thickness and quality of the food and to
consumer taste.
• Use a meat thermometer when roasting
meat, or simply press on the roast with a
spoon. If it is hard, it is ready; If not, it
needs another few minutes cooking.
Advice for cooking with the Grill and the
Fan grill
• Meat can be grilled even when it is put
into the cold oven or into the preheated
oven if you wish to change the effect of
the cooking.
• With the Fan grill function, we
recommend that you preheat the oven
cavity before grilling.
• We recommend placing the food at the
centre of the rack.
• With the Grill function, we recommend
that you set the maximum temperature in
order to optimise cooking.
Advice for cooking desserts/pastries and
biscuits
• Use dark metal moulds: They help to
absorb the heat better.
• The temperature and the cooking time
depend on the quality and consistency
of the dough.
• To check whether the dessert is cooked
right through: At the end of the cooking
time, put a toothpick into the highest point
of the dessert. If the dough does not stick
to the toothpick, the dessert is cooked.
• If the dessert collapses when it comes
out of the oven, on the next occasion
reduce the set temperature by about
10°C, selecting a longer cooking time if
necessary.
Advice for defrosting and proving
• Place frozen foods without their
packaging in a lidless container on the
first shelf of the oven cavity.
• Avoid overlapping the food.
• To defrost meat, use the rack placed on
the second level and a tray on the first
level. In this way, the liquid from the
defrosting food drains away from the
food.
• The most delicate parts can be covered
with aluminium foil.
• For successful proving, a container of
water should be placed at the bottom of
the oven cavity.
To save energy
• Stop cooking a few minutes before the
time normally used. Cooking will
continue for the remaining minutes with
the heat which has accumulated inside
the oven.
• Reduce any opening of the door to a
minimum to avoid heat dispersal.
• Keep the inside of the appliance clean
at all times.
• (Where fitted) When it is not being used,
remove the pizza stone and put the
cover back in its slot.

Use
17
EN
Cooking information table
Food Weight
(Kg) Function Shelf Temperature (°C) Time
(minutes)
Lasagne 3 - 4 Convection 1 220 - 230 45 - 50
Pasta bake 3 - 4 Convection 1 220 - 230 45 - 50
Roast veal 2 Supercook/Fan Assisted 2 180 - 190 90 - 100
Pork 2 Supercook/Fan Assisted 2 180 - 190 70 - 80
Sausages 1.5 Fan grill 4 250 15
Roast beef 1 Supercook/Fan Assisted 2 200 40 - 45
Roast rabbit 1.5 Fan forced/Fan Assisted 2 180 - 190 70 - 80
Turkey breast 3 Supercook/Fan Assisted 2 180 - 190 110 - 120
Roast pork neck 2 - 3 Supercook/Fan Assisted 2 180 - 190 170 - 180
Roast chicken 1.2 Supercook/Fan Assisted 2 180 - 190 65 - 70
1st surface 2nd surface
Pork chops 1.5 Fan grill 4 250 15 5
Spare ribs 1.5 Fan grill 4 250 10 10
Bacon 0.7 Grill 5 250 7 8
Pork fillet 1.5 Fan grill 4 250 10 5
Beef fillet 1 Grill 5 250 10 7
Salmon trout 1.2 Supercook/Fan Assisted 2 150 - 160 35 - 40
Delicate fish 1.5 Supercook/Fan Assisted 2 160 60 - 65
Flounder 1.5 Supercook/Fan Assisted 2 160 45 - 50
Pizza 1 Supercook/Fan Assisted 2 250 8 - 9
Bread 1 Fan forced/Fan Assisted 2 190 - 200 25 - 30
Focaccia 1 Supercook/Fan Assisted 2 180 - 190 20 - 25
Ring cake 1 Fan forced/Fan Assisted 2 160 55 - 60
Tarts 1 Fan forced/Fan Assisted 2 160 35 - 40
Ricotta cake 1 Fan forced/Fan Assisted 2 160 - 170 55 - 60
Jam tarts 1 Supercook/Fan Assisted 2 160 20 - 25
Paradise cake 1.2 Fan forced/Fan Assisted 2 160 55 - 60
Profiteroles 1.2 Supercook/Fan Assisted 2 180 80 - 90
Sponge cake 1 Fan forced/Fan Assisted 2 150 - 160 55 - 60
Rice pudding 1 Supercook/Fan Assisted 2 160 55 - 60
Brioches 0.6 Fan forced/Fan Assisted 2 160 30 - 35
The times indicated in the table do not include preheating times and are provided as a guide only.

Cleaning and maintenance
18
4 Cleaning and maintenance
4.1 Instructions
4.2 Cleaning the appliance
Advice for cleaning the oven cavity
In order to keep your oven in the best
possible condition, clean it regularly after
letting it cool down.
Do not allow food residues to dry inside the
oven cavity because doing so could
damage the enamel.
Before cleaning, remove all the parts that
can be removed.
For easier cleaning, it is recommended to
remove:
• The door
• The rack/tray support frames
• The seal (not on pyrolytic models).
4.3 Removing the door
For easier cleaning, it is recommended to
remove the door and to place it on a tea
towel.
To remove the door proceed as follows:
1. Open the door completely and insert two
pins into the holes on the hinges as
indicated in the figure.
Improper use
Risk of damage to surfaces
• Do not use steam jets to clean the
appliance.
• Do not use cleaning products containing
chlorine, ammonia or bleach on steel
parts or parts with metallic surface
finishes (e.g. anodizing, nickel- or
chromium-plating).
• Do not use abrasive or corrosive
detergents (e.g. scouring powders, stain
removers and metallic sponges) on
glass parts.
• Do not use rough or abrasive materials
or sharp metal scrapers.
We recommend the use of
cleaning products distributed by
the manufacturer.
If you use specific oven cleaning
products, it is recommended to
operate the appliance at maximum
temperature for about 15-20
minutes afterwards in order to burn
off any residues.

Cleaning and maintenance
19
EN
2. Grasp the door on both sides with both
hands, raise it so that it forms an angle of
around 30° and remove it.
3. To replace the door, insert the hinges in
the relative slots in the appliance, making
sure that the grooved sections Aare
resting completely in the slots. Lower the
door and once it is in place, remove the
pins from the holes in the hinges.
4.4 Cleaning the door glazing
The glass in the door should always be kept
thoroughly clean. Use absorbent kitchen
roll. In case of stubborn dirt, wash with a
damp sponge and an ordinary detergent.
Removing the internal glass panels
For easier cleaning, the internal glass
panels of the door can be removed.
1. Remove the internal glass panel by
pulling the rear part gently upwards,
following the movement indicated by the
arrows (1).
2. Then, pull the front part upwards (2). In
this way, the 4 pins attached to the glass
are released from their seats in the oven
door.
3. Some models have an intermediate glass
panel. Remove the intermediate glass
panel by lifting it upwards.

Cleaning and maintenance
20
4. Clean the external glass panel and the
panels removed previously. Use
absorbent kitchen roll. In case of
stubborn dirt, wash with a damp sponge
and a neutral detergent.
5. Refit the panels in the reverse order in
which they were removed.
6. Reposition the internal glass panel. Take
care to centre and secure the 4 pins into
their seats in the oven door by applying
slight pressure.
Removing rack/tray support frames
Removing the rack/tray support frames
enables the sides to be cleaned more
easily. This operation should be performed
each time the automatic cleaning cycle is
used (on some models only).
Removing the rack/tray support frames:
1. Pull the frame towards the inside of the
oven cavity to unhook it from its
groove A.
2. Then slide it out of the seats on the
back B.
3. When cleaning is complete, repeat the
above procedures to replace the rack/
tray support frames.

Cleaning and maintenance
21
EN
Cleaning the top of the oven cavity (on
some models only - not on pyrolytic
models)
The appliance is equipped with a tilting grill
element that allows the upper part of the
oven cavity to be cleaned easily.
1. Slightly raise the roof heating element
and rotate the retaining latch by 90° in
order to release the heating element.
2. Carefully lower the heating element until
it stops.
3. When you have finished cleaning, place
the heating element back in position and
turn the retaining latch to lock it in place.
4.5 Vapour Clean (on some models
only)
Preliminary operations
Before starting the Vapour Clean cycle:
• Completely remove all accessories from
inside the oven. The roof lining can be
left inside the oven.
High temperature inside the oven
during use
Danger of burns
• The following must only be carried out
when the oven is completely cold and
switched off.
Improper use
Risk of damage to the appliance
• Do not excessively flex the element
during cleaning.
Vapour Clean is an assisted
cleaning procedure which
facilitates the removal of dirt.
Thanks to this process, it is possible
to clean the inside of the oven very
easily. The dirt residues are
softened by the heat and water
vapour for easier removal
afterwards.
Improper use
Risk of damage to surfaces
• Remove from the inside of the oven any
food residues or large spills from
previous cooking operations.
• Carry out assisted oven cleaning
operations only when the oven is cold.

Cleaning and maintenance
22
• Pour approx. 40 cc of water onto the
floor of the oven. Make sure it does not
overflow out of the cavity.
• Spray a water and washing up liquid
solution inside the oven using a spray
nozzle. Direct the spray against the side
walls, upwards, downwards and
towards the deflector.
• Close the door.
Vapour Clean setting
1. Turn the function knob and the
temperature knob to the symbol.
2. Set a cooking time of 18 minutes using
the timer knob.
3. At the end of the cooking time, the timer
will switch the oven heating elements off
and the buzzer will start to sound.
End of the Vapour Clean cycle
4. Open the door and wipe away the less
stubborn dirt with a microfibre cloth.
5. Use an anti-scratch sponge with brass
filaments on tougher encrustations.
6. In case of grease residues use specific
oven cleaning products.
7. Remove the water left inside the oven.
We recommend spraying approx.
20 times at the most.
