Smeg SAH460SS-1 User manual

EAN 9345025000491
dimensions 162mmH x 598mmW x 304mmD closed
162mmH x 598mmW x 474mmD open
NB: 262mm height when direct ducting
fascia rail 68mmH stainless steel, front recirculating
42mmH stainless steel, direct ducting
integration fascia rail removable and replaceable for full
integration
motor 60 watt
speeds two: right-hand rocker switch
lighting 2 x LED
noise rating 38–52 dBA (full)
capacity 275m³/hr ducted
200m³/hr recirculated
filter 2 x one piece, 3-ply aluminium — removable,
washable
supplied • fitted 68mmH stainless steel fascia rail
• tape-covered front recirculation vents
• accessory 42mmH stainless steel fascia
rail
• 100mmH spigot adaptor for 125mm
diameter ducting direct to atmosphere
• template
• instructions for installation, operation,
maintenance
• brackets, screws
electricity supply 240 volt, 50Hz
electrical connection connected one-metre power cord with 3-pin
10 amp plug
total wattage 140 watts
current 0.583 amp
packaged dimensions 700mm x 375mm x 235mm = 0.062m³
net weight 6.5kg
gross weight 7.8kg
555
v
v
40
284
0-170
<
<
20
600
v
v
68
162
NB: drawings are not to scale — they are to assist only
SAH460SS-1 smeg 60cm front-recirculating retractable rangehood
COMMERCIAL ONLY PRODUCT
ID060712
code SAH460SS-1
WARNING: technical specications and product sizes can be varied by the manufacturer
without notice. Cutouts for appliances should only be by physical product measurements.
The above information is indicative only.

SAH460SS-1 smeg 60cm front-recirculating retractable rangehood
COMMERCIAL ONLY PRODUCT
ID0630712
code SAH460SS-1
WARNING: technical specications and product sizes can be varied by the manufacturer
without notice. Cutouts for appliances should only be by physical product measurements.
The above information is indicative only.
replaceable
rail for full
cabinetry
integration
><
><
68
20
162
power cord
filtered air back
into kitchen
alternative
direct ducting to
atmosphere
FRONT RECIRCULATING
555
598
95cm power cord
125
<
<
0-170
284
<
<
20
> <
68
DIRECT DUCTING
123o
/
*
>
<
42
replaceable fascia rail
for full integration
123o/
162
*
100
NB: drawings are not to scale — they are to assist only
> <
42
PLAN
SIDE ELEVATION
SIDE ELEVATION
PLAN
* spigot to fit
125mm diameter
ducting
