Smeg LBL16 User manual

19 590 1670 02 1
Index Pag.
1. Instructions for unpack and transport 2
2. Plinth dismount 3
3. Rubber strap dismount 4
4. Rubber strap use 5
5. Door dismount 6
6. Cleaning 7
7. Caution 7

19 590 1670 02 2
1. Instruction for unpack and transport
NO NO
NO NO
YES YES

19 590 1670 02 3
2. Plinth dismount
1) With a screwdriver, makes lever on the points
…. 2) … indicated, with a movement from the bottom to the upper …
3) in order to permit the plastic tooth, on the
plinth, to come out from the site 4) After the described operation on both sides, proceed with the plinth dismount following the
order in picture.
5) For the assemblage of the plinth, follow the
order on the picture. 6) Finish the operation with a light pressare on the points in picture. The “click” sound will
indicate that the plinth is assembled.
2
1
2
3
1
2
1
A

19 590 1670 02 4
3. Rubber strap dismount
1) For remove the rubber straps on the door 2) rotates the plastic terminal for 180° ….
3) … with a light pressure… 4) and the extract them.

19 590 1670 02 5
4. Rubber strap use
In picture, the possibility to insert some products in the vain can be appreciated …
ATTENTION:
Weight Max 4,0kg
… these products are of daily use, e.g. detergents, softener etc.
ATTENTION
This appliance is intended for use by adults.
Do not allow children to tamper with the controls or play with the washing machine.
Do not allow children to approach the appliance.
Keep children away from the appliance.

19 590 1670 02 6
5. Door dismount
1) For remove the door, unscrew the indicated
screw 2) on both the hinges (cross screwdriver)
SI
NO
3) support the door and extract … 4) .. the hinges from their sites.

19 590 1670 02 7
6. Instruction for cleaning
ATTENTION !!
Only use non-abrasive sponges, soap and water to clean the
washing machine!!
Never use the following:
•Abrasive sponges (e.g.: for washing dishes, etc.)
•Powder cleansers and detergents that could ruin the surface of
the basin
To preserve the external appearance of the sink, never allow the
following materials to come into contact with it:
•Nail varnish removers
•Stain removers
•Drain cleaners
•Ethanol
•Solvents
•Acids at any concentration level
•Engine oil
•Chloroform
•Ether
•Formalin
•Iodine
7. Caution
The washbasin only works if the washing machine is powered (plug
inserted).
