smirthwaite Connect Series User manual

2/11
Connect Table
INSTRUCTIONS FOR USE
Codes 2311-2366

1
CONTENTS PAGE
1.0 INTRODUCTION 1
2.0 ILLUSTRATION OF YOUR CONNECT TABLE 2
3.0 FOR YOUR SAFETY 3
4.0 UNPACKING AND ASSEMBLING YOUR PRODUCT 3
5.0 SETTING UP AND ADJUSTING YOUR PRODUCT 4
6.0 CARE & MAINTENANCE 5
7.0 GUARANTEE & SERVICE 5
8.0 CONTINUOUS IMPROVEMENT 6
9.0 WARRANTY & AFTERSALE 7
1.0 INTRODUCTION
Thank you for choosing the Smirthwaite Connect Table.
The Birchwood range of rectangular and triangular tables has been designed to
encourage good posture when your child is seated. All the tables are adjustable in
height, and can be easily arranged into modular groups using different configurations
to meet a variety of classroom needs.
IMPORTANT!
These instructions should be read by all therapists and carers using
the equipment and should be retained for future reference. The
product should always be used under adult supervision.
Any incorrect use of the product and failure to follow the instructions
may put the user at risk or impede the function. If you have any
queries using this product or wish for further copies, please do not
hesitate to contact Customer Service department on
T: [phone].

2
2.0ILLUSTRATION OF YOUR CONNECT TABLE
A. Table top
B. Leg frames
C. Leg outriggers
2.1 TECHNICAL DATA
B
C
A

3
3.0 FOR YOUR SAFETY
STOP!
Please read these instructions CAREFULLY and THOROUGHLY.
The user should NOT be left unattended whilst using the product. Always ensure a
responsible therapist or carer is in attendance.
If you believe the product to be faulty at any time, DO NOT USE –contact
Smirthwaite by telephone on [phone].
The therapist should be familiar with the methods of adjustment and have
completed all adjustments appropriately to meet the needs of the child before use.
The product is ONLY to be used indoors on a flat level surface.
Regular maintenance checks and cleaning are essential for the safe use of this
equipment (see Section 6.0 Care and Maintenance).
Always keep this product away from naked flames, cigarettes and sources of heat
including open fireplaces, radiators and heaters.
DO NOT fit parts or accessories of other manufacturers to this product unless
authorised to do so in writing by G&S Smirthwaite Ltd. Failure to follow these
instructions will not only invalidate the guarantee but could make the product
dangerous to use. G&S Smirthwaite Ltd will not accept liability for any injury or
damage incurred through such malpractices. Any repairs required must be carried
out by G&S Smirthwaite Ltd authorised personnel.
4.0 UNPACKING AND ASSEMBLING YOUR PRODUCT
Your product will be delivered flat-packed, ready for assembly.
To ease final assembly, it may be preferable to turn the table upside down and lay
on the floor or another table.
Hold each leg frame against the rails on the table top battens, as indicated by the
attached marker labels. Line up the holes and secure them with screws, using the
hexagonal tool provided.
Note: Rectangular tables have three leg frames, triangular tables have two.
Turn the table onto its feet, and check both stability and screw tightness.
If you believe this product to be faulty - DO NOT USE - Contact G&S Smirthwaite Ltd
on T: [phone].

4
5.0 SETTING UP AND ADJUSTING YOUR PRODUCT
STOP!
If in any doubt, ALWAYS seek ADVICE.
Always turn handwheels, levers and screws clockwise to tighten or
anti-clockwise to loosen.
5.1 TABLE HEIGHT
The table height can be adjusted to suit the client’s needs, and to promote correct
sitting posture with feet flat to the floor, wherever possible.
Use the hexagonal key
supplied to remove the screws
(A) on each of the leg frames .
The leg outrigger (B) can now
be positioned at the desired
height setting.
Re-insert the screws (A) and
tighten.
Repeat for the three other leg
outriggers.
Ensure the table is level
before use.
Ensure all screws are secure
before use.
5.2 TABLE CONFIGURATIONS
B
A

5
6.0 CARE AND MAINTENANCE
IMPORTANT!
Cleaning is recommended on a regular basis
Clean wooden parts with a damp cloth and mild detergent.
Stubborn marks on wood work should be cleaned by using a soft brush.
Do not soak or immerse the product in water.
Store the product in a cool dry place and out of direct sunlight.
DO NOT use bleach, solvents, abrasives, synthetic detergents, wax polishes,
antibacterial sprays or wipes.
For further information please refer to MHRA or your NHS cleaning guidelines.
6.1 DAILY CHECKS
Check all parts for signs of wear and tear or damage.
Ensure all screws are present and tightened.
STOP!
The product should not be in use while the checks are carried out.
6.2 SERVICE INTERVAL
Connect Tables should be serviced every 3 years. Servicing must only be undertaken
by a Smirthwaite service engineer, or by a Smirthwaite trained representative.
7.0 GUARANTEE & SERVICE
The product is issued with a full parts and labour guarantee for 2 years from the date
of delivery. This guarantee does not apply to accidental damage caused through
inappropriate use of the product. This guarantee is issued at the discretion of G&S
Smirthwaite Ltd on RTB (Return to Base) basis. If you have any questions or doubts
relating to the safety or use of the product please contact us for advice or assistance
on:
T: [phone]
E: [email protected]

6
8.0 CONTINUOUS IMPROVEMENT
G&S Smirthwaite Ltd are committed to continuous improvement to their product range.
Should you have any suggestions or comments please send them to our product
design department at: [email protected].
G&S Smirthwaite Ltd reserve the right to change the specification or material without
prior notice.
For catalogues, help and further information on our products please contact us at:
G&S Smirthwaite Ltd
17 Wentworth Road
Heathfield
Devon TQ12 6TL
T: [phone]
F: [phone]
E: [email protected]
W: www.smirthwaite.co.uk

7
9.0 WARRANTY & AFTERSALE
9.1 Product Information
Model:
Size:
Date of Manufacture:
Serial Number:
9.2 Service & inspection record form:
Date
Procedure
Service
Personnel

8
G&S Smirthwaite, 17 Wentworth Road, Heathfield, Newton Abbot, Devon.TQ12 6TL
T: [phone] F: [phone] E: [email protected]
W: www.smirthwaite.co.uk
