Smith Flow Control SFC-EDE User manual




























Model No.: SFC-EDE Torque Tool
Serial No.:
SFC Ref No.:




CONTENTS
1 ContentsPage&Introduction
2 TrainingRequirementsGeneralSafety
3 GeneralSafetyContinued,ManualNoise&VibrationLevels
4SFC‐EDEToolFeatures&Accessories
5TypicalSFC‐EDETorqueSetting
6 SFC‐EDETorqueSettingContinued&OperatingtheTorqueTool
7 Maintenance,Recalibration,Warranty&ContactInformation




















1. INTRODUCTION
TheSFC‐EDEElectricTorqueToolisahandheld,batterydrivenreversiblenon‐impactingtorquetool
intendedtosafelymanagevalveoperations.
The SFC‐EDE ElectricTorqueToolmustalwaysbeusedwiththefollowing:‐
110vor240vElectricalSupply(Dependentonmodelpurchased)
ReactionKit

Itistheresponsibilityoftheusertoconsiderassociatedsiterisksbeforeintroducingtheequipmentinto
theworkplace.
2. TRAININGREQUIREMENTS
TrainingonthecorrectuseoftheSFC‐EDEElectricTorqueToolisavailable.PleasecontactSmithFlow
ControlLimitedformoreinformation.
GENERALSAFETY
TheimproperuseoftheSFC‐EDEElectricTorqueToolisunsafeandmayresultinpersonalinjury.Itis
importantthatoperatorshaveread,understoodandcomplywithallinstructionsinthisuserguide.
Operatorsmustbeequippedwiththefollowingpersonalprotectiveequipment(PPE):
•EyeProtection(SafetyGlasses/Goggles)
•SafetyFootwear(SteelToeCapBoots)
•HeavyGloves

3. GENERALSAFETYCONTINUED
Allelectricequipmentandancillaryproductsshouldbeinspectedfordamageandirregularities
priortouse.
Ensurethatpowercablesarenotrunacrosswalkways,ladders,roadwaysanddoorways,etcand
thatpersonnelwhoarelikelytopassthroughtheworkingareaaremadeawareofthepotential
hazard.Takecarenottostandon,runoverortripoverthepowercable.
Directthetoolawayfromoperator/personnel.
Toprevententanglementwithrotatingparts,operatorsmustnotwearlooseitemse.g.clothing,
ties,jewelleryandlonghairmustbetiedback.
Keephands,fingersandbodypartsclearofthereactionarmatalltimesastrappingcanresultin
seriouspersonalinjury.





SFC‐EDETORQUETOOLMODELSCOVEREDBYTHISMANUAL
ModelWeight
kg
SpeedrpmTorqueRange(~Nm)Square
Drive
SingleAutoMinMax
SFC‐EDE64.521N/A1505003/4”

NOISE&VIBRATIONLEVELS

NOISE: EquivalentcontinuousAweightedsoundpressurelevelislessthan85dB(A).
VIBRATION: Vibrationlevelathandledoesnotexceed2.5m/sec.
4. SFC‐EDVCTORQUETOOLFEATURES


ACCESSORIESAVAILABLE

Thefollowingaccessoriesareavailableuponrequestandcanbecustommadetosuitrequirements.
PleasecontactSmithFlowControlLimitedformoreinformation:‐

•ReactionKit
•OffsetGearbox







TORQUEREACTION
AllvalvemovementisfullycontrolledbytheTorqueReactionDevice,providingcompleteprotectionfrom
potential‘kick’.
5. SETTINGTORQUEFORVALVEOPERATION(CLOSING)

Ensurethedirectionselectorswitch(D)issettoforward
Identifythetorquerequiredfortheboltingapplication.
oTheSFC‐EDEElectricTorqueToolcomeswithatorquecalibrationcertificate.Thetorque
calibrationcertificatedisplaysalphaandnumericcharactersthataredialledinonthetool
thatcorrespondtothetorquevaluestotheright.Toselectadesiredtorque,dialinyour
SFC‐EDEbyusingthealphaandnumericselectors(E)onthetopoftheSFC‐EDVC.
oForexampleonthe“SampleSFC‐EDECalibrationCertificate”belowtotightento730Nm
settheAlphaandNumericSelectors(E)toC,3.

CAUTION:DONOTATTEMPTTORUNTHETOOLWITHSETTINGSTHATARENOTDISPLAYEDONTHE
TORQUECHARTORCALIBRATIONCERTIFICATE.FAILURETODOSOCOULDCAUSETHETOOLTOFAIL
ANDVOIDYOURWARRANTY









SampleSFC‐EDECallibration
Certificate(Nm)
B2380
C2450
E2520
F2590
G2660
C3730
D3800
E3870
F3940
G31010
D41080
E41150
C51220
F41290
G41350




SETTINGTORQUEFORVALVEOPERATION(OPENING)

Ensurethedirectionselectorswitch(D)issettoreverse
Setthetorquetomaximum
oTheSFC‐EDEElectricTorqueToolcomeswithatorquecalibrationcertificate.Thetorque
calibrationcertificatedisplaysalphaandnumericcharactersthataredialledinonthetool
thatcorrespondtothetorquevaluestotheright.Toselectadesiredtorque,dialinyour
SFC‐EDEbyusingthealphaandnumericselectors(E)onthetopoftheSFC‐EDE.
oForthe“SampleSFC‐EDETorqueCalibrationCertificate”shownabovethemaximum
torqueisG,4

6. OPERATINGTHETORQUETOOL

1) Fitthetoolintotheuniversal,‘bolt‐on’,handwheeldriveplate.
2) MovetheDirectionSelectorSwitch(D)fromtheneutralpositionandintoeitherforwardor
reverseasrequired.
3) SqueezethesoftstartTrigger(C)toactivatethetoolandapplythetorque.
4) FullypressthesoftstartTrigger(C)andkeeppresseduntilthetoolstalls.Ifthetriggerisreleased
beforethetorquetoolstalls,fulltorquewillnotbeappliedtothevalve.Oncethemotorstallsdo
not“blip”thetrigger,orincorrecttorquewillbeapplied.
5) Inuse,thetorquetoolmustbesupportedatalltimes.
6) Ifavalvewillnotoperatewhenthetoolissettomaximumonthecalibrationcertificate,donot
“blip”thetriggerrepeatedly,andusetoolingofhighertorqueoutput.
7) Removetoolfromvalve.
IMPORTANT:Ifbreakdown,malfunctionordamageoccursdonotattempttorepair,contactSmithFlow
ControlLimited
7) MAINTENANCEANDRECALIBRATION
Topreventprematurefailureandensureconfidenceintorquesupply,itisrecommendedthatthis
equipmentisservicedandcalibratedatleastonanannualbasis.
WARRANTY
SFC‐EDEcomeswithaoneyear(1)conditionalwarranty.
SFC‐EDEisguaranteedagainstmanufacturerandmaterialdefects,butnotagainstabuse,misuseor
neglectbytheuser.TheSquareDriveisanonwarrantyitem.





8) CONTACTDETAILS
SmithFlowControlLtd
6WatersideBusinessPark
EastwaysIndustrialEstate
Witham
Essex
CM83YQ
UnitedKingdom

Tel:+44(0)1376517901
Email:[email protected]

