SMSC LAN9132 User manual

FEATURES BENEFITS
RipStream technology combines support of multiple HD streams,
software protocol stack management and security
Two bidirectional TSI ports which directly interface to video
processing functions
Supports PCI-based interface
Integrated 10/100 MAC/PHY with HP Auto-MDIX
Crypto block supports both DTCP-IP and WMDRM 10
Video codec agnostic
Can boot from Flash memory or host processor
Integrated DLNA, UPnP and TCP/IP stacks
Highly flexible software architecture; customer can decide
whether LAN9132 or host runs UPnP stack
High throughput; two HD MPEG2 or multiple MPEG4 streams
Handles multiple HD streams concurrently
Offers design flexibility and the option to use existing PCI-based designs
Complete networking solution that eliminates the need for special “crossover”
cables when connecting LAN devices together
Provides DRM copyright protection. Flexible support for major industry
standards; eliminates need for separate crypto device
Handles any video codec (MPEG2, MPEG4, WMV9/VC-1, H.264/AVC)
Reduces need for additional components
Consumer Electronics interoperability; ability to recognize other UPnP devices
and offload host TCP/IP implementation
Allows ease of integration to various architectures; allows system designer to
optimize the architecture to application needs
LAN9132
High-Performance Network Multimedia Processing Engine, supporting a PCI-
based interface and featuring RipStream™Technology
Industry’s first high-performance, wired 10/100 network multimedia processing engine
solely supporting a PCI-based interface and employing RipStream technology, which
combines support for multiple high-definition (HD) streams, software protocol stack
management and security.
nRipStream technology supporting DLNA
guidelines
Supports multiple HD video streams
Built-in UPnP, HTTP, TCP/IP protocol
stacks
Integrated 128-bit AES encryption/
decryption for Digital Rights
Management (DRM)
•Supports Windows®Media
DRM10 (WMDRM 10)
•Supports Digital Transmission
Content Protection over Internet
Protocol (DTCP-IP)
•Fast DTCP-IP AKE key exchange
time (0.6 sec.)
nTwo Transport Stream Interfaces (TSIs)
to MPEG encoder/decoder SoCs
Either interface can be used in
server or rendering applications
nIntegrated ARM926™ core
nTCP/UDP checksum offload
nPCI-based Interface
PCI Local Bus Specification revision
3.0 compliant
32-bit/33-MHz PCI bus
Supports device and host modes of
operation
In host mode it supports up to four
external PCI devices
PCI Power management support D0,
D1, D2, D3cold and D3hot
DMA-based high speed transfers
nVideo codec agnostic
Supports MPEG2, MPEG4,
WMV9/VC-1, H.264/AVC
nNetwork agnostic platform allowing
for integration of future advanced
standards
nIntegrated 10/100 MAC/PHY with HP
Auto-MDIX support and multiple power
management modes
nEthernet-based Video/Media
Distribution Systems
nDigital Video Recorders
nHigh-definition Televisions
nVideo Servers
nNetwork Attached Storage (NAS)
nThin Client Set-top Boxes
nDigital Media Clients/Servers
nHome Gateways
nWireless Multimedia Streaming
Target Applications
Features and Benefits
Highlights
* Playing/viewing of content which is streamed or transferred between networked DLNA Certified devices depends
on the media format supported by the DLNA Certified devices.

Hardware Block Diagram
Network Multimedia Processing Engine Applications
Feature- and Performance-Rich
n128-bit AES encryption/decryption
nRipStream technology provides the high-performance
Ethernet data rates required to enable multiple HD streams
nTSI port can be used in server and rendering applications
nInteroperability with other devices supporting UPnP and
DLNA
nIntegrated 802.3 (10/100) Ethernet MAC/PHY with HP
Auto-MDIX support
n324-pin LFBGA package with other options
nSupports DRM technology - DTCP/IP and WMDRM 10
ARM926EJ-S
200 MHz
16KB Instruction Cache
16KB Data Cache
PCI Bridge
AES-128
Cipher
DMA
Engine
PLLs
Vectored IRQ
Controller
POWER
Management
ARM
GPIO
UART
SPI
8 Timers
Watch-Dog
Timer
External Memory
Controller
Real-Time
Clock
Streaming
Interface
Controller
Streaming
Interface
Controller
AHB/APB
Bridge
10/100
Ethernet
MAC and
PHY
JTAG Test &
Debug
Embedded
Trace Buffer
Multi-Level AHB Bus with Distributed DMA
Thin-Client
STB
Thin-Client
STB
Thin-Client
STB
Thin-Client
STB
Application for LAN9132 – Home Environment
Living Room Home Office
Den Bedroom
Cable,
Satellite,
Terrestrial
Input
TV
STB
DVR
TV
DVR
TV
PC
DVR
Application for LAN9132 – Multiple-User Environment
Central
Video Server
Video
Server
STB
Cable,
Satellite,
Terrestrial
Input
10/100 Ethernet Distribution
NAS
10/100 Ethernet
For more information visit www.smsc.com or call 1.800.443.SEMI
SMSC 80 Arkay Drive, Hauppauge, NY 11788
For RoHS compliance and environmental information, please visit www.smsc.com/rohs
SMSC Literature #NP-ETH-032-05/08-1
Copyright ©2008 SMSC or its subsidiaries. All rights reserved. Although the information in this document has been checked and is believed to be accurate, no responsibility is assumed for inaccu-
racies. SMSC reserves the right to make changes to product descriptions and specifications at any time without notice. Contact your local SMSC sales office to obtain the latest specifications before
placing your product order. The provision of this information does not convey any licenses under any patent rights or other intellectual property rights of SMSC or others. All sales are expressly condi-
tional on your agreement to the terms and conditions of the most recently dated version of SMSC’s standard Terms of Sale Agreement dated before the date of your order. Products may contain design
defects or errors known as anomalies which may cause a product’s functions to deviate from published specifications. Anomaly sheets are available upon request. SMSC products are not designed,
intended, authorized or warranted for use in any life support or other application where product failure could cause or contribute to personal injury or severe property damage. Any and all such uses
without prior written approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer. Copies of this document or other SMSC literature, as well as the
Terms of Sale Agreement, may be obtained by visiting SMSC’s website at http://www.smsc.com. SMSC and the SMSC logo are registered trademarks and RipStream is a trademark of Standard
Microsystems Corporation (“SMSC”). Other names mentioned may be trademarks of their respective holders. All claims made herein speak as of the date of this material. The company does not
undertake to update such statements. (05/08)
Ease of Integration/Minimized Design
Time and Risk
nInterfaces to any video codec/decoder via TSI
nMinimal host/SoC overhead
nIntegrated TCP/IP stack
nMinimal software development required
nIntegrated DLNA Stack
