Snorkel MHP1335 Owner's manual

REPAIR PARTS
MANUAL
Part Number 14108-2
$XJXVW201(Rev A)
Version3
Serial Number MHP1335-07-000003 and after
Diesel
Gasoline
Battery Electric
Bi-Energy Options

GENERAL INFORMATION
General Information 1-1
REPAIR PARTS
Trailer Assembly 2-1
Trailer Assembly After Serial Number MHP1335-07-180200105 2-2
Column Assembly 2-3
Slew Ring Assembly 2-4
Covers Assembly 2-5
Boom Assembly 2-6
Basket Assembly 2-7
Placards and Decals 2-8
Honda Engine Assembly 2-9
1750kg Axle Assembly 2-10
HYDRAULICS
Auto Stabiliser Manifold, No Fittings 3-1
Auto Stabiliser Manifold, With Fittings 3-2
Double Pilot Check Valve Manifold 3-3
Main Control Valve Assembly 3-4
Hydraulic Oil Tank Assembly 3-5
Rotate Cylinder Assembly 3-6
Upper Lift Cylinder Assembly 3-7
Lower Lift Cylinder Assembly 3-8
Flyboom Cylinder Assembly 3-9
Stabiliser Leg Cylinder Assembly Before Serial Number MHP1335-07-180900112 3-10
Stabiliser Cylinder Assembly After Serial Number MHP1335-07-180900112 3-11
ELECTRICAL
Loom List 4-1
LED Tail Lights 4-2
Auto Stabiliser Contorl Box Assembly 4-3
Lower Control Box Assembly 4-4
Upper Control Box Assembly 4-5
OPTIONS
Platform Rotate Assembly 5-1
240V AC Basket Outlet Assembly 5-2
Honda 240V Gas/AC Option, Pump Assembly 5-3
Honda 240V Gas/AC Option, Column Assembly 5-4
24V DC Electric Motor Option 5-5
Bi Energry Option Assembly 5-6
24V DC Electric Motor, Option Assembly 5-7
15LD350 Kohler Engine Assembly 5-8
KD225 Kohler Engine Assembly 5-9
Auto Stabiliser Option 5-10

Flashing Light Option 5-11
Honda 240V Gas/AC Option, PDL Enclosure 5-12
SCHEMATICS
Hydraulic Schematics 6-1
Electrical Schematics 6-2
A A
B B

The aerial platform is not electrically insulated. Death or serious injury will result from contact
with, or inadequate clearance from, an energized conductor.
Do not go closer than the Minimum Safe Approach Distance as defined by ANSI standards.
Regard all conductors as energized.
Allow for electrical wire sag and aerial platform sway.
If the platform, boom, or any part of the aerial platform contacts a high-voltage electrical conductor,
the entire machine can become electrically charged.
If that happens, remain on the machine and do not contact any other structure or object. This in-
cludes the ground, adjacent buildings, poles, and any other objects that are not part of the aerial
platform.
Such contact could make your body a conductor to the other object, creating an electrical shock
hazard resulting in death or serious injury.
Ifanaerialplatformisincontactwithanenergizedconductortheplatformoperatormustwarnground
personnelinthevicinitytostayaway.Theirbodiescanconductelectricitycreatinganelectricalshock
hazard resulting in death or serious injury.
Do not approach or leave the aerial platform until the electricity has been turned off.
Do not attempt to operate the lower controls when the platform, booms, or any part of the aerial
platform is in contact with a high-voltage electrical conductor or if there is an immediate danger of
such contact.
Personnel on or near an aerial platform must be continuously aware of electrical hazards, recogniz-
ing that death or serious injury can result from contact with an energized conductor.
© Snorkel – all rights reserved
California
Proposition 65 Warning
Battery posts, terminals and related accessories contain lead
andleadcomponents, chemicals knowntotheState of California
to cause cancer and birth defects or other reproductive harm.
Wash hands after handling.

S3219E – 1502788
MHP1335 - 14108-2 i
General Information
About This Manual
This manual covers MHP1335 aerial platforms.
Information is included for machines that have been
manufacturedto conform to allapplicablerequirements
of the following organizations:
American National Standards Institute (ANSI)
Canadian Standards Association (CSA)
European Committee for Standardization (CE)
Australian Standards (AS) certification
Part pages include a drawing and a bill of material.
The bill of material lists the item number that is on the
drawing, the Snorkel part number, quantity used and a
description of the item.
Some callouts in the drawings may have a balloon with
two numbers. The top number is the item number and
the bottom number is the quantity of the item at that
location.
WhileSnorkelhas attemptedineverywayto confirmthat
all information in this manual is correct, improvements
are being constantly made to the machine that may not
be reflected in this manual.
If you find information in this manual that is not correct
or is confusing, you are urged to report your findings to
Snorkel for our evaluation. Your input is important to us
and will be used in future printings of this manual.
This machine is covered by a limited warranty that spe-
cificallyidentifiesitemswarrantiedbySnorkeland those
items covered by original manufacturer's warranty. A
copy of the Snorkel Limited Warranty is located on the
inside of the back cover of this manual.
Repairs and Maintenance
Every person who maintains, inspects, tests or repairs
the machine must be qualified and authorized to do so.
Caution
Do not modify this aerial platform without prior
written consent of Snorkel Engineering Department.
Modification may void the warranty, adversely affect
stability or affect the operational characteristics of
the aerial platform.
Abbreviations
The following abbreviations may be used in this manual.
AC alternating current
ANSI American National Standards Institute
AR as required
CCA cold cranking amps
cm centimeter
DC direct current
ft feet
GFCI ground fault circuit interruptor
in inch
lbs pounds
mm millimeter
no number
NPT national pipe thread
psi pounds per square inch
qty quantity
rpm revolutions per minute
UL Underwriters Laboratories Inc.
Additional Information
Allcorrespondencerelative to thismachine,suchas field
reports, discrepancy reports, requests for information,
etc., should be directed to:
Snorkel North America
P.O. Box 1160
St. Joseph, MO 64502-1160 USA
Phone: [phone]
Snorkel Europe
Vigo Centre
Birtley Road
Washington
Tyne & Wear
NE38 9DA
Phone: [phone]
http://www.snorkellifts.com

S3219E – 1502788 MHP1335 - 14108-2
ii
Component Identification
Jockey Wheel
Auto Stabiliser Control Box
Serial Plate
Lower Control Box
Engine
Basket
Tow Coupling
Stabiliser Legs

S3219E – 1502788
MHP1335 - 14108-2 iii
Service and Parts Information
Ordering Parts
Whenplacinganorderforserviceor repair parts, please
havethefollowing machine informationreadilyavailable.
Model number
Serial number
Snorkel part number
Description of part
Quantity of parts required
Your purchase order number
Address for order to ship to
The desired shipment method
If ordering parts off-line, the parts order form on the
following page may be mailed or faxed to the attention
of the Parts Department at the following location:
Snorkel North America
P.O. Box 1160
St. Joseph, MO 64502-1160 USA
Phone: [phone]
Parts Fax: [phone]
Snorkel Europe
Vigo Centre
Birtley Road
Washington
Tyne & Wear
NE38 9DA
Phone: [phone]
Parts Fax: [phone]
Attention: Parts Department
For your convenience, our electronic on-line ordering
system is accessible from the following Internet location:
http://www.snorkellifts.com
ANSI and OSHA Compliance
All owners and users of the aerial platform must read,
understand and comply with all applicable regulations.
UltimatecompliancetoOSHAregulationsis the respon-
sibility of the user and their employer.
ANSI publications clearly identify the responsibilities
of all personnel who may be involved with the aerial
platform.Areprint of the “Manual of Responsibilities for
Dealers, Owners, Users, Operators, Lessors and Les-
sees of ANSI/SIAA92.6-2006 Self-Propelled Elevating
Work Platforms” is available from Snorkel dealers or
from the factory upon request.
Copies are also available from:
Scaffold IndustryAssociation, Inc.
P.O. Box 20574
Phoenix, AZ 85036-0574 USA
Manuals
Manuals are available from Snorkel to support any of
the machines that we produce.
The specific manuals for MHP1335 aerial platforms are
as follows:
MHP1335 Operator’s Manual ANSI
Snorkel part number – 13619-1
MHP1335 Repair Parts Manual
Snorkel part number – 14108-2
ANSI Manual of Responsibilities
ANSI/SIAA92.6-2006
Snorkel part number – 0361367
Machine Information
Model Number:
Serial Number:
Date of Purchase:
Purchased From:
Snorkel Dealer or Distributor:

Parts Order Form
Date:
Company:
Address:
Contact Name:
Phone Number:
Fax Number:
Account Number:
Purchase Order Number:
Model Number:
Serial Number:
Ship To:
Shipping Method:
Part Number Description Quantity
Note: Backordered parts will be shipped as soon as available using the same shipping method as the original
order unless otherwise indicated below.
Ship complete order only. Do not backorder parts.
Ship all available parts and disposition of backordered parts.
Other instructions as specified:
Fill out completely and fax attention Parts Department to:
Snorkel USA 1-785-989-3077
Snorkel Europe [phone]
iv

REPAIRPARTS
MHP1335 VERSION 3 PARTS MANUAL Trailer Assembly
Trailer Assembly Tue Mar 23 07:51:01 UTC 2021 2-1

アイテム 部品番号 名前 数量 UOM
1 1273-2 LevelBubble,TShape 1 EA
2 1649-041 WheelNut1/2UNF 12 EA
3 1651 CassapaValve 1 EA
4 1771-1 Lynchpin 2 EA
5 3603-06 PlainWasher 22 EA
6 3603-08 PlainWasher 22 EA
7 3603-10 PlainWasher 4 EA
8 3603-12 PlainWasher 5 EA
9 3604-06020 PanHeadScrew 2 EA
10 3605-12 SpringWasher 8 EA
11 3606-06025 CountersunkSocketHeadScrew 4 EA
12 3610-06012 MetricBolt 12 EA
13 3610-06020 MetricBolt 8 EA
14 3610-08025 MetricBolt 8 EA
15 3610-08065 MetricBolt 3 EA
16 3610-10016 MetricBolt 4 EA
17 3610-10020 MetricBolt 8 EA
18 3610-12035 SetscrewM12x35HT 1 EA
19 3610-12100 MetricBolt 2 EA
20 3610-12100 MetricBolt 2 EA
21 3610-16080 MetricBolt 2 EA
22 3611-06 MetricNylocNut 8 EA
23 3611-08 MetricNylockNut 11 EA
24 3611-10 MetricNylocNut 2 EA
25 3611-12 MetricNylocNut 13 EA
26 3611-16 MetricNylocNut 2 EA
27 3626-1 FlangedPermaglideBush 16 EA
28 3626-5 FlangedPermaglideBush 8 EA
29 3633-3 RollPin 8 EA
MHP1335 VERSION 3 PARTS MANUAL Trailer Assembly
Trailer Assembly Tue Mar 23 07:51:01 UTC 2021 2-1

アイテム 部品番号 名前 数量 UOM
30 8626 PinKeeper 12 EA
31 9875-1 ReflectorLensOrange 2 EA
32 9875-2 ReflectorLensWhite 2 EA
33 11112-3 BoomLockPin 1 EA
34 11369 Pin7/8"x76mm 4 EA
35 11492-3 TabWasher 12 EA
36 11585-3 MudFlap 2 EA
37 12062 PinLockRetainer 2 EA
38 13223 StabiliserLegWeldment 4 EA
39 12418 ControlGuard 1 EA
40 12419 BoomRestWeldment 1 EA
41 12420 SlewStopTraveller 1 EA
42 12439 TrimPanel 1 EA
43 12444 SlewStopTravellerHoldDown 1 EA
44 12475 15"PlasticMudguard 2 EA
45 12701 DropAxleandHubAssembly 1 EA
46 12703-1 7LeafSpring,1750kg/Pair 2 EA
47 12703-3 UBolt 4 EA
48 12741 Pin 8 EA
49 12742 Pin 4 EA
50 12772 WheelandTyreAssembly 2 EA
51 12790 Foot 4 EA
52 12826 AxlePlate 2 EA
53 13388 ChainAssembly 1 EA
54 13676 TowCoupling 1 EA
55 13908 JockeyWheel-Rubber 1 EA
56 45500-6 KeyRing32mm 2 EA
57 12336A LegCylinderAssembly 4 EA
MHP1335 VERSION 3 PARTS MANUAL Trailer Assembly
Trailer Assembly Tue Mar 23 07:51:01 UTC 2021 2-1

REPAIRPARTS
MHP1335 VERSION 3 PARTS MANUAL Trailer Assembly After Serial Number MHP1335-07-180200105
Trailer Assembly After Serial Number MHP1335-07-180200105 Tue Mar 23 07:51:01 UTC 2021 2-2

アイテム 部品番号 名前 数量 UOM
1 1273-2 LevelBubble,TShape 1 EA
2 1649-041 WheelNut1/2UNF 12 EA
3 1651 CassapaValve 1 EA
4 1771-1 Lynchpin 2 EA
5 3603-06 PlainWasher 22 EA
6 3603-08 PlainWasher 22 EA
7 3603-10 PlainWasher 4 EA
8 3603-12 PlainWasher 5 EA
9 3604-06020 PanHeadScrew 2 EA
10 3605-12 SpringWasher 8 EA
11 3606-06025 CountersunkSocketHeadScrew 4 EA
12 3610-06012 MetricBolt 12 EA
13 3610-06020 MetricBolt 8 EA
14 3610-08025 MetricBolt 8 EA
15 3610-08065 MetricBolt 3 EA
16 3610-10016 MetricBolt 4 EA
17 3610-10020 MetricBolt 8 EA
18 3610-12035 SetscrewM12x35HT 1 EA
19 3610-12100 MetricBolt 2 EA
20 3610-12100 MetricBolt 2 EA
21 3610-16080 MetricBolt 2 EA
22 3611-06 MetricNylocNut 8 EA
23 3611-08 MetricNylockNut 11 EA
24 3611-10 MetricNylocNut 2 EA
25 3611-12 MetricNylocNut 13 EA
26 3611-16 MetricNylocNut 2 EA
27 3626-1 FlangedPermaglideBush 16 EA
28 3626-5 FlangedPermaglideBush 8 EA
29 3633-3 RollPin 8 EA
MHP1335 VERSION 3 PARTS MANUAL Trailer Assembly After Serial Number MHP1335-07-180200105
Trailer Assembly After Serial Number MHP1335-07-180200105 Tue Mar 23 07:51:01 UTC 2021 2-2

アイテム 部品番号 名前 数量 UOM
30 8626 PinKeeper 12 EA
31 9875-1 ReflectorLensOrange 2 EA
32 9875-2 ReflectorLensWhite 2 EA
33 11112-3 BoomLockPin 1 EA
34 11369 Pin7/8"x76mm 4 EA
35 11492-3 TabWasher 12 EA
36 11585-3 MudFlap 2 EA
37 12062 PinLockRetainer 2 EA
38 14011 StabiliserLegWeldment 4 EA
39 12418 ControlGuard 1 EA
40 12419 BoomRestWeldment 1 EA
41 12420 SlewStopTraveller 1 EA
42 12439 TrimPanel 1 EA
43 12444 SlewStopTravellerHoldDown 1 EA
44 12475 15"PlasticMudguard 2 EA
45 12701 DropAxleandHubAssembly 1 EA
46 12703-1 7LeafSpring,1750kg/Pair 2 EA
47 12703-3 UBolt 4 EA
48 12741 Pin 8 EA
49 12742 Pin 4 EA
50 12772 WheelandTyreAssembly 2 EA
51 12790 Foot 4 EA
52 12826 AxlePlate 2 EA
53 13388 ChainAssembly 1 EA
54 13676 TowCoupling 1 EA
55 13908 JockeyWheel-Rubber 1 EA
56 45500-6 KeyRing32mm 2 EA
57 12336A LegCylinderAssembly 4 EA
MHP1335 VERSION 3 PARTS MANUAL Trailer Assembly After Serial Number MHP1335-07-180200105
Trailer Assembly After Serial Number MHP1335-07-180200105 Tue Mar 23 07:51:01 UTC 2021 2-2

REPAIRPARTS
MHP1335 VERSION 3 PARTS MANUAL Column Assembly
Column Assembly Tue Mar 23 07:51:02 UTC 2021 2-3

アイテム 部品番号 名前 数量 UOM
1 1288 BatteryG41 1 EA
2 1814 CableGland 1 EA
3 3603-05 PlainWasher 28 EA
4 3603-06 PlainWasher 21 EA
5 3603-08 PlainWasher 4 EA
6 3603-12 PlainWasher 2 EA
7 3604-04030 MetricHeadPanScrew 2 EA
8 3604-05012 PanHeadScrew 4 EA
9 3604-05016 PanHeadScrew 4 EA
10 3604-05025 PanHeadScrew 6 EA
11 3605-06 SpringWasher 14 EA
12 3605-08 SpringWasher 4 EA
13 3610-06012 MetricBolt 6 EA
14 3610-06016 MetricBolt 21 EA
15 3610-08025 MetricBolt 4 EA
16 3610-10020 MetricBolt 1 EA
17 3610-12050 MetricBolt 2 EA
18 3611-05 MetricNylocNut 14 EA
19 3611-06 MetricNylocNut 8 EA
20 8626 PinKeeper 1 EA
21 10268-2 BatteryBracket 1 EA
22 11492-3 TabWasher 1 EA
23 11943 SlewDriveandBrakeAssembly 1 EA
24 12239-3 PinEndCap 2 EA
25 12381-18 LowerControlBoxMount 1 EA
26 12381-25 PinionGearGuard 1 EA
27 12381-40 HeatDeflector 1 EA
28 12399 Pin 1 EA
29 12401 Latch-Compression 1 EA
MHP1335 VERSION 3 PARTS MANUAL Column Assembly
Column Assembly Tue Mar 23 07:51:02 UTC 2021 2-3

アイテム 部品番号 名前 数量 UOM
30 12403 ButtHinge-SS-76.2X38.1mm 2 EA
31 12413 EngineAssembly 1 EA
32 12414-20 StayPivotMount 2 EA
33 12414-5 CoverStayWeldment 1 EA
34 12445 MicroSwitch 1 EA
35 12453 Locktab40mmPin 2 EA
36 13573A LowerControlBoxAssembly 1 EA
37 12734 Pin 1 EA
38 13485-01 Trionics-GP400C 1 EA
39 3030181 Trionics-TBM 1 EA
40 13549 MountBracket-GP400 1 EA
41 13550 MountBracket-TBM 1 EA
42 13551 CoverBoxFold 1 EA
43 13632-10 StayBracket 2 EA
44 13879-01 MainManifold 1 EA
45 11430A HydraulicOilTank 1 EA
46 12483A RemoteGreaseNipple 1 EA
MHP1335 VERSION 3 PARTS MANUAL Column Assembly
Column Assembly Tue Mar 23 07:51:02 UTC 2021 2-3

REPAIRPARTS
MHP1335 VERSION 3 PARTS MANUAL Slew Ring Assembly
Slew Ring Assembly Tue Mar 23 07:51:02 UTC 2021 2-4

アイテム 部品番号 名前 数量 UOM
1 1034-120 M16GalvHardened&Temp
Washer 12 EA
2 1067 SlewRing 1 EA
3 3613-12035 SocketHeadCapScrew 10 EA
4 3631-12 DiscLockWasher 10 EA
5 3631-16 DiscLockWasher 12 EA
6 60020-028N UNFHexBolt 12 EA
7 60021-016 UNFNut 12 EA
MHP1335 VERSION 3 PARTS MANUAL Slew Ring Assembly
Slew Ring Assembly Tue Mar 23 07:51:02 UTC 2021 2-4

REPAIRPARTS
MHP1335 VERSION 3 PARTS MANUAL Covers Assembly
Covers Assembly Tue Mar 23 07:51:03 UTC 2021 2-5
