SnowEx Renegade S150A User manual

This manual supersedes all editions with an earlier date.
March 1, 2023
Lit. No. 31195EN, Rev. 00
Renegade™ Hopper Spreaders
#S150A, S220A, S300A, S400A, S500A
S150C, S220C, S300C, S400C, S500C
Owner's Manual
Original Instructions
CAUTION
Read this document before operating
or servicing the spreader.
This Owner's Manual is for SnowEx®Renegade hopper spreaders
with serial numbers beginning with 230301 and higher.

Lit. No. 31195EN, Rev. 00 3 March 1, 2023
Translated Owner's Manuals can be found online at
https://library.snowexproducts.com/publications.asp?cat=739
PREFACE
This manual has been prepared to acquaint you with
the safety information, operation, and maintenance of
your new hopper spreader. Please read this manual
carefully and follow all recommendations. This will
help ensure protable and trouble-free operation of
your hopper spreader. Keep this manual accessible. It
is a handy reference in case minor service is required.
When service is necessary, bring your hopper
spreader to your distributor/dealer. They know your
spreader best and are interested in your complete
satisfaction.
NOTE: This spreader is designed to spread snow
and ice control materials only. Do not use it for
purposes other than those specied in this
manual.
Register your spreader online at www.snowexproducts.com
OWNER'S INFORMATION
Owner's Name: ______________________________________________________________________
Date Purchased: _____________________________________________________________________
Outlet Name: ______________________________________________ Phone:_________________
Outlet Address: ______________________________________________________________________
Vehicle Model: _______________________________________________ Year: _______________
Spreader Type (model): ________________________________ Serial #:______________________
Length:________________________ Weight: __________________ lb/kg: _________________

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 3 March 1, 2023
TABLE OF CONTENTS
Safety..........................................................................4
Safety Denitions.................................................. 4
Warning/Caution Labels ....................................... 4
Auger Units..................................................... 5
Chain Units..................................................... 6
Serial Number Label ............................................. 7
Safety Precautions................................................ 7
Fuses .................................................................... 9
Personal Safety..................................................... 9
Fire and Explosion ................................................ 9
Cell Phones........................................................... 9
Ventilation ............................................................. 9
Battery Safety ..................................................... 10
Noise................................................................... 10
Vibration.............................................................. 10
Torque Chart ....................................................... 10
Loading .................................................................... 11
Certication......................................................... 11
Material Weights ................................................. 11
Spreader Specications...................................... 11
Load Volume ....................................................... 12
Determining Vehicle Payload.............................. 12
Mounting the Spreader........................................... 14
Install Hopper in Truck Bed................................. 14
Chute Installation ................................................ 16
Operating the Spreader.......................................... 18
Cab Control......................................................... 18
Powering the Control.................................... 18
Starting and Stopping Spreader................... 19
Controlling Material Application.................... 19
BLAST/Maximum Application ................ 19
Cab Control Modes ...................................... 20
Standby Mode........................................ 20
Ready Mode........................................... 20
ON Mode................................................ 20
Error Mode ............................................. 20
Cab Control Codes....................................... 21
Setup Procedures......................................... 24
Calibrate the Empty Hopper Setting
(Cb and EH Codes) ............................ 24
Clearing Empty Hopper Calibration Data
(Cc Code)............................................ 24
Adjust LED Brightness Level
(LS and SL Codes).................................... 25
Spread Pattern Adjustment................................. 26
Material Spread Patterns.............................. 27
Dump Function.................................................... 28
Accessory Work Light......................................... 28
Maintenance ............................................................ 29
Grease Fittings ................................................... 29
Conveyor Pintle Chain Tension...........................30
Removing the Chute ........................................... 31
After Each Use.................................................... 31
Cab Control......................................................... 32
Storage ............................................................... 32
Fuse Replacement.............................................. 33
Recycle ............................................................... 33
Electrical Components...........................................34
Vehicle Harness Diagram ...................................34
Electrical Control Box Diagram...........................35
Auger Spreader ............................................35
Chain Spreader ............................................36
Troubleshooting Guide........................................... 37

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 4 March 1, 2023
SAFETY
SAFETY
SAFETY DEFINITIONS
WARNING
Indicates a potentially hazardous situation
that, if not avoided, could result in death or
serious personal injury.
CAUTION
Indicates a potentially hazardous situation
that, if not avoided, may result in minor or
moderate injury. It may also be used to alert
against unsafe practices.
NOTE: Indicates a situation or action that can
lead to damage to your spreader and vehicle or
other property. Other useful information can also
be described.
WARNING/CAUTION LABELS
Become familiar with and inform users about the
warning and caution labels on the spreader.
NOTE: If labels are missing or cannot be read, see
your sales outlet.

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 5 March 1, 2023
SAFETY
Warning/Caution Label
(both sides of hopper)
Auger Units

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 6 March 1, 2023
SAFETY
Chain Units
Warning/Caution Label
(both sides of hopper)

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 7 March 1, 2023
SAFETY
SAFETY PRECAUTIONS
Improper installation and operation could cause
personal injury and/or equipment and property
damage. Read and understand labels and the
Owner's Manual before installing, operating, or making
adjustments.
WARNING
• Driver to keep bystanders minimum of 25 feet
(7.62 m) away from operating spreader.
• Before working with the spreader, secure all
loose-tting clothing and unrestrained hair.
• Before operating the spreader, verify that all
safety guards are in place.
• Before servicing the spreader, wait for
conveyor or auger, and spinner to stop.
• Do not climb into or ride on spreader.
WARNING
Overloading could result in an
accident or damage. Do not exceed
GVWR or GAWR ratings as found
on the driver-side vehicle door
cornerpost. See Loading section to determine
maximum volumes of spreading material.
WARNING
Do not install the control for this product in
the deployment path of an air bag. Refer to
vehicle manufacturer's manual for air bag
deployment area(s).
WARNING
With chute removed, use dump switches to
operate conveyor.
Code Denition
YY 2-Digit Year
MM 2-Digit Month
DD 2-Digit Day
LL 2-Digit Location Code
XXXX 4-Digit Sequential Number
ZZZZZ 5- to 7-Digit Assembly PN
SERIAL NUMBER LABEL

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 8 March 1, 2023
SAFETY
WARNING
Vehicles <10,000 lb (4536 kg) GVWR:
Obstructing the visibility from the vehicle's
rear camera could result in serious injury or
damage. An auxiliary camera system shall
be installed if the vehicle's rear camera is
removed or blocked.
CAUTION
If rear directional, CHMSL light, or brake
stoplights are obstructed by the spreader, the
lights shall be relocated, or auxiliary directional
or brake stoplights shall be installed.
CAUTION
During the hopper installation we recommend
the addition of an OSHA compliant backup
alarm. This alarm is required for OSHA
governed employers.
CAUTION
• Do not operate a spreader in need of
maintenance.
• Before operating the spreader, reassemble
any parts or hardware removed for cleaning
or adjusting.
• Before operating the spreader, remove
materials such as cleaning rags, brushes,
and hand tools from the spreader.
• While operating the spreader, use auxiliary
warning lights, except when prohibited by law.
• Tighten all fasteners according to the
Torque Chart. Refer to Torque Chart for the
recommended torque values.
CAUTION
Disconnect electric and/or hydraulic power
and tag out if required before servicing or
performing maintenance.
CAUTION
DO NOT leave unused material in
hopper. Material can freeze or solidify,
causing unit to not work properly.
Empty and clean after each use.
NOTE: Lubricate grease ttings after each use.
Use a good quality multipurpose grease.

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 9 March 1, 2023
SAFETY
FUSES
The electrical system contains several blade-style
automotive fuses. If a problem should occur and
fuse replacement is necessary, the replacement
fuse must be of the same type and amperage
rating as the original. Installing a fuse with a higher
rating can damage the system and could start a
re. Fuse Replacement, including fuse ratings and
locations, is located in the Maintenance section of this
Owner's Manual.
PERSONAL SAFETY
• Remove ignition key and put the vehicle in park or
in gear to prevent others from starting the vehicle
during installation or service.
• Wear only snug-tting clothing while working on
your vehicle or spreader.
• Do not wear jewelry or a necktie, and secure
long hair.
• Wear safety goggles to protect your eyes from
battery acid, gasoline, dirt, and dust.
• Avoid touching hot surfaces such as the engine,
radiator, hoses, and exhaust pipes.
• Always have a re extinguisher rated BC handy,
for ammable liquids and electrical res.
FIRE AND EXPLOSION
WARNING
Gasoline is highly ammable and gasoline
vapor is explosive. Never smoke while
working on vehicle. Keep all open ames
away from gasoline tank and lines. Wipe up
any spilled gasoline immediately.
Be careful when using gasoline. Do not use gasoline
to clean parts. Store only in approved containers away
from sources of heat or ame.
CELL PHONES
A driver's rst responsibility is the safe operation
of the vehicle. The most important thing you can
do to prevent a crash is to avoid distractions and
pay attention to the road. Wait until it is safe to
operate mobile communication equipment such as
cell phones, text messaging devices, pagers, or
two-way radios.
VENTILATION
WARNING
Vehicle exhaust contains lethal fumes.
Breathing these fumes, even in low
concentrations, can cause death. Never
operate a vehicle in an enclosed area without
venting exhaust to the outside.

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 10 March 1, 2023
SAFETY
BATTERY SAFETY
CAUTION
Batteries normally produce explosive gases
which can cause personal injury. Therefore,
do not allow ames, sparks, or lit tobacco
to come near the battery. When charging or
working near a battery, always cover your
face and protect your eyes, and also provide
ventilation.
• Batteries contain sulfuric acid, which burns
skin, eyes, and clothing.
• Disconnect the battery before removing or
replacing any electrical components.
NOISE
Airborne noise emission during use is below 70 dB(A)
for the spreader operator.
VIBR ATION
Operating spreader vibration does not exceed 2.5 m/s2
to the hand-arm or 0.5 m/s2to the whole body.
TORQUE CHART
CAUTION
Read instructions before assembling.
Fasteners should be nger tight until
instructed to tighten according to the Torque
Chart. Use standard methods and practices
when attaching spreader, including proper
personal protective safety equipment.
M6 x 1.00 7.7 10.4 11.1 15.0 M20 x 2.50 325 441450 610
M8 x 1.25 19.5 26.4 26.9 36.5 M22 x 2.50 428 580613 831
M10 x 1.50 38.5 52.2 53.3 72.2 M24 x 3.00 562 762778 1055
M12 x 1.75 67 91 93 126M27 x 3.00 796 1079 1139 1544
M14 x 2.00 107 145148 200M30 x 3.50 1117 1515 1545 2095
M16 x 2.00 167 226231 313M33 x 3.50 1468 1990 2101 2849
M18 x 2.50 222 301318 431M36 x 4.00 1952 2647 2701 3662
1/4-20 8.4 11.4 11.9 16.2 9/16-12 109 148154 209
1/4-28 9.7 13.1 13.7 18.5 9/16-18 121 164171 232
5/16-18 17.4 23.6 24.6 33.3 5/8-11 150 203212 287
5/16-24 19.2 26.0 27.3 36.9 5/8-18 170 230240 325
3/8-16 30.8 41.8 43.6 59.1 3/4-10 269 365376 510
3/8-24 35.0 47.5 49.4 67.0 3/4-16 297 403420 569
7/16-14 49.4 67.0 69.8 94.6 7/8-9 429 589606 822
7/16-20 55.2 74.8 77.9 105.67/8-14 474 643669 907
1/2-13 75.3 102.1106.4 14 4.31-8 644 873909 1232
1/2-20 85.0 115.2120.0 162.71-12 704 954995 1349
Recommended Fastener Torque Chart
Size Size
Torque ft-lb N·m
Grade
5
Grade
8
Metric Fasteners Class 8.8 and 10.9
These torque values apply to fasteners
except those noted in the instructions.
Torque ft-lb N·m
Grade
5
Grade
8
Size Size
Torque ft-lb N·m
Class
8.8
Class
10.9
Torque ft-lb N·m
Class
8.8
Class
10.9
Inch Fasteners Grade 5 and Grade 8

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 11 March 1, 2023
LOADING
LOADING
This Owner's Manual covers vehicles that have been
recommended for carrying the hopper spreader.
Please see your local dealer for proper vehicle
applications.
CERTIFICATION
WARNING
New untitled vehicle installation of a spreader
requires National Highway Tra󰀩c Safety
Administration altered vehicle certication
labeling. Installer to verify that struck load of
snow or ice control material does not exceed
GVWR or GAWR rating label and complies
with FMVSS.
WARNING
Overloading could result in an accident or
damage. Do not exceed GVWR or GAWR as
found on the driver-side cornerpost of vehicle.
CAUTION
Never use wet materials or materials with
foreign debris with any of these spreaders.
These units are designed to handle dry, clean,
free-owing material.
CAUTION
Read and adhere to manufacturer's
ice-control material package
labeling, including Safety Data
Sheet requirements.
MATERIAL WEIGHTS
Density
Material (lb/ft3)(lb/yd3)(kg/m3)
Salt 80 2160 1282
Sand 100 2700 1602
Material densities are approximate and are based on dry,
loose material. It is the responsibility of the operator to
know the weight of the material to be spread and the vehicle
carrying capacity.
SPREADER SPECIFICATIONS
Hopper
Model
Overall
Length
(in / cm)
Hopper
Length
(in / cm)
Overall
Width
(in / cm)
Bed
Height
(in / cm)
Bed
Length
(in / cm)
Empty
Weight
(lb / kg)
S150C 96 / 244 84 / 213 50 / 127 32 / 81 76 / 193 587 / 266
S150A 102 / 259 84 / 213 50 / 127 32 / 81 76 / 193 580 / 263
S220C 114 / 290 96 / 244 50 / 127 36 / 91 90 / 229 641 / 291
S220A 114 / 290 96 / 244 50 / 127 36 / 91 90 / 229 633 / 287
S300C 114 / 290 96 / 244 70 / 178 41 / 104 90 / 229 811 / 368
S300A 120 / 305 96 / 244 70 / 178 41 / 104 90 / 229 794 / 360
S400C 116 / 295 108 / 274 70 / 178 44 / 112 96 / 244 854 / 387
S400A 120 / 305 108 / 274 70 / 178 44 / 112 96 / 244 836 / 379
S500C 116 / 295 108 / 274 70 / 178 51 / 130 96 / 244 900 / 408
S500A 120 / 305 108 / 274 70 / 178 51 / 130 96 / 244 881 / 400
C = Chain; A = Auger

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 12 March 1, 2023
LOADING
DETERMINING VEHICLE PAYLOAD
WARNING
Overloading could result in an accident or
damage. Do not exceed GVWR or GAWR
ratings as found on the driver-side door
cornerpost of the vehicle. See Loading
section to determine maximum volumes of
spreading material.
1. Install the hopper spreader and optional
equipment according to the Installation
Instructions.
2. Install or attach any other equipment that will be
on the vehicle while the hopper spreader will be in
use (step bumper, trailer hitch, snowplows, etc.).
Fill gas tanks.
3. Obtain the Gross Vehicle Weight Rating (GVWR),
Front Gross Axle Weight Rating (FGAWR), and
Rear Gross Axle Weight Rating (RGAWR) from
the certication label located inside the driver-side
door jamb or door.
4. With the occupants in the truck for normal hopper
spreader operation, weigh the vehicle to obtain
gross vehicle weight (GVW).
5. Subtract the GVW from the GVWR to determine
the available material payload.
6. Obtain the weight per cubic yard (lb/yd3) or cubic
meter (kg/m3) of the desired material. Divide the
weight into the payload to determine the maximum
volume of material that can be carried.
7. Refer to the Load Volume table and diagrams to
determine the maximum ll level for the material.
8. Fill the hopper with material to the calculated level.
Reweigh the vehicle with occupants and verify that
the Loaded Gross Vehicle Weight, Front Gross
Axle Weight, and Rear Gross Axle Weight are less
than the vehicle's ratings.
9. Repeat Steps 6–8 for each type of material.
The worksheet for Determining Vehicle Payload (next
page) includes an example.
A
B
C
D
LOAD VOLUME
Hopper
Model
Load Volume (yd3/ m3)
ABCD
S150 1.9 / 1.45 1.5 / 1.15 1.1 / 0.84 0.7 / 0.54
S220 2.5 / 1.91 2.2 / 1.68 1.2 / 0.92 0.8 / 0.61
S300 3.4 / 2.60 3.0 / 2.29 2.5 / 1.91 1.0 / 0.76
S400 4.4 / 3.36 4.0 / 3.06 2.6 / 1.99 1.1 / 0.84
S500 5.4 / 4.13 5.0 / 3.82 2.6 / 1.99 1.1 / 0.84
A: Rounded Load
B: Struck Load
C: Second Bump
D: First Bump

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 13 March 1, 2023
LOADING
Determining Vehicle Payload Worksheet
Material Type Example:
Dry Salt
AEquipment installed when
vehicle was weighed
8' Stainless
Steel Hopper
Spreader
BFront Gross Axle Weight
Rating [FGAWR] (lb/kg) 6000
CRear Gross Axle Weight
Rating [RGAWR] (lb/kg) 7000
DGross Vehicle Weight
Rating [GVWR] (lb/kg) 11,000
EGross Vehicle Weight [GVW],
empty (lb/kg) – 7402
F Payload Available (lb/kg) = 3598
GMaterial Density
(lb/yd3) or (kg/m3)÷ 2160
HMaximum Volume (yd3/m3)= 1.67
I
Maximum Material Fill Level,
approx. Refer to Load Volume
table and diagrams.
C
J
Loaded Front Gross Axle
Weight (lb/kg) Must be less than
weight in Row B.
K
Loaded Rear Gross Axle
Weight (lb/kg) Must be less than
weight in Row C.
L
Loaded Gross Vehicle Weight
[GVW] (lb/kg) Must be less than
weight in Row D.

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 14 March 1, 2023
MOUNTING THE SPREADER
INSTALL HOPPER IN TRUCK BED
NOTE: Periodically throughout the snow and ice
control season, verify that mounting devices
are secure.
1. Remove the top screens and set them aside.
Remove any debris from inside the hopper.
2. If the material chute has been stored inside the
hopper, remove the chute and set it aside. Two or
more people are recommended for this step, as
the chute weighs more than 60 lb (27.2 kg).
3. Remove the vehicle tailgate.
MOUNTING THE SPREADER
4. Lift the spreader by the four diagonal corner
rails, as shown, using slings or chains. Move the
spreader into the truck bed.
Use all four rails
when lifting.
CAUTION
Before lifting, verify that the hopper is empty
of material. The lifting device must be able to
support the spreader's weight as shown in
the spreader specications table.

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 15 March 1, 2023
MOUNTING THE SPREADER
WARNING
Spreader shall be bolted to vehicle frame.
Do not rely on the tie-down chains or straps
alone to hold spreader in vehicle.
5. Adjust the spreader position to align the holes in
the hopper support legs with the mounting holes
in the truck bed. If mounting holes are not already
drilled, refer to the hopper spreader Installation
Instructions.
Install the spreader to the truck bed using four
5/8" Grade 5 bolts (as required by the vehicle
application), 5/8" at washers on both sides, and
5/8" locknuts.
If the mounting holes are not directly over
the truck box supports, the truck bed must
be braced to the frame to prevent buckling or
deforming the truck bed. Accessory mounting
bars are available for installations that require
additional bracing. Contact your authorized dealer.
NOTE: Pay special attention when drilling or
clamping dissimilar metals to aluminum bodies.
Galvanic corrosion can occur if not handled
properly. Contact vehicle manufacturer for
recommended attachment practices.
6. Connect the vehicle-side harness to the
hopper-side harness.
7. Reinstall the top screens.
8. Install the sill spacer between the end of the
hopper sill and the front of the truck bed as shown.
If you do not have a spacer, refer to the hopper
spreader Installation Instructions for directions on
building one. Failure to install this spacer could
result in damage to the spreader.
Spacer
Built to Fit
Tie-Down Straps
Install tie-down straps from the tie-down loops on the
spreader body to the truck frame. Use one strap per
loop, pulling diagonally away from the hopper body.

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 16 March 1, 2023
MOUNTING THE SPREADER
CHUTE INSTALLATION
Chute Congurations
The chute comes in two lengths.
• Short Chute for S150 and S220 Models: Short
chute conguration is standard and will t most
pickup trucks
◦Chain Units: The chute extends 20" (51 cm)
below the truck bed.
◦Auger Units: The chute extends 18.5" (47 cm)
below the truck bed.
• Long Chute for S300, S400, and S500 Models:
Long chute conguration is standard. Required for
at bed and dump truck installations.
◦Chain Units: The chute extends
32" (81 cm) below the truck bed.
◦Auger Units: The chute extends
30.5" (77 cm) below the truck bed.
Ideal spinner height is 12"–18" (30 cm–46 cm) above
the ground. For some installations the chute length
may need to be adjusted to achieve the desired
spinner height.
If no length adjustment is required, go to "Install Chute
to Hopper."
Extending a short chute requires installation of
the Chute Middle Section Kit (available from your
authorized dealer). Follow the instructions packed with
the kit.
A long chute can be shortened by removing the middle
section. Refer to the hopper spreader Installation
Instructions.
Chain versions of chute shown.
Long Chute
for
S300C, S400C & S500C Models
Short Chute
for
S150C & S220C Models

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 17 March 1, 2023
MOUNTING THE SPREADER
2. Insert a 1/2" x 8-1/2" chute pin on each side and
secure with a 3/32" x 2-1/4" cotter pin.
The chute can pivot on either pin to provide
access to the feed area of the hopper. The chute
is designed to swing open in one direction only.
It cannot be opened without disconnecting the
hopper harness cable.
3. Connect the chute motor plug to the hopper
harness plug.
Install Chute to Hopper
1. Two people are recommended for this step. Pick
up the chute from each side and slide the chute
hinges over the hopper hinges. Line up the hinge
pivot holes.
Auger Spreaders
Hinge
Pivot Holes
Hinge
Pivot Holes
Chute
Pivot Pins
Chain Spreaders
Hinge
Pivot Holes
Hinge
Pivot Holes
Chute
Pivot Pins

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 18 March 1, 2023
OPERATING THE SPREADER
OPERATING THE SPREADER
CAB CONTROL
WARNING
Never operate equipment when under the
inuence of alcohol, drugs, or medications
that might alter your judgment and/or
reaction time.
WARNING
Never exceed 45 mph (72 km/h) when loaded
spreader is attached to vehicle. Braking
distances may be increased and handling
characteristics may be impaired at speeds
above 45 mph (72 km/h).
WARNING
Never allow children to operate or climb on
equipment.
Powering the Control
Power is not applied to the control until the vehicle
ignition is turned to ACC or ON. Once the control
has power it performs a light check and displays the
software version on the status display. The control
then checks for a connected spreader. If no spreader
is detected, the control does the following:
• nC (no connection) appears on the red status
display for ve seconds;
• A single beep;
• Control enters Standby mode with no lights
illuminated.
If any button is pressed on the control, it will wake and
check again for spreader connection. If no spreader is
detected, it will act as described above. If a spreader
is detected, it will transition to Ready mode.
Material
Width
Material
Flow
VIBRATELIGHT STROBE PREWET
MINMAX
ON/OFF
MI
NM
AX
BLAST
Material Width
Control Knob
(spinner speed)
Indicator Lights
(8 per knob)
Material Flow
Control Knob
(feed rate)
BLAST Button
(maximum application)
ON/OFF Button
& Emergency Stop
Status/Error Code
Display (red)
Accessory
Control Buttons

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 19 March 1, 2023
OPERATING THE SPREADER
Starting and Stopping Spreader
WARNING
Before starting the spreader, the driver shall
verify that all bystanders are a minimum of
25 feet (7.62 m) away from operating spreader.
To start the spreader, press the ON/OFF button. The
control backlights are illuminated when the vehicle
ignition is ON and the spreader is connected. When
the spreader is ON, the ON/OFF button and inner arc
around each control knob will also illuminate.
To stop the spreader, press the ON/OFF button
again.
The ON/OFF button also operates as an emergency
stop when required.
NOTE: The vehicle ignition must be ON to start
the spreader.
NOTE: If vehicle ignition is turned OFF while
spreader is running, the motors will stop.
Controlling Material Application
The material application settings can be adjusted
while spreader is ON or OFF. Settings are shown by
the indicator lights around the control knobs. When
the spreader is OFF, a single LED will light to show the
current setting. When the spreader is ON, the number
of blue LEDs illuminated will increase/decrease as the
knobs are turned clockwise/counterclockwise.
The hopper drive will not deliver material until the ON
button is pressed.
The Material Width (left) knob controls spinner speed.
Turning the knob clockwise will increase the width of
the application area.
The Material Flow (right) knob controls the hopper
drive. Turning the knob clockwise will increase the
feed rate of material to the spinner.
Turning the control knobs counterclockwise will
decrease the width of the application area and the
feed rate of material, respectively.
BLAST/Maximum Application
1. Press and hold the BLAST button when maximum
ow rate and application area are needed
temporarily. The BLAST button will illuminate
while depressed.
2. Release the button when maximum application
settings are no longer needed.
NOTE: Spinner speed and material feed rate revert
to the previous settings once the BLAST button
is released.

Lit. No. 31193EN/31194EN/31195EN, Rev. 00 20 March 1, 2023
OPERATING THE SPREADER
Cab Control Modes
Standby Mode
Vehicle ignition is set to ACC or ON; cab control is
OFF. Control has power. No spreader was detected.
No lights are illuminated on the control. Press any
button to wake.
Ready Mode
Vehicle ignition is set to ACC or ON; cab control is OFF.
Control has power. Spreader is detected.
The Material Width and Material Flow control knobs
can be set to start-up conditions, but the spinner and
drives will not operate until the cab control is turned
ON.
Accessory lights and vibrator (if installed) are
operational. The BLAST function is not operational.
ON Mode
Vehicle ignition is set to ACC or ON; cab control is ON.
Spinner and hopper motors will start. All cab control
functions are operational. Accessory lights and
vibrator (if installed) are operational.
During normal spreader operation, no control codes
are displayed. Information or setup codes will appear
when relevant. These codes will not stop spreader
operation.
Error Mode
When an error condition occurs, spreader operation
will shut down. A two-character error code will ash
on the display and a beep will sound. If there are
multiple error codes, the codes will ash in a repeating
sequence.
Refer to the Error Codes portion of the
following Cab Control Codes table. Also see the
Troubleshooting Guide section of this manual.
Once the error condition has been resolved, press the
ON/OFF button to clear the error code(s). Press the
ON/OFF button again to resume spreader operation.
The error code will reappear if the error condition
has not been rectied. If the error condition persists,
contact your authorized dealer.
Multiple resets within a short time frame will cause
the hopper module to time out if components are
overheating. The control will display an EF error code.
Accessory work lights and strobe lights can be used
when an error code is in e󰀨ect and will remain in
their current state. The vibrator and pre-wet will not
function.
