SNOWJOE Sunjoe GTS4002C User manual

© 2019 by Snow Joe®, LLC
All rights reserved. Original instructions. SAVE THESE INSTRUCTIONS
A Division of Snow Joe®, LLC
OPERATOR’S MANUAL
Model GTS4002C Form No. SJ-GTS4002C-880E-MR3
CORDLESS LAWN + GARDEN
MULTI-TOOL SYSTEM
24-VOLT MAX* | POLE HEDGE TRIMMER | POLE CHAIN SAW | POLE GRASS TRIMMER
R
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
General Safety
mWARNING! This appliance is not intended for use
by children or by unassisted, unsupervised persons whose
physical, sensory or mental capabilities prevent them from
using it safely. Children should be supervised to ensure that
they do not play with the appliance.
Before starting up your machine, please check it carefully for
HU`KLMLJ[Z0M`V\ÄUKHU`KVUV[Z[HY[\W`V\YTHJOPUL
Contact your authorized Snow Joe®+ Sun Joe®dealer
mWARNING! When using the power tool, basic safety
precautions should always be followed to reduce the risk of
ÄYLLSLJ[YPJZOVJRHUKWLYZVUHSPUQ\Y`;OLZLPUJS\KL!
1. Keep work area clean and well-lit – Cluttered, dark
areas invite accidents.
2. Avoid dangerous environments – Do not use the power
tool in rain, in damp or wet locations, or in bad weather,
especially when there is a risk of lighting. This decreases
the risk of being struck by lighting. Do not operate the
power tool in gaseous or explosive atmospheres or use
[OLWV^LY[VVSULHYÅHTTHISLVYJVTI\Z[PISLSPX\PKZ
Motors in these tools normally spark, and the sparks
might ignite fumes.
3. Know your product – Know how to start and stop the
machine. Be thoroughly familiar with the controls.
4. Keep children, bystanders, and pets away –
All spectators, including pets, should be kept a safe
distance away from the work area.
5. Dress properly – Do not wear loose clothing or jewelry.
They can get caught in moving parts. Protective rubber
gloves and non-slip footwear are recommended when
working outdoors.
6. mCAUTION! – Exercise caution to avoid slipping or
falling. Wear protective footwear that will protect your feet
and improve your footing on slippery surfaces.
7. Stay alert – Watch what you are doing. Use common
sense. Do not operate the power tool when you are tired,
VY\UKLY[OLPUÅ\LUJLVMHSJVOVSVYKY\NZ
8. Do not overreach – Keep proper footing and balance
at all times.
9. Avoid unintentional starting – Do not carry the power
[VVS^P[O`V\YÄUNLYVU[OL[YPNNLY4HRLZ\YL[OLZ^P[JO
PZVɈILMVYLPUZLY[PUN[OLIH[[LY`
10. Use the right appliance – Do not use the power tool
for any applications other than those for which it was
intended.
11. Blades are sharp – Don't grasp the exposed cutting
blades or cutting edges when picking up or holding the
power tool.
12. Use two hands – Hold the telescoping pole and handle
with both hands to avoid loss of control.
13. Remove the battery – Remove the battery from the
power tool when it is not in use, before servicing it,
when changing accessories, and when performing any
other maintenance task.
14. Use safety glasses – Also use safety footwear,
ZU\NÄ[[PUNJSV[OPUNWYV[LJ[P]LNSV]LZOLHYPUNHUK
head protection.
15. Use head protection – Always use head protection when
operating the power tool overhead. Falling debris can
result in serious personal injury.
16. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it was designed.
17. Store indoors – When not in use, the power tool should
be stored indoors in a dry and high or locked-up place out
of the reach of children.
18. Check for damaged parts – Before further use of the
appliance, all guards and parts should be carefully
checked to determine that it will operate properly and
perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts,
TV\U[PUNHUKHU`V[OLYJVUKP[PVU[OH[TH`HɈLJ[P[Z
operation. A guard or other part that is damaged should
be properly repaired or replaced.
1

2
19. Maintain the power tool with care – Keep the cutting
edges sharp and clean for optimal performance and to
reduce the risk of injury. Keep the handles dry, clean,
and free from oil and grease. Follow the additional
recommendations described in the maintenance section
of this manual.
20. Do not use the power tool if the switch does not turn it on
HUKVɈ(U`WV^LY[VVS[OH[JHUUV[ILJVU[YVSSLK^P[O[OL
switch is dangerous and must be repaired.
21. Keep all parts of the body away from the cutting blades/
chain. Do not remove cut material or hold material to be
cut when blades/chain are moving. Make sure the switch
PZVɈ^OLUJSLHYPUNQHTTLKTH[LYPHS;OLISHKLZJOHPU^PSS
JVU[PU\LTV]PUNMVYH^OPSLHM[LY[OL[VVSPZ[\YULKVɈ
A moment of inattention while operating the power tool
may result in serious personal injury.
22. Carry the power tool by the handle with the cutting blade/
chain stopped. When transporting or storing the power
tool, always keep the blades/chain covered.
Proper handling of the garden tool will reduce
possible personal injury from the cutting blades.
23. Hold the product by insulated gripping surfaces only,
because the cutting blades/chain may contact hidden
wiring. Cutting blades/chain contacting a “live” wire may
make exposed metal parts of the product “live”and could
give the operator an electric shock.
24. The unit has not been designed to provide protection
from electric shock in the event of contact with overhead
electric lines. Never use the power tool near any electrical
power lines. Contact with or use near power lines may
cause serious injury or electric shock resulting in death.
Maintain a minimum clearance of 50 ft (15 m) from all
power lines.
mWARNING! Before inspecting, cleaning, or servicing
the machine, remove the battery and wait for all moving parts
to stop. Failure to follow these instructions can result in serious
personal injury or property damage.
mWARNING! Do not use this appliance without reading
this instruction manual.
mWARNING! Do not use the appliance within range of
persons unless they are wearing protective clothing.
mWARNING! Do not operate the cordless power tool in
H[YLLVUHSHKKLYVYVUHZJHɈVSK<ZPUN[OL[VVS\UKLYZ\JO
circumstances is extremely dangerous.
mWARNING! Do not let familiarity with this type of tool
prevent you from taking all necessary precautions. Remember
[OH[HJHYLSLZZMYHJ[PVUVMHZLJVUKPZZ\ɉJPLU[[VPUÅPJ[
serious injury.
mWARNING! The multi-tool system must be fully
assembled before operation! Do not use the tool that is only
partly assembled or assembled with damaged parts!
mWARNING! Starting, stopping, and restarting an
electric motor repeatedly within a few seconds can generate
a great deal of heat and damage the motor. To protect the life
of your cordless power toolHS^H`Z^HP[H[SLHZ[Ä]LZLJVUKZ
after stopping before restarting the unit.
mWARNING! Electrical Shock Hazard – Before starting
up your machine, please check it carefully for any defects.
0M`V\ÄUKHU`KVUV[Z[HY[\W`V\YTHJOPULHUKJVU[HJ[`V\Y
distributor.
NOTE: Take care of small parts that are removed during
assembly or when making adjustments. Keep them secure
to avoid loss.
Any operation WLYMVYTLKPUHU\UH\[OVYPaLKZLY]PJLJLU[LY
VYI`\UX\HSPMPLKpersonnel will completely invalidate the
warranty.
mWARNING! -VY`V\YZHML[`HUK[OH[VMV[OLYZ!
࠮Correct maintenance is essential to maintain the original
LɉJPLUJ`HUKZHML[`VM[OLTHJOPULV]LY[PTL
࠮Keep all nuts, bolts, and screws tight to be sure the
LX\PWTLU[PZPUZHML^VYRPUNJVUKP[PVU
࠮Never use the machine with worn or damaged parts.
Damaged parts are to be replaced and never repaired.
mWARNING! Always wear protective gloves during
maintenance operations.
mWARNING! Use only original manufacturer’s
replacement parts, accessories and attachments. Failure to
do so can cause possible injury and poor performance.
Cleaning the Tool
mWARNING! 5L]LYSL[HU`SPX\PKNL[PUZPKL[OLTV[VY
housing and NEVERPTTLYZLHU`WHY[VM[OLOV\ZPUNPUSPX\PK
1. Stop the motor and remove the battery.
2. Clean dirt and debris from the body of the tool, using a
damp cloth with a mild detergent.
NOTE: Do not use any strong detergents on the plastic
housing or the handle, as they can be damaged by certain
aromatic oils such as pine and lemon, and by solvents
such as kerosene.

3
Storage
mWARNING! +VUV[H[HU`[PTLSL[IYHRLÅ\PKZNHZVSPUL
petroleum-based products, penetrating oils, etc., come in
contact with plastic parts. Chemicals can damage, weaken, or
destroy plastic which may result in serious personal injury.
1. Stop the motor and remove the battery.
2. Clean the multi-tool system thoroughly before storing.
3. Always place the blade cover on the blade and bar sheath
on the chain bar before storing or transporting the multi-
tool system. Use caution to avoid the sharp teeth of the
blade and the chain.
4. Store the multi-tool system indoors, in a dry place that is
inaccessible to children. Keep away from corrosive agents
such as garden chemicals and de-icing salts.
5. We recommend using the original package for storage or
covering the product with a suitable cloth or enclosure to
protect it against dust.
:WLJPÄJ:HML[`>HYUPUNZ
for Pole Chain Saw
1. Only the pole chain saw operator should be in the
work area.
2. Do not use the pole chain saw to cut down trees.
3. Always use two hands when operating the pole chain
saw. Grip the pole chain saw securely with one hand on
the trigger and the other hand on the pole or the auxiliary
handle.
4. Before starting the pole chain saw, make sure that the
saw chain is not in contact with any object.
5. Do not allow the pole chain saw to make contact with
grounded objects such as pipes, fences, and metal posts.
6. Do not force the pole chain saw while cutting. Apply light
WYLZZ\YL0[^PSSWLYMVYTTVYLLɈLJ[P]LS`HUKZHMLS`PMP[PZ
used at the rate for which it was designed.
7. Use extreme caution when cutting a limb that is under
tension. When wood tension is released, the limb could
spring back and strike the operator, causing severe injury
or death.
8. During transport, hold the pole at its balance point,
with the guide bar and chain facing to the rear.
9. Do not cut small brush and saplings with the pole chain
saw. Small branches may catch in the chain and be
whipped towards the operator, which could pull the
VWLYH[VYVɈIHSHUJL
10. Never stand directly under the limb you are trimming.
Always position yourself outside the path of falling debris.
11. 2LLWHÄYTZ[LHK`WYLZZ\YLVU[OLWVSLJOHPUZH^^OPSL
cutting. Do not try to cut limbs larger in diameter than the
length of the guide bar.
12. Keep other people and pets away from the cutting end of
the pole chain saw and at a safe distance away from the
work area.
Kickback
mWARNING! Kickback may occur when the nose or tip
of the guide bar touches an object, or when the wood closes
in and pinches the saw chain in the cut.
AVOID CONTACTING THE GUIDE BAR TIP WITH ANY
OBJECT. In some cases, when the tip makes contact with an
object, it may cause a fast reverse reaction, kicking the guide
bar up and back towards the operator. Pinching the saw chain
along the top of the guide bar may also push the guide bar
rapidly back towards the operator. Either of these reactions
may cause you to lose control of the pole chain saw, which
could result in serious personal injury.
࠮ 2PJRIHJRZHML[`KL]PJLZVU[OPZWVSLJOHPUZH^PUJS\KL
a skip chain and a low kickback guide bar. These will
reduce, but not entirely prevent, kickbacks. Follow the
necessary precautions indicated in this operator's manual
to avoid kickbacks.
࠮ (S^H`Z\ZL[^VOHUKZ^OLUVWLYH[PUN[OLWVSLJOHPUZH^
one hand gripping the trigger and the other hand gripping
[OLWVSLVY[OLH\_PSPHY`OHUKSL<ZLHÄYTNYPW
;O\TIZHUKÄUNLYZT\Z[^YHWHYV\UK[OL[YPNNLYHUK
the pole/auxiliary handle.
࠮ 2LLWHSSN\HYKZPUWSHJLVU[OLWVSLJOHPUZH^4HRLZ\YL
they are in proper working order.
࠮ +VUV[V]LYYLHJOVYL_[LUKHYTZHIV]LZOV\SKLYOLPNO[
࠮ 2LLWZVSPKMVV[PUNHUKIHSHUJLH[HSS[PTLZ
࠮ 5L]LY[Y`J\[[PUN[OYV\NO[^VIYHUJOLZH[[OLZHTL[PTL
Only cut one at a time.
࠮ +VUV[I\Y`[OLN\PKLIHYUVZLVY[Y`[VJ\[I`IVYPUN[OL
guide bar nose into the wood.
࠮ >H[JOMVYZOPM[PUNVM^VVKVYV[OLYMVYJLZ[OH[TH`WPUJO
the chain.
࠮ <ZLL_[YLTLJH\[PVU^OLUYLLU[LYPUNHWYL]PV\ZJ\[
࠮ <ZL[OLSV^RPJRIHJRJOHPUHUKN\PKLIHYZ\WWSPLK^P[O
this pole chain saw. Only use genuine Snow Joe®+
Sun Joe®YLWSHJLTLU[WHY[ZKLZPNULKZWLJPÄJHSS`MVY\ZL
with this pole chain saw.
࠮ 5L]LY\ZLHK\SSVYSVVZLJOHPU2LLW[OLJOHPUZOHYWHUK
properly tensioned.
:WLJPÄJ:HML[`>HYUPUNZ
for Pole Hedge Trimmer
1. Remove any adjusting key or wrench before turning
the power tool on. A wrench or key left attached to the
rotating part of the power tool may result in personal
injury.
2. Remove any blade that has been damaged. Always make
sure that the blade is installed correctly and securely
fastened before each use. Failure to do so can cause
serious injury.
3. Never cut any material over 0.6 in. (1.5 cm) in diameter.

4
4. 4HPU[HPUHÄYTNYPWVU[OLOHUKSLHUK[OLWVSLH\_PSPHY`
handle while cutting with the blade. Keep the blade away
from body.
5. Use the pole hedge trimmer and accessories in
accordance with these instructions, taking into account
the working conditions the work to be performed. Use of
[OLWV^LY[VVSMVYVWLYH[PVUZKPɈLYLU[MYVTPU[LUKLK\ZL
could lead to a hazardous situation.
:WLJPÄJ:HML[`>HYUPUNZMVY
Grass Trimmer + Edger
mCAUTION! The safety guard is critical to the safety of
the operator and the safety of people standing within a safe
distance of the grass trimmer. The safety guard keeps the unit
in good working order and must always be in place during
operation. Failure to have the guard in place during operation
is dangerous and will void the warranty.
1. Keep away from the cutting line – It can seriously injure
the skin.
2. Do not try to stop the cutting device with your hands –
Always let it come to a stop by itself.
mCAUTION! The trimmer line spool will continue to rotate
after turning the trimmer OFF. Wait until the trimmer line spool
has completely stopped before making contact.
3. Only use the same type of line originally provided with
the tool.
4. Do not use the unit to cut grass that is not in contact with
the ground.
5. Keep guards in place and in working order.
6. Keep blades sharp.
7. Keep hands and feet away from cutting area.
8. Do not switch the grass trimmer + edger ON in enclosed
or poorly ventilated spaces or in the presence of
ÅHTTHISLHUKVYL_WSVZP]LZ\IZ[HUJLZZ\JOHZSPX\PKZ
gases, and powders.
9. The user of the grass trimmer + edger is responsible for
any damage sustained by third parties that has been
caused by the grass trimmer + edger within the
working area.
10. 6US`J\[K\YPUNIYVHKKH`SPNO[VY^P[OHKLX\H[L
HY[PÄJPHSSPNO[
11. Do not cross roads or gravel paths while the unit is
still running.
12. When the grass trimmer + edger is not in use, store it in a
dry place and out of the reach of children.
13. The grass trimmer + edger must be operated in a vertical
position, perpendicular to the ground.
14. Check regularly that all screws are properly secured.
15. Never use the grass trimmer + edger when it is raining or
when excessively moist and humid conditions are present.
Do not cut damp grass or leave the tool outside overnight.
16. If the grass trimmer + edger strikes a foreign object or
becomes entangled with it, stop the tool immediately.
Remove the battery, check for damage, and have any
damage repaired before proceeding with operation.
Do not operate the tool with a broken hub or spool.
Battery & Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT!(UHS`ZLZJVUÄYT[OH[PUJVYYLJ[\ZLHUKWVVY
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the power tool and cause it to
malfunction, which can lead to serious personal injury.
mWARNING! Do not use a battery pack or appliance that
PZKHTHNLKVYTVKPÄLK+HTHNLKVYTVKPÄLKIH[[LYPLZTH`
L_OPIP[\UWYLKPJ[HISLILOH]PVYYLZ\S[PUNPUÄYLL_WSVZPVUVYYPZR
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
/H]L`V\YIH[[LY`WHJRZLY]PJLKI`HX\HSPÄLKYLWHPYWLYZVU
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the
24V iON+ lithium-ion battery pack only in its designated
24V iON+ lithium-ion charger. Other types of chargers present
YPZRVMÄYLWLYZVUHSPUQ\Y`HUKKHTHNL+VUV[^PYLHIH[[LY`
pack to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery pack.
࠮Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
L_WSVZP]LH[TVZWOLYLZNHZLV\ZM\TLZK\Z[VYÅHTTHISL
materials) because sparks may be generated when inserting
VYYLTV]PUN[OLIH[[LY`WHJR^OPJOJV\SKSLHK[VHÄYL
࠮Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
]LU[PSH[PVU+VUV[HSSV^ZTVRPUNVYVWLUÅHTLZULHYH
charging battery pack. Vented gases may explode.

5
NOTE: The safe temperature range for the battery is 40°F
(4.5°C) to 105°F (40.5°C). Do not charge the battery outside
in freezing weather; charge it at room temperature.
࠮Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
࠮Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
^PYLKL_[LUZPVUJVYKWVZLZHYPZRVMÄYLHUKLSLJ[YPJZOVJR
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
࠮Charger 24VCHRG-AC is rated for 100 – 240 volt
AC only – The charger must be plugged into an
appropriate receptacle.
࠮Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk
VMÄYLLSLJ[YPJZOVJRVYWLYZVUHSPUQ\Y`
࠮Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
VYTHPU[LUHUJL+VUV[HSSV^^H[LY[VÅV^PU[V[OLJOHYNLY
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
࠮Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage.
Toxic fumes and materials are created when battery
packs are burned.
࠮Do not crush, drop or damage battery packs – Do not
use the battery pack or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
࠮Do not disassemble – Incorrect reassembly may pose
HZLYPV\ZYPZRVMLSLJ[YPJZOVJRÄYLVYL_WVZ\YL[V[V_PJ
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer
࠮Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth. If a
damaged battery pack leaks battery chemicals, use rubber
or neoprene gloves to safely dispose of it. If skin is exposed
[VIH[[LY`Å\PKZ^HZO[OLHɈLJ[LKHYLH^P[OZVHWHUK
water and rinse with vinegar. If eyes are exposed to battery
JOLTPJHSZPTTLKPH[LS`Å\ZO^P[O^H[LYMVY
20 minutes and seek medical attention. Remove and
dispose of contaminated clothing.
࠮Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
VMÄYLHUKZL]LYLWLYZVUHSPUQ\Y`
࠮Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. The battery pack supplied with your cordless power tool is
only partially charged. The battery pack has to be charged
JVTWSL[LS`ILMVYL`V\\ZL[OL[VVSMVY[OLÄYZ[[PTL
2. For optimum battery performance, avoid low discharge
J`JSLZI`JOHYNPUN[OLIH[[LY`WHJRMYLX\LU[S`
3. Store the battery pack in a cool place, ideally at
59°F (15°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
SVUNLYJHWHISLVMTLL[PUN[OLOPNOWV^LYYLX\PYLTLU[Z
needed for the proper operation of your multi-tool system,
and therefore pose a safety risk.
5. +VUV[[OYV^IH[[LY`WHJRZPU[VHUVWLUÄYLHZ[OPZWVZLZ
a risk of explosion.
6. +VUV[PNUP[L[OLIH[[LY`WHJRVYL_WVZLP[[VÄYL
7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers.
Place the battery pack in storage only after it has
been fully charged.
8. Protect batteries and the tool from overloads. Overloads
^PSSX\PJRS`YLZ\S[PUV]LYOLH[PUNHUKJLSSKHTHNLPUZPKL
the battery housing even if this overheating is not
apparent externally.
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than
3 feet (1 meter) or those that have been exposed to violent
shocks, even if the housing of the battery pack appears
to be undamaged. The battery cells inside the battery may
OH]LZ\ɈLYLKZLYPV\ZKHTHNL0UZ\JOPUZ[HUJLZ
please read the waste disposal information for proper
battery disposal.

6
10. 0M[OLIH[[LY`WHJRZ\ɈLYZV]LYSVHKPUNHUKV]LYOLH[PUN
[OLPU[LNYH[LKWYV[LJ[P]LJ\[VɈ^PSSZ^P[JOVɈ[OL
LX\PWTLU[MVYZHML[`YLHZVUZ
IMPORTANT! Do not press the ON/OFF switch any more
PM[OLWYV[LJ[P]LJ\[VɈOHZILLUHJ[P]H[LK;OPZTH`
damage the battery pack.
11. Use only original battery packs. The use of other batteries
WVZLZHÄYLYPZRHUKTH`YLZ\S[PUPUQ\YPLZVYHUL_WSVZPVU
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
WSH[L5L]LYJVUULJ[P[[VHKPɈLYLU[THPUZ]VS[HNL
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
I`HX\HSPÄLK[LJOUPJPHUH[HUH\[OVYPaLK:UV^1VL®+
Sun Joe®dealer
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
NYV\UKLKHWWSPHUJLZ<UTVKPÄLKWS\NZHUKTH[JOPUN
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s) and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before inserting it into the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
KPZJOHYNLKIH[[LYPLZ-YLX\LU[PUZLY[PVUVMHJOHYNLKVY
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge batteries if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
OHZHSYLHK`Z\ɈLYLKKHUNLYV\ZKHTHNLL_OH\Z[P]L
discharge).
9. Charging batteries at a temperature below 50°F (10°C) will
JH\ZLJOLTPJHSKHTHNL[V[OLJLSSZHUKTH`JH\ZLHÄYL
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
Z\ɈLYLKKHUNLYV\ZKHTHNL
11. +VUV[\ZLIH[[LYPLZ[OH[OH]LZ\ɈLYLKJ\Y]H[\YLVY
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).
12. Never fully discharge the battery pack
(maximum recommended depth of discharge is 80%).
A complete discharge of the battery pack will lead to
premature aging of the battery cells.
7YV[LJ[PVUMYVTLU]PYVUTLU[HSPUÅ\LUJLZ
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
]HWVYZHUKÅHTTHISLSPX\PKZ
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 40°F – 105°F
(4.5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 104°F (40°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 40°F – 105°F
(4.5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 50°F – 68°F
(10°F – 20°C). Protect the battery pack, charger and
cordless tool from humidity and direct sunlight.
Only place fully charged batteries in storage (charged to
at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than
60 minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.

7
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
WARNING! Do not expose the unit
to rain or wet conditions. Keep dry.
Symbols SymbolsDescriptions Descriptions
Indoor use only. Only use battery
charger indoors.
50 ft
(15 m) WARNING! SHOCK HAZARD –
Keep at least 50 ft (15 m) away
from power lines. Do not overreach.
Keep proper footing and balance at
all times.
DANGER! ROTATING BLADES
–Keep hands and feet away from
openings while the saw is running.
Thrown objects and rotating blades
can cause severe injury.
Keep bystanders a minimum
distance of 50 ft (15 m) away from
the work area.
Wear protective gloves when using
the machine and handling debris.
DANGER! Beware of thrown
objects to bystanders. Keep
bystanders at least 15 m (50 ft)
away from the machine.
Wear foot protection when using
the machine and handling debris.

8
Know Your Cordless Lawn + Garden Multi-tool System
Read the owner’s manual and safety instructions carefully before operating the cordless multi-tool system. Compare the
illustration below to the cordless multi-tool system in order to familiarize yourself with the location of the various controls and
adjustments. Save this manual for future reference.
R
R
24
V
O
LT
1. Hedge trimmer blade cover
2. Hedge trimmer head
3. Lock tab
4. Rotating button
5. Hedge trimmer blade
6. Edging wheel
7. Grass trimmer + edger head
8. Converting switch
9. Telescoping pole
10. Soft grip
11. Auxiliary handle
12. Auxiliary Handle lock knob
13. Handle
14. Safety lock switch
15. 6U6ɈB;YPNNLYDZ^P[JO
16. Battery compartment
17. Auxiliary handle loop
18. Telescoping lock
19. Assembly lock
20. Safety guard
21. Trimmer line
22. Flower guard
23. Spool
24. Chain bar cover
25. Oil tank cap
26. Chain saw head
27. Chain/sprocket end cover
28. Chain/sprocket end cover knob
29. Chain tensioner ring
30. 8-inch cutting chain
31. 8-inch guide bar
32. Oil level window
33. 24V iON+ lithium-ion battery
(24VBAT-LTE) featuring exclusive
EcoSharp®technology
34. Push lock button
35. Battery indicators
36. Push button for battery indicator
37. Charge socket
38. 24V iON+ lithium-ion charger
(24VCHRG-AC)
39. Charger plug
1
2
34
5
6
79
1014
15
13
16 18 19
Bottom of the grass
trimmer head
21
22
24
25
27
20
34
Back of the chain saw head
23
26
3
4
28 29 30 31
32
33
35
363738
39
8
11
12
34
17

9
Technical Data
Battery Voltage*..........................24 V D.C.
Battery Capacity.........................2.0 Ah
Charging Time Max ....................1 hr 20 min
Telescoping Pole Length ............3.7 ft to 5.3 ft
....................................................(1.1 m to 1.6 m)
Auxiliary Handle Angles..............-45° | 0° | 45°
Charger Input..............................100 – 240 V 50/60HZ
Charger Output...........................26 V DC 1.5 A
Pole Chain Saw
Motor..........................................350 W
Bar/Chain Length ....................... 8 inch (20.3 cm)
Cutting Thickness.......................4H_!PUJO JT
....................................................Recommended: 6.5 in. (16.5 cm)
Oil Tank Capacity .......................ÅVaTS
Overhead Reach Max.................13 ft (4 m)
Head Angles ...............................0° to 30°
Battery Run Time Max................40 mins
Weight (with Battery Installed) ....7.7 lbs (3.5 kg)
Pole Hedge Trimmer
Motor..........................................250 W
Blade Length ..............................17.7 inch (45 cm)
Cutting Diameter ........................ 0.6 inch (1.5 cm)
Head Angles ...............................-45° to 90°
Battery Run Time Max................55 mins
Weight (with Battery Installed) ....7.7 lbs (3.5 kg)
Grass Trimmer + Edger
Motor..........................................200 W
Cutting Diameter ........................ 10 inch (25 cm)
Spool Length ..............................16.5 ft (5 m)
Spool Advance ...........................Auto-feed
Line diameter..............................0.055 inch (1.4 mm)
Head Angles ...............................0° to 60°
Battery Run Time Max................50 mins
Weight (with Battery Installed) ....6.2 lbs (2.8 kg)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
࠮ ;LSLZJVWPUNWVSL^P[Oauxiliary handle
࠮Chain saw head with chain and bar pre-mounted
࠮ *OHPUZH^IHYZOLH[O
࠮Hex key wrench
࠮Hedge trimmer head with blade
࠮Hedge trimmer blade sheath
࠮Grass trimmer + edger head
࠮Grass trimmer + edger safety guard
࠮ =P65SP[OP\TPVUIH[[LY`
࠮ =P65SP[OP\TPVUJOHYNLY
࠮Manuals with registration card
1. Carefully remove the multi-tool system and check to see
that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
KHTHNLVJJ\YYLKK\YPUNZOPWWPUN0M`V\ÄUKKHTHNLKVY
missing parts, DO NOT return the unit to the store.
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
multi-tool system. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT!;OLLX\PWTLU[HUKWHJRHNPUNTH[LYPHSHYL
not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
Z\ɈVJH[PVUYPZR
Battery Pack Operation
;OLLX\PWTLU[PZWV^LYLKI`HSP[OP\TPVUIH[[LY`;OLIH[[LY`
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
;OLIH[[LY`WHJRPZLX\PWWLK^P[OHW\ZOI\[[VUMVYJOLJRPUN
[OLJOHYNLSL]LS:PTWS`WYLZZ[OLW\ZOI\[[VU[VYLHKVɈ[OL
IH[[LY`JOHYNLSL]LSMYVT[OL3,+ZVM[OLIH[[LY`PUKPJH[VY!
࠮ (SSSL]LSTVUP[VYPUN3,+ZHYLSP[!)H[[LY`JOHYNLSL]LS
is high.
࠮ SL]LSTVUP[VYPUN3,+ZHYLSP[!)H[[LY`JOHYNLSL]LSPZ
decreasing. Stop work as soon as possible.
࠮ SL]LSTVUP[VYPUN3,+PZSP[!)H[[LY`PZÅH[:[VW^VYR
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
Battery + Charger

10
NOTE: If the charge level button does not appear to be
working, insert the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
mWARNING! Charge only 24V iON+ lithium-ion battery
packs with its compatible 24V iON+ lithium-ion charger. Other
types of batteries may cause personal injury and damage.
;VYLK\JL[OLYPZRVMLSLJ[YPJZOVJRKVUV[HSSV^^H[LY[VÅV^
into the charger's AC/DC plug.
When to Charge the iON+ 24VBAT-LTE
Lithium-iON Battery
NOTE: The iON+ 24VBAT-LTE lithium-ion battery packs do
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery pack before inserting the charger plug.
࠮ <ZL[OLIH[[LY`PUKPJH[VYSPNO[Z[VKL[LYTPUL^OLU[VJOHYNL
your iON+ 24VBAT-LTE lithium-ion battery pack.
࠮ @V\JHU[VWVɈ`V\YIH[[LY`WHJRZJOHYNLILMVYLZ[HY[PUN
a big job or after a long day of use.
Charging the Battery
1. Push the push lock button on the battery to pull the
battery pack out from the battery compartment (Fig. 1).
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, plug the
charger adaptor into an appropriate AC power outlet.
Connect the charger plug into the charge socket of the
battery to start charging (Fig. 2).
3. The battery will take approximately 80 minutes to charge.
The battery indicator LEDs will twinkle and illuminate one
by one during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
[OLV\[SL[ÄYZ[[OLUKPZJVUULJ[[OLJOHYNLYMYVT[OLIH[[LY`
mWARNING! This charger does not automatically
[\YUVɈ^OLU[OLIH[[LY`PZM\SS`JOHYNLKPlease take care
not to leave the battery plugged into the charger. Switch
VɈVY\UWS\N[OLJOHYNLYH[[OLTHPUZ^OLUJOHYNPUNPZ
complete.
4. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
`V\UV[PJLHKYVWPU[OLLX\PWTLU[ZWV^LY
Charge level button
The battery is at 30% capacity
HUKYLX\PYLZJOHYNPUN
The battery is at 60% capacity
HUKYLX\PYLZJOHYNPUNZVVU
The battery is at full capacity
Light IndicatorsLights
R
Fig. 1
Push button
Fig. 2
Battery
indicators

11
IMPORTANT! Never allow the battery pack to become
fully discharged as this will cause irreversible damage to
the battery.
Assembly
mDANGER! Never start the motor before installing the
guide bar, chain, and chain/sprocket end cover. Without all
[OLZLWHY[ZPUWSHJL[OLJS\[JOJHUÅ`VɈVYL_WSVKLL_WVZPUN
the user to potentially serious injuries.
Installing/Replacing Guide Bar And
Cutting Chain
;VVSZHUKZ\WWSPLZYLX\PYLK!
࠮ /L_RL`^YLUJOWYV]PKLK
࠮ /LH]`K\[`^VYRNSV]LZ
NOTE: When replacing the guide bar and chain, use only
identical replacement parts. Make sure the pole chain saw
is disconnected with the battery before proceeding with
installation.
1. Remove the hex bolt by screwing it counterclockwise with
the hex key wrench (Fig. 3).
2. Screw the chain/sprocket end cover knob
counterclockwise to release chain/sprocket end cover
(Figs. 4 – 5).
3. Remove the bar and chain from the mounting surface
(Fig. 6).
4. Remove the old chain from the bar.
5. Lay out the new saw chain in a loop and straighten any
kinks. THE SHARP SIDE OF THE TEETH MUST FACE
AWAY FROM YOU IN THE DIRECTION OF THE CHAIN
ROTATION INDICATED ON THE GUIDE BAR .
If the teeth face backwards, turn the loop over (Fig. 7).
6. Starting at the tip, mount the chain drive links into the
bar groove, leaving a loop at the back of the bar. The
JOHPU^PSSSVVZLS`Ä[\U[PSP[PZWSHJLKVU[OLZWYVJRL[
(Figs. 8 – 9).
Pole Chain Saw
Fig. 3
Chain/sprocket
end cover Hex bolt
Hex key wrench
Fig. 4
Chain/sprocket
end cover Chain/sprocket
end cover knob
Fig. 5
Chain/sprocket
end cover
Fig. 6
Cutting chain
Guide bar
Fig. 7
Chain rotation
Sharp cutting edge
Chain drive link

12
NOTE: Make certain of the direction of the chain .
If the chain is mounted backwards, the saw will vibrate
abnormally and will not cut.
7. Hold the chain in position on the bar and place the loop
around the sprocket. -P[[OLIHYÅ\ZOHNHPUZ[[OLTV\U[PUN
surface so that the bar studs are in the long slot of the bar
and the adjusting pin is in the chain tension pin hole
(Fig. 10).
8. Replace the chain/sprocket end cover by positioning the
cover onto the saw head. Tighten the end cover knob,
but leave the bar free to move for tension adjustment.
Put back the hex bolt by screwing it clockwise with the
hex key wrench.
9. Remove all slack from the chain by turning the chain
tensioner ring clockwise until the chain seats snugly
against the bar with the drive links in the bar groove
(Fig. 11).
NOTE: The chain is correctly tensioned when there is no
sag on the underside of the guide bar; the chain is snug,
but can be rotated by hand without binding. For more
information on chain tensioning, see the Maintenance +
Care section beginning on pg. 17.
Connecting to the Telescoping Pole
1. Open the assembly lock on the telescoping pole, and
push the chain saw head into the opening on the end of
the pole (Fig. 12).
2. When the lock tabs snap in, lock back the assembly lock,
the pole chain saw will be ready to use (Fig. 13).
Fig. 8
Fig. 9
Loop
Fig. 10
Sprocket
Adjusting pin
Chain tension
pin hole
Fig. 11
Chain/sprocket
end cover Chain tensioner
ring
Fig. 12
Telescoping pole
Assembly lock
Chain saw head
R
Fig. 13
Lock tab
Assembly lock

13
3. ;VYLTV]L[OLJOHPUZH^OLHKYLSLHZL[OL6U6ɈZ^P[JO
and remove the battery. Unlock the assembly lock.
Push the lock tabs on both sides, and pull the chain saw
head out (Fig. 13).
Operation
Starting and Stopping
1. Slide the battery into the battery compartment until it
clicks to lock into position (Fig. 14).
2. To turn the pole chain saw ON, push and hold the safety
lock switch (located on the handle) forward with your
[O\TIHUK[OLUZX\LLaL[OL6U6ɈZ^P[JO^P[O`V\Y
ÄUNLYZ6UJL[OL[VVSPZY\UUPUN`V\JHUYLSLHZL[OL
safety lock switch (Fig. 15).
3. To turn the tool OFF, release the 6U6ɈZ^P[JO-PN.
Adjusting the Telescoping Pole
;OPZTHJOPULPZLX\PWWLK^P[OH[LSLZJVWPUNWVSL^OPJO
provides up to 7.2 ft (2.2 m) of overhead reach. To adjust the
telescoping pole, follow the instructions below.
1. Disconnect the saw from the power supply by removing
the battery from the compartment.
2. Unclip the telescoping lock to release the pole. Extend the
pole to the desired length (Fig. 16).
NOTE: Push poles toward each other to shorten the pole
or pull them away from each other to lengthen the pole.
Only extend the pole to the TPUPT\TSLUN[OYLX\PYLK[V
reach the limb.
3. Lock the pole in position by closing the telescoping lock
(Fig. 17), and ensure that the pole is secured.
mWARNING! Failure to lock the telescoping lock as
directed could result in personal injury or property damage.
Adjusting the Multi-Angle Head
;OLWVSLJOHPUZH^OLHKJHUILYV[H[LKMVYKPɈLYLU[J\[[PUN
angles for 0º, 15º, and 30º (Fig. 18). Follow the below
instructions to adjust angles.
1. Rotate the chain saw head to the desired cutting angle
while pressing the rotating buttons located on both sides
simultaneously (Fig. 19).
Fig. 14
Battery
Fig. 15
6U6ɈZ^P[JO
Safety lock
switch
Fig. 16
Pull Pull
Telescoping lock
Fig. 17
Telescoping lock
Fig. 18
0º
15º
30º

14
2. Release the buttons when the chain saw head is set to the
desired angle.
NOTE: Failure to properly secure the chain saw head may
result in personal injury and/or property damage.
mWARNING! Always ensure the chain saw head is
securely locked! Do not attempt to use the pole chain saw with
the head in any other position or unlocked!
Adjusting the Auxiliary Handle
;OLJOHPUZH^PZLX\PWWLK^P[OHUH\_PSPHY`OHUKSL[OH[JHUIL
adjusted and removed. Follow the instruction below to operate
the auxiliary handle
mWARNING! Make sure the knob, bolt, and the screws
HYLÄ_LKPU[VWSHJL-HPS\YL[VSVJRHU`VM[OLTHZKPYLJ[LK
could result in personal injury or property damage.
To Remove the Auxiliary Handle
1. Disconnect the saw from the power supply by removing
the battery from the compartment.
2. Unscrew the auxiliary handle lock knob and remove it and
the bolt, then the auxiliary handle can be pulled out
(Fig. 20).
3. Re-assemble the auxiliary handle lock knob and the bolt
on (Fig. 21).
To Adjust the Position of the Auxiliary Handle
1. Disconnect the saw from the power supply by removing
the battery from the compartment.
2. Remove the auxiliary handle lock knob, the bolt, and the
auxiliary handle. Use a screw driver to remove the two
ZJYL^Z[OH[\ZLK[VÄ_[OLH\_PSPHY`OHUKSLSVVWZ
Remove the loops from the pole (Fig. 22).
3. Re-assemble the auxiliary handle loop on the desired spot
on the pole by using the two screws, and put back the
auxiliary handle, the auxiliary handle lock knob and the
bolt (Fig. 22).
Fig. 19
Rotating button
Front Side
Back Side
Rotating button
R
Fig. 20 Auxiliary handle
Auxiliary handle
lock knob
Bolt
R
Fig. 21
R
Fig. 22 Auxiliary handle
Auxiliary
handle
lock knob
Bolt
Auxiliary
handle loop
Screws
Auxiliary
handle loop

15
To Adjust the Angle of the Auxiliary Handle
1. :[VW[OLZH^I`YLSLHZPUN[OL6U6ɈZ^P[JO
2. The auxiliary handle can be adjusted in -45°, 0°, 45°.
Rotate the auxiliary handle lock knob to unlock the handle,
and then rotate the handle to the desired angle (Fig. 23).
3. Rotate the auxiliary handle lock knob back to lock the
handle in position.
Cutting Tips for Pole Chain Saw
mCAUTION!
࠮Before starting the saw, remove the oil tank cap and add
bar & chain oil to the top of the oil level window (Fig. 24).
One minute of use will consume approximately ÅVa
TSVMVPS9LÄSS^OLU[OLVPSSL]LSKYVWZ[VVMH[HUR
NOTE: Your pole chain saw headPZLX\PWWLK^P[OHU
automatic oil pump for bar and chain oiling. You must add
bar and chain oil or your pole chain saw will not function.
mWARNING! Be sure that the chain is not in contact with
any object when you start the motor.
mWARNING! Keep hands away from chain. Keep hands
on handles. Do not overreach.
(NVVKÄYTNYPWVU[OL[VVS\ZPUNIV[OOHUKZ^PSSOLSW`V\
maintain control. Place one hand on the soft grip or the
auxiliary handle, and the other hand on the handle with your
[O\TIZHUKÄUNLYZLUJPYJSPUN[OLWVSLHUKOHUKSL(ÄYTNYPW
combined with proper positioning of the handle against your
body will help you maintain control of the saw. Do not let go of
the saw while it is in operation.
mCAUTION! The chain will continue to run for several
ZLJVUKZHM[LY[\YUPUNVɈ[OL[VVS
Do not use the pole chain saw under wet conditions.
Use extreme caution when cutting small brush, saplings,
or limbs under tension because slender and tense material
TH`JH[JO[OLZH^HUKIL^OPWWLK[V^HYK`V\W\SS`V\VɈ
balance, or spring back.
Do not use the pole chain saw to cut vines and/or small
underbrush.
Prior to each cutting session, run through the daily checklist
(see pg. 19).
mWARNING! Do not cut trees near electrical wires.
mWARNING! Failure to lubricate the chain will cause
KHTHNL[V[OLIHYHUKJOHPU<ZLVUS`HNVVKX\HSP[`IHY
HUKJOHPUVPSKLZPNULKZWLJPÄJHSS`MVY\ZL^P[OJOHPUZH^Z
6ULTPU\[LVM\ZL^PSSJVUZ\TLHWWYV_PTH[LS`ÅVa
(4 ml) of oil.
NOTE: It is normal for oil to seep from the saw when not in
use. To prevent seepage, empty the oil tank after each use.
When storing the unit for a long period of time (3 months or
longer), be sure the chain is lightly lubricated; this will prevent
rust on the chain and bar sprocket.
mWARNING! Kickback may occur when the moving
chain contacts an object at the upper portion of the tip of
the guide bar or when the wood closes in and pinches the
chain saw in the cut (Fig. 25). Contact at the upper portion
of the tip of the guide bar can cause the chain to dig into
the object and stop the chain for an instant. The result is a
lightning-fast reverse reaction, which kicks the guide bar up
and back toward the operator. If the chain saw is pinched
along the top of the guide bar, the guide bar can be driven
rapidly back toward the operator. Either of these reactions
R
Fig. 23
Auxiliary
handle lock
knob
Fig. 24 Oil tank cap
Oil level
window
KICKBACK DANGER ZONE
Fig. 25

16
can cause loss of saw control, which can throw the operator
VɈIHSHUJLHUKYLZ\S[PUZLYPV\ZPUQ\Y`+VUV[YLS`L_JS\ZP]LS`
upon the safety devices built into the saw. As a user, you
should take several precautions to keep your cutting jobs free
from accident or injury.
Proper Cutting Stance
࠮Balance your weight with both feet on solid ground.
࠮Your body should always be to the left of the chain line.
࠮The most typical cutting application is to position the
\UP[H[HUHUNSLVMVYSLZZKLWLUKPUNVU[OLZWLJPÄJ
situation (Fig. 26). As the angle of the pole chain saw shaft
to the NYV\UKPUJYLHZLZ[OLKPɉJ\S[`VMTHRPUN[OLÄYZ[
cut (from the underside of limb) increases.
Basic Cutting Procedure
This unit with the chain saw head is designed for trimming
small branches and limbs up to recommended 6.5 in.
(16.5 cm), not to exceed a Max. cut of 7.5 in. (19 cm) in
diameter depending on type of wood. Practice cutting a few
ZTHSSSPTIZ\ZPUN[OLMVSSV^PUN[LJOUPX\L[VNL[[OL¸MLLS¹VM
using the saw before you begin a major sawing operation.
࠮Take the proper stance in front of the tree with the
saw OFF (Fig. 26).
࠮Switch on the pole chain saw and let the chain accelerate
to full speed before entering the cut.
࠮ 2LLW[OLZH^Y\UUPUN[OLLU[PYL[PTL`V\HYLJ\[[PUN"
maintain a steady speed.
࠮Allow the chain to cut for you; exert only light downward
pressure. If you force the cut, damage to the bar, chain, or
unit can result.
࠮PUSH and PULL – This reaction force is always opposite
to the direction the chain is moving when it is in contact
with the wood. Thus, the operator must be ready to
control the PULL when cutting on the bottom edge of the
bar, and PUSH when cutting along the top edge.
࠮Do not put pressure on the saw at the end of the cut.
Pruning
Pruning is the process of trimming limbs from a live tree.
࠮Remove long branches in several stages.
࠮ *\[SV^LYIYHUJOLZÄYZ[[VHSSV^[OL[VWIYHUJOLZTVYL
room to fall.
࠮ >OLUWY\UPUN[YLLZP[PZPTWVY[HU[UV[[VTHRL[OL
ÄUPZOPUNJ\[UL_[[V[OLTHPUSPTIVY[Y\UR\U[PS`V\OH]L
J\[VɈ[OLMHY[OLZ[S`PUNSPTI;OPZ^PSSYLK\JL[OL^LPNO[
and prevent stripping the bark from the main member.
࠮ <UKLYJ\[[OLIYHUJO[OYV\NOMVY`V\YÄYZ[J\[
@V\YZLJVUKJ\[ZOV\SKV]LYJ\[[VKYVW[OLIYHUJOVɈ
(Fig. 27). Be prepared to balance the weight of the pole
chain saw when the limb falls.
R
Fig. 26
60º MAXIMUM
Fig. 27
Load
Second Cut
First Cut
1/3 Diameter
Finishing Cut

17
࠮ 5V^THRL`V\YÄUPZOPUNJ\[MYVT[OL[VWZPKLVM[OL
branch smoothly and neatly against the main member so
the bark will grow back to seal the wound.
࠮Release the 6U6ɈZ^P[JO as soon as the cut is
completed. Failure to follow proper cutting procedures will
result in the bar and chain binding and becoming pinched
or trapped in the limb.
Limbing
Limbing is the process of removing branches from a fallen tree.
࠮You should cut limbs one at a time. Remove the cut limbs
from the work area often to help keep the work area clean
and safe.
࠮Cut branches under tension from the bottom up to avoid
binding the bar and chain.
࠮Keep the tree between you and the pole chain saw while
limbing. Cut from the side of the tree opposite the branch
you are cutting.
If the Saw Becomes Pinched or Trapped
1. >HP[MVY[OLISHKL[VZ[VW^HP[Ä]LTPU\[LZMVY[OLZH^[V
cool, remove the battery, and wear gloves to protect your
hands from the chain teeth.
2. If you can reach the limb from the ground, lift the limb
while holding the saw. This should release the “pinch” and
free the saw.
3. If the saw is still trapped, call a professional for
assistance.
Maintenance + Care
mWARNING! Always remove the battery before
performing any adjustments, maintenance, or repairs to your
cordless pole chain saw.
࠮Use protective gloves when handling the bar and chain.
࠮ 2LLW[OLIHYLUJHZLKPUP[ZZOLH[OL_JLW[^OLU^VYRPUN
directly on the bar or the chain.
࠮Never dispose of oils or other polluting materials in
unauthorized places.
Chain Tension
Check the chain tension before using the saw when the chain
is cold. The correct tension of a cold chain is when there is no
slack on the underside of the guide bar; the chain is snug, but
you can rotate it by hand without binding.
During normal saw operation, the temperature of the chain
will increase. The drive links of a correctly tensioned warm
chain will hang approximately 0.050 in. (1.25 mm) out of the
bar groove (Fig. 28). Be aware that a chain tensioned while
warm, may be too tight upon cooling. Check the “cold tension”
before next use. The chain must be re-tensioned whenever the
ÅH[ZVU[OLKYP]LSPURZOHUNV\[VM[OLIHYNYVV]L-PN
NOTE: A new chain tends to stretch. Check the chain tension
MYLX\LU[S`HUKYL[LUZPVUHZULLKLK
Nuts and Screws
Periodically check that all the nuts and screws are tightened
securely. Check that the telescoping lock and assembly lock
are intact and in proper working order.
Chain Sharpening
mWARNING! To ensure that the saw works safely and
LɉJPLU[S`P[PZLZZLU[PHS[OH[[OLJ\[[PUNJVTWVULU[ZHYL
well-sharpened. It is highly recommended to replace the
chain once it loses its ability to cut cleanly and safely.
It is possible, however, to sharpen the existing chain if the
sharpening is carefully performed. Any work on the chain
HUKIHYYLX\PYLZZWLJPÄJL_WLYPLUJLHUKZWLJPHS[VVSZ
For safety purposes, we recommend you contact an
authorized Snow Joe®+ Sun Joe®dealer
:OHYWLUPUNPZULJLZZHY`^OLU!
࠮;OLZH^K\Z[SVVRZSPRLK\Z["
࠮CuttingILJVTLZTVYLKPɉJ\S[;
࠮The cut is not straight;
࠮Vibrations increase.
Fig. 28 Properly Adjusted Warm Chain
Approximately 0.050 in. (1.25 mm)
Flats are
visible here
Flats are not
visible here
Chain Needs Tensioning

An authorized service center will sharpen the chain using the
right tools to ensure minimum removal of material and even
sharpness on all the cutting edges.
If you sharpen the chain yourself, use special round-section
ÄSLZ^P[O[OLYPNO[KPHTL[LYKLWLUKPUNVU[OL[`WLVMJOHPU
(see “Chain Maintenance Table” on pg. 19). You need a certain
amount of skill and experience to avoid damaging the cutting
edges.
:OHYWLU[OLJOHPUHZMVSSV^Z-PN !
࠮ :LJ\YL[OLIHYÄYTS`^P[O[OLJOHPUTV\U[LK
in a suitable vise.
࠮Tighten the chain if it is loose.
࠮ 4V\U[[OLÄSLPU[OLN\PKLHUK[OLUPUZLY[P[PU[OL[VV[O
at a constant angle from the cutting edge.
࠮Sharpen in a forward motion a few times and repeat this
on all the cutting edges facing the same way (right or left).
࠮ ;VTV]L[OLJOHPUMVY^HYK\ZLHZJYL^KYP]LY
࠮Turn the bar over in the vise and repeat on all the other
cutting edges.
࠮Check that the depth limiter tooth does not stick out
farther than the inspection toolHUKÄSLHU`WYVQLJ[PUN
WHY[Z^P[OHÅH[ÄSLYV\UKPUNVɈ[OLLKNLZ-PN 25).
࠮ (M[LYZOHYWLUPUNYLTV]LHSS[YHJLZVMÄSPUNHUKK\Z[
and lubricate the chain in an oil bath. Replace the chain
^OLUL]LY!
– The length of the cutting edges decreases to
5 mm or less;
– There is too much play between the links and the rivets.
Guide Bar Maintenance
When the guide bar shows signs of wear, turn it over on the
saw to distribute the wear for maximum bar life. Feathering or
burring of the bar rails is a normal process of bar wear. You
ZOV\SKZTVV[OZ\JOMH\S[Z^P[OHÄSLHZZVVUHZ[OL`VJJ\Y
9LWSHJLHIHY^P[OHU`VM[OLMVSSV^PUNMH\S[Z!
࠮ ^LHYPUZPKL[OLIHYYHPSZWLYTP[[PUN[OLJOHPU[VSH`V]LY
sideways
࠮ ILU[N\PKLIHY
࠮ JYHJRLKVYIYVRLUYHPSZ
࠮ ZWYLHKYHPSZ
Turn the saw over, check the underside of the guide bar, and
make sure that the lubrication holes and chain groove are free
from impurities.
Chain Sprocket
Regularly check the condition of the sprocket and replace it
when wear exceeds 0.5 mm (Fig. 30).
Do not mount a new chain with a worn sprocket or vice-versa.
Fig. 29
Inspection tool
Depth limiter tooth
Cutting edge
Depth
limiter
tooth
< 0.5 mm
Fig. 30
18

Troubleshooting
Troubleshooting Tips
4VZ[KPMMPJ\S[PLZHYLLHZ`[VMP_*VUZ\S[[OL[YV\ISLZOVV[PUN
table for common problems and their solutions.
mWARNING! Always remove the battery before
performing any adjustments, maintenance, or repairs to your
cordless chain saw.
Troubleshooting Table
Daily Checklist, Cleaning
and Storage
Daily Checklist
To help maintain your pole chain saw for optimum
performance, we recommend you complete this checklist prior
to each work session.
mWARNING! Do not insert the battery until you have
completed all of the daily checks.
࠮ 0UZWLJ[MVYHU`]PZPISLKHTHNL[V[OLJOHPUN\PKLIHYVY
motor housing.
࠮ 0UZWLJ[[OLVPSWVY[HUKN\PKLIHYYHPSZHUKJSLHU[OLT[V
remove any debris.
࠮Check the chain tension.
࠮Check the chain teeth for sharpness.
࠮ *OLJR[OLIHYHUKJOHPUVPSSL]LS"ÄSS^P[OVUS`UL^JOHPU
VPSZWLJPÄJHSS`MVYT\SH[LKMVYJOHPUZH^Z
NOTE: If you notice anything unusual, such as a vibration or an
odd sound, shut the saw OFF immediately. Remove the battery
and check the saw for any damage.
0M`V\JHUUV[ÄUK[OLJH\ZLVM[OLWYVISLTVYHYL\UJLY[HPU
what to do, then have the saw inspected by an authorized
Snow Joe®+ Sun Joe®dealer
mCAUTION!
࠮ 9LTV]L[OLIH[[LY`HUK^HP[H[SLHZ[Ä]LTPU\[LZMVY[OL
saw to cool before servicing or storing your unit.
࠮If you drop the saw, carefully inspect it for damage. If the
guide bar is bent, the housing is cracked, the handle is
IYVRLUVYPM`V\ZLLHU`V[OLYJVUKP[PVU[OH[TH`HɈLJ[
the saw’s operation, DO NOT USE the tool. Instead, have
it serviced at an authorized Snow Joe®+ Sun Joe®
dealer
Problems Corrective Action
The saw
motor fails
to start
࠮Check that you have inserted the battery properly
and the battery has enough power to work.
࠮Make sure that you fully depress, push forward
HUKOVSK[OLZHML[`SVJRZ^P[JOILMVYLZX\LLaPUN
the ON/OFF trigger switch.
࠮The chain is too tight; re-tension.
࠮The chain tension is too tight; re-tension.
࠮;OLJOHPUVPS[HURPZLTW[`"YLÄSS
࠮The lubrication holes are plugged; clean them out.
࠮The chain tension is too tight; re-tension.
࠮The guide bar or chain is damaged; inspect
and replace the damaged part.
The saw
runs, but
the chain
speed is
low
Bar and
chain
running
hot and
smoking
The saw
motor
runs, but
the chain
is not
turning
19
Chain Maintenance Table
33
3/8
inches mm
Drive Links Chain Pitch Chain Gauge File Diameter
inches mm inches mm
9.5 0.050 1.3 45/32

Assembly
mWARNING! Do not insert battery until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
Fitting the Safety Guard
mWARNING! The guard must be properly installed.
The guard provides the operator and other bystanders with
some protection from thrown objects.
1. Align the safety guard with the grass trimmer + edger
head as shown (Fig. 31).
2. Firmly press the safety guard into place until it clicks into
the position (Fig. 32).
Connecting to the Telescoping Pole
1. Open the assembly lock on the telescoping pole, and
push the grass trimmer + edger head into the opening on
the end of the pole (Fig. 33).
2. When the lock tabs snap in, lock back the assembly lock,
and the grass trimmer + edger will be ready to use
(Fig. 34).
3. To remove the grass trimmer + edger head, release
[OL6U6ɈZ^P[JOHUKYLTV]L[OLIH[[LY`<USVJR[OL
assembly lock, push the lock tabs on both sides, and pull
the grass trimmer + edger head out (Fig. 34).
Grass Trimmer + Edger
Fig. 31
Safety Guard
Grass trimmer
+ edger head
Fig. 32
Safety Guard
Grass trimmer
+ edger head
Telescoping pole
Fig. 33 Grass trimmer
+ edger head
Assembly lock
Fig. 34
Lock tab
Assembly lock
20
