SNOWJOE Sunjoy L-GZ724PST-BPK-1 User manual

1
Assembly Instructions
Item#: L-GZ724PST-BPK-1
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble
or install the product.
WARNING
Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area.
Keep all flame and heat sources away from the tent fabric. This tent is made with
fabric that meets CPAI-84 specification for flame resistance. It is not fireproof. The
fabric will burn if left in continuous contact with any flame sources. The application
of any foreign substance to the tent fabric may render the flame-resistant properties
ineffective.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts
with package contents list. If any part ismissing or damaged, do not attempt to assemble
the product.

2
Estimated Assembly Time: 10 minutes
No Tools Required for Assembly.
QTY LINE DRAWING OF PART
1
1
DESCRIPTION
Small Canopy
Large Canopy
PART #
B
A
Parts List
Undo the fastener straps on the valance of the existing gazebo (sold separately) to
release the existing large canopy from the beam ends.
Fig.1:
Important: For technical assistance on assembly or replacement parts. Please
call Sunjoy Industries at 1(866) 578-6569 from 8:30 AM to 4:30 PM EST Monday
to Friday or fax the replacement part form which is in the box to (740)-283-3549
or Email [email protected] for assistance. Attention! Please
don't return the products to Lowe's store!

3
Remove the existing small canopy from the top.
Fig.2:
Remove the existing large canopy from the top.
Fig.3:
Attach the new large canopy (B) to the top, but do not secure it now.
Fig.4:
B

4
Attach the new small canopy (A) to the top.
Fig.5:
Secure the large canopy (B) to the beam ends with preassembled fasteners.
Fig.6:
A
B

5
Limited Warranty:
This limited warranty is extended to the original purchaser and applies to defects in
material and workmanship of your item provided the item is maintained with care and
used only for personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of
one (1) year. We don't reimburse for transportation or delivery costs,or compensate the
individual or any outside party for assembling or disassembling the product.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items
damaged due to acts of nature, vandalism, misuse, or improper assembly are not
covered. Corrosion or rusting of hardware is not covered.Proof of purchase
(dated register receipt) is required for warranty claims. Warranty is to the original
purchaser and is non-transferable. Any replacement of warranted items will be in
the original style and color, or a similar style and color if the original is unavailable
or has been discontinued. As some states do not allow exclusions or limitations on
an implied warranty, the above exclusions and limitations may not apply. This
warranty gives you specific rights, and you may also have other rights, which vary
from state to state.
CARE AND MAINTENANCE
Do not use bleach acid, or other abrasive cleaners.
