Socket AC4088-1657 User manual

ATTACHABLE
CHARGING MOUNT
USER GUIDE

USB Charging Cable
Hanger Bolt
Command Barcode label
to place on mount
2 x Hex Nuts
Charging Mount
AC Adapter
Use the plug that is
regionally appropriate
© 2017Socket Mobile, Inc. All rights reserved. Socket, the Socket logo, and
SocketScan are registered trademarks or trademarks of Socket Mobile, Inc. USA,
and any use by Socket Mobile, Inc. is under license. All other trademarks and
trade names contained herein may be those of their respective owners.
or
PACKAGE CONTENTS

Magnet
Hook
Charging Mount
*Illuminates Red when connected to AC adapter.
Charging Pins
LED*
PRODUCT INFORMATION
3

A. Charging Mount
B. Micro USB (2m)
C. Cushion Crown
D. Pem Cap / Camera Mount*
E. 2 x Hex Nuts
F. Hanger Bolt**
A.
B.
D. E.
F.
C.
*Optional for Camera Mount (See page 9)
**Optional for table mount (see page 8)
1/4” - 20
Machine
bolt thread
Screws into
wooden
surface
Tapered
lag-screw
Screws into
camera mount or
Charging Mount
ASSEMBLY OVERVIEW
4

A. Remove Micro USB cover.
B. Insert Micro USB connector into port and t usb
cable into the cord keeper.
C. Secure the cable to prevent from movement.
A.
B.
C.
HOW TO CONNECT USB CABLE
5

When charging the scanner, make
sure the charging pins on the Mount
and the scanner make contact with
each other and the red LED on the
Mount is illuminated.
“Beep
Beep”*
CHARGING MOUNT OPERATIONS
6

4-6 inches
(10 - 15 cm)
CHARGING MOUNT OPERATIONS
7

Charging Mount Modes
Mobile Mode - Normal (default)* Scanning
this bar code will enable the scanner to
enter mobile mode. It will always be in
manual trigger mode even when placed in
the mount or cradle.
*Scanner Factory Reset returns to Mobile
Mode. #FNB 41FBA50000#
Auto Mode (Presentation Mode)
Scanning this bar code will enable the
scanner to enter auto mode. When the
scanner is in auto mode, it will switch to
presentation trigger mode when it
detects power on the cradle pins. When
the scanner is removed from the cradle it
will remain in presentation trigger mode
until the users presses the trigger. At that
point it will switch to normal manual trig-
ger mode. Auto Mode command barcode is
also printed on the product label.
#FNB 41FBA50003#
COMMAND BARCODES
8

Auto Mode (In the Mount)
Action Behavior
Notication
Beep
Pattern
LED Activity Vibrate
Place
Scanner in
the Mount
Scanner
switches to
Presentation
Mode
High-high
tone conrms
proper seating*
Battery
Status LED
is Disabled
None
Place a
barcode in
the
Scanners
Field of
View
Decode Bar
Code
1 Beep when
Data
successfully
scanned
Green LED
blinks (while
scanning)
None
Auto Mode: Bar Codes placed in the Scanner’s eld of view are
automatically scanned.
*Note: 7Qi/7Xi/D750 will beep High-high tone even if the Scanner is
Power Off (to indicate charging)
*Lights for D750 will function as described in the D750 user guide.
AUTO MODE
9

Action Behavior
Notication
Beep
Pattern
LED
Activity
Vibrate
Remove the
Scanner from
the Mount
and press the
Trigger button
Scanner
switches
to Mobile
Mode
None Battery
Status LED
is Enabled
Enabled
Press the
Trigger
button
Decode
Bar Code
1 Beep
when Data
successfully
scanned
Green LED
blinks (while
scanning)
Vibrate
when Data
successfully
scanned
Mobile Mode: Pressing the Trigger button initiates a scan.
Mobile Mode (Not in the Mount)
AUTO MODE
10

1. Pair and connect the 7Qi/7Xi/D750 to your device prior to placing the
scanner in Auto Mode. The Scanner is not discoverable when in Auto
Mode and in the Mount. This facilitates a fast connection to the
current connected device when powered on (for example the start of
the new business day).
2. The Trigger button must be pressed to disable Presentation Mode
(and enable Mobile Mode) after the scanner is removed from the
Mount.
3. The Scanner will not turn off when its in Presentation Mode and in
the Mount under AC Power.
4. To avoid excessive power drain, the scanner should not be left out of
the Mount in Auto Mode. Either press the Trigger button or Power off
the scanner.
AUTO MODE (CONTINUED)
11

We include a Hanger Bolt to secure the Charging Mount directly to a
wooden surface. Since the Pem Cap connects to a Camera Mount, popu-
lar with IP Cameras, many OEM solutions are
available which do not require the Hanger Bolt.
If you plan to use the Hanger Bolt follow the special instructions for
mounting on a wooden surface.
If you have many Hanger Bolts to install, you may want to use a 1/4”-20
Hanger Bolt Driver with an Electric Screw Driver. (Image below)
INSTRUCTIONS FOR MOUNTING ON WOODEN SURFACE
12
1
/
4
“

1/4“x 13/4”
Special instructions for mounting on wooden surface:
1. Screw two Hex nuts (1/4”-20 thread, not included) onto the
machine-threaded portion of the Hanger Bolt.
2. Use an open-ended wrench to lock the nuts against each other.
3. Drill a pilot hole into the surface you wish to place the
Charging Mount.
4. Thread the lag portion of the Hanger Bolt into this surface as far as
you can by hand.
5. Use a wrench on the outermost nut to drive the Hanger Bolt into the
surface.
6. When the lag portion is sufciently threaded, unjam the two nuts
from each other, and run them off (unscrew them).
INSTRUCTIONS FOR MOUNTING ON WOODEN SURFACE
13

A. Attach the Pem cap to
your Camera Mount
(1/4” - 20, 3/4” depth
thread) and turn to the
right.
B. Attach the Charging
Mount to the Pem cap.
A.
B.
CONFIGURATION WHEN USING A CAMERA MOUNT
14

Dimensions
Charging Mount Width 1.80 in (46 mm)
Charging Mount Length 5.50 in (140 mm)
Antimicrobial Rating JLS z2801:2000 Test: 2.49 on MRSA 6.07
when cleaned with SaniCloth Plus cloth
wipes Biosafe HM4100, EPA#83019-1
CE MARKING AND EUROPEAN UNION COMPLIANCE
The unit under test was found compliant with all the applicable Direc-
tives, 2004/108/EC and 2006/95/EC.
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
The WEEE directive places an obligation on all EU-based manufactur-
ers and importers to take-back electronic products at the end of their
useful life.
ROHS STATEMENT OF COMPLIANCE
This product is compliant to Directive 2011/65/EU.
NON-MODIFICATION STATEMENT
Changes or modications not expressly approved
by the party responsible for compliance.
RoHS
PRODUCT SPECIFICATIONS
COMPLIANCE STATEMENT
15
