Solarc scottyPro User manual

Manual scottyP r o Page 1
Solar module
Frontframe
Clip
power supply
connection
Batteries
Battery cover
LED for charging
Output port for
adaptercable
Manual
scottyPro the solar battery charger

Manual scottyP r o Page 2
Sunlight
what is "scottyPro" ?
scottyPro beams the sun into the world of the electronic appliances: scottyPro can charge your
batteries, mobile phones, PDAs, MP3 player etc. and to this he needs only the sunlight as an energy
source. Mobile energy everywhere, independence pure and environmental friendly: with one scottyPro
up to 100 AA Alkaline primary batteries can be saved every year!
There are lots of accessories available, e. g. adapter cables, mains adapter, booster solar module etc.
to enlarge the functionality of scottyPro.
how does scottyPro work ?
Just fold up the solar module and place it directly to the sunlight without shadowing. The solar cells will
now charge the internal batteries via the integrated charge electronics. The more direct and stronger
the irradiation, the better for the charging efficiency.
flap the clip ...and place scottyPro in the sun ...or clip on a belt

Manual scottyP r o Page 3
On Off
On Off
Full:
Empty:
On Off
On Off
After charging you can either take the batteries and insert them into your external equipment or you
attach scottyPro directly to the device. For that purpose different adapter cables with different
pluggable adapters can be used. The energy stored in the batteries can be transferred much faster
into your device with the adapter cable as if the solar module was attached directly to the device.
During the energy transfer to external devices scottyPro can off course be placed in the sunlight which
even enlarges is efficiency.
However, you can alternatively operate or charge your external devices in direct solar operation mode
with scottyPro. For that you only have to remove the internal batteries, connect the external device via
adapter cable and place scottyPro into the sunlight as described before. Note: This operation mode
only makes sense at full sunshine and does not work with some devices since the current is too low.
Status of frequency of the LED charging display:

Manual scottyP r o Page 4
LED twinkels
The light-emitting diode integrated in the back shows the charge condition of the integrated batteries if
an adapter cable is plugged in. The bigger the on/off ratio the more charge is stored in the batteries. If
the batteries are flat the LED display goes off and scottyPro is switched off internally.
If - e. g. in winter – there is low sunlight irradiation you can charge the internal batteries via the
optional mains adapter. For that purpose just connect the adapter to the input jack at the back of
scottyPro and attach it to the mains socket overnight. By the way: it works worldwide at all power
supply systems (100 to 240 volt voltage). If you attach your device to scottyPro with the mains adapter
(in several countries you need an adapter which is not part of scottyPro) at the same time you have a
universal power supply unit for all devices which can be operated with scottyPro. Therefore you only
need 1 scottyPro + mains adapter instead of many different mains adapters!

Manual scottyP r o Page 5
The rear input jack is also used for connecting the optional booster solar module to scottyPro. It boosts
the charging power by a factor 3 and thus reduces the charging time of the internal batteries by the
same factor (compare table below).
And in emergency cases you even can insert normal Alkaline primary batteries in scottyPro and
operate or charge external devices with their energy!

Manual scottyP r o Page 6
Charging times
Example
Standard mobile phone Solar charge scottyPro Charging cell phone Average operation time cell phone
scottyPro with NiCd
Batteries 800 mAh, 50%
Charging, full sun
4 hours
(1,2 hours with booster module) 45 minutes
60 h Standby
50 min talk time
scottyPro with NiMH
Batteries 2.000 mAh, 50%
Charging, full sun
10 hours
(3 hours with booster module) 2 hours
150 h Standby
125 min talk time
scottyPro with Alkaline
primary batteries 100% full no solar charge possible 3 hours 180 h Standby 160 min talk time
Comparison operation time of appliances after 1 hour solar charge
Cell phone PDA Discman GPS
15 hours Standby
12 minutes talk time 1 - 3 hours 0,5 – 1,5 hours 0,5 – 1 hours
Charging scottyPro (100%) with universal mains adapter:
8 - 10 hours with NiCd batteries 600 – 1.000 mAh,
12 - 16 hours with NiMH batteries 1.200 – 2.200 mAh.

Manual scottyP r o Page 7
Charging at a cloudy sky: considerably longer charge times than at direct sun irradiation (ca. factor
5 – 50, dependant of weather), therefore only suitable for trickle charge of full batteries or for very slow
charging.
Adapter cables, mains adapters and other scottyPro accessories are available in the Internet under
www.solarc.de or ask your dealer.
Important notes
•Ambient temperatures of 0 – 25 °C are optimum for charging of the internal batteries. At
higher temperatures over 40 °C, e. g. behind a car window in the summer sun, the
batteries can be charged only at a small fraction and both solar module and batteries even
might get damaged, so such situations should be avoided urgently!
•Do not insert any batteries with different capacity or charge condition in scottyPro. Charge
the batteries frequently in a mains charger or use scottyPro with the mains adapter.
•Alkaline primary batteries may not be charged with scottyPro and shall be used only for
emergency (1-time) energy supply of external devices. Charging in scottyPro with solar
power or the mains adapter may damage the batteries and scottyPro.
•Use AAA (Micro) batteries with the optional AAA adapter.
•Only use the adapter cables and plugs for the devices indicated in the respective table.
Note polarity and voltage of your external device input at usage of the universal adapter
cable, otherwise your device or scottyPro might be damaged.
•scottyPro can produce up to 13 volts at the adapter cable. Caution with small children and
tongue tests therefore!

Manual scottyP r o Page 8
•scottyPro must remain dry if water has penetrated into the inside of the device. In this
case remove batteries immediately and let scottyPro dry.
•scottyPro doesn't like aggressive cleaning agents, don't spare on his solar module at all -
just wipe off only with a soft, dry rag or with warm water.
•Do not short-circuit any contacts at scottyPro and note the correct polarity while inserting
the batteries in scottyPro.
Technical data
Output voltage 2.5 – 13.0 V
Output current max. 2 amps at 2.4 – 3.0 V and 250 mA at 4 – 6 V
Solar module power 0,55 watts at full sun, 25 °C module temperature
Life time standard batteries 100 – 1.000 cycles or 1 – 6 years depending on temperature
Utilizable batteries/battery systems NiCd, NiMH, RAM, sizes AA, AAA
Recommenden ambient temperature Charging internal accu’s: 0 ... +40 °C,
Charging external devices: -20 … +50 °C
(temperature measured in the shade)
Max. relative humidity 90 %
Dimensions (L x B x H) 100 x 68 x 38 mm
Weight without batteries approx. 110g

Manual scottyP r o Page 9
Used materials Case of PC/ABS, Santoprene
Disposal Case and batteries recyclable, electronics and
solar module into appropriate electronic scrap
Examining signs CE, RoHS compliant
Possible problems and remendy
Problem Test Result
scottyPro doesn’t get
charged Remove batteries, attach adapter cable, hold scottyPro under electric
light bulb or in sunlight
LED must illuminate
scottyPro gets charged
too slowly*Insert empty, well working batteries,
charge for 1 hour at full sun or
putting under electric light bulb in
approx. 15 cm distance for 3 hours
LED must flash after plugging in an
adapter cable, external device must
be charged for ca. 5 – 10 min.
scottyPro doesn’t charge
an external equipment Charging with spare cable and charged batteries at your dealer The external device must indicate charging process
*)Indication for the brightness topic: The light intensity which is converted in to electric power in solar
cells behaves considerably different from the "brightness" felt by the human eye, e. g.:

Manual scottyPro Page 10
•Sunlight at noon, outside BscottyPro: 100% charging current / eye: very bright
•Light clouds, behind window BscottyPro: approx. 20% charging current / eye: bright
•Luminescent light indoor BscottyPro: approx. 0,5% charging current (no effective charge!) /
eye: bright
Please send your scottyPro together with the adapter cable, adapters and batteries to your dealer or
directly to SOLARC if it doesn't work after the described tests as indicated.
Battery- / battery disposal
Batteries don't belong into the domestic garbage. As consumers you are legally obliged to return used
batteries. You can return used batteries at the public gathering points of your municipality or
everywhere there where the respective batteries are sold.
You find these signs on batteries containing pollutant:
Pb = battery contains lead
Cd = battery contains cadmium
Hg = battery contains mercury
Pb
Cd Hg
WEEE

Manual scottyPro Page 11
Warrenty
Warranty: 2 years as of purchase date
The Warranty applies to material and production faults. It isn't valid and we are only liable in the
context of the legal regulations of German law when unscrewing the device or other interventions by
persons not authorized by us, at an improper treatment, at use of other batteries than these of us
recommended, as well as these arise from improper operation of scottyPro or the accessories
enclosed by us for damages. This also includes improper operation of scottyPro with external devices
or an operation with external devices who are not listed in the device table.
SOLARC Innovative Solarprodukte GmbH
Germany
web: www.solarc.de
mail: [e-mail]
Glogauer Str. 21
D - 10999 Berlin
Tel.: [phone]
Fax: [phone]
September/11
