SOLARFOCUS maximus 150 User manual

Operation manual for the system operator
Read carefully before operating.
DR-0159-EN / v5-201904
Commercial boiler maximus

1 About this manual
1 About this manual 2
2 Safety information 3
3 Warranty, guarantee, liability 3
4 Product information 5
4.1 Proper use 5
4.2 Fuel 5
4.3 Spare parts 5
4.4 Type plate 5
4.5 CE declaration of conformity 5
4.6 Safety devices 5
4.7 Efficient and low-emission operation 8
4.8 Functional components, combustion prin-
ciple 9
4.9 Technical specifications 11
4.10 Dimensions 13
5 Use and operation 14
5.1 Main screen of the control unit 14
5.2 Boiler operating mode 14
5.3 Selection menu 14
5.3.1 Heating circuit output test 15
5.4 Customer menu 15
5.4.1 Required boiler values 15
5.4.2 User lock 16
5.4.3 Message log 17
5.4.4 Operating hours counter 17
5.4.5 Qualified personnel menu 17
6 Heating circuit 20
6.1 Heating circuit settings 21
6.1.1 Heating circuit operating mode 21
6.1.2 General settings 21
6.1.3 Heating curve 22
7 DHW heating 24
7.1 Domestic hot water tank 24
7.1.1 DHW tank settings 24
7.2 Fresh water module - FWM (optional) 25
8 Recirculation control 25
8.1 Circulation settings 26
8.2 Recirculation control - Options 26
9 Buffer tank 27
10 Solar system 28
11 Temperature difference charge control 28
12 mySOLARFOCUS app 29
12.1 Requirements for use 29
12.2 Connecting the control to the internet 29
12.3 Register on the web server 29
12.4 Install app, register user 30
12.5 Add system 30
12.6 Use of the mySOLARFOCUS app 31
12.7 Approve additional users 31
13 Weatherman function 32
13.1 Information 32
13.2 Heating circuit 32
13.3 Domestic hot water 33
13.4 Buffer tank loading 34
14 Maintenance and cleaning 34
15 Perform emissions measurement 36
15.1 Emission measurement for external boilers 37
16 Filling the pellet store 37
17 Troubleshooting 37
1 About this manual
Dear customer,
To ensure reliable and efficient operation of your boiler,
the following points are extremely important:
–Professional planning and installation of the hea-
ting system.
–Training of customers in starting up the heating boi-
ler.
–Regular maintenance by the operator.
–Regular maintenance by qualified personnel.
–Comply with the specifications and instructions in
this manual.
Software version for control unit
The guide describes the software version 19.040 of
the controlecomanager-touch ;Main screen of the
control unit > 14
Language
The language of the original manual is German. All
other language versions of this manual are trans-
lations of the original.
Storage
Keep the manual for the entire service life of the pro-
duct and ready to hand. The manual must be pas-
sed on to the new owner when the product is
dismantled/reused. If the manual is lost or
destroyed, request a new copy from the manu-
facturer.
2 Operation manual maximus
Content

2 Safety information
Tips and Warnings
The tips used in this manual are highlighted with
symbols and signal words. The signal word indi-
cates the level and nature of the danger and how to
avert it.
iIndicates information for correct handling of the
product.
!CAUTION - Failure to comply with this instruc-
tion could result in damage to property.
DANGER - Failure to comply with this instruc-
tion poses a danger to people.
Manufacturer
SOLARFOCUS GmbH
Werkstrasse 1, A-4451 St.Ulrich
Company register no. 281755x
Tel.: [phone], Fax: [phone]
[e-mail]
www.solarfocus.com
Technical questions about our products
–Service-Hotline
0043 7252 50002-4920
[e-mail]
2 Safety information
Qualification of personnel
–The work procedures described in this manual
must be carried out by qualified specialist per-
sonnel.
–Work on electrical components must be performed
by trained electricians and in accordance with the
relevant laws and directives.
Installation and commissioning
–System may only be serviced and put into ope-
ration by certified qualified personnel
(SOLARFOCUS service technician or
SOLARFOCUS service partner.
Keep unauthorized persons and children away
–Danger of burns due to hot lines and hot com-
ponents, risk of injury from mechanically moving
parts. Keep unauthorised persons away, do not
leave children unattended, and control access to
the boiler room and fuel storage room.
Safety devices
–Never disengage the safety equipment > 5 of the
heating system. In case of failure, arrange for
immediate repair.
Maintenance and repair
–Perform maintenance activities at the specified
intervals. No or incorrect maintenance leads to inef-
ficient operation, higher failure risk of the boiler and
increased potential for hazards.
–Have repairs done by qualified personnel only
Improper repairs can lead to risks for the user and
impaired operation
–Store hot ashes only in metal containers. Never
put hot or warm ash in the dustbin. There is a great
danger of fire.
–For repairs use only original spare parts or parts
approved by the manufacturer (e.g. standard
parts).
Damage to the system
–If the electrical insulation on cables, plugs, swit-
ches becomes damaged, switch off the voltage
supply and have the insulation repaired.
–In the case of visible damage (e.g. thermal defor-
mation, mechanical damage) the operation of the
system must not be continued. The system may
only be operated if it is in perfect technical con-
dition.
3 Warranty, guarantee, liability
For warranty and warranty claims (with conclusion of a
maintenance contract) observe the following points.
–The warranty begins at the time at the time of han-
dover (delivery note, commissioning form).
–The warranty period is calculated from the date of
initial commissioning.
–The warranty periods are based on the relevant
regulations.
–We must be notified promptly and accurately of
any damage incurred, so that the cause can be cla-
rified.
–The supply air into the boiler must not contain any
aggressive substances (such as chlorine or fluo-
rine compounds, used in cleaning agents, sol-
vents, adhesives, etc.). These can cause
corrosion in boiler and fireplace.
–If the system has defects despite correct instal-
lation (in compliance with the technical docu-
mentation), we grant a warranty provided that the
system has been examined by the plant customer
service (commissioning form).
Operation manual maximus 3

2 Safety information
–The guarantee applies to technical, construction-
related faults and faults in the manufacture of the
system that prevent correct and problem-free
usage.
–We shall not be liable for components that we have
not manufactured; however, we will be prepared to
transfer our rights to claim against the manu-
facturer of defective components to the purchaser.
–In fulfilling the warranty/guarantee services, we
shall cover only the assembly time and the mate-
rials used, but not any travel or accommodation
costs necessary for the fitters/engineers or any
return transport costs.
–SOLARFOCUS GmbH assumes no liability for
any consequential costs of damages.
–The repair and/or warranty replacement shall be
carried out on site or in the SOLARFOCUS factory
at our discretion.
–The company SOLARFOCUSwill determine whe-
ther such work requires a repair or whether the
parts are to be replaced free of charge.
Expiry of maintenance, warranty and gua-
rantee services:
The maintenance, warranty and guarantee services
expire if one of the following points applies:
–Non-observance of information in the planning,
installation and operation manual.
–Faults that occur due to use of unsuitable fuels > 5.
–Commissioning and maintenance carried out by
non-certified companies.
–Undocumented commissioning and maintenance
checklist
–Incorrect operation and failure to perform main-
tenance and cleaning as prescribed.
–Damage due to force majeure (water, fire, etc.).
–Damage during transport.
–Wilful damage.
–Insufficient energy or water, fault in the hydraulics.
–No functioning return booster module installed.
–No claims can be accepted under the warranty if
unauthorised intervention (or action that has not
been explicitly approved by us) has been carried
out. In addition, the goods must be paid for within
the specified payment timeframe.
–It is almost impossible to produce flawless painted
parts; for this reason, slight defects that do not
adversely affect proper use shall not be deemed as
grounds for complaint.
Limitation of liability
SOLARFOCUS GmbH assumes no liability for injury
or material damage resulting from:
–Failure to observe the instructions in this manual.
–Use of the product for any purpose other than for
its intended use > 5.
–Deployment of unqualified personnel.
–Use of non-approved spare parts.
–Technical modification of the product by the sys-
tem operator.
4 Operation manual maximus

4 Product information
4 Product information
4.1 Proper use
–The heating boiler maximus is intended for heating
up water in closed heating systems.
–Only use fuel as specified in the next chapter Fuel.
–The maximum running time per year is 3000 full-
load hours.
4.2 Fuel
Pellets
Use wood pellets only in accordance with these spe-
cifications:
–Pellets according to the ISO 17225-2 standard,
class A1.
–Pellets that meet the additional ENplus cer-
tification.
–Pellets that meet the additional DINplus cer-
tification.
Wood chips
Use wood chips only in accordance with these spe-
cifications:
–Wood chips according to the EN ISO 17225-
4:2014 standard
–Classes A1, A1, A2, B1
–Sizes P16S and P31S
–Moisture content maximum 40%(M40)
Product view
Fig. 2-1
4.3 Spare parts
For repairs use only original spare parts or parts appro-
ved by the manufacturer (e.g. standard parts).
The manufacturer cannot accept any liability for
damage caused by spare parts not authorised by the
manufacturer.
4.4 Type plate
4.5 CE declaration of conformity
The conformity of the produce is declared by the manu-
facturer in accordance with the Machinery Directive
2006/42/EC; the documents are available for inspec-
tion at the manufacturer.
The product corresponds to Directive 2011/65/EU
(RoHS 2) and does not use any materials containing
asbestos. The product does not contain any PCB or
mercury.
4.6 Safety devices
Heat dissipation
–This function of the boiler control is a safety device
that prevents overheating of the boiler.
–Functioning: If the boiler temperature exceeds the
set Heat dissipation maximum boiler temperature
(in the service menu - General Settings), all pumps
relating to the energy consumer units (e.g. heating
circuit, DHW tank, buffer tank, etc.) will be swit-
ched on and the heating circuit mixer opened. In
this way, energy is drained from the boiler and it
may be possible to prevent other safety devices
tripping.
–If the boiler temperature falls below the set Heat
dissipation maximum boiler temperature minus
1°C again, the pumps and mixers will be operated
in standard mode again.
Operation manual maximus 5

4 Product information
Overtemperature reset (OTR)
The safety temperature limiter (STL) is a safety device
that prevents overheating of the boiler.
Functioning: The STL stops the heating process at a
boiler temperature ~95°C (exclusively electrical func-
tion; fuel and air supply are interrupted).
After tripping, the STL must be manually released
again by unscrewing the black sealing cap 1and pres-
sing the button as soon as the boiler temperature falls
below 60°C.
If the safety overtemperature reset trips, this is indi-
cated in the boiler control display.
Fig. 2-2:Unscrew the closure cap
Thermal overload protection
–The thermal overload protection prevents an uncon-
trolled increase in temperature and pressure of the
boiler.
–Functioning: At a boiler water temperature > 95°C,
the valve opens and directs cold water through the
two series-connected safety heat exchangers.
This lowers the temperature of the boiler and avo-
ids the need for further safety precautions or equip-
ment damage.
Safety valve (to protect against excess pres-
sure in the system)
–The safety valve 1is a safety device for protecting
against overpressure in the water circuit of the hea-
ting system.
–Functioning: The valve opens when the system
pressure exceeds 3 bar. Water/steam are dischar-
ged into an open drain via a discharge line, which
avoids consequential damage to the heating sys-
tem. The valve is closed during normal operation.
–For normative specification see EN 12828.
Fig. 2-3: Safety valve integrated into boiler safety group
EMERGENCY OFF switch
–The EMERGENCY OFF switch is a manually ope-
rated safety device. The burner and the fuel supply
to the boiler are stopped. Circulation pumps remain
in operation to dissipate heat and cool the boiler.
–The switch must be installed outside the heating
room in a safe place that is easy to access.
Temperature monitor in the fuel storage
room (TM)
–Required according to guideline TRVB 118 H for
wood chips, depending on system design, heating
capacity and fuel storage quantity.
–Functioning: On the channel of the fuel delivery
auger, a temperature sensor of a protected design
must be installed in the area of the wall penetration
(inside the storage room). When a temperature of
about 70°C is exceeded, the warning device is
(optically or acoustically)triggered.
–Art. No.: 6565 and 6567
6 Operation manual maximus

4 Product information
Automatically triggered extinguishing
device (ATED)
Fig. 2-4
1 Pocket sleeve for temperature sensor
2 Connection for water discharge
–Functioning: If at the temperature sensor 1the
temperature exceeds 50°C (direct extraction) or 95
°C (downpipe extraction), the valve 2opens and
floods the feeder channel with water.
–This extinguishing device serves to automatically
suppress burn-back within the feeder. Due to the
proper nature and location of the fire detection
element, burn-back must be reliably detected and
the extinguishing device must be triggered instanta-
neously and automatically (this must be ensured
even in the event of a power failure).
–The extinguishing device must be connected either
directly to a pressurised water supply or to a water
reservoir (Note: Domestic waterworks may also be
affected in case of power failure).
–The water supply must be equal to three times the
volume of the feeder equipment, but at least 20
litres. The container must be equipped with a fill
level monitor, including connection to the warning
device (temperature monitor > 6). The extinguis-
hing water inlet opening in the feeder is to be
arranged and executed so that blockage by
delivery operation is not possible and this can
easily be checked at any time. The routing of the
extinguishing system must be made as a non-
combustible version.
–Art. No.: 63260 and 6553
–Specification yes/no see TRVB 118 H
Manually triggered extinguishing device
(MTED)
–This extinguishing device is used to combat a fire
source in the fuel storage room, or fuel storage in
the area of the extraction/delivery line. The trig-
gering must be done manually.
–This device consists of an empty pipe with a mini-
mum nominal size of DN 20 and is to be installed in
the fuel storage as specified by the manufacturer
of the firing system directly above the delivery line
in front of the wall or ceiling passage in such a way
that the greatest possible success can be achie-
ved in extinguishing. The empty piping must be
connected directly to a pressurized water supply
and provided with a shut-off valve arranged in the
boiler room. Mark this valve with a sign "Extin-
guisher - Fuel Storage Room".
–The execution of the extinguishing system must be
done so that damage during fuel feed or from the
extraction device is not possible. In addition, make
sure that the fuel supply to the delivery line is not
affected.
–Specification yes/no see TRVB 118 H.
Rotary valve
The rotary valve fulfils all normative requirements for
the approved fuels regarding fire protection, burn-back
safety, backflow of gases:
Fig. 2-5:Rotary valve
–Complies with requirements regarding burn-back
protection devices (BPD) according to TRVB 118
H.
–Prevents backflow of flammable products of com-
bustion into the fuel supply or into the intermediate
store (according to EN 303-5).
–Prevents spreading of fire into the fuel supply or
into the intermediate store (according to EN 303-5).
Operation manual maximus 7

4 Product information
Safety switch on the channel cover
Opening the channel cover interrupts the power supply
to the motor of the extraction auger.
4.7 Efficient and low-emission operation
Please note the following recommendations from the
EU Energy Efficiency Directive:
Use of a buffer tank
Since maximum combustion is possible only in stan-
dard operation of the boiler, and greater losses and hig-
her emissions occur during the warm-up and burn-out
phases, use of a buffer tank is recommended.
This tank stores the water heated by the boiler, allo-
wing the connected devices (e.g. heating circuit, DHW
tank, fresh water module, etc.) to access it as requi-
red. This ensures sufficiently long, uninterrupted com-
bustion periods for the boiler.
Use of high-efficiency heating pumps
When using external heating pumps (e.g. return tem-
perature rise, heating circuit pumps, etc.), high-effi-
ciency pumps with energy efficiency class A should
preferably be used.
This delivers savings potential of up to 80 % in drive
energy (compared to conventional heating pumps) with
identical feed results.
8 Operation manual maximus

4 Product information
Operation manual maximus 9
4.8 Functional components, combustion principle
Burner
Fig. 2-6
Functional components
1 Rotary valve 5 Ash auger burner 9 Rotary drive for secondary air
2 Feeder unit 6 Ash container 10 Combustion chamber temperature sensor
3 Push grate 7 Rotary drive for primary air 11 Flue gas recirculation line
4 Ash scraper 8 Primary air outlet
Fuel path
–The fuel falls through the rotary valve 1into the channel of the feeder unit 2. The auger delivers the fuel to the
feed grate 3.
–During combustion, the fuel is transported on the feed grate, and the resulting ash falls down through the grate.
–The ash pusher 4push the ashes to the ash auger 5, and auger takes over the transport into the ash box 6.
Airflow
–Primary air is sucked in at the opening 7, forwarded in a space on the left and right side of the boiler; at the holes
8the primary air openings under the combustion grate, and makes it through the feed grate into the combustion
chamber.
–Secondary air is sucked in at the opening 9, and passes through openings in the fire brick (left, right, back) above
the combustion grate in the combustion chamber.
–Flue gas recirculation: If the sensor measures 10 too high a combustion chamber temperature, then flue gas from
the flue gas pipe 11 is introduced here and added to the primary air. This leads to the cooling of the feed grate and
the combustion chamber and thus to lower stress on the components.

Heat exchanger
Fig. 2-7
Functional components
13 Ash container 15 Heat exchanger
14 Electrostatic dust collector
De-ashing
–The ashes falling on the feed grate are transported from the transverse ash auger into the ash container 13.
–The ashes falling on electrostatic dust separator 14 are transported forward by the ash auger 15 into the ash con-
tainer.
Flue gas guide
–The flue gas from the combustion chamber flows past the heat exchanger 15, on the electrostatic dust separator
into the flue gas pipe and into the chimney.
4 Product information
10 Operation manual maximus

4 Product information
Operation manual maximus 11
4.9 Technical specifications
maximus 150 200 250 300
Wood chips output [kW] 149 201 240 -
Pellets output [kW] 149 201 250 299
Boiler class (acc. to EN305:5
2012) 5 5 5 5
Dimensions
Width [cm] 189 189 189 189
Height incl. adjustable feet [1] [cm] 207 207 207 207
Depth with ID fan [cm] 222 222 222 222
Burner insertion dimension
(width) [cm] 90 90 90 90
Heat exchanger insertion dimen-
sion (width) [cm] 110 110 110 110
Minimum room height [2] [cm] 275 275 275 275
Weight
Burner weight [kg] 700 700 700 700
Hat exchanger weight [kg] 950 950 950 950
Total weight [kg] 1650 1650 1650 1650
Water side
Water content [l] 565 565 565 565
operating temp. [°C] 70 - 90 70 - 90 70 - 90 70 - 90
Maximum permissible tem-
perature [°C] 90 90 90 90
Max. permissible operating pres-
sure [bar] 3 3 3 3
Min. return flow temperature [°C] 60 60 60 60
Connection Boiler inflow/Boiler
return flow [“] G 2“OT G 2“OT G 2“OT G 2“OT
Drain connection [“] 1” 1” 1” 1”
Connection for thermal overload
protection [“] G 1/2“OT G 1/2“OT G 1/2“OT G 1/2“OT
Electrical systems
Electrical connection 400 V AC, 50 Hz,
16 A, 3P+N+PE
400 V AC, 50 Hz,
16 A, 3P+N+PE
400 V AC, 50 Hz,
16 A, 3P+N+PE
400 V AC, 50 Hz,
16 A, 3P+N+PE
Fuel
Fuel - wood chips Wood chips in accordance with EN ISO 17225-4, classes A1, A2, B1, B2;
sizes P16S and P31S; water content max. 40% (M40) > 5
Fuel - wood pellets Wood pellets according to ENISO17225-2 > 5
Flue gas side
Flue gas pipe diameter [cm] 25 25 25 25
Height of flue gas pipe [1] [cm] 207 207 207 207
Minimum draught requirement [3] [Pa] 5 5 5 5
Maximum flue gas temperature
[4] full load [°C] 140 140 140 140

maximus 150 200 250 300
Emissions according to test
report:Wood chips
Flue gas value [5] from test
report:
Test institute / test report no.
18-IN-AT-UW-OÖ-
EX-205/3
TÜV Austria
Interpolation accor-
ding to EN303-5
18-IN-AT-UW-OÖ-
EX-205/4
TÜV Austria
-
CO full load [mg/m³] 19 30 38 -
CO Partial load [mg/m³] 20 20 20 -
NOXfull load [mg/m³] 120 120 115 -
NOXpartial load [mg/m³] 93 93 93 -
Org. C full load [mg/m³] 2 2 2 -
Org. C partial load [mg/m³] 2 2 2 -
Dust content full load [mg/m³] 9.5 11.6 13.8 -
Dust content partial load [mg/m³] 6.5 6.5 6.5 -
Flue gas mass flow full load [g/s] 97.9 130.5 156.7 -
Flue gas mass flow partial load [g/s] 29.4 39.2 47.0 -
Emissions according to test
report:Pellets
Flue gas value [5] from test
report:
Test institute / test report no.
18-IN-AT-UW-OÖ-
EX-205/1
TÜV Austria
Interpolation accor-
ding to EN303-5
Interpolation accor-
ding to EN303-5
18-IN-AT-UW-OÖ-
EX-205/2
TÜV Austria
CO full load [mg/m³] <3 3 3.6 3.6
CO Partial load [mg/m³] 29 29 29 29
NOXfull load [mg/m³] 112 112 113 113
NOXpartial load [mg/m³] 83 83 83 83
Org. C full load [mg/m³] 2 2 2 2
Org. C partial load [mg/m³] 2 2 2 2
Dust content full load [mg/m³] 6.5 8 8.7 10.2
Dust content partial load [mg/m³] 5 5 5 5
Flue gas mass flow full load [g/s] 94.5 126.0 157.6 189.1
Flue gas mass flow partial load [g/s] 28.4 37.8 47.3 56.7
[1] Adjustable feet at maximum depth of thread
[2] The minimum room height is required for maintenance work
[3] A draught stabiliser must be fitted if the specified draught of 15 Pa is exceeded
[4] Flue gas temperature can be adjusted electronically.
[5] Flue gas values in mg/m3are based on 13% O2of the volume flow
4 Product information
12 Operation manual maximus

4 Product information
4.10 Dimensions
Side view
Top view
Front
Operation manual maximus 13

5 Use and operation
5 Use and operation
Touch display for operation
If the boiler is supplied with a mains power supply, the
boiler control startsecomanager-touch. The control is
started up to show the main screen.
iOperate the touch display with your fingers, do
not use any hard objects.
If no inputs are made for 5 minutes (factory setting),
the display will switch to standby mode.
Tapping the display again restarts the display with the
main screen.
Buffer battery in operating element
A replaceable buffer batter (CR2032) ensures that data
(time, settings) are retained in the operating element
when the supply voltage is switched off.
5.1 Main screen of the control unit
Fig. 2-8:Main screen
1 Software version for control unit
2 outside temperature
3 Boiler output (rotational speed of induced
draught fan)
4 Boiler temperature and residual oxygen content
in flue gas
5 Operating mode > 14
6 Status line
Tapping the main screen changes to the Selection
menu > 14
5.2 Boiler operating mode
1Chimney sweep function
This function is used to perform the emission mea-
surements prescribed by law.
►Perform emissions measurement > 36
2STOP
The burner is switched off. No heating requirements of
the consumers are fulfilled.
!WARNING - The burner must not start! Only
the automatic start-up of the heating circuit
pump is active to protect against frost.
3START
After pressing the START button, the burner is in the
selected operating mode and ready for operation, and
is able to fulfil heating requests from the consumers.
The burner goes into standby as soon as a heating
request is fulfilled, or the time release > 15 is no longer
available.
5.3 Selection menu
Fig. 2-9: Selection menu
1 Customer menu > 15
2 Heating circuit output test > 15
CAUTION, only to be undertaken by qualified
personnel.
3 Heating circuit > 20
4 Domestic hot water heating > 24
5 Circulation control (optional) > 25
7 Solar system (optional) > 28
8 Temperature difference, charge control (optio-
nal) > 28
10 Weatherman function (optional) > 32
11 Information
15 Boiler cleaning > 34
14 Operation manual maximus

5 Use and operation
5.3.1 Heating circuit output test
The available outputs can be switched on/off directly
using the button. Can be used to test function of indi-
vidual components.
!CAUTION - Only to be undertaken by qualified
personnel.
Fig. 2-10
Fig. 2-11
5.4 Customer menu
Fig. 2-12: Customer menu
1 Required boiler values > 15
4 User lock > 16
5 Message log [2] Record alarm and notifications
> 17
6 Operating hours counter > 17
7 Output test boiler (CAUTION, only to be under-
taken by qualified personnel).
8 Qualified personnel menu > 17
[2] Button is only visible if a message is active.
5.4.1 Required boiler values
Fig. 2-13:Required boiler values
Burner release time 1
The burner can start within the release times; outside
of these times, starting does not take place and/or the
burner is stopped. A release time from 00:00 to 23:59
means that no restriction is pending and the burner can
start at any time.
!CAUTION - In order to protect against frost,
only automatic start-up of the heating circuit
pump is active outside time release.
Operation manual maximus 15

5 Use and operation
iDomestic hot water heating in summer
If the boiler s used for heating domestic hot
water, then the required chimney pull of 5 Pa
may not be present in the summer months (or
outside the heating period). This may result in
smoke escaping in the heating room.
Reason: High temperature on the chimney
head (greater than 30°C); as a result the cooler
air does not rise (~ 20°C air temperature when
the burner starts)in the chimney.
Remedy: Set the burner time release from
00:00 to 07:00 or from 21:00 to 23:59.
Burner release outdoor temperature 2
The burner may not start if the outside temperature
exceeds this value.
External boiler release 3
On switches the function to standby. I.e. a connected
external boiler may only start when it receives the
release from the SOLARFOCUS boiler (e.g. on the
basis of a lack of fuel, operating fault).
5.4.2 User lock
Fig. 2-14:Main screen with active user lock
The function serves as protection against unaut-
horised modification of the control parameters. When
the user lock is active, the parameters of the individual
screens are displayed but cannot be changed. The
active user lock is indicated by the padlock icon 1in
the screens.
User lock screen
Fig. 2-15: User lock screen
Enter the password 2
To define a new password (maximum 20 characters).
Password 3
The currently valid password is displayed.
User lock 4
Off: The user lock is switched off.
On: Switches on the user lock function. If the display
is not touched for one minute, the user lock is active in
the screens.
Password reset 5
The current password is reset to the value solarfocus.
Accept as new password 6
Enter a new password in the input field and press the
button. Note on screen keyboard; Confirm input with
the button.
16 Operation manual maximus

5 Use and operation
5.4.3 Message log
Fig. 2-16: Message log
Every fault message which has occurred in the control
unit is recorded here, with the time that it began and
ended. The message with the highest priority is high-
lighted in red, acknowledged messages are highlighted
in green.
Press the 2button to quit messages. Button 1opens
the power failure log.
5.4.4 Operating hours counter
Fig. 2-17: Operating hours counter screen
5.4.5 Qualified personnel menu
Fig. 2-18: Qualified personnel menu
1 Service menu > 17
2 IP VNC (for remote access) > 17
3 Sending emails > 19
4 mySOLARFOCUS-App > 29
5 Language selection > 20
6 Date and time > 20
5.4.5.1 Service menu
In theService menu there are technical (factory pre-
defined) settings for an optimum combustion process
in the boiler. These can only be accessed by qualified
personnel (code input required).
5.4.5.2 IP VNC (for remote access)
The control unit ecomanager-touch allows access to the
control unit screens from a PC or mobile device (e.g.
smartphone). This is effected via VNC (Virtual Net-
work Computing) software. The control has an inte-
grated VNC server, while the VNC Viewer, which is
available free of charge on the Internet, is required for
remote access.
A cable connection is required on site for the connec-
tion of the control unit to the router. Use the Ethernet
socket (type RJ45) on the rear of the control panel
(Touch display).
iInstallation and configuration of this function
must be performed by the customer (i.e. not
included in the commissioning, service and sup-
port activities).
The following points are helpful for setting up a PC/-
router to control the VNC server, which requires know-
ledge of networking technology.
Operation manual maximus 17

5 Use and operation
IP configuration
►To access the IP-VNC icon, select it in the control
–Selection menu screen
–Customer menu screen
–Trained qualified personnel button
►Enter the data for your router. Recommend pro-
cess:
–Select DHCPON.
ÄThe IP address is determined.
–Select the DHCP OFF + Apply button .
Fig. 2-19.
–The IP address must be unique in each Ethernet
network and is dependent on the other network
components (PC, modem/router, etc.).
–Recommendation: Set a fixed IP address (=DHCP
OFF), i.e. the control unit has a constant IP
address.
Version 1: Installation of VNC viewer for access
from a local PC (PC in the home network)
►Download the free VNC Viewer from the Internet,
install it on the PC and start the application.
►Enter the previously defined IP address of the con-
trol.
–As soon as the VNC Viewer is able to access
the control unit, a password must be entered.
–The password predefined by the manufacturer
is solarfocus
–After login, the screen view of the control unit is
available.
Changing the VNC password
Fig. 2-20
►Press the Change VNC password button on the
IP setup view.
►To change it, first enter the old password, then the
new password, then press the Accept button.
►The new password must be used to log on after
restarting the VNC Viewer on the local PC.
►Press the Reset password button to reset the
password to the default password solarfocus.
Version 2: Installation of VNC viewer for access
from an external PC (PC outside the home net-
work)
–The user's local router does not always have the
same IP address on the Internet (it is allocated by
an Internet Service Provider – ISP).
–Nevertheless, Dynamic Domain Name Systems,
also referred to as DynDNS or DDNS, allows
access to the router.
–These systems allow a unique host name to be
assigned on the Internet; the unique name is then
also entered in the router. If the router is then assi-
gned a different address by the ISP, it enters the
updated IP address as the defined host name on
the DynDNS server. The router and therefore the
home network can then be reached using this host
name.
–To create a connection with the control unit, a port
diversion is required from the external port of the
router[1] to the IP address and to VNC port 5900 of
the control unit.
[1] Port 5950 is recommended
iAvoid any port forwarding from external port
5900 of the router to IP address and VNC port
5900 of the control.
18 Operation manual maximus

5 Use and operation
5.4.5.3 Sending e-mails
Function: The boiler control ecomanager-touch auto-
matically sends status e-mails and alarm e-mails (to
predefined addresses) if required.
Status e-Mail: An automatic e-mail (e.g. sent daily) pro-
vides information on the current boiler status.
Alarm email: a message is sent when a fault occurs.
iInstallation and configuration of this function
must be performed by the customer (i.e. not
included in the commissioning, service and sup-
port activities).
Fig. 2-21
Outgoing mail server 1
Enter the access data for the e-mail server you use.
Fig. 2-22
Use SSL: Select if the e-mail server uses a TLS/SSL
encryption protocol.
Address book 2
A maximum of 10 contacts can be added. If there are
several addresses for a contact, these should be
comma-separated.
Write e-mail 3
Used to manually send e-mails. The recipient’s
address can be selected from the address book using
To and CC or manually entered in the recipient line.
Alarm test 4
Used to test the e-mail settings. Pressing the button
sends an e-mail to the Recipient status email.
Send alarm email 5
Activates/deactivates the automatic sending of alarm
e-mails. The sending of status e-mails is not affected
by this.
Alarm configuration 6
Settings for the alarm e-mails to be sent automatically.
Fig. 2-23
Alarm subject: is used for all alarm e-mails and status
e-mails, therefore it should be as meaningful as pos-
sible (e.g. boiler type / name of system operator; 40
characters available).
Alarm groups: For prioritisation of the alarm messages
(e.g. Alarm group 1 receives all messages, Alarm
group 2 receives only non-critical messages, such as
information on necessary maintenance, boiler
cleaning, etc.).
Status e-Mail: Set time at which the status e-mail is
sent. The automatically generated content of the sta-
tus e-mail is:
–Current status of the heating system
–Fault present, and which
Alarm selection: This is where you define which alarm
group is reported for which event.
Operation manual maximus 19

6 Heating circuit
5.4.5.4 mySOLARFOCUS app
Pressing the button displays the screen with infor-
mation relating to online registration for the
mySOLARFOCUS app (serial number, PIN,status,
etc.) > Abb. 2-41, page 30
Detailed information on using the mySOLARFOCUS
app > 29
5.4.5.5 Language selection
Fig. 2-24
5.4.5.6 Date and time
Fig. 2-25
switchover from summer/winter time is made auto-
matically when the Switchover Summer-Winter 1para-
meter has the value Europe. Switchover takes place
on the last Sunday of the months of March and Octo-
ber. If America is set, the clock is changed to summer
time on the first Sunday in April.
6 Heating circuit
Fig. 2-26
1 outside temperature
2 Average outside temperature
3 Room temperature (optional)
4 Temperature of the energy source, (e.g.boiler, buf-
fer)
5 Flow temperature of the heating circuit
6 Position of the heating circuit mixer
0 % - the mixer is closed, the heating circuit is supplied from
the heating circuit return.100% - the mixer is open, the hea-
ting circuit is supplied from the heating boiler flow.
7 Info line: Heating requirement (Yes/No) to the
energy source.
8 Status line of the heating circuit
9 Heating circuit settings > 21
10 Display of the heating circuit operating mode
set on the optional room temperature controller
(Art. no. 6160)
20 Operation manual maximus
